Michelin 12264 User manual

UNIQUE
DIGITAL GAUGE
™
USB
DIGITAL
POWER SOURCE
COMPACT ‘TOP UP’ DIGITAL
TYRE INFLATOR
USER GUIDE
12264UG
03/19
THANK YOU FOR PURCHASING THE
MICHELIN COMPACT ‘TOP UP’ DIGITAL TYRE INFLATOR.
Please read the operating instructions carefully before using your inflator. Improper use can cause damage
to property and possibly harm the user. When using the inflator ensure the vehicle is parked in a safe
location, off the road, with the vehicle handbrake on and where your personal safety is not at risk.
WARNING!
◼Never allow children to use this inflator.
◼Never over inflate.
◼Always use in a safe area away from traffic and other dangers.
Only suitable for vehicles with a negative earth. Check your vehicle owner’s manual.
◼This inflator is designed for topping-up pressure, not inflating from flat. Do not inflate over
40 PSI.
◼When topping up vehicle tyres this inflator should ONLY be used for car tyres and bicycle
tyres.
Max power requirement during normal use: 6A / 72W.
WARNING! COMPRESSED AIR CAN BE DANGEROUS
◼Never allow children to use this tyre inflator.
◼Never leave unattended when running.
◼Never overinflate.
◼Always use in a safe area away from traffic and other dangers.
◼Never run for more than 8 minutes. After each 8 minute run allow inflator to cool down.
WARNING! ENSURE CORRECT TYRE PRESSURES
◼Correct tyre pressure is vital for road safety.
◼Under or overinflated tyres can be dangerous.
◼Always ensure that regular weekly checks are carried out to the vehicle manufacturer’s
recommended pressures including the spare, but excluding space saver tyres. Always check
before a long journey or after loading or unloading the vehicle.
◼Always check pressures in an ambient temperature, never immediately after a long journey.
CAUTION
◼Inspect the tyre inflator before each use.
◼Do not leave connected to 12V DC socket unattended.
◼Do not kink or block the air hose while the compressor is working.
◼Do not use the compressor if bent, broken, melted, burnt, wet or any of the components are
damaged.
◼The compressor contains no user serviceable parts –DO NOT OPEN.
THIS PRODUCT CONFORMS TO THE CRITERIA SET OUT IN PROCEDURE 2 AS DEFINED IN ANNEX VI
OF DIRECTIVE 2000/14/EC, ROHS DIRECTIVE 2011/65/EU AND EMC DIRECTIVE 2004/108/EC.
COMPACT ‘TOP UP’ DIGITAL TYRE INFLATOR
OPERATING FEATURES
1 4
2
5
3
6
1.
On/Off button
4.
5V USB outlet source
2.
White LCD digital display
5.
PSI, BAR & kPa button / Reset button
3.
14 cm (approx.) high pressure air
6.
Input for 280 cm (approx.) detachable
hose with tyre valve connector
power cord
SPECIFICATIONS:
Max pressure:
40 PSI for car tyres (100 PSI for cycle tyres)
Pressure accuracy:
Backlit pressure gauge (+/- 1PSI up to 50 PSI)
Pressure resolution:
PSI / BAR / kPa
Max current:
6.0A / 72W
Fuse size:
10A glass
Hose length:
14 cm (approx.)
Power cord:
280 cm (approx.)

DIGITAL POWER SOURCE (D.P.S) FEATURES
This MICHELIN tyre inflator incorporates a 5V USB port.
USB PORT
Under the right hand cover is a single 5V USB port (4) suitable for charging mobile phones with a
maximum rating of 0.5A.
TYRE INFLATION:
1. With the On/Off button (1) in Off position, unwind power cord and plug the small end into the input
(6) and the 12V power plug into your vehicle’s 12V power plug socket. Wait a few seconds until
digital display shows zero. Please note - when the On/Off button is in the Off position, it protrudes
from the unit slightly. When in the On position the button is flush to the unit.
2. Press the PSI, BAR & kPa button (5) to select desired pressure format.
PSI
12V POWER PLUG
TO REPLACE FUSE IN 12V PLUG:
Undo knurled ring anti-clockwise
Anti-clockwise
Replace fuse and knurled ring. (Max. 10A)
Fuse
TROUBLE SHOOTING
OTHER MICHELIN PRODUCTS AVAILABLE:
TYRE INFLATORS FOOTPUMPS DIGITAL TYRE CAR MATS
PRESSURE
GAUGES
kPa BAR
Lift up the high pressure hose and screw the tyre valve connector (3) onto the tyre valve. Always
connect the 12V power plug before connecting the high pressure hose to the tyre. Check the tyre
pressure shown on the display. If the display reads 0.00 or Err then refer to the Trouble Shooting
guide. When connected correctly the gauge will display the current pressure in the tyre. If this is the
pressure as stated in your vehicle’s handbook, you can simply remove the tyre valve connector (3).
3. To start inflating press On/Off button (1).
4. You will now see the pressure increasing on the display (2). Due to the sensitive nature of the tyre
pressure measuring system, you may find that when you switch the tyre inflator off at the required
pressure the gauge may drop back slightly. If this happens, switch back on and inflate to a slightly
higher pressure. Switch off and re-check.
5. If you are inflating multiple tyres then follow the procedure stated from 3. to 4. above.
If the 12V power supply is disconnected then always reconnect the 12V power supply before
connecting the high pressure hose to the tyre valve. If there is a power interruption during the
inflation cycle, please follow the reset procedure outlined in the Trouble Shooting guide.
Gauge does not illuminate
Unit fails to run with switch in ‘On’ position
Power lead/plug becomes hot
Gauge appears to read incorrectly or
is unreadable
Gauge reads 0.0 or ERR
Unit is running but tyre is not inflating
Gauge does not display when tyre valve
is connected
Check that plug is fully inserted into 12V socket
Check internal plug fuse (10A glass type).
Your car may require the ignition key to be
turned to the accessory position.
If power lead is coiled, uncoil to full length.
Ensure 12V socket is clean with no debris in it.
Ensure 12V plug components are tight and clean.
When the tyre valve connector is attached,
before switching the unit on, ensure the gauge
is reading your current tyre pressure.
Disconnect valve connector from the tyre.
Remove plug from power source for at
least 5 seconds, reconnect to power.
Press and hold yellow reset button until
display shows all the digits then returns to
0.0. Connect valve connector to tyre.
Check that the tyre valve connector is
correctly fitted to tyre valve.
Ensure tyre valve is correctly connected to the
tyre valve connector
AIR
DOOR PROTECTORS
SNOW CHAINS
FRESHENERS
