Midea 350142 User manual

KITCHEN STAND MIXER
USER MANUAL
350142
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.
PART NAME
TECHNICAL DATA OF THE PRODUCT
INSTRUCTIONS FOR USE
IMPORTANT NOTE: Please read the manual carefully before operating your
product. Retain it for future reference.
CLEANING AND MAINTENANCE
CIRCUIT PRINCIPLE DIAGRAM
ABNORMALITY ANALYSIS AND HANDLING
1
3
3
4
8
12
12
13
RECIPES

To avoid the risk of serious injury when using your kitchen machine,
basic safety precautions should be followed, including the following.
READ ALL INSTRUCTIONS, SAFEGUARDS, AND WARNINGS
BEFORE OPERATING KITCHEN MACHINE.
Do not immerse the motor unit in water nor rinse it under the tap.
Before you connect the appliance tothe power, make sure that the
voltage indicated on the bottom of the appliance corresponds tothe local
power voltage.
Do not use the appliance if the power cord, the plug, protecting cover,
rotating sieve or any other parts are damaged or has visible cracks.
If the power cord is damaged, you must have it replaced by a service
center authorized , or similarly qualified persons to avoid a hazard.
This appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in
asafe way and if they understand the hazards involved.
Children shall not play with the appliance.
This appliance shall not be used by children. Keep the appliance and its
cord out of reach of children.
Never let the appliance run unattended.
Remove the beater, whisk or dough hook from your kitchen machine
before washing.
Be careful if hot liquid is poured into the bowl, as it can be ejected out of
the appliance due toasudden steaming.
This appliance is intended for household use only.
There is a potential injury from misuse. Please handle it with care.
Do not touch acidic food or soak in acidic solution for stirring
accessories.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
1
IMPORTANT SAFETY INSTRUCTIONS

2
SAVE THESE INSTRUCTION.
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.
1.
2.
3.
4.
5.
6.
7.
8.
9.
Always switch off and unplug the appliance if it is left unattended, and
before assembling, disassembling, cleaning and changing
accessories, or approaching parts that move in use.
In order to avoid a hazard due to inadvertent resetting of the thermal
cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected toacircuit that is
regularly switched on and off by the utility.
Always switch off the appliance by turning the knob to off(0) position.
Always wait until the moving parts stop running after switching off,
and then unplug the appliance before lifting the arm of the stand, or
opening, disassembling or removing the parts of any of the
accessories from the stand.
Do not exceed total 1500g ingredient the accessories (bowl).
Follow the quantities, processing time and speed when using the
kitchen machine tools, as indicated in the user manual.
Thoroughly clean the parts that come into contact with food before
you use the appliance for the first time. Refer tothe instructions and
table for cleaning given in the user manual.
Never use any accessories or parts from other manufactures that
does not specifically recommend. If you use such accessories or
parts, your guarantee becomes invalid.
Let hot ingredients cool down before processing them. Do not add
ingredients 60℃hotter than ambient temperature.
Always let the appliance cool down to room temperature after each
batchthat you process.
Caution:
IMPORTANT SAFETY INSTRUCTIONS

3
PART NAME
TECHNICAL DATA OF THE PRODUCT
Product name Model No. Rated voltage Rated frequency Rated power
(Optional)
(5.0L)
KITCHEN STAND MIXER
350142 220-240V~ 50-60Hz 375W
Arm lock lever

4
INSTRUCTIONS FOR USE
Kitchen machine
13 2
465
Always make sure mixer is
unplugged and setting control
is set to OFF(0).
Press the head of the mixer, then
release the lock lever right.
Tilt mixer head up, then, lock the
lever left.
Place bowl in bowl base and turn
clockwise until bowl locks into
place.
Release the lock lever right, press
down the head of the mixer.
Then lock the lever left.
Slide the bowl lid.
Insert attachment onto output
shaft and press upward as far
as possible.Turn the attachment
counterclockwise, hooking
attachment over pin on shaft.
12
311
Select desired speed.
control to Off(0).
Unplug from outlet. Slide out the bowl lid.
7
7
10
3
798
Plug mixer into wall outlet.

