MicW Audio iShotgun Instruction manual

$!"
%!"
0
350
340
33
0
32
0
31
0
240
230
220
210
200
190
180
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
300
290
280
270
260
250
Polar Pattern
500
5k
10k
1k
Introduction
Welcome to
the MicW iSeries of professional micro-
phones. MicW have been producing high quality
microphones for measurement and recording applica-
tions since
1998
.
The
iSeries
has now applied this wealth of knowledge
and technology to mobile devices such as smartpho-
nes, DLSR cameras and camcorders.
The
iShotgun
is a super-cardioid
shotgun mic
for
professional use.
- Highly directional
- Compact and elegant design
- Rugged aluminum body and lightweight
Applications
Diagrams
Frequency response
-2
0
-1
0
0
10
20
20
200
2000
20000
dB
Hz
special
microphones
ENG • Interview • Podcast • Video/Film Production
Perfect for
The perfect microphone
for Camcorder, Cameras and mobile devices
Type
Electret Condenser
Operation
Interference tube
Polar pattern
Super cardioid
Sensitivity (± 3 dB)
8 mV/Pa (- 42 dB)
Frequency Response
100 Hz - 18 kHz
S/N ratio
> 65 dB
Impedance
< 2,2 kOhm
Power supply
Plug and Play
Operating temperature
-20°C - +50°C
Diameter
8,0 mm
Size
length 13,6 mm
Weight
20 g
Connector
3,5 mm •
4-pole
headphone jack
Product Reliaility*
The microphone is supplied with a pre-polarized capsule
which is tested in a high temperature and high humidity
environment for more than 24 hours.
* Every device must supply PlugIn-Power
* It is recommended that you use "Airplane Mode" for recording.
iPhone • iPad • iPod touch •
Samsung Galaxy • HTC Desire •
Motorola XT Series • Canon5D, 7D •
Sony Al-pha6 and 7 Series • Nikon
D7000 • Panasonic X900M / X909 /
V707 • Sony CX250 / CX570 /
CX730 • Canon HFD10 • Computers
with Microphone Input…
The iShotgun, as well as the whole iSeries, has
been tested with the following devices:
Power Supply* comes straight from the connector,
there is no need for an extra battery.
Features:
- No battery required
- Many accessories included
ash
™
iShotgun

Using the iShotgun with a computer is very simple.
Just use the adaptor-cable
CB002S
together with the
extension cable
CBO30S
to get connected. Then acti-
vate the Mic-Input in your system settings.
On many
mobile devices
, the MicW iShotgun will
automatically
be detected by simply connecting it
to the headset jack.
For those situations where distance is critical, you
can use the included boom-pole to get right in on
the action.
The two
adaptors
SA0111
and
SA012
enable you
to use the microphone and the headset simulta-
neously. Just plug the adaptor you need between
the jack of the mobile device and the headphones/
microphone.
Computer and Mixer*
is a member of
BSWA Technology Ltd.
Unit 1003, North Ring Center, No.18 Yumin Road, Xicheng District, Beijing 100029, China
Phone: [phone] • Fax: [phone] • [e-mail] • www.mic-w.com
MicW
When using the shockmount, it is important to cross
the rubber band on both sides (diagram below). This
will secure the iShotgun in place and help minimise
handling noise.
User manual
PP013 Shockmount
CBO30S 3.0m
extension cable
iShotgun
microphone
SA011 Split-Adaptor
for microphone and
heaphones
BM100 1.0m Boom-pole
SA012 Split-Adaptor (T-Style)
for microphone and heaphones
WS810 Windscreen
CB002S 0.2m
Camera-Adaptor for
Caneras, Camcorders
and Computers
SA013
SA012
SA011
Camera & Camcorder
The Y Adapter SA013 enables you to use two
microphones simultaneously from two direction for
interview purpose.The SA013 also ts on the new
iPhone5 and other smartphones for taking videos.
SA013
Split-Adaptor(Y Style)
for two microphones
* Make sure your computer has a microphone input with PlugIn-Power
When using the iShotgun on
Cameras
and
Camcor-
ders
, use the
adaptor-cable CB002S
and the shock-
provides a good
isolation
from handling noise.
What‘s in the box
Split-Adaptor SA011 and SA012 Split-Adaptor SA013
Mobile devices • Smartphones
