Part 1 - General Information
Part 1
General Information
1Indoor and Outdoor Unit Capacities ...................................................... 4
2External Appearance..............................................................................6
3Outdoor Unit Combinations................................................................... 8
4Nomenclature...................................................................................... 10
5Combination Ratio............................................................................... 11
6Selection Procedure............................................................................. 13

VC Pro VRF 50/60Hz
4
Midea VC Pro Series Engineering Data Book
1Indoor and Outdoor Unit Capacities
1.1 Indoor Units
1.1.1 Standard indoor units
Table 1-1.1: Standard indoor unit abbreviation codes
Abbreviation
code
Type
Abbreviation
code
Type
Q1
One-way Cassette
T1
High Static Pressure Duct
Q2
Two-way Cassette
G
Wall-mounted
Q4C
Compact Four-way Cassette
DL
Ceiling & Floor
Q4
Four-way Cassette
F
Floor Standing
T2
Medium Static Pressure Duct
Z
Console
Table 1-1.2: Standard indoor unit capacity range
Capacity
Capacity
index
Q1
Q2
Q4C
Q4
T2
T1
G
DL
F
Z
kW
HP
1.8
0.6
18
18
—
—
—
—
—
—
—
—
—
2.2
0.8
22
22
22
22
—
22
—
22
—
22
22
2.8
1
28
28
28
28
28
28
—
28
—
28
28
3.6
1.25
36
36
36
36
36
36
—
36
36
36
36
4.5
1.6
45
45
45
45
45
45
—
45
45
45
45
5.6
2
56
56
56
—
56
56
—
56
56
56
—
7.1
2.5
71
71
71
—
71
71
71
71
71
71
—
8.0
3
80
—
—
—
80
80
80
80
80
80
—
9.0
3.2
90
—
—
—
90
90
90
90
90
—
—
10.0
3.6
100
—
—
—
100
—
—
—
—
—
—
11.2
4
112
—
—
—
112
112
112
—
112
—
—
14.0
5
140
—
—
—
140
140
140
—
140
—
—
16.0
6
160
—
—
—
—
—
160
—
160
—
—
20.0
7
200
—
—
—
—
—
200
—
—
—
—
25.0
9
250
—
—
—
—
—
250
—
—
—
—
28.0
10
280
—
—
—
—
—
280
—
—
—
—
40.0
14
400
—
—
—
—
—
400
—
—
—
—
45.0
16
450
—
—
—
—
—
450
—
—
—
—
56.0
20
560
—
—
—
—
—
560
—
—
—
—
1.1.2 Fresh air processing unit
Table 1-1.3: Fresh air processing unit capacity range
Capacity
12.5kW
14kW
20kW
25kW
28kW
45kw
56kw
Capacity index
125
140
200
250
280
450
560
1.2 Heat recovery ventilator
Table 1-1.4: Heat recovery ventilator capacity range
Capacity
200m3/h
300m3/h
400m3/h
500m3/h
800m3/h
1000m3/h
1500m3/h
2000m3/h

