Midea C16-SKY1613 User manual

Instruction manual for induction cooker
Thank you for purchasing this induction cooker. Please thoroughly read through this
instruction manual before use and store it carefully for future use.The pictures are only
for reference, please keep the real product as a standard.

Safety instructions .......................................................
Product summary ........................................................
Part list .................................................................
Preparation ..............................................................
Instructions for use .......................................................
Proper pots ..............................................................
Cleaning and maintenance ................................................
Self-diagnosis for abnormalities ............................................
1
6
6
6
7
9
10
10
Specifications
120W -1600W 355x269x65 1.95C16-SKY1613 1600W
220-240V 50/60
Model Rated
power
Power adjustment
range
Appearance
dimension
(mm)
Weight
(kg)

Never heat food in sealed containers
such as compressed products like cans
or coffee pots, to avoid explosion caused
by heat expansion.
To avoid affecting product performance and
to prevent injury, do not heat empty pots.
When in use, do not leave the appliance
without supervision for a long time. When
leaving the appliance without supervision,
make sure there is enough water in the pot.
Do not heat iron items on the induction
cooker heating plate. It can get heated due
to high temperature.
Do not rinse this induction cooker under
water. Avoid spilling water and soup into
the internal parts of the induction cooker.
Do not place the induction cooker when
in use, on a gas stove (the magnetic
lines can heat the metal parts of the
gas stove)
Safety instructions
1

Keep electrical appliance out of reach from
children or inform person. Do not let them
use the appliances without supervision.
To avoid danger, do not insert any foreign
objects, such as iron wire, nor block the air
ventilation opening or entry port.
Do not place paper, aluminium foil, cloth or
other unsuitable articles onto the induction
cooker heating plate.
Do not put it on any metal platforms (such
as iron, stainless steel, aluminium), or
place a non-metal pad less than 10 cm
thick on the heating plate while the cooker
is in use.
Unplug the power cord from the outlet after
use to avoid fire and/or damaging the
electronic components caused by prolonged
electrical connection.
Safety instructions
2

People with heart pacemakers should consult
a doctor. Only use the appliance after
confirming that it does not affect the
pacemaker.
Avoid causing impacts on the heating plate.
It may damage the plate. If cracking is found
on the cooker plate, turn off the appliance to
avoid any electrical shock that might occur.
When using the induction cooker, place it
horizontally and allow atleast 10 cm of
free space between the sides and back of
the induction cooker and the wall. Do not
use the induction cooker in narrow spaces.
Please keep the ventilation opening free,
for release of heat.
Do not use the appliance if the plug or the
main cord or the appliance is damaged. If
the power cord is damaged, have it
replaced by agent of the manufacturer, its
service department or specialized person
from a similar department.
Please use a dedicated and high quality
power outlet, with high power rating (13A).
Do not use poor quality outlets. It is advisable
not to share the power outlet with electrical
appliances with high power ratings, such
as an air conditioners, electrical stoves etc.
to avoid fires caused by overburdening
the outlet.
Safety instructions
3
13A

Do not place the induction cooker onto a
carpet, tablecloth or thin paper while on
use to avoid blocking the air inlet opening
or air outlet opening, which will affect the
heat emission.
Metal objects, such as knives,forks,spoons
and lids should not be put on the surface
of the cooking area, as they will be heated.
When using the induction cooker or after
use, please keep it clean. Protect the
induction cooker from bugs, dust and
humidity. Avoid letting cockroaches etc
fall into the internal parts of the induction
cooker and causing a short circuit of the
electrical board. When not in use for a
long period, please clean it and put into a
plastic bag to store it.
Do not place the induction cooker near a
gas stove, kerosene stove, gas cooker or
in any space with an open fire or in an
environment with high temperature.
Safety instructions
4

