Maintenance Schedule
Inlet seals:
Drum gear:
Level Wind:
Grease inlet seals every 100 hours.
Grease drum gear every 100 hours.
Gearbox: Change gearbox oil once a season with 80W/90 gear oil.
Grease level wind every 100 hours, replace level wind knife every 1000 hours.
6 mm Nozzle 80% RUN TIME(HRS)
INLET
PSI GPM MAX WIDTHADJ WIDTH MAX
LENGTH0.10
INCH 0.25
INCH 0.50
INCH
45 7.5 90 72 287 2.40 6.01
55 8.5 95 76 290 2.24 5.60
65 9.4 100 80 292 2.13 5.33
75 10.4 108 86 296 2.07 5.18
85 11.6 110 88 297 1.90 4.75
7 mm Nozzle 80% RUN TIME(HRS)
INLET
PSI GPM MAX WIDTHADJ WIDTH MAX
LENGTH 0.10
INCH 0.25
INCH 0.50
INCH
50 9.8 92 74 288 1.89 4.73
60 11.1 98 78 291 1.76 4.40
70 12.2 106 85 295 1.75 4.36
80 13.7 112 90 298 1.65 4.11 8.23
90 14.8 118 94 301 1.59 3.98 7.96
8 mm Nozzle 80% RUN TIME(HRS)
INLET
PSI GPM MAX WIDTHADJ WIDTH MAX
LENGTH 0.10
INCH 0.25
INCH 0.50
INCH
55 12.9 99 79 292 1.53 3.84 7.67
65 14.8 110 88 297 1.49 3.72 7.45
75 16 112 90 298 1.41 3.52 7.05
85 17.1 114 91 299 1.33 3.33 6.67
95 18.2 118 94 301 1.29 3.23 6.47
9 mm Nozzle 80% RUN TIME(HRS)
INLET
PSI GPM MAX WIDTHADJ WIDTH MAX
LENGTH 0.10
INCH 0.25
INCH 0.50
INCH
65 16.4 108 86 296 1.31 3.28 6.57
75 17.3 113 90 299 1.30 3.26 6.52
85 18.8 118 94 301 1.25 3.13 6.26
95 21 123 98 304 1.17 2.92 5.85
105 23 130 104 307 1.13 2.83 5.66
10 mm Nozzle 80% RUN TIME(HRS)
INLET
PSI GPM MAX WIDTHADJ WIDTH MAX
LENGTH 0.10
INCH 0.25
INCH 0.50
INCH
75 19.5 108 86 296 1.10 2.76 5.52
85 21.9 116 93 300 1.06 2.66 5.32
95 23.2 120 96 302 1.04 2.59 5.18
105 23.9 121 97 303 1.02 2.54 5.08
NOTICE: These specifications are for a guide only and are based on theoretical calculations and performance tests.
This is to be used as a guide only, as performance may vary under field conditions.
Performance Chart
