Midea CCM-180A/WS User manual

Commercial Air Conditioners
Service
Manual
VRF
iOS Version Android Version
Midea CAC After-service Application
Add.: Midea Headquarters Building, 6 Midea Avenue, Shunde, Foshan, Guangdong, China
Postal code: 528311
Tel: [phone] Fax: [phone]
cac.midea.com global.midea.com
Note: Product specifications change from time to time as product improvements and
developments are released and may vary from those in this document.
Commercial Air Conditioner Division
Midea Group
Touch Screen
Centralized Controller
6.2-inch
CCM-180A/WS

1CCM-180A/WS
201803 1
CCM-180A/WS Service Manual
Content
1 General Safety Precautions .............................................................................................2
1.1 General ......................................................................................................................................... 2
1.2 Installation Site.............................................................................................................................. 2
1.3 Electrical........................................................................................................................................ 2
2 Packing List .....................................................................................................................4
2.1 Specifications ................................................................................................................................ 4
3 Installation Procedure.....................................................................................................5
3.1 Mounting the Controller ................................................................................................................ 5
3.2 Centralized Controller Wiring Diagram ........................................................................................... 7
3.3 Debugging the Centralized Controller............................................................................................. 8
4 Getting Started ...............................................................................................................9
4.1 Home Page Button and Display Description.................................................................................... 9
4.2 Control Page ................................................................................................................................ 12
4.3 Schedule Page Description ........................................................................................................... 19
4.4 Fault Report Page ........................................................................................................................ 24
4.5 Installation Interface.................................................................................................................... 27
4.6 Settings Page ............................................................................................................................... 30
4.7 Help Interface.............................................................................................................................. 42

CCM-180A/WS
2 201803
CCM-180A/WS Service Manual
1General Safety Precautions
Please read these general safety precautions carefully before installing the CCM-180A/WS.
After completing the installation, make sure the power supply and CCM-180A/WS operate properly during the startup
operation.
1.1 General
If you are not sure how to install or operate CCM-180A/WS, contact your dealer.
NOTICE
Improper installation or attachment of equipment or accessories could result in electric shock, short-circuit,
leaks,fire or other damage to the equipment. Only use accessories, optional equipment and spare parts made
or approved by Midea.
WARNING
Make sure installation, testing and applied materials comply with the applicable legislation.
CAUTION
Wear adequate personal protective equipment (protective gloves, safety glasses,…) when installing,
maintaining or servicing the system.
WARNING
Tear apart and throw away plastic packaging bags so that nobody, especially children, can play with them.
Possible risk: suffocation.
1.2 Installation Site
Do NOT install the equipment in a potentially explosive atmosphere.
1.3 Electrical
DANGER: RISK OF ELECTROCUTION
Turn OFF all power supply before connecting electrical wiring or touching electrical parts.
Disconnect the power supply for more than 1 minute, and measure the voltage at the terminals of main
circuit capacitors or electrical components before servicing. The voltage must be less than 50 V DC before you
can touch electrical components. For the location of the terminals, see the wiring diagram.
Do NOT touch electrical components with wet hands.
Do NOT leave the equipment unattended when the service cover is removed.
WARNING
A main switch or other means for disconnection, having a contact separation in all poles providing full
disconnection under overvoltage category III condition, shall be installed in the fixed wiring.
WARNING
Only use copper wires.
Make sure the field wiring complies with the applicable legislation. Do NOT touch electrical components
with wet hands.
All field wiring must be performed in accordance with the wiring diagram supplied with the product.
Make sure to install earth wiring. Do NOT earth the unit to a utility pipe, surge absorber, or telephone
earth. Incomplete earth may cause electrical shock.
Make sure to use a dedicated power circuit. NEVER use a power supply shared by another appliance.

1CCM-180A/WS
201803 3
CCM-180A/WS Service Manual
Make sure to install the required fuses or circuit breakers.
Make sure to install an earth leakage protector. Failure to do so may cause electric shock or fire.
Note: Install the wires at least 1 meter away from televisions or radios to prevent interference. Depending on the radio waves, a distance of 1 meter may not
be sufficient.
WARNING
After finishing the electrical work, confirm that each electrical component and terminal inside the
electrical cabinet is securely connected.
Make sure all covers are closed before starting up the units.