Always clean the induction cooker to
prevent mess from getting into the fan,
which could influence the normal
operation of the appliance.
The cooker cannot be overloaded.
Overloading the plate may damage
the plastic cover and cooker plate.
This appliance is intended to be used in
household and similar applications such
as: -staff kitchen areas in shops, offices
and other working environments; -farm
houses;-by clients in hotels, motels and
other residential type environments ;
-bed and breakfast type environments.
The instructions shall state that
appliance are not intended to be
operated by means of an external timer
or separate remote-control system.
When operating the appliance or after
moving the pot, the cooking area will
remain hot for a period of time. Do not
touch it, be careful of scalding caused
by the high temperature.
Always make sure the plug is inserted
firmly into the socket.
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children without supervision.
Safety instructions
5
The utensils provided for the induction
cooker can only be used for cooking with
it. These cooking utensils cannot be used
on both induction cooker and gas stove.

This induction cooker is designed for household use. Please refer to
the instructions for detailed cooking methods.
Air ou tl et Po we r co rd
Ai r in ta ke
Control panel
Co oker p la te
Co oking zone
Pa rt list
Product summa ry
Prepa ra tion
Before using, please first check if the power plug connects well with the
power outlet.
Before placing the pot on the cooker plate, please clean up water stains,
oil spots or any other adherent dirt from the outside surface of the pot and
cooker plate.
Please put the pot to be heated on the central part of the induction
cooker. Do not put an empty pot on the cooker plate to be heated.
6

Instructions for use
Function selection
Connecting the power and switching on
Power adjustment
After pressing the “ON/OFF” key, the induction cooker
enters into manual cooking mode.
After pressing the “ON/OFF” key, if no proper vessel is placed on the
cooker plate, the induction cooker will not heat up and the alarm will
sound to indicate that a vessel is required. After one minute later it will
switch off automatically.
After switching on the appliance, press the corresponding cooking
buttons to enter the desired cooking mode.
Please refer to “Functional cooking mode instructions” for the details
of the corresponding heating process for each cooking mode.
After selecting a mode, you can press “+” or “-” to adjust
the power.
For some modes, during the heating procedure, the
induction cooker can automatically adjust the power
according to the cooking requirement.
For certain modes, the power is restricted complying
with the cooking requirement.
Timer adjustment
If timer function is not activated, the induction cooker
will heat the ingredients for the default time duration.
If timer is needed, first press the “Timer” key. When
the numbers blink on the display, press the key “+” or
“-” to adjust the time duration.
When the adjustment is finished, the number on the display
will be shown after blinking for several seconds. The induction
cooker starts counting down.
When the counting down is over, the induction cooker automatically
stops heating and switches off.
Special notice: Please read the corresponding instruction
manual for each specific induction cooker purchased.
7
Timer

8
Instructions for use
Switch off
When the operating time is over, the induction cooker
switches off automatically.
If switch off is needed in advance, press the “ ON/OFF ” key
to turn the appliance off.
The cooking modes of Fry and Deep fry fit to high temperature cooking.
In the heating procedure, the time and power can be adjusted at any time.
When the temperature of the ingredients reaches the temperature level
provided by the selected mode (the highest temperature of various modes
are different), the induction cooker will switch to interval heating or stops
heating. After the temperature cools down, the induction cooker restarts
heating.
For the cooking modes of Porridge, Soup and Braise, the induction cooker
can automatically control the power according to the time duration that has
been set and the temperature of the ingredients. Under these modes, the
power can be adjusted within the adjustable power range at any time. After
this manual adjustment, the induction cooker will return to auto power control
according to the cooking purpose two minutes later. Among these modes,
when Porridge, or Soup mode is selected, the induction cooker will start the
auto two-hour keeping warm function after the operation is finished.
Fry Deep fry
Hot pot
Braise
Soup
Porridge
Functional cooking mode instructions
The cooking modes of “Hot pot” individually fit to heating requirements, such
as hotpot and boiling water. In the heating procedure, the time and power can
be adjusted at any time. If the water in the pot dries up or the temperature is
abnormally high, the induction cooker automatically switches off or starts
protection function.
Users can select among the different cooking modes according to cooking
purpose. For your convenience, we provide the following instructions:

