Read the instructions carefully before using this device.
øÂ‰ ‚ËÍÓËÒÚ‡ÌÌˇÏ ÔË·‰Û Û‚‡ÊÌÓ ÔÓ˜ËÚ‡ÈÚ ˆ˛ iÌÒÚÛ͈i˛.
øÂ‰ ËÒÔÓθÁÓ‚‡ÌËÂÏ ÔË·Ó‡ ‚ÌËχÚÂθÌÓ ÔÓ˜ÚËÚ ‰‡ÌÌÓ ÛÍÓ‚Ó‰ÒÚ‚Ó.

Microlife BP AG1-10
Aneroid Blood Pressure Kit
Instruction Manual (1-13)
MÂı‡Ì˘ÂÒÍËÈ ÔË·Ó ‰Îˇ ËÁÏÂÂÌˡ
‡ÚÂˇθÌÓ„Ó ‰‡‚ÎÂÌˡ
PÛÍÓ‚Ó‰ÒÚ‚Ó ÔÓ ÔÓθÁÓ‚‡Ì˲ (14-27)
øË·‰ ‰Îˇ ‚ËÏi˛‚‡ÌÌˇ
‡ÚÂi‡Î¸ÌÓ„Ó ÚËÒÍÛ
lÌÒÚÛ͈iˇ ‰Îˇ ÍÓËÒÚÛ‚‡˜i‚ (28-41)
EN
RU
UA

Aneroid Blood Pressure Kit
Instruction Manual

Table of contents
1. Introduction
1.1. Features
1.2. Important information about self-measurement
2. Important information on the subject of blood pressure and its measurement
2.1. How does high/low blood pressure arise?
2.2. Which values are normal?
2.3. What can be done, if regular high/low values are obtained?
3. The various components of the blood pressure kit
4. Carrying out a measurement
4.1. Before the measurement
4.2. Common sources of error
4.3. Fitting the cuff
4.4. Measuring procedure
4.4.1. Putting the chestpiece under the cuff
4.4.2. Inflating the cuff
4.4.3. Systolic blood pressure reading
4.4.4. Diastolic blood pressure reading
4.4.5. Recording your readings
5. Malfunction / Troubleshooting
6. Care and maintenance, recalibration
7. Guarantee
8. Reference to standards
9. www.microlife.com
10. Technical specifications
1
EN

1. Introduction
1.1. Features
The aneroid blood pressure kit is a non-automated, mechanical blood pressure measuring device
for use on the upper arm.
It offers proven reliability and superior performance at an economical price. With the advanced
non-stop pin mechanism and ergonomic bulb with complete valves, the BP AG1-10 ensure you
a precise and consistent measurement. Its oversized cuff can be applied to users whose arm
circumference ist 25 the least and up to 40 cm. Nevertheless, its durable nylon cuff, high-grade
bearing and aneroid bellow provide consistent operation. The entire unit stores in a zippered
Nylon bag for easy portability.
Before using, please read through this instruction manual carefully and then keep it in a safe
place. For further questions on the subject of blood pressure and its measurement, please
contact your doctor.
Attention!
1.2. Important information about self-measurement
• Donotforget:self-measurement means control, not diagnosis or treatment. Unusual
values must always be discussed with your doctor. Under no circumstances should you alter
the dosages of any drugs prescribed by your doctor.
2. Important information on the subject of blood pressure and its measurement
2.1. How does high/low blood pressure arise?
The level of blood pressure is determined in a part of the brain, the so-called circulatory centre,
and adapted to the respective situation by way of feedback via the nervous system. To adjust the
blood pressure, the strength and frequency of the heart (Pulse), as well as the width of circulatory
blood vessels is altered. The latter is effected by way of fine muscles in the blood-vessel walls.
Thelevelofarterialbloodpressurechangesperiodicallyduringtheheartactivity:Duringthe
2

3
«blood ejection» (Systole) the value is maximal (systolic blood pressure value), at the end of
the heart’s «rest period» (Diastole) minimal (diastolic blood pressure value). The blood pressure
values must lie within certain normal ranges in order to prevent particular diseases.
2.2 Which values are normal?
Blood pressure is too high if at rest, the diastolic pressure is above 90 mmHg and/or the systolic
blood pressure is over 140 mmHg. In this case, please consult your doctor immediately. Long-
term values at this level endanger your health due to the associated advancing damage to the
blood vessels in your body.
With blood pressure values that are too low, i.e. systolic values under 100 mmHg and/or diastolic
values under 60 mmHg, likewise, please consult your doctor.
Even with normal blood pressure values, a regular self-check with your blood pressure monitor is re-
commended. In this way you can detect possible changes in your values early and react appropriately.
If you are undergoing medical treatment to control your blood pressure, please keep a record of
the level of your blood pressure by carrying out regular self-measurements at specific times of
the day. Show these values to your doctor. Never use the results of your measurements to
alter independently the drug doses prescribed by your doctor.
Tableforclassifyingbloodpressurevalues(unitsmmHg)accordingtoWorldHealthOrganization:
Range Systolic Diastolic Measures
Blood pressure Blood pressure
Hypotension lower than 100 lower than 60 Consult your doctor
Normal range between 100 and 140 between 60 and 90 Self-check
Mild hypertension between 140 and 160 between 90 and 100 Consult your doctor
Moderately serious between 160 and 180 between 100 and 110 Consult your doctor
hypertension
Serious hypertension higher than 180 higher than 110 Consult your doctor
immediately