CCM-180A/WS
4 201803
CCM-180A/WS Service Manual
2Packing List
Name
Qty (specification)
Adapter
x1 (output 12V DC)
Manual
x1
Cable tie
x1
Screw
x4 (ST3.9*16)
Centralized
controller
x1
2.1 Specifications
Table 1 Specifications
Adapter
Input (AC)
100-240V, 50/60Hz, 800mA
Output (DC)
12.0V, 2A
Centralized
controller
Input voltage
12VDC
Ambient Temperature
23~110°F (-5~43°C)
Ambient Humidity
RH40%~RH90%
Dimensions (mm)
181x124x30

1CCM-180A/WS
201803 5
CCM-180A/WS Service Manual
3Installation Procedure
Figure 1 Front view and back view of the centralized controller (unit: mm)
3.1 Mounting the Controller
3.1.1 Remove the back cover from the controller using a Phillips-head screwdriver. See Figure 2.
Figure 2 Remove back cover from controller
3.1.2 Attach the back cover to the wall using screws. See Figure 3.
Figure 3 Attach back cover to wall

CCM-180A/WS
6 201803
CCM-180A/WS Service Manual
3.1.3 This product adopts a concealed installation mode. The communication cable and power cord are fixed to the
positions shown in Figure 4 using cable ties.
Figure 4 Centralized controller wiring diagram and cable tie fixing hole
3.1.4 Insert the centralized controller into two buckles slantwise at the bottom of back cover, as shown in Figure 5.
Figure 5 Insert controller into back cover
Fixing line position
of the cable tie (in
the accessory bag)

1CCM-180A/WS
201803 7
CCM-180A/WS Service Manual
3.1.5 Press the upper part of the centralized controller into the back cover, so it gives a click sound , as shown in Figure
6.
Figure 6
3.2 Centralized Controller Wiring Diagram
This centralized controller can connect to up to eight refrigerant systems and control up to 64 IDUs. Automatic addressing
needs to be set for the ODU main board according to the manual.
Connect the centralized controller to the XY terminal of the communication board of the ODU through the shielded wire
using the method shown in Figure 7(a).
Alternatively, connect the XY terminal of the centralized controller to the XY terminal of the first-generation AC/DC IDU, as
shown in Figure 7(b).
Figure 7(a) Connecting the centralized controller to the ODU
6.2-inch
X,Y P,Q,E P,Q,E P,Q,E
P,Q,E P,Q,E P,Q,E
Up to 8
refrigerant systems P,Q,E P,Q,E P,Q,E
Up to 64
indoor units
X,Y
X,Y

CCM-180A/WS
8 201803
CCM-180A/WS Service Manual
Figure 7(b) Connecting the centralized controller to the IDU (the first generation of AC/DC IDU)
Figure 7(c) Adapter outlet terminal (12 VDC) shown in the left figure has a red positive pole and black negative pole. Connect it to the
corresponding wiring terminal on the centralized controller back
3.3 Debugging the Centralized Controller
The technician installing the products needs to perform debugging. For the detailed steps, see section 4.5.
Note: The centralized controller will automatically search for connected devices when it is powered on for the first time. If other devices are used later, they
must be searched for again on the installation interface.
+
-

1CCM-180A/WS
201803 9
CCM-180A/WS Service Manual
4Getting Started
4.1 Home Page Button and Display Description
This section includes the descriptions for login page and home page and provides the instructions related to these two
pages.
Figure 8
Figure 9
○
1
○
2
○
3
○
5
○
4
○
6
○
7

CCM-180A/WS
10 201803
CCM-180A/WS Service Manual
Figure 10
Table 2 Home Page Button and Display Description
NO.
Button and Display
Description
1
Screen ON/OFF button
Turn the Screen on/off
2
Username
Enter login username
3
Password
Enter login password
4
Save Password
Enable/disable the automatic login password saving
function
5
Auto-login
Allow automatic login after powering on again
6
Login
Login
7, 18
USB2.0 socket (at the bottom
of centralized controller)
Externally connecting to the USB storage device to provide
the software upgrading and error code exporting functions
8
Logout
Back to login page
9
Date and Time
Display date and time
10
Today’s Schedule
Display the list of schedules
11
Advanced information of IDU
and ODU
Display the IDU and ODU spot inspection parameters
12
Control menu
Enter the control page
13
Schedule menu
Enter the schedule page
14
Reports menu
Enter the report page
15
Configuration menu
Enter the configuration page
16
Settings menu
Enter the setting page
17
Help menu
Enter the help page
19
Communication terminal
Connect to the control device through the XY shield line
20
Power supply terminal
Connect to the 12VDC adapter
○
18
○
19 ○
20