VC Pro VRF 50/60Hz
5
Part 1 - General Information
1.3 Outdoor Units
Table 1-1.5: Outdoor unit capacity range
Capacity
Model Name
Combination Type
8HP
MVC-224WV2GN1
/
10HP
MVC-280WV2GN1
/
12HP
MVC-335WV2GN1
/
14HP
MVC-400WV2GN1
/
16HP
MVC-450WV2GN1
/
18HP
MVC-500WV2GN1
/
20HP
MVC-560WV2GN1
/
22HP
MVC-615WV2GN1
/
24HP
MVC-670WV2GN1
/
26HP
MVC-730WV2GN1
/
28HP
MVC-785WV2GN1
/
30HP
MVC-850WV2GN1
/
32HP
MVC-900WV2GN1
16HP+16HP
34HP
MVC-950WV2GN1
22HP+12HP
36HP
MVC-1010WV2GN1
20HP+16HP
38HP
MVC-1065WV2GN1
22HP+16HP
40HP
MVC-1120WV2GN1
24HP+16HP
42HP
MVC-1180WV2GN1
26HP+16HP
44HP
MVC-1235WV2GN1
28HP+16HP
46HP
MVC-1300WV2GN1
30HP+16HP
48HP
MVC-1345WV2GN1
26HP+22HP
50HP
MVC-1400WV2GN1
28HP+22HP
52HP
MVC-1465WV2GN1
30HP+22HP
54HP
MVC-1515WV2GN1
28HP+26HP
56HP
MVC-1570WV2GN1
28HP+28HP
58HP
MVC-1635WV2GN1
30HP+28HP
60HP
MVC-1700WV2GN1
30HP+30HP
62HP
MVC-1750WV2GN1
30HP+16HP+16HP
64HP
MVC-1795WV2GN1
26HP+22HP+16HP
66HP
MVC-1850WV2GN1
28HP+22HP+16HP
68HP
MVC-1915WV2GN1
30HP+22HP+16HP
70HP
MVC-1965WV2GN1
28HP+26HP+16HP
72HP
MVC-2020WV2GN1
28HP+28HP+16HP
74HP
MVC-2085WV2GN1
30HP+28HP+16HP
76HP
MVC-2150WV2GN1
30HP+30HP+16HP
78HP
MVC-2185WV2GN1
28HP+28HP+22HP
80HP
MVC-2250WV2GN1
30HP+28HP+22HP
82HP
MVC-2315WV2GN1
30HP+30HP+22HP
84HP
MVC-2355WV2GN1
28HP+28HP+28HP
86HP
MVC-2420WV2GN1
30HP+28HP+28HP
88HP
MVC-2485WV2GN1
30HP+30HP+28HP
90HP
MVC-2550WV2GN1
30HP+30HP+30HP
Notes:
1. The combinations of units shown in the table are factory-recommended. Other combinations of units are also possible.

VC Pro VRF 50/60Hz
6
Midea VC Pro Series Engineering Data Book
2External Appearance
2.1 Indoor Units
2.1.1 Standard indoor unit
Table 1-2.1: Standard indoor unit appearance
One-way Cassette
Two-way Cassette
Q1
Q2
Compact Four-way Cassette
Four-way Cassette
Q4C
Q4
Medium Static Pressure Duct
High Static Pressure Duct
T2
T1
Wall-mounted
Ceiling & Floor
G
DL
Floor Standing
Console
F
Z
2.1.2 Fresh air processing unit
Table 1-2.2: Fresh air processing unit appearance
Fresh Air Processing Unit
FA
2.2 Heat Recovery Ventilator
Table 1-2.3: Heat recovery ventilator appearance
Heat Recovery Ventilator

VC Pro VRF 50/60Hz
7
Part 1 - General Information
2.3 Outdoor Units
2.3.1 Single units
Table 1-2.4: Single outdoor unit appearance
8/10/12/14/16HP
(with single fan)
18/20/22HP
(with dual fans)
24/26/28/30
(with dual fans)
2.3.2 Combinations of units
Table 1-2.5: Combination outdoor unit appearance
32HP
34/36/38/HP
40/42/44/46HP
48/50/52HP
54/56/58/60HP
62HP
64/66/68HP
70/72/74/76HP
Table continued on next page…