a
c
ef
b
d
Please use the attached pots sold by Midea. Do not use other pots as
replacements to avoid influencing the performance.
The maximum load for the frying pan is 4kg. When using it, do not let
the weight of the ingredients exceed this weight to avoid danger.
If other pots are used, please comply with the following conditions:
1. Requirements for pot material: containing iron material.
2. Requirement of pot shape: with even bottom, the diameter is not
less than 12cm while not more than 18cm.
Ir on sto ck p o t Ir on mil k p ot
Ir on wok Ir on water kettle
Ir on fryin g pa n Ir on ste amer p an
Note: For optimum performance, please use the standard pots
provided.
In particular, do not use pressure containers to avoid danger.
Proper pots
9
Instructions for use
Please refer below table for wattage and corresponding temperatures
Wattage (W) 120
60
300
100
500
130
700
160
900
180
1100
200
1300
220
1600
240
Temperature (C
)
*Above shown temperature is only for reference and actual temperature may differ.

Be fo re cle an in g, pl ea se swi tch off the a pp li an ce fir st a nd the n
di scon ne ct th e p o wer pl ug fro m the p o wer ou tl e t. Wai t til l th e co oker
pl ate of the i nd ucti on coo ke r is no t h ot an d star t cle an in g.
Afte r usin g the i nd ucti on coo ke r fo r a l o n g time, th e op en in g of ai r
in le t/ai r ou tl et wi l l pi le u p wi th d ust o r othe r d i r t, pl ea se wi p e i t with a
so ft d r y clo th. Dust i n the a ir i nl et an d ou tl e t can b e cle an e d b y u sing
a so ft b r u sh or a min i va cu u m cle a ne r.
Note: Please do not rinse it with water
Fo r oi l sp ots o n th e co o ker p la te , wip e th e cooker p la te b y u si ng a
so ft moist clo th with a l i ttl e tooth pa ste or mil d de te rg en t. An d th e n
use a so ft mo i st clo th to wi p e i t u n til n o stai n re ma i n s.
Wh en n ot usin g it fo r a l o ng time, pl ea se d isco nn ect the p o wer pl ug
fr om th e p o wer ou tl e t a n d p r o tect the i nd u cti on coo ke r fro m an y du st
or b ug s.
Abnormalities Key checkingpoints andtrouble shooting
After plugging in the power cord
and pressing the “ON/OFF” key,
the indicator and display do not
light up.
The “ON/OFF” indicator lights up
and the display works normally, but
heating does not start.
Heating suddenly stops during the
process.
Is the power plug properly connected?
Is the switch, power outlet, fuse or power cord
damaged?
Is the pot material proper?
Is the appliance in a “Preset” working status?
For other causes, please take the appliance to a
repairing and maintenance site to be fixed.
Is the temperature of the oil toohigh whenfrying dishes?
Is the temperature of the surroundings very
high?
Is the air inlet or air outlet of the induction
cooker blocked?
Is the default heating time of the induction
cookerover?
The self-safety protection of the induction
cooker starts, wait for several minutes and
connect powerto useit.
Cleaning and maintenance
Self-diagnosis for abnormalities
10

The description above is for diagnosing and checking common issues. If the problems cannot be
solved, please send the product to a repair and maintenance site or inquiry by calling service number.
Do not disassemble or repair the product by yourself to avoid product damage or personal injury.
The protection codes appear
Protection for over-high
temperature of the
induction cooker
Protection for over-high
temperature of the
cooker plate
The temperature inside the induction cooker is too high. When
the temperature lowers, press the “ON/OFF ” key, the heating
can start normally.
The temperature of the cooker plate is too high. When the
temperature lowers, press the “ON/OFF ” key, the heating
can start normally.
Protection for the inner
sensor of the induction
cooker
When using the induction cooker, if the temperature of the
surroundings is too low, the auto protection function will start.
With switching on the appliance again or switching after simple
warm-up, the appliance can return to normal working status
automatically.
Call the service number or the professional repair and
maintenance site to make an inquiry.
11
Self-diagnosis for abnormalities

If there is technical amendment for the
product, it will be edited into the updated
version of the instruction manual. Please
be aware that we will not inform customers
of this separately. If the appearance or
color of the product is modified, please
refer to the real appliance as a standard.