1CCM-180A/WS
201803 11
CCM-180A/WS Service Manual
4.1.1 Login
1. Power on the centralized controller.
2. Enter the user name and password on the login interface and tap the Login button.
Note: 1. For users, the technician will provide the user name and password to you .
2. For technicians, please use the administrator account to debug the controller. The default account name is “admin”, password is “123456”.
3. After you tap to save the password and select automatic login, the centralized controller will log in to the home interface
automatically. It will then skip the login interface after it is powered on each time.
4.1.2 Logout
Tap the icon marked "8" in the top left corner of the home page to exit the login interface.
4.1.3 Turning on the Screen
If the user does not touch the interface for a long time after login, the screen backlight will turn off automatically. The user
can press the on/off button "1" on the top of the centralized controller or tap any position on the screen to turn on the
screen.
4.1.4 Turning off the Screen
After login, press the on/off button marked "1" on the top of the centralized controller to turn off the screen backlight or
set the automatic off time for the backlight in general settings.

CCM-180A/WS
12 201803
CCM-180A/WS Service Manual
4.2 Control Page
This section describes the functions and operations of the Control page.
Figure 11 Homepage 1 of the Control Page
4.2.1 Select/Deselect All IDUs
Tap the "Select All" position marked "1" in Figure 11. If the tick is displayed in blue, all the IDUs are selected. Tap the
"Select All" position. The tick changes to gray, indicating that no IDU is selected.
4.2.2 Choosing IDU Group
Tap the position marked "2" in Figure 11 to open the drop-down menu, as shown below. Select the set IDU group for group
control. Group editing is detailed on the installation interface in section 3.5.
Figure 12
4.2.3 Sorting IDUs in Order
Tap the position marked "3" in Figure 11, as shown in the following figure. You can select whether to sort the IDUs by
name, operating mode or model.

1CCM-180A/WS
201803 13
CCM-180A/WS Service Manual
Figure 13
4.2.4 Setting the IDU Display
Tap the position marked "4" in Figure 11. The display mode can be switched to icon (as shown in Figure 11) or list (as
shown in the figure below). For the list display mode, only the status parameters of the IDU can be viewed. Table 3
provides the parameter abbreviations and corresponding description. IDUs can be selected for operations on in the icon
display mode.
Figure 14
Table 3 Displayed parameter description of Control page list
No.
Parameter
Description
1
IDU
Device name
2
Mode
Current operating mode
3
Temp.
Current set temperature
4
Fan Speed
Current fan speed
5
Swing
Swing switch

CCM-180A/WS
14 201803
CCM-180A/WS Service Manual
6
Lock
Locking switch
7
Lower
Lower limit of cooling temperature
8
Upper
Upper limit of heating temperature
IDU icon
Figure 15
Table 4 icon function description of Control page
Mark
Function
Description
1
Operation Mode and
Device Status Icon
The icon changes according to different operating modes
and IDU statuses (refer to Table 5).
2
Model icon
The icon will change according to the model (refer to
Table 6). The icon may be different from the actual
appearance.
3
Room Temperature
Display the indoor temperature.
4
Operation Mode
Display the operating mode of the IDU.
5
Set temperature
Display the set temperature
(Note: In auto mode, the autocooling temperature is displayed in the
cooling status, and the auto heating temperature is displayed in the
heating status)
6
IDU name
Display the device name

1CCM-180A/WS
201803 15
CCM-180A/WS Service Manual
Table 5 Operating mode, status and corresponding color
Color
Operation Mode
Blue
AUTO (automatic)
Red
HEAT (heating)
Green
FAN (air supply)
Light blue
COOL (cooling)
Purple
DRY (dehumidifying)
Gray
ERROR/OFFLINE/OFF
Table 6 Icons and corresponding models
Icon
Model
Icon
Model
Low static pressure and middle
static pressure (L-DUCT/M-DUCT)
Vertical concealed installation/vertical
surface mounting (FS)
High static pressure (H-DUCT)
Four-way Cassette
Purifier (FAPU)
Compact Four-way Cassette (COMPACT)
Wall mounting (WALL)
Ceiling-floor type (C&F)
Old IDU (1st Gen. IDU)
Two-way Cassette
One-way Cassette
CONSOLE
Group control device icon
New ODU (New generation ODU)
IDU function description and icon
Invalid
Valid
Fault
Off
On
Schedule
Off
On
Lock
Off
On
Swing
Off
On