VC Pro VRF 50/60Hz
8
Midea VC Pro Series Engineering Data Book
Table 1-2.5: Combination outdoor unit appearance
78/80/82HP
84/86/88/90HP
3Outdoor Unit Combinations
Table 1-3.1: Outdoor unit combinations
System capacity
Number
of units
Modules1
Outdoor branch
joint kit2
kW
HP
8
10
12
14
16
18
20
22
24
26
28
30
22.4
8
1
●
—
28.0
10
1
●
33.5
12
1
●
40.0
14
1
●
45.0
16
1
●
50.0
18
1
●
56.0
20
1
●
61.5
22
1
●
67.0
24
1
●
73.0
26
1
●
78.5
28
1
●
85.0
30
1
●
90.0
32
2
●●
FQZHW-02N1E
95.0
34
2
●
●
101.0
36
2
●
●
106.5
38
2
●
●
112.0
40
2
●
●
118.0
42
2
●
●
123.5
44
2
●
●
130.0
46
2
●
●
134.5
48
2
●
●
140.0
50
2
●
●
146.5
52
2
●
●
151.5
54
2
●
●
157.0
56
2
●●
163.5
58
2
●
●
170.0
60
2
●●
175.0
62
3
●●
●
FQZHW-03N1E
179.5
64
3
●
●
●
185.0
66
3
●
●
●
191.5
68
3
●
●
●
196.5
70
3
●
●
●
202.0
72
3
●
●●
208.5
74
3
●
●
●
215.0
76
3
●
●●
218.5
78
3
●
●●
225.0
80
3
●
●
●
231.5
82
3
●
●●
235.5
84
3
●●●
Table continued on next page…

VC Pro VRF 50/60Hz
9
Part 1 - General Information
Table 1-3.1: Outdoor unit combinations
System capacity
Number
of units
Modules1
Outdoor branch
joint kit2
242.0
86
3
●●
●
FQZHW-03N1E
248.5
88
3
●
●●
255.0
90
3
●●●
Notes:
1. The combinations of units shown in the table are factory-recommended. Other combinations of units are also possible.
2. For systems with two or more outdoor units, outdoor branch joints (sold separately) are required.

VC Pro VRF 50/60Hz
10
Midea VC Pro Series Engineering Data Book
4Nomenclature
4.1 Indoor Units
4.1.1 Standard indoor units
M
I
2
-
22
Q1
D
H
N1
○
1
○
2
○
3
○
4
○
5
○
6
○
7
○
8
Legend
No.
Code
Remarks
1
M
Midea
2
I
VRF indoor unit
3
2
The 2nd generation VRF DC indoor unit
4
22
Capacity index (the capacity in kW multiplied by 10)
5
Q1
Indoor unit type
Q1: One-way Cassette
Q2: Two-way Cassette
Q4C: Compact Four-way Cassette
Q4: Four-way Cassette
T2: Medium Static Pressure Duct
T1: High Static Pressure Duct
G: Wall-mounted
DL: Ceiling & Floor
F: Floor Standing
Z: Console
6
D
Series category (D: DC series)
7
H
Power supply
Omit: 1 phase, 220-240V, 50Hz
H: 1 phase, 220-240V, 50/60Hz
8
N1
Refrigerant type (N1: R410A)
4.1.2 Fresh air processing unit
M
I
2
-
280
FA
D
H
N1
○
1
○
2
○
3
○
4
○
5
○
6
○
7
○
8
Legend
No.
Code
Remarks
1
M
Midea
2
I
VRF indoor unit
3
2
The 2nd generation VRF DC indoor unit
4
280
Capacity index (the capacity in kW multiplied by 10)
5
FA
Indoor unit type
FA: Fresh Air Processing Unit
6
D
Series category (D: DC series)
7
H
Power supply
Omit: 1 phase, 220-240V, 50Hz
H: 1 phase, 220-240V, 50/60Hz
8
N1
Refrigerant type (N1: R410A)