☞Further information
• Ifyourvaluesaremostlystandardunderrestingconditionsbutexceptionallyhighundercon
ditions of physical or psychological stress, it is possible that you are suffering from so-called
«labile hypertension». Please consult your doctor if you suspect that this might be the case.
• Correctlymeasureddiastolicbloodpressurevaluesabove120mmHgrequireimmediate
medical treatment.
2.3. What can be done, if regular increased/low values are obtained?
a) Please consult your doctor.
b) Increased blood pressure values (various forms of hypertension) are associated long- and
medium term with considerable risks to health. This concerns the arterial blood vessels of
your body, which are endangered due to constriction caused by deposits in the vessel walls
(Arteriosclerosis). A deficient supply of blood to important organs (heart, brain, muscles) can
be the result. Furthermore, with long-term continuously increased blood pressure values, the
heart will become structurally damaged.
c) There are many different causes of the appearance of high blood pressure. We differentiate
between the common primary (essential) hypertension, and secondary hypertension. The
latter group can be ascribed to specific organic malfunctions. Please consult your doctor for
information about the possible origins of your own increased blood pressure values.
d) There are measures which you can take, not only for reducing a medically established high
bloodpressure,butalsoforprevention.Thesemeasuresarepartofyourgeneralwayoflife:
A) Eating habits
• Striveforanormalweightcorrespondingtoyourage.Reduceoverweight!
• Avoidexcessiveconsumptionofcommonsalt.
• Avoidfattyfoods.
B) Previous illnesses
Followconsistentlyanymedicalinstructionsfortreatingpreviousillnesssuchas:
 •Diabetes(Diabetesmellitus)
 •Fatmetabolismdisorder
 •Gout
4

5
C) Habits
• Giveupsmokingcompletely
• Drinkonlymoderateamountsofalcohol
• Restrictyourcaffeineconsumption(Coffee)
D) Physical constitution
• Afterapreliminarymedicalexamination,doregularsport.
• Choosesportswhichrequirestaminaandavoidthosewhichrequirestrength.
• Avoidreachingthelimitofyourperformance.
• Withpreviousillnessesand/oranageofover40years,pleaseconsultyourdoctorbefore
beginning your sporting activities. He will advise you regarding the type and extent of types
of sport that are possible for you.
3. The various components of the Aneroid Blood Pressure Kit
TheillustrationshowstheBPAG110,consistingof:
a) Measuringunit:
b) Cuff:
Type ACXLNP-1, for arm circumference 25 - 40 cm
Soft bag
Cuff
Manometer
Bulb & Valves

4. Carrying out a measurement
4.1. Before the measurement
• Avoideating,smokingaswellasallformsofexertiondirectlybeforethemeasurement.All
these factors influence the measurement result. Try and find time to relax by sitting in an
armchair in a quite atmosphere for about ten minutes before the measurement.
• Removeanygarmentthatfitscloselytoyourupperarm.
• Measurealwaysonthesamewrist(normallyleft).
• Attempttocarryoutthemeasurementsregularlyatthesametimeofday,sincetheblood
pressure changes during the course of the day.
4.2. Common sources of error
Note: Comparablebloodpressuremeasurementsalwaysrequirethesameconditions!Theseare
normally always quiet conditions.
• Alleffortsbythepatienttosupportthearmcanincreasethebloodpressure.Makesureyou
are in a comfortable, relaxed position and do not activate any of the muscles in the measu-
rement arm during the measurement. Use a cushion for support if necessary.
• Ifthearmarteryliesconsiderablylower(higher)thantheheart,anerroneouslyhigher
(lower)bloodpressurewillbemeasured!(Each15cmdifferenceinheightresultsin
ameasurementerrorof10mmHg!)
• Cuffsthataretoonarrowortooshortresultinfalsemeasurementvalues.Selectingthecorrect
cuff is of extraordinary importance. The cuff size is dependent upon the circumference of the arm
(measured in the centre). The permissible range is printed on the cuff. If this is not suitable for
your use, please contact your dealer. Note: Only use clinically approved Original-Cuffs!
• Aloosecufforasidewaysprotrudingairpocketcausesfalsemeasurementvalues.
4.3. Fitting the cuff
a) Push the cuff over the left upper arm so that the tube
points in the direction of the lower arm.
6

7
b) Lay the cuff on the arm as illustrated. Make certain
that the lower edge of the cuff lies approximately
2 to 3 cm above the elbow and that the rubber tube
leaves the cuff on the inner side of the arm.
Important! The mark (ca. 3 cm long bar) must lie
exactly over the artery which runs down the inner
side of the arm.
c) Tighten the free end of the cuff and close the cuff
with the closer.
d) There must be no free space between the arm and
the cuff as this would influence the result. Clothing
must not restrict the arm. Any piece of clothing which
does (e.g. a pullover) must be taken off.
e) Secure the cuff with the closer in such a way that it
lies comfortably and is not too tight. Lay the arm on
the table (palm upwards) so that the cuff is at the
same height as the heart. Make sure that the tube is
not kinked.
f) Remain seated quietly for two minutes before you
begin the measurement.
Comment:
If it is not possible to fit the cuff to the left arm, it can also be placed on the right one. However
all measurements should be made using the same arm.
2–3 cm
tube
