MS4
Mobile Digital Projector
www.microtek.com
High performance. Low Price.
High performance. Low Price.
Microtek’s MS4 mobile digital projector is a
high-performance choice that offers versatility,
high resolution and stellar color clarity. Whether
in the boardroom or in the classroom, on
the road or in the home, the MS4 sets up
in seconds, runs whisper-quiet and delivers
brilliant contrast and vivid colors.
State-of-the-art DLP™ technology from Texas
Instruments® provides 1200 ANSI lumen
brightness, 1500:1 contrast ratio, and native
SVGA (800x600) resolution, ensuring sharp
and crisp images in any lighting condition.
Clearly marked inputs and Plug and Project
compatibility guarantee your HDTV video, slide
show, or Excel® spreadsheet will be up and
running immediately.
With a stylish understated design, sleek
carrying case and affordable price, the MS4
is the perfect projector to help you keep the
focus on what is important —you and your
presentation.
Superior hardware leads to
superior performance
• Stylish ultraportable design at
just over 4 lbs
• Superior image quality with
DLP technology
• Bright and crisp 1200 ANSI
lumens and 1500:1 contrast ratio
• SVGA (800x600) resolution for
sharp images
• HDTV-ready
• Extensive computer and video
connections, including DVI for
high end digital video
• Manual focus and digital zoom
• +/- 15º( keystone correction
eliminates distortion
• Whisper quiet fan provides
minimal distracting noise
• Kensington® security lock
• Quick startup and shutdown
• Includes soft carrying case

Microtek MS4 Mobile Digital Projector
Projection System Features
Part Number 1102-03-991000
Native Resolution 800 x 600 (SVGA)
Max Resolution 1024 x 768 (SXGA)
Display Type 0.55” DDR DLP Technology
Brightness (typical) 1200 ANSI lumens
Lamp 200 watt VIP
Lamp Life 2000 hours
Brightness Uniformity (typical) >80%
Projection Lens 1.16:1 manual zoom; F 2.4 - 2.6, f 24.0 - 28.8mm manual focus
Displayable Colors 24-bit; 16.7 million
Contrast Ratio 1500:1
Aspect Ratio 4:3 (supports 16:9)
Projected Distance 4.9’ - 23’ (1.5m - 7.0m)
Screen Size (diagonal) 37” - 202.8” (0.94m - 5.15m)
Digital Keystone Correction ±15 degrees
Audio Built-in 1 watt mono speaker x1
Security Lock Kensington® MicroSaver Securiity System
Remote Control Features Wireless remote with laser pointer, mouse function, power, auto image,
source select, keystone, menu, enter, volume, arrow keys, and full OSD
controls
Technical Specifications
Horizontal Scan Rate 15, 31KHz - 70KHz
Vertical Refresh Rate 50Hz - 85Hz
Installation Options Front, rear, ceiling
Plug and Project VESA® DDC 1/2B
Power Consumption 280W; 20W standby mode
Power Supply Voltage Universal 100 - 240V, 50/60Hz AC
Operating Temperature 50°F - 95°F (10°C - 35°C)
Dimensions (WxHxD) 11” x 3.8” x 8” (28cm x 9.7cm x 20cm)
Weight 4.5 lbs / 2 kg
Audible Noise <35dB (nominal room condition)
Connectivity
Computer Inputs DVI x1
Video Inputs S-video Mini DIN 4 pin x1, RCA composite video x1
Audio Inputs Stereo mini jack x1
Outputs Stereo Mini jack x1, D-sub HD 15-pin x1, USB x1, PS/2 x1
Video NTSC, NTSC 4.43, B/G/H/I/M/N 60, SECAM, SDTV 480i, EDTV 480p, 720p,
HDTV 1080i
Included Accessories
Soft carry case, user’s manual, remote control with laser pointer (with 2 AAA batteries), power cord, VGA 15-pin
D-sub to DVI cable, S-video cable, audio mini jack to RCA cable, USB cable
Warranty and Support
Warranty Standard one year limited warranty, 90-day lamp warranty.
Support One year technical support with dedicated line.
www.support.microtek.com
Microtek Lab, Inc. • 16941 Keegan Avenue • Carson, CA 90746
Specifications, hardware and software bundles are subject to change without notice. © 2005 Microtek Lab, Inc. Microtek is a trademark of Microtek
Lab, Inc. All other trademarks or registered trademarks are the property of their respective holders. Lamp brightness subject to change with usage. Not responsible for typographical
errors. MLIDS-MS4-0405
Projection distance and screen size at
4:3 aspect ratio reference chart
www.microtek.com
MS
4






Top View
Side View
11”
8”
3.8”