VC Pro VRF 50/60Hz
11
Part 1 - General Information
4.2 Heat recovery ventilator
AC Series
HRV
-
200
○
1
○
2
Legend
No.
Code
Remarks
1
HRV
Heat recovery ventilator
2
200
Airflow in m3/h
DC Series
HRV
-
D
200
○
1
○
2
○
3
Legend
No.
Code
Remarks
1
HRV
Heat recovery ventilator
2
D
Series category (D: DC series)
3
200
Airflow in m3/h
4.3 Outdoor Units
M
VC
-
224
W
V2
G
N1
○
1
○
2
○
3
○
4
○
5
○
6
○
7
Legend
No.
Code
Remarks
1
M
Midea
2
VC
VC Pro series outdoor units
3
224
Capacity index (the capacity in kW multiplied by 10)
4
W
Unit category (W: VRF outdoor unit)
5
V2
Type (V2: All DC inverter)
6
G
Power supply (G: 3 phase, 380-415V, 50/60Hz)
7
N1
Refrigerant type (N1: R410A)
5Combination Ratio
Table 1-5.1: Indoor and outdoor unit combination ratio limitations
Type
Minimum
combination ratio
Maximum combination ratio
Standard indoor
units only
Fresh air processing
units only
Fresh air processing units and
standard indoor units together
VC Pro series outdoor units
50%
130%1
100%
100%2
Notes:
1. The total capacity of the indoor units can be up to a maximum of 130% of the combined capacity of the outdoor unit for a system where not all the indoor
units are operating at the same time.
2. When fresh air processing units are installed together with standard indoor units, the total capacity of the fresh air processing units must not exceed 30%
of the total capacity of the outdoor units and the combination ratio must not exceed 100%.
Combination ratio =
Sum of capacity indexes of the indoor units
Capacity index of the outdoor units

VC Pro VRF 50/60Hz
12
Midea VC Pro Series Engineering Data Book
Table 1-5.2: Combinations of Indoor and outdoor units
Outdoor unit capacity
Sum of capacity indexes of connected
indoor units (standard indoor units
only)
Sum of capacity indexes of
connected indoor units
(fresh air processing units
and standard indoor units
together)
Maximum number of connected
indoor units
kW
HP
Capacity
index
22.4
8
224
112 to 291.2
112 to 224
13
28
10
280
140 to 364
140 to 280
16
33.5
12
335
167.5 to 435.5
167.5 to 335
20
40
14
400
200 to 520
200 to 400
23
45
16
450
225 to 585
225 to 450
26
50
18
500
250 to 650
250 to 500
29
56
20
560
280 to 728
280 to 560
33
61.5
22
615
307.5 to 799.5
307.5 to 615
36
67
24
670
335 to 871
335 to 670
39
73
26
730
365 to 949
365 to 730
43
78.5
28
785
392.5 to 1020.5
392.5 to 785
46
85
30
850
425 to 1105
425 to 850
50
90
32
900
450 to 1170
450 to 900
53
95
34
950
475 to 1235
475 to 950
56
101
36
1010
505 to 1313
505 to 1010
59
106.5
38
1065
532.5 to 1384.5
532.5 to 1065
63
112
40
1120
560 to 1456
560 to 1120
64
118
42
1180
590 to 1534
590 to 1180
123.5
44
1235
617.5 to 1605.5
617.5 to 1235
130
46
1300
650 to 1690
650 to 1300
134.5
48
1345
672.5 to 1748.5
672.5 to 1345
140
50
1400
700 to 1820
700 to 1400
146.5
52
1465
732.5 to 1904.5
732.5 to 1465
151.5
54
1515
757.5 to 1969.5
757.5 to 1515
157
56
1570
785 to 2041
785 to 1570
163.5
58
1635
817.5 to 2125.5
817.5 to 1635
170
60
1700
850 to 2210
850 to 1700
175
62
1750
875 to 2275
875 to 1750
179.5
64
1795
897.5 to 2333.5
897.5 to 1795
185
66
1850
925 to 2405
925 to 1850
191.5
68
1915
957.5 to 2489.5
957.5 to 1915
196.5
70
1965
982.5 to 2554.5
982.5 to 1965
202
72
2020
1010 to 2626
1010 to 2020
208.5
74
2085
1042.5 to 2710.5
1042.5 to 2085
215
76
2150
1075 to 2795
1075 to 2150
218.5
78
2185
1092.5 to 2840.5
1092.5 to 2185
225
80
2250
1125 to 2925
1125 to 2250
231.5
82
2315
1157.5 to 3009.5
1157.5 to 2315
235.5
84
2355
1177.5 to 3061.5
1177.5 to 2355
242
86
2420
1210 to 3146
1210 to 2420
248.5
88
2485
1242.5 to 3230.5
1242.5 to 2485
255
90
2550
1275 to 3315
1275 to 2550

