Microzone MC6A User manual

User Manual
Precautions
1). Suitable for use with: Aircraft, Vehicles, Boats and Multi Rotors (Quads)
2). Transmit Power: Less than or equal to <13dbm
3). Transmission Frequency: 2401.5 MHz --- 2445.5 MHz
4). Ground Control Range: More than 800 meters
5). Transmitter Power Requirements: DC +6V (4 x AA Batteries)
6). Receiver Power Requirements: DV +6V
Binding Instructions.
To bind your transmitter and receiver together, please take the following steps.
1). Turn off the transmitter and power to the receiver
2). Connect the ESC signal line to the third channel of the receiver, then connect the battery to the ESC. If you are
not using an ESC then you can connect the battery (6v Max) to the third channel of the receiver.
3). The orange LED on the receiver will now be flashing.
4). Press the ’bind’ button on the receiver, the LED will begin to flash faster.
5). Make sure the throttle is fully closed on the transmitter and then switch on the transmitter
6
6). The LED will now be on solid and not flashing.
7). Disconnect the battery from the ESC or receiver, switch off the transmitter.
8). Plug in your servos to the receiver, switch on the transmitter and reconnect power to the receiver. Check you
have full control over all of the channels. If not please follow the bind instructions again.

Throttle channel reverse switch (CH.3)
Rudder channel reverse switch (CH.4)
Antenna
Power Indicator
Signal Light
Variable Channel 6
Elevator Trim
Power Switch
Aileron Trim
Dual Rate Switch
Channel 5
Mixing Function Activation
Throttle Trim
Rudder Trim
V-Tail Mixing
Delta Wing Mixing (Elevons)
To install the batteries remove the battery
cover and insert 4 AA batteries according
to the polarity marked inside the battery
box and then replace the battery cover.
Elevator channel reverse switch (CH.2)
Aileron channel reverse switch (CH.1)
