Microlife BP3GT1-6X User manual

Table of contents
1. Intro uction
1.1. Features of your touch screen blood pressure monitor
1.2. Important information about self-measurement
2. Important information on bloo pressure an its measurement
2.1. How does high/low blood pressure arise?
2.2. Which values are normal?
2.3. What can be done if regular high/low values are obtained?
3. Components of your bloo pressure monitor
4. Using your bloo pressure monitor for the first time
4.1. Inserting the batteries
4.2. Power switch
4.3. Using the interactive touch screen
4.4. Setting the date and time
4.5. Using the AC power adapter
4.6. Cuff tube connection
4.7. Select the user
4.8. Select the measuring mode: standard or measurement averaging mode
4.9. Measurement averaging mode technology (MAM)
5. Measurement proce ure
5.1. Before measurement
5.2. Common sources of error
5.3. Fitting the cuff
5.4. Measuring procedure
5.5. Memory – displaying the last 120 measurements
5.6. Discontinuing a measurement
5.7. Setting the medication reminder
5.8. Hypertension risk indicator
5.9. Irregular heartbeat detector
5.10. Battery charge indicator
6. Software functions
6.1. Installation and data transmission
1

2
7. Error messages/troubleshooting
8. Care an maintenance
9. Warranty
10. Certifications
11. Technical specifications
12. How to contact us

1. Intro uction
1.1. Features of your Touch Screen Bloo Pressure Monitor
Your blood pressure monitor is a fully automatic digital blood pressure measuring
device for use by adults on the upper arm at home or in your doctor’s/nurse’s office. It
enables very fast and reliable measurement of the systolic and diastolic blood pressure
as well as the pulse by way of the oscillometric method. This device offers clinically
proven accuracy and has been designed to be user friendly.
Before using please read this instruction manual carefully and then keep it in a safe
place. Please contact your doctor for further questions on the subject of blood pressure
and its measurement.
Attention!
1.2. Important information about self-measurement
• Self-measurement means control not diagnosis or treatment. Unusual values must
always be discussed with your doctor. Under no circumstances should you alter the
dosages of any drugs prescribed by your doctor.
• The pulse display is not suitable for checking the frequency of heart pacemakers.
• In cases of irregular heartbeat measurements made with this instrument should
only be evaluated after consultation with your doctor.
Electromagnetic interference:
The device contains sensitive electronic components. Avoid strong electrical or electro-
magnetic fields in the direct vicinity of the device (e.g. mobile telephones microwave
ovens). These can lead to temporary impairment of the measuring accuracy.
2. Important information on bloo pressure an its measurement
2.1. How oes high/low bloo pressure arise?
Your level of blood pressure is determined in the circulatory center of the brain and
adjusts to a variety of situations through feedback from the nervous system. To adjust
blood pressure the strength and frequency of the heart (pulse) as well as the width of
circulatory blood vessels is altered. Blood vessel width is affected by fine muscles in
the blood vessel walls.
Your level of arterial blood pressure changes periodically during heart activity. During
the "blood ejection" (Systole) the value is highest (systolic blood pressure value). At
the end of the heart’s "rest period" (Diastole) pressure is lowest (diastolic blood
pressure value).
3

Blood pressure values must lie within certain normal ranges in order to prevent particu-
la r diseases.
2.2. Which values are normal?
Blood pressure is too high if your diastolic pressure is above 100 mmHg and/or your
systolic blood pressure is over 160 mmHg while at rest. In this case please consult
your physician immediately. Long-term values at this level endanger your health due to
continual damage to the blood vessels in your body.
If your systolic blood pressure values are between 140 mmHg and 159 mmHg and/or
the diastolic blood pressure values are between 90 mmHg and 99 mmHg consult your
physician. Regular self-checks are necessary.
If you have blood pressure values that are too low (i.e. systolic values under 105
mmHg and/or diastolic values under 60 mmHg) consult your physician.
Even with normal blood pressure values a regular self-check with your blood pressure
monitor is recommended. You can detect possible changes in your values early and
react appropriately.
If you are undergoing medical treatment to control your blood pressure keep a record
of values along with time of day and date. Show these values to your physician.
Never use the results of your measurements to in epen ently alter the rug
oses prescribe by your physician.
Which values are normal?
The following standards for assessing high blood pressure (in adults) have been
established by the National Institutes of Health JNC7 2003.
4
Category Systolic Diastolic
(mmHg) (mmHg)
Normal <120 and <80
Pre-Hypertension 120-139 or 80-89
Hypertension
Stage 1 Hypertension 140-159 or 90-99
Stage 2 Hypertension ≥160 or ≥100