VC Pro VRF 50/60Hz
13
Part 1 - General Information
6Selection Procedure
6.1 Procedure
Step 1: Establish design conditions
Step 2: Select indoor units
Step 3: Select outdoor units
Notes:
1. If the indoor design temperature falls between two temperatures listed in the indoor unit's capacity table, calculate the corrected capacity by interpolation.
If the indoor unit selection is to be based on total heat load and sensible heat load, select indoor units which satisfy not only the total heat load
requirements of each room but also the sensible heat load requirements of each room. As with total heat capacity, the sensible heat capacity of indoor
units should be corrected for indoor temperature, interpolating where necessary. For the indoor unit capacity tables, refer to the indoor unit technical
manuals.
Yes
Design temperature and humidity (indoor and outdoor)
Required heat load of each room
System peak load
Piping length, level differences
Indoor unit specifications (type and quantity)
Decide indoor unit safety factor
Select indoor unit models ensuring that:
Indoor unit capacity corrected for indoor air temperature WB1≥Required heat load × Indoor unit safety factor
Determine required total heat load on outdoor units
Use the sum of the peak load of each room
Use the system peak load
Provisionally select outdoor unit capacity based on combination ratio
limitations
Confirm that the number of indoor units connected to the outdoor units is within limitation
Correct cooling capacities of the outdoor units for the following items:
Outdoor air temperature / Indoor air temperature WB / Combination ratio / Piping length, level
difference / Piping heat loss
Is corrected outdoor unit capacity ≥Required total heat load on outdoor units?
VRF system selection is complete
No

VC Pro VRF 50/60Hz
14
Midea VC Pro Series Engineering Data Book
6.2 Example
The following is a selection example based on total heat load for cooling.
Figure 1-6.1: Room plan
Room A
Room H
Room G
Room F
Room B
Room E
Room C
Room D
Step 1: Establish design conditions
Indoor air temperature 25°C DB, 18°C WB; outdoor air temperature 33°C DB.
Determine peak load of each room and system peak load. As shown in Table 1-6.1, the system peak load is 50.7kW.
Table 1-6.1: Required heat load of each room (kW)
Time
Room A
Room B
Room C
Room D
Room E
Room F
Room G
Room H
Total
9:00
4.8
4.8
3.0
3.0
9.1
9.0
2.9
2.9
39.5
12:00
6.6
7.1
5.1
5.1
7.4
6.8
4.0
4.0
46.1
14:00
9.0
9.4
4.9
4.9
7.3
6.8
4.2
4.2
50.7
16:00
10.6
10.7
3.9
3.9
6.3
6.2
3.8
3.8
49.2
The maximum piping lengths and level differences in this example are as given in Figure 1-6.2.
Figure 1-6.2: System diagram
Indoor unit type for all rooms: Medium Static Pressure Duct (T2).
Step 2: Select indoor units
In this example, a safety factor is not used (i.e. the safety factor is 1).
Select indoor unit models using the medium static pressure duct cooling capacity table. Each indoor unit's corrected
capacity needs to be greater than or equal to the peak load of the relevant room. The selected indoor units are shown
in Table 1-6.3.
Equivalent length of piping 60m
Level
difference
40m
Outdoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit
Indoor
Unit

