Midea C21-RT2120 User manual

Instruction manual for induction cooker
Thank you for purchasing this induction cooker. Please thoroughly read through this
instruction manual before use and store it carefully for future use.The pictures are only
for reference, please keep the real product as a standard.
Model: C21-RT2120

2

3

4

5

6
This induction cooker is designed for household use. Please refer to
the instructions for detailed cooking methods.
Air outlet
Power cord
Air intake
Control panel
Cooker plate
Cooking zone
Part list
Product summary
Preparation
Before using, please first check if the power plug connects well with the
power outlet.
Before placing the pot on the cooker plate, please clean up water stains,
oil spots or any other adherent dirt from the outside surface of the pot and
cooker plate.
Please put the pot to be heated on the central part of the induction
cooker. Do not put an empty pot on the cooker plate to be heated.

7
Instructions for use
Function selection
Connecting the power and switching on
Power adjustment
After pressing the “ ” key, press the function keys to select
the required mode. The induction cooker enters working mode.
After pressing the “ ” key, if no function key is pressed for 10
seconds, the induction cooker will switch off automatically.
After pressing the function key, if there is no proper pot on the cooker plate,
the induction cooker will not heat up and the alarm will sound to indicate that
a pot is required. One minute later, it will switch off automatically.
After switching on the appliance, press the “Function” to enter the desired
cooking mode.
Please refer to “Functional cooking mode instructions” for the details of the
corresponding heating process for each cooking mode.
After selecting a mode, you can press “+” or “-” to adjust
the power.
For some modes, during the heating procedure, the
induction cooker can automatically adjust the power
according to the cooking requirement.
For certain modes, the power is restricted complying
with the cooking requirement.
Timer adjustment
If timer function is not activated, the induction cooker
will heat the ingredients for the default time duration.
If timer is needed, first press the “Timer” key. When
the numbers blink on the display, press the key “+” or
“-” to adjust the time duration.
When the adjustment is finished, the number on the display
will be shown after blinking for several seconds. The induction
cooker starts counting down.
When the counting down is over, the induction cooker automatically
stops heating and switches off.
Special
notice: Please read the corresponding instruction
manual for each specific induction cooker purchased.
Timer

8
Instructions for use
Switch off
When the operating time is over, the induction cooker switches off automatically.
If switch off is needed in advance, press the “ ” key to turn the appliance off.
The cooking modes of Fry fit to high temperature cooking. In the heating
procedure, the time and power can be adjusted at any time. When the
temperature of the ingredients reaches the temperature level provided by
the selected mode (the highest temperature of various modes are different),
the induction cooker will switch to interval heating or stops heating. After the
temperature cools down, the induction cooker restarts heating.
Functional cooking mode instructions
The cooking modes of “Hot pot” individually fit to heating requirements, such
as hotpot and boiling water. In the heating procedure, the time and power can
be adjusted at any time. If the water in the pot dries up or the temperature is
abnormally high, the induction cooker automatically switches off or starts
protection function.
Users can select among the different cooking modes according to cooking
purpose. For your convenience, we provide the following instructions:
Hot pot
Fry
The pause function is designed for temporarily stopping heating during the
normal operation process. You can switch to pause status in any cooking mode.
During operation, when pause is needed, please press the function key “Pause”.
Now, the pause indicator lights up, the display and other function indicators stay in the
previous status.The power indicator turns off and the induction cooker stops heating.
When the induction cooker is in pause, press the “Pause” key again or select any
cooking mode to quit the pause status and return to the normal heating process.
After setting pause, the induction cooker stops heating. The default pause time
interval is 10 minutes. After 10 minutes, if the pause mode is not
cancelled, the induction cooker will sound an alarm. The alarm
will last for several seconds, then the induction cooker will switch
off automatically.
Pause adjustment
Press the“+” and “-” key at the same time to lock. The “child lock” indicator
lights up. Now only the “ ” key can be used to switch off the appliance.
Press the “+” and “-” key at the same time to quit the lock function.
The indicator turns off.
Child Lock
Pause