5
INSTRUCTIONS FOR USE
Before you start , make sure that you pick the desired attachment from following and
assemble according to user manual.
Mixing bowl tools
Your kitchen machine will be automatically turned off after 10 minutes of continuous
operation. This can avoid potential safety problems due to prolonged usage.
Before you use the kitchen machine and accessories for the first time, thoroughly clean the
parts that come into contact with food. You can only plug in and switch on the appliance after
you correctly assemble the accessories.
Before first use
Auto stop
Before switching on your kitchen machine, make sure the knob is at 0 position and then
attach the whisk, beater or dough hook.
Up to 500g of flour plus other ingredients can be processed in the bowl.
Follow the recommended quantities, processing time and speed as indicated in user
manual. Do not exceed the suggested processing speed to avoid damage tothe
machine.
Note
1.
2.
3.
Press the head of the mixer, then
lock lever left.
Release lock lever right, press
down the head of the mixer.
Remove attachment by trunning
the attachment counterclockwise
and pull to remove.
16 17 18
4
15
Remove attachment by turnning
the attachment counterclockwise
and pull to remove.
14
Press the head of the mixer, then
release the lock lever right.
Tilt mixer head up, then lock the
lever left.
13

6
To avoid splashing, always increase speed gradually.
Whisk: before whisking egg whites or cream, make sure that the bowl and the whisk
are dry and free from grease.
Kneading: use the dough hook toknead yeast dough for bread and pizzas.
You need to adjust the amount of liquid toform the dough according tothe humidity
and temperature condition.
If you want to re-knead the dough with your kitchen machine, press the dough down to
the bottom of the bowl to avoid the dough wrapping on the tool. Make sure that you
re-knead the dough within the recommended speed.
Tip
•
•
•
•
•
INSTRUCTIONS FOR USE
Name Purpose
Hook
Beater
Whisk
•For making green onion Chinese pancake
•Suggested processing speed: 2
• 1750g flour , 1260ml water, some green onion and little salt, 10 min.
•For making cake, cookies, pie, pastry, mashed potato,
pasta dough, gluten free bread, and cold butter
•Suggested processing speed:1-4
•For making egg white, cream, meringues, mousses,
and sou és
•Suggested processing speed:7

7
Ingredient:
• 500g flour • 50g olive oil • 1 teaspoon salt
•1teaspoon sugar • 7g yeast • 260ml warm water
1. Add all the dry ingredients tothe bowl and turn the rotary knob to speed 1.
2. Pour in the water and then the oil.
3. Switchto speed 2 and continue kneading until one smooth dough ball is formed.
4. Grease a bowl with vegetable oil.
5. Put the dough ball tothis bowl and cover it with cling film.
6. Let it rise for 1 hour until it is doubled in size.
7. Remove the air from the raised dough.
8. Fold it into a log shape and fit it into a loaf pan.
9. Cover it and let it rise in the tray for 1 hour.
10. Bake at 180°C for 40 minutes.
Recipes: Bread dough (Hook)
RECIPES

8
Ingredient:
• 3 eggs • 150g butter • 150 g castor sugar • 150g flour • 3g baking powder
1. Cut the butter into cubes of 2 cm.
2. Put the cubes with sugar in the bowl and mix them with speed 1.
3. Gradually increase the speed from 1 to 4.
4. Add the eggs one by one and keep mixing with speed 4 until you receive consistency.
5. Fold in baking powder and flour tothe mixture and mix with speed 4 until allthe ingredients
are well mixed.
6. Put the batter into a 30 cm long aluminum tin.
7. Place it in the middle of the oven.
8. Bake it for 30-40 minutes at the temperature of 180°C.
Recipe: Cake batter (Beater)
RECIPES
Ingredient:
• 4 egg whites • 1 cup (200 grams) superfine or caster sugar
1. Whisk the egg whites with speed 7 until soft peaks are formed.
2. Gradually add the sugar while processing with speed 4 until firm peaks are formed.
Recipes: Meringue (Whisk)
Piepastry (Beater)
Ingredient:
• 340g cups all-purpose flour, plus extra for rolling •1teaspoon salt • 1 teaspoon sugar
• 227g cold unsalted butter, cut into 2 cm inch cubes •6to8tablespoon ice water
1. Put all the dry ingredients tothe bowl and turn the rotary knob to speed
2. Add the cold butter into the dry ingredients and gradually increase the speed from 1 to 3.
3. Add 1 tablespoon iced water at atime tothe mixture until it forms crumbly dough. If the
dough doesn't hold together, add a little more water and mix it for a longer time. Do not add
too much water. Otherwise, it will make the crust tough.
4. Form the dough into the shape you want and wrap it with plastic wrap.
5. Keep it in the refrigerator for at least 1 hour and up to 2 days.
6. Rest the dough in the room temperature for a few minutes before rolling and baking.
7. Bake it for 25-30 minutes at the temperature of 180°C.
Piepastry (Beater)