VC Pro VRF 50/60Hz
15
Part 1 - General Information
Table 1-6.2: Extract from medium static pressure duct (T2) cooling capacity table
Model
Capacity
index
Indoor air temperature
14°C WB
16°C WB
18°C WB
19°C WB
20°C WB
22°C WB
24°C WB
20°C DB
23°C DB
26°C DB
27°C DB
28°C DB
30°C DB
32°C DB
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
TC
SHC
T2
22
1.5
1.4
1.8
1.5
2.1
1.6
2.2
1.6
2.3
1.7
2.4
1.5
2.4
1.5
28
1.9
1.7
2.3
1.9
2.6
2.1
2.8
2.1
3.0
2.1
3.1
2.0
3.1
1.9
36
2.5
2.1
2.9
2.3
3.4
2.5
3.6
2.6
3.8
2.7
4.2
2.8
3.9
2.3
45
3.1
2.6
3.7
2.8
4.2
3.1
4.5
3.2
4.8
3.2
4.9
3.1
5.1
2.9
56
3.9
3.0
4.6
3.3
5.3
3.6
5.6
3.7
5.9
3.8
6.2
3.7
6.2
3.4
71
4.9
3.9
5.8
4.3
6.7
4.7
7.1
4.9
7.5
4.8
7.8
4.6
7.8
4.3
80
5.5
4.4
6.6
4.9
7.5
5.3
8.0
5.5
8.4
5.5
8.8
5.2
8.8
4.8
90
6.2
5.3
7.3
5.8
8.4
6.3
9.0
6.4
9.6
6.5
9.9
6.1
9.9
5.7
112
7.7
6.4
9.1
7.1
10.5
7.7
11.2
7.8
11.9
8.1
12.5
7.8
12.5
7.4
140
9.7
7.8
11.3
8.6
13.2
9.6
14.0
9.8
14.8
9.8
15.7
9.7
15.4
8.8
Abbreviations:
TC: Total capacity (kW); SHC: Sensible heat capacity (kW)
Table 1-6.3: Selected indoor units
Room A
Room B
Room C
Room D
Peak heat load (kW)
10.6
10.7
5.1
5.1
Selected indoor unit
MI2-140T2DHN1
MI2-140T2DHN1
MI2-56T2DHN1
MI2-56T2DHN1
Corrected TC (kW)
13.2
13.2
5.3
5.3
Room E
Room F
Room G
Room H
Peak heat load (kW)
9.1
9.0
4.2
4.2
Selected indoor unit
MI2-112T2DHN1
MI2-112T2DHN1
MI2-45T2DHN1
MI2-45T2DHN1
Corrected TC (kW)
10.5
10.5
4.2
4.2
Step 3: Select outdoor units
Determine the required total heat load from the indoor units to the outdoor units based on either the sum of the
peak loads of each room or the system peak load. In this example, it is determined based on the system peak load.
Therefore, the required heat load is 50.7kW.
Provisionally select outdoor units using the sum of the capacity indexes (CIs) of the selected indoor units (as shown in
Table 1-6.4), ensuring that the combination ratio is between 50% and 130%. Refer to Table 1-6.5. As the sum of CIs of
the indoor units is 706, outdoor units from 20HP to 50HP are potentially suitable. Start from the smallest, which is the
20HP unit.
Table 1-6.4: Sum of indoor unit capacity indexes
Model
Capacity Index
No. of units
MI2-140T2DHN1
140
2
MI2-112T2DHN1
112
2
MI2-56T2DHN1
56
2
MI2-45T2DHN1
45
2
Sum of CIs
706