CCM-180A/WS
16 201803
CCM-180A/WS Service Manual
4.2.5 Turning IDUs on/off
Tap the " " icon to power the system on/off in the area marked "1" in Figure 16.
Figure 16 Homepage 2 of the Control page
4.2.6 Setting the Temperature
Tap the " / " button of the icon marked "2" in Figure 16 to increase or reduce the set temperature of the IDU in the
range of 17°C to 30°C (62°F to 86°F).
Note: The centralized controller automatically identifies whether the connected system is in auto mode. If yes, two temperature points will be displayed. If
no, only one temperature point is available, as shown in the above figure.
4.2.7 Setting Mode
Directly tap the area marked "3" in Figure 16. Select one of the five modes.
Note: The centralized controller automatically identifies if the connected system is in auto mode. If yes, the auto mode button will be displayed. If no, the
auto mode button will not be available. Auto mode and dry mode are not available when only the purifier is selected.
4.2.8 More Setting Options
Select an IDU. Tap the "Settings" button marked "4" in Figure 16 to enter the interface below.
4.2.9 Setting Fan Speed
Tap the " / " icon marked "1" in Figure 17 to increase or reduce the fan speed. Auto fan speeds 1 to 7 or
high/middle/low speed is displayed according to the selected IDU.
Note: If the fan has an AC motor, 1 and 2 indicate "Low" fan speed, 3 and 4 indicate "Mid" fan speed, and 5, 6 and 7 indicate "High" fan speed.

1CCM-180A/WS
201803 17
CCM-180A/WS Service Manual
Figure 17 Settings 1 of the Control page
4.2.10 Setting Auto Swing
Tap the " / " icon marked "2" in Figure 17 to set the Vertical automatic swing switch.
4.2.11 Lock Control Panel
Tap the "Advanced" option marked "3" in Figure 17 to access the interface below. The locking panel function is detailed in
Table 7.
Figure 18

CCM-180A/WS
18 201803
CCM-180A/WS Service Manual
Table 7 Lock control panel function description
Item
Description
On-Off
[Lock-OFF] button: Disable turning on IDUs
[Lock-ON] button: Disable turning off IDUs
[Unlock] button: Disable the lock
Mode
[Lock] button: Disable changing mode
[Unlock] button: Disable the lock
Cooling Set Temp. Limit
[17°C~30°C / 62°F~86°F] button: Set the lowest temperature
limitation
[17°C~30°C / 62°F~86°F]:
[Unlock] button: Disable the lock
Heating Set Temp. Limit
[17°C~30°C / 62°F~86°F] button: Set the highest temperature
limitation
[17°C~30°C / 62°F~86°F]:
[Unlock] button: Disable the lock
Remote controller
[Lock] button: Disable remote control for all features
[Unlock] button: Disable the lock.

1CCM-180A/WS
201803 19
CCM-180A/WS Service Manual
4.3 Schedule Page Description
This section provides the descriptions and instructions for the Schedule page.
Figure 19 Homepage of Schedule page
Table 8 Schedule page icons and description
Mark
Function
Description
1
Date
Display the date. Use the [◀] and [▶] buttons to select a
date. Tap any date to add a schedule. Tap the position of
“today” to return to the current date quickly. AA black spot
in the upper left of a date means there is a set schedule for
that day.
2
Edit the schedule for the
current day
Display and edit the schedule list information for the
current day
3
Holiday settings
Add or edit the schedule list
4
Add Schedule Event
Create a new schedule plan
5
Schedule list
Display the schedule list and schedule information for the
current date
6
Enable/disable a
schedule
Enable or disable the selected schedule command
7
Schedule information
Display the schedule information
8
Delete the current
schedule
Delete the current schedule
9
Edit
Edit the selected schedule
10
Delete all the schedules
Delete all the schedule settings
