Microtek CX6 User manual

—
— Q Qu ui ic ck k S St ta ar rt t G Gu ui id de e — —
21
CHECK PARTS LIST
Congratulations on your purchase!
Please check that the following items are
included with your pr
ojector.
Parts List
1. CD-ROM(Usermanual)
2. Carrying case
3. Remote control with batteries
4. Projector
5. Power cord
6. Computer cable (DVI-DB15)
7. USB cable
8. S-video cable
Contact your dealer immediately if any
items are missing or damaged.
2
IDENTIFY PROJECTOR PARTS
Projector Parts Description
1. Turn to adjust zoom
2. Projector controls
3. IR receiver
4. Turn ring to focus
5. Side foot—adjusts level of projector
6. Height adjuster button—push to ad-
just height
7. Speaker
Caution:
Overheating can damage the projector.
Do not block any of the air vents around
the unit.
23
IDENTIFY REMOTE PARTS
Remote Buttons Description
1. Use as on-screen pointer. DO NOT
POINT IN EYES.
2. Transmits signals to projector
3. Lights when the remote is used
4. Optimizes image size, position, and
resolution
5. Makes the screen blank
6. Changes settings in the OSD
7.
8. Navigates and changes settings in
the OSD
9. Moves the on-screen cursor when
connected to a PC
10.
11 Corrects keystone (wider top/bottom)
effect
12 Mutes the built-in speaker
13
14 Function as mouse buttons when
connected to a PC
15
16 Adjusts volume
17
18 Navigates and changes settings in
the OSD
19 Opens the On-Screen Display (OSD)
20 Freeze/unfreezes the on-screen pic-
ture
21 Detects the input device
22 Turns the projector on or off
4
INSERTREMOTECONTROLBATTERY
1. Remove the battery
compartment cover by sliding
the cover in the direction of the
arrow.
2. Insert the supplied batteries
taking note of the polarity (+/-).
3. Replace the cover.

—
— Q Qu ui ic ck k S St ta ar rt t G Gu ui id de e — —
25
MAKE CONNECTIONS
Warning:
As a safety precaution, disconnect all
power to the projector and conn
ecting
devices before making co
nnections.
Label Description
1. DVI-I in Connect the supplied DVI
cable from a computer.
2. RGB in Connect an RGB cable
from a computer (not sup-
plied).
3. RGB
out
Connect an RGB cable (not
supplied) to an external
monitor.
4. RS-232 Reserved service port for
firmware upgrades.
5. USB Connect the supplied USB
cable from a computer.
6. Audio-
in
Connect an audio cable
(not supplied) from the
computer’s audio-out con-
nector.
7. Audio-
out
Connect an audio cable
(not supplied) to audio-in
port of a amplifier device
8. L-
Audio-
R
Connect an audio cable
(not supplied) from a video
device.
9. Video
in
Connect a composite video
cable (not supplied) from a
video device.
10. S-video Connect the supplied S-
video cable from a video
device.
11. Compo-
nent
Videoin
Connect a component video
cable (not supplied) from a
video device.
6
POWERON/OFF ANDSETLANGUAGE
1. Connect the power cord to the
projector (A). Connect the other
end to a wall outlet.
Turn the main power switch on
(B).
The Power LED and Lamp-ready
LED turn on.
2. Turn on the connected devices.
3. Ensure the Lamp-ready LED is
orange (not flashing) and then
press the Power button to turn
on the projector (B).
The projector splash screen
displays and connected devices
are detected.
4. Press the Menu button and then
press the cursor button until
Language is highlighted (C).
5. Press the cursor button until
the language you want is
highlighted (D).
6. Press the cursor ENTER button
to confirm the language.
7. Press the Menu button twice to
close the OSD.
8. To turn off the projector, press
the power button once and then
again after the prompt. Then,
turn off the main power switch.

—
— Q Qu ui ic ck k S St ta ar rt t G Gu ui id de e — —
7
ADJUST PROJECTOR LEVEL
1. To raise the level of the
projector, lift the projector (A)
and press the height adjuster
buttons (B).
The height adjusters drops down
(C).
2. To lower the level of the
projector, press the height
adjuster buttons [B] and push
down [A] on the top of the
projector.
28
ADJUST IMAGE AND VOLUME
1. Use the Image-zoom control (on
the projector only) to resize the
projected image and screen size
(A).
2. Use the Image-focus control (on
the projector only) to sharpen
the projected image (B).
3. Use the Keystone buttons (on
the remote control or projector)
to correct keystone (wider top or
bottom) effect (C).
4. Use the Volume buttons (on the
remote control or projector) to
adjust the volume.
NEED MORE INFORMATION?
The CD-ROM that shipped with your pro-
jector features a detailed user manual in
a printer-friendly format. The user man-
ual includes detailed hardware,
operation, and maintenance descrip
tions.
You will also find troubleshooting proce-
dures and instructions on securing the
projector by means of a security lock.
The projector has an On-Screen Display
(OSD) that lets you make image adjust-
ments and change various settings. To
open the OSD, press the Menu button
on the remote control. Use the remote
Cursor buttons to navigate and make
changes to the projector settings.
Refer to the “On-Screen Display Set-
tings” section of the CD-ROM user
manual for more information.
Warning message:
Before unplug power cord, pls ensure
the Lamp-ready LED is orange (not
flashing).