VC Pro VRF 50/60Hz
16
Midea VC Pro Series Engineering Data Book
Table 1-6.5: Extract from Table 1-5.2 Combinations of Indoor and outdoor units
Outdoor unit capacity
Sum of capacity indexes of
connected indoor units (standard
indoor units only)
Maximum number of
connected indoor
units
kW
HP
Capacity
index
50.0
18
500
250 to 650
29
56.0
20
560
280 to 728
33
61.5
22
615
307.5 to 799.5
36
67.0
24
670
335 to 871
39
73.0
26
730
365 to 949
43
78.5
28
785
392.5 to 1020.5
46
85.0
30
850
425 to 1105
50
90.0
32
900
450 to 1170
53
95.0
34
950
475 to 1235
56
101.0
36
1010
505 to 1313
59
106.5
38
1065
532.5 to 1384.5
63
112.0
40
1120
560 to 1456
64
118.0
42
1180
590 to 1534
123.5
44
1235
617.5 to 1605.5
130.0
46
1300
650 to 1690
134.5
48
1345
672.5 to 1748.5
140.0
50
1400
700 to 1820
146.5
52
1465
732.5 to 1904.5
The number of connected indoor units is 8 and the maximum number of connected indoor units on the 20HP outdoor
unit is 33, so the number of connected indoor units is within the limitation.
Calculate the corrected capacity of the outdoor units:
a) The sum of the indoor unit CIs is 706 and the CI of the 20HP outdoor unit (MVC-560WV2GN1) is 560, so the
combination ratio is 706 / 560 = 126%.
b) Using the outdoor units’cooling capacity table, interpolate to obtain the capacity (“B”) corrected for outdoor air
temperature, indoor air temperature, and combination ratio. Refer to Tables 1-6.6 and 1-6.7.
Table 1-6.6: Extract from Table 2-8.7 MVC-560WV2GN1
cooling capacity
Table 1-6.7: Cooling capacity calculated by
interpolation
CR
Outdoor
air
temp.
(°C DB)
Indoor air temp.
(°C DB / °C WB)
CR
Outdoor
air
temp.
(°C DB)
Indoor air temp.
(°C DB / °C WB)
25.8 / 18.0
25.8 / 18.0
TC
PI
TC
PI
kW
kW
kW
kW
130%
31
61.3
15.94
130%
33
60.37
16.55
33
60.37
16.55
35
59.47
17.19
B = 59.951
120%
31
60.2
15.44
120%
33
59.32
16.06
33
59.32
16.06
35
58.37
16.68
Notes:
1. 59.32 + (60.37 –59.32) × (126 –120) / (130 –120) =
59.95

VC Pro VRF 50/60Hz
17
Part 1 - General Information
c) Find the correction factor for piping length and level difference (“K1”)
Figure 1-6.3: VC rate of change in cooling capacity
Notes:
1. The horizontal axis shows equivalent length of piping between farthest indoor unit and
first outdoor branch joint; the vertical axis shows the largest level difference between
indoor unit and outdoor unit. For level differences, positive values indicate that the
outdoor unit is above the indoor unit, negative values indicate that the outdoor unit is
below the indoor unit.
d) Calculate the corrected capacity of MVC-560WV2GN1 (“C”) by using K1:
C = B × K1 = 59.95 × 0.898 = 53.8kW
The corrected capacity 53.8kW is larger than required total heat load 50.7kW, so selection is complete. (In the event
that the corrected capacity is lower than the required total heat load, Step 3 should be repeated from the point
where the outdoor unit capacity is provisionally selected.)
90
-90
-100
-110
80
-80
70
-70
60
-60
50
-50
40
-40
30
-30
20
-20
10
10
1.0
0.97
0.95
0.92
0.90
0.87
0.85
0.84
0.81 0.80 0.78 0.78 0.77 0.76
1.0
0.97
0.95
0.92
0.90
0.87
0.85
0.84
0.81 0.80 0.78 0.78 0.77
20 30 40 50 60 70 80
K1 = 0.898
90 100 110 120 130 140 150 160 170 180 190 200
-10
0
0

VC Pro VRF 50/60Hz
18
Midea VC Pro Series Engineering Data Book

VC Pro VRF 50/60Hz
19
Part 2 - Outdoor Unit Engineering Data
Part 2
Outdoor Unit
Engineering Data
1Specifications ...................................................................................... 20
2Dimensions.......................................................................................... 30
3Installation Space Requirements.......................................................... 40
4Piping Diagrams................................................................................... 41
5Wiring Diagrams .................................................................................. 45
6Electrical Characteristics ...................................................................... 47
7Functional Components and Safety Devices......................................... 50
8Capacity Tables .................................................................................... 51
9Operating Limits ................................................................................ 134
10 Sound Levels...................................................................................... 135
11 Accessories........................................................................................ 138