9
Instructions for use
The mode is for boiling water. After the water is boiled, the induction cooker
can switch off automatically.
The cooking mode of gentle heat with slow fire fits to the situation that needs
continuous heating with gentle power. When using this mode to stew soup or
boil congee, please first use the “Hot pot” mode to make the ingredients boil,
and then heat it by using “Slow fire”. The stewing time duration can be set
according to the feature of original material or personal taste.
The cooking mode is for heating with strong power. When the temperature
of the ingredients reaches the temperature level provided by the selected
mode (the highest temperature of various modes are different), the induction
cooker will switch to interval heating or stops heating. After the temperature
cools down, the induction cooker restarts heating.
The cooking mode fits for cooking that needs gentle heat to maintain warmth.
Under this mode, the induction cooker heats the ingredients with gentle power
to maintain a certain temperature inside the pot.
Functional cooking mode instructions
Boil
Note:
.It is recommended to put water that occupies 30% to 80% of the pot capacity
1
when boiling water.
.When boiling water, factors such as uneven pot bottom, scale or weather
2
conditions could influence the boiling effect.
.Please use the specific stock pot or water kettle when boiling water.
3
Note:
Under this mode, the power cannot be adjusted. If adjustment is needed,
please switch to the other modes, such as “Hot pot”. Then the power can be
adjusted at will.
Note: Under this mode, the power cannot be adjusted.
Slow fire
Fierce fire
Keep
warm
For the cooking modes of Porridge, Soup and Braise, the induction cooker
can automatically control the power according to the time duration that has
been set and the temperature of the ingredients. Under these modes, the
power can be adjusted within the adjustable power range at any time. After
this manual adjustment, the induction cooker will return to auto power control
according to the cooking purpose two minutes later. Among these modes,
when Porridge, or Soup mode is selected, the induction cooker will start the
auto two-hour keeping warm function after the operation is finished.
Porridge
Braise
Soup

10
Please use the attached pots sold by Midea. Do not use other pots as
replacements to avoid influencing the performance.
The maximum load for the frying pan is 4kg. When using it, do not let
the weight of the ingredients exceed this weight to avoid danger.
If other pots are used, please comply with the following conditions:
. Requirements for pot material: containing iron material.
1
2
. Requirement of p
ot shape: with even bottom, the diameter is not
less than 14.5cm while not more than 20cm.
Iron stock pot
Iron milk pot
Iron wok
Iron water kettle
Iron frying pan
Iron steamer pan
Note:
For
optimum
performance,
please
use
the
standard
pots
provided.
In particular, do not use pressure containers to avoid danger.
Proper pots

11
Before
cleaning,
please
switch
off
the
appliance
first
and
then
disconnect the power plug from the power outlet. Wait till the cooker
plate of the induction cooker is not hot and start cleaning.
After using the induction cooker for a long time, the opening of air
inlet/air outlet will pile up with dust or other dirt, please wipe it with a
soft dry cloth. Dust in the air inlet and outlet can be cleane
d by using
a soft brush or a mini vacuum cleaner.
Note: Please do not rinse it with water
For oil spots on the cooker plate, wipe the cooker plate by using a
soft moist cloth with a little tooth paste or mild detergent. And then
use a soft moist cloth to wipe it until no stain remains.
When not using it for a long time, please disconnect the power plug
from the power outlet and protect the induction
cooker from any dust
or bugs.
Abnormalities
Key checking points and trouble shooting
After
plugging
in
the
power
cord
and
pressing
the
“ ”
key,
the
indicator
and
display
do
not
light up.
The
“ ”
indicator
lights
up
and the display works normally, but
heating does not start.
Heating suddenly stops during the
process.
Is the power plug properly connected?
Is the switch, power outlet, fuse or power cord
damaged?
Is the pot material prop
er?
Is the appliance in a “Preset” working status?
For other causes, please take the appliance to a
repairing and maintenance site to be fixed.
Is the temperature of the oil too high when frying dishes?
Is
the
temperature
of
the
surroundings
very
high?
Is
the
air
inlet
or
air
outlet
of
the
induction
cooker blocked?
Is
the
default
heating
time
of
the
induction
cooker over?
The
self-safety
protection
of
th
e
induction
cooker
starts,
wait
for
several
minutes
and
connect power to use it.
Cleaning and maintenance
Self-diagnosis for abnormalities

12

If
there
is
technical
amendment
for
the
product, it will be edited into the updated
version of the instruction manual. Please
be aware that we will not inform customers
of
this
separately.
If
the
appearance
or
color
of
the
product
is
modified,
please
refer to the real appliance as a standard.