电磁炉说明书
感谢您购买该电磁炉，在使用前请先详细阅读此说明书，阅后请小心收藏,以备日后查阅。
图片仅供参考，产品以实物为准。

安全注意事项 ............................................................
产品简介 ................................................................
零部件说明 ..............................................................
准备工作 ................................................................
使用说明 ................................................................
适用锅具 ................................................................
清洁保养 ................................................................
异常现象自检 ............................................................
1
6
6
6
7
9
10
10
规格
120W -1600W 355x269x65 1.95C16-SKY1613 1600W
220-240V 50/60
型号 额定功率 功率调节范围 外形尺寸
(mm)
重量
(kg)
目录
额定频率额定电压

密封容器或密封食品不能放在电磁炉上加热，
如高压类、罐头类、咖啡壶等, 避免受热膨胀
而产生爆炸危险。
切勿空锅干烧，以免影响产品使用性能，甚至
发生危险。使用中，请勿长时间离开，若需离
开，请确保锅具内的水量。
请勿将铁片放在灶面板上加热，避免因高温而
产生危险。
请勿用水直接冲洗电磁炉，注意勿将水、汤溅
入电磁炉内部，以免发生危险。
请勿将电磁炉放置在燃气灶上使用（磁力线会
将燃气灶的铁质金属件加热），以免发生意外。
安全注意事项
标记的含义: 禁止 强制 警告 注意
1

安全注意事项
标记的含义: 禁止 强制 警告 注意
器具应放置在儿童、语言有障碍的人不能随便
拿得到的地方，以免他们不当使用器具。
不能插入铁丝等异物或堵塞排气口及吸气口，
以免发生危险。
请勿以纸张、铝箔纸、布等无关物品垫在灶面
板上间接加热。
请勿将电磁炉放在任何金属（铁质、不锈钢、
铝质等）平台上使用，包括在其上垫厚度小
于10cm的非金属垫。
使用完后将电源线插头拔离插座，避免长时间
通电引起电子元器件损坏，甚至起火。
2

使用心脏起搏器者，请与专业医生研究确认无
影响后方可使用本产品。
请避免用力冲击板，以免板损坏。如果灶面有
裂纹，关掉器具以避免可能出现的电击。
使用时，电磁炉应水平放置，侧面、背面与墙
要有10cm以上的距离。请勿将电磁炉放在狭
窄的空间内使用，不要被异物挡住吸排风口而
影响散热。
如果电源线损坏，为了避免危险，必须由制
造商、其维修部或类似部门的专业人员更换。
请单独使用13A的大功率优质插座，不要使
用劣质插座。不要与空调、电炉等大功率电器
共用一个插座。以免出现电流过大引起火灾。
3
安全注意事项
标记的含义: 禁止 强制 警告 注意
13A

避免将电磁炉放置在地毯、台布、薄纸上使
用，以免堵塞吸气或排气口，影响炉腔散热。
金属物体如刀、叉、勺和盖不应放在烹饪区
域表面，因为它们可能变热。
电磁炉使用过程中和使用完成后，请注意保
持清洁，做好炉体的防虫、防尘、防潮保护，
避免蟑螂等进入电磁炉内部造成电路板短路；
长期不使用时，建议清洁后套上塑料袋收存。
请勿将电磁炉摆放在靠近瓦斯炉、煤油炉、
燃气灶等有明火或高温环境中使用。
4
安全注意事项
标记的含义: 禁止 强制 警告 注意