+Further information
• If your values are mostly normal under resting conditions but exceptionally high
under conditions of physical or psychological stress it is possible that you are
suffering from so-called "labile hypertension." Consult your doctor.
• Correctly measured diastolic blood pressure values above 120 mmHg require
immediate medical treatment.
This evice is not inten e for use on chil ren 12 years of age or younger.
2.3. What can be one if regular high or low values are obtaine ?
a) Consult your doctor.
b) Increased blood pressure values (various forms of hypertension) are associated with
considerable health risks over time. Arterial blood vessels in your body are
endangered due to constriction caused by deposits in the vessel walls (arteriosclero-
sis). A deficient supply of blood to important organs (heart brain muscles) can result
from arteriosclerosis. Furthermore the heart will become structurally damaged with
increased blood pressure values.
c) There are many different causes of high blood pressure. We differentiate between
the common primary (essential) hypertension and secondary hypertension. The latter
group can be ascribed to specific organ malfunctions. Please consult your doctor for
information about the possible origins of your own increased blood pressure values.
d) There are measures which you can take to reduce and even prevent high blood
pressure. These measures must be permane nt lifestyle changes.
1) Eating habits
• Strive for a normal weight corresponding to your age. See your doctor for your ideal weight.
• Avoid excessive consumption of common salt.
• Avoid fatty foods.
2) Previous illnesses
• Consistently follow all medical instructions for treating illness such as:
• Diabetes (diabetes mellitus)
• Fat metabolism disorder
• Gout
5

3) Habits
• Give up smoking completely.
• Drink only moderate amounts of alcohol.
• Restrict your caffeine consumption (e.g. coffee).
4) Physical constitution
• After a preliminary me ical examination, o regular exercise.
• Choose sports which require stamina and avoid those which require strength.
• Avoid reaching the limit of your performance.
• With previous illnesses and/or an age of over 40 years please consult your doctor
before beginning your exercise routine. You must receive advice regarding the type
and extent of exercise that is appropriate for you.
3. Components of your bloo pressure monitor
a) Measuring unit
6
Cuff Socket
Time/Date
START/STOP
ENTER
Mode Switch
Select 1 or 3
Meas rements
USB Port
Memory Recall
AC Adapter
Port
Hypertension
Risk Indicator
Power Switch/
ON/OFF
Touch Screen
Lock
Cuff Storage
Cradle
Switch User

b) Wi e Range Cuff:
For arm circumference 22 cm-46 cm (8.7” - 18.1 ”)
If you ever need to buy a replacement cuff call blood
pressure support toll-free at 1-800-568-4147.
Please Note:
Arm circumference should be measured with a measuring tape in the middle of the
relaxed upper arm. Do not force cuff connection into the opening. Make sure the cuff
connection is not pushed into the AC adapter port. If the cuff is too small call
1-800-568-4147 for further information. This unit will only work accurately with the
included cuff.
4. Using your bloo pressure monitor for the first time
4.1. Inserting the batteries
After you have unpacked your device insert the batteries.
The battery compartment is located on the bottom of the
device.
a) Remove the battery cover.
b) Insert the batteries (4 x size AAA 1.5 V) observing the
indicated polarity.
c) If a battery warning appears in the display the batteries
are discharged and must be replaced.
Attention!
• After the low battery indicator appears the device won’t
function until the batteries have been replaced.
• Please use "AAA" Long-Life or Alkaline 1.5 V batteries.
• If the blood pressure monitor is not used for long
periods remove the batteries from the device.
4.2. Power switch
To activate your monitor push the switch on the right hand
side downwards to the unlock position.
7
unlocked
locked
Discharged
Battery

4.3. Using the interactive touch screen
This monitor features an interactive touch screen which
operates similarly to traditional buttons but requires only
a light touch of the finger to operate.
The following functions are made easier through the
interactive touch screen:
• Setting time and date
• Scrolling through memories
• Selecting the user
• Starting/stopping the blood pressure measurement
4.4. Setting the ate an time
1. After the new batteries are activated and the monitor is
unlocked the year number flashes in the display. You can
advance the year by pressing minus and plus. To confirm
and then set the month press enter.
2. You can now set the month using the minus and plus. To
confirm and then set the day press enter.
3. Please follow the instructions above to set the day hour
and minutes.
4. Once you have set the last minute and pressed enter the
date and time are set and the time is displayed.
5. If you want to change the date and time press and hold
the time down for approximately 3 seconds until the year
number starts to flash. Now you can enter the new
values as described above.
6. To bypass setting date and time press the time.
8
TIME PM
Enter
Enter

4.5. Using the AC power a apter
You may also operate this monitor using the included AC
adapter. Use only the included AC adapter to avoid
damaging the unit.
a) Ensure that the AC adapter and cable are not damaged.
b) Plug the adapter cable into the AC adapter port on the
right side of monitor.
c) Plug the AC adapter into a 110 V power socket (U.S. or
Canada).
d) Test that power is available by switching the screen lock
located on the right side of the monitor off and on. The
screen display will be visible if the power is available.
Note:
• No power is taken from the batteries while the AC
adapter is connected to the instrument.
• If the power is interrupted during a measurement (e.g. by
removal of the adapter from the wall socket) the
instrument must be reset by removing the plug from the
instrument.
If you have any questions regarding the AC adapter call
Blood Pressure Support at 1-800-568-4147.
4.6. Cuff tube connection
Insert the cuff tube into the opening on the left side of the
instrument.
Note: This unit will only work accurately with the included
cuff.
9