9
RECIPES
3. Spoon the meringue onto a baking tray which is covered with baking paper.
4. Preheat your oven to 105°C and place the tray with the meringue in the center of the oven.
5. Bake the meringues for approximately 1-1.5 hours until they are dry and crisp.
6. Turn off the oven and dry the meringues in the oven for 1.5 hours.
Before you use the appliance for the first time, thoroughly clean the parts that come into
contact with food.
Before you start, make sure you assemble according to Sausage horn.
For disassembly, refer to Sausage horn.
Make sure that the projections on the feedingtube align with the notches of the motor.
Do not block the air outlet grooves of the sausage horn.
Do not make the sausages too thick in case the sausage skin is overstretched.
Keep the sausage skin wet to prevent it fromsticking on the sausage horn.
Note
Make sausages

10
RECIPES
Ingredients:
• 4,500g ground pork • 5 Tbsp. of salt • 1 tsp. of ginger
• 1 Tbsp. of ground hot red pepper • 1 Tbsp. of nutmeg • 1 Tbsp. of thyme
• 1 Tbsp. of ground white pepper • 470ml ice water • 2 Tbsp. of rubbed sage
Directions:
1. Mince the meat with the coarse grinding disc.
2. Thoroughly mix the minced meat and other ingredients.
3. Follow the instructions above to make your own sausages.
Yield: 5-8 servings
Ingredients:
•Outer casing • 400g lamb, cut into strips • 15ml oil • 2 medium onions, nely chopped
• 500g lamb or fat-free mutton, cut into strips • 500g bulgur wheat, washed and drained
• 1 small onion •Filling • 15ml plain flour • salt and pepper • 5-10ml ground allspice
Before you use the appliance for the first time, thoroughly clean the parts that come into
contact withfood.
Before you start, make sure you assemble according toKebbe spacer.
For disassembly, refer toKebbe spacer.
Make kebbe
Directions:
•Outer casing
1) Mince the meat, wheat, and onion together with the ne grinding disc.
2) Thoroughly mix the minced ingredients, and then mince the mixture twice again.
3) Use the kebbe maker toshape the mixture into kebbe casing.
•Filling
1) Mince the meat with the ne grinding disc.
2) Fry the onion chops until they turn golden brown.
3) Add the minced meat and other ingredients in, and then cook for 1-2 minutes.
4) Drain off excessive fat and cool the filling down.
• Cooking
1) Push some filling into the outer casing, and then pinch both ends to seal it.
2) Heat the oil for deep frying (190°C).
3) Deep fry the kebbe for 3-4 minutes, or until it turns golden brown.

11
That it is plugged in correctly.
That the accessories are correctly locked.
That the safety cover is present and locked when the high-speed outlet is not
used.
That the multi-function head is locked in a horizontal position.
Your appliance comes with a microprocessor that controls and analyses the
operationg power. If the load becomes too high, your appliance will stop automat-
ically. To restart your appliance, turn the rotary button to the "0" position and
remove some of your ingredients. Allow your appliance to cool down for a few
minutes. You can the select the desired speed to complete your preparation.
Before you clean the appliance, unplug it.
Refer to the table for infomation on cleaning the parts with water, dishwashing
machine and or moist cloth.
ABNORMALITY ANALYSIS AND HANDLING
In case of abnormalities such as abnormal noises, smell, smoke, etc., you should
immediately cut off power and stop use.
If the product cannot work, please check if the power supply is connected, if the
switch is put to the 1-7 speed position and if fittings are installed in place.
If the product still cannot work after checks mentioned above, please consult the
designated repair centre for maintenance.
Abnormality Handling
1.
2.
3.
CLEANING AND MAINTENANCE
Caution:
•
•
Clean the main unit with a moist cloth.
Clean the other parts in hot water(<60 ) with some washing-up liquid or in a
dishwasher (refer to the table).
Store the appliance and accessories in a dry place after cleaning.
1.
2.
3.
If your appliance does not work,check;

12
ACL
ACN
ACL
ACN
M1
M2
CONTROL PCBA
M
Lift up Switch
CIRCUIT PRINCIPLE DIAGRAM
CLEANING AND MAINTENANCE
Plastic

13
The appliance must not be disposed of with regular household waste.
At the end of its service life, the appliance must be properly delivered
to a collection point for the recycling of electrical and electronic
equipment. By Collection and recycling of old appliances,
you are making an important contribution to the conservation of our
natural resources and provide for environmentally sound and healthy
disposal.
Environmental protection
