Midea TMF No Frost Series User manual

Service Manual_2020-V1.0
1
Service Manual
TMF No Frost Series
Applicable Models
Product Models
Applicable Models
HD-663FWEN
UR-BCD510WE-SQ
22031020006981
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer
to accumulate through the daily work.

Service Manual_2020-V1.0
2
WARNING
Important Safety Notice
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement
Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to
prevent shock, fire or other hazards. Do not modify the original design without permission of
manufacturer.
WARNING
Important Safety Notice
The Maintenance Manual is only for the use of maintenance personnel with certain experience and
background in electrical, electronic and mechanical field.
Any attempt to repair main devices may lead to personal injury and property loss.
Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof.
Midea Refrigerators
Technical Maintenance Manual
Copyright @2017
All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without
written approval by the Overseas Sales Corporation of Midea Refrigerators.

Service Manual_2020-V1.0
3
Contents
1. SIGNIFICANT UPDATE NOTES (NONE)........................................................................................................ 5
2. SAFETY WARNING............................................................................................................................................... 6
2.1WARNING FOR OPERATION SAFETY ........................................................................................................................... 6
2.2 SAFETY INSTRUCTION FOR REFRIGERANT................................................................................................................. 8
3. INSTALLATION AND COMMISSIONING............................................................................................................ 9
3.1 HANDLING................................................................................................................................................................... 9
3.2 DOOR DISASSEMBLY AND ASSEMBLY ........................................................................................................................ 9
3.3 INSTALLATION LOCATION ............................................................................................................................................ 9
3.4 LEVELING OF THE REFRIGERATOR ........................................................................................................................... 10
3.5 LEFT OR RIGHT OPEN DOOR REVERSAL................................................................................................................... 10
3.6 INSTALLATION OF HANDLE（OPTION）................................................................................................................... 12
4. MAIN PARTS AND EXTERNAL DIMENSION....................................................................................................14
4.1 MAIN PARTS.............................................................................................................................................................. 14
4.2 EXTERNAL DIMENSION ............................................................................................................................................. 15
4.3 MIDEA PRODUCT SERIAL NUMBER AND LOCATION ................................................................................................... 15
5. ELECTRIC CONTROL SYSTEM.........................................................................................................................17
5.1 ELECTRICAL PARTS PARAMETERS............................................................................................................................ 17
5.2 CIRCUIT DIAGRAM .................................................................................................................................................... 19
5.3 MAIN PCB TERMINAL CONNECTION DIAGRAM......................................................................................................... 20
6. REFRIGERATION SYSTEM................................................................................................................................21
6.1 REFRIGERATION SYSTEM WORKING PRINCIPLE....................................................................................................... 21
6.2 COOLING PIPELINE AND DRAIN PIPE INSIDE THE CABINET........................................................................................ 21
6.3 CIRCULATING ROUTE OF COOLING AIR..................................................................................................................... 22
6.4WELDING POINTS IN CHAMBERS OR FOAM LAYER.................................................................................................... 22
6.5WELDING POINT IN THE COMPRESSOR CASE........................................................................................................... 23
7. DISMANTLING OF PARTS..................................................................................................................................24
7.1 PARTS ON THE DOOR................................................................................................................................................ 24
7.2 PARTS INSIDE THE REFRIGERATOR .......................................................................................................................... 24
7.3 LIGHT SYSTEM.......................................................................................................................................................... 25
7.4AIR DUCT COMPONENTS REFRIGERATING CHAMBER AND FAN MOTOR.................................................................... 25
7.5AIR DUCT COMPONENTS IN FREEZING CHAMBERAND FAN MOTOR.......................................................................... 26
7.6 EVAPORATOR AND DEFROST SYSTEM...................................................................................................................... 27
7.7 COMPRESSOR CASE ................................................................................................................................................ 28
7.8 DISPLAY CONTROL BOARD ....................................................................................................................................... 33
7.9 MAIN CONTROL BOARD ............................................................................................................................................ 34
7.10 VARIABLE FREQUENCY DRIVER BOARD（NONE）................................................................................................ 34
7.11WATER DISPENSER（NONE）............................................................................................................................... 34

Service Manual_2020-V1.0
4
8. TEMPERATURE SENSING SYSTEM.................................................................................................................35
8.1 POSITION OF SENSORS............................................................................................................................................ 35
8.2 REPLACEMENT OF SENSORS ................................................................................................................................... 35
8.3 SENSOR WITHOUT TERMINAL REPLACEMENT .......................................................................................................... 36
8.4 SENSOR R/TTABLE.................................................................................................................................................. 37
9. FUNCTION AND OPERATION............................................................................................................................39
9.1 DISPLAY OPERATION PANEL ..................................................................................................................................... 39
9.2 TEMPERATURE CONTROL......................................................................................................................................... 39
9.3 MODE SETTING......................................................................................................................................................... 40
9.4 DEFROSTING FUNCTION........................................................................................................................................... 40
9.5 OPEN DOORALARM (NONE)..................................................................................................................................... 40
9.6 ERROR CODE AND SOLUTIONS................................................................................................................................. 40
9.7 TEST MODE............................................................................................................................................................... 41
9.8 DEMO MODE（NONE）........................................................................................................................................... 41
9.9 BACKUP DATA FOR POWER FAIL ............................................................................................................................... 41
10. COMPRESSOR ..................................................................................................................................................42
10.1 COMPRESSOR ON AND OFF CONTROL SPECIFICATIONS........................................................................................ 42
11. TROUBLESHOOTING METHOD......................................................................................................................43
11.1 NO COOLING (AIR COOLING-ELECTRONIC)............................................................................................................ 43
11.2 NO WORKING OF COMPRESSOR............................................................................................................................. 45
11.3 INSIDE FROSTING,NO DEFROSTING....................................................................................................................... 46
11.4 INSIDE FROSTING,NO DEFROSTING-MAINTENANCE GUIDELINES.......................................................................... 47
11.5 LIGHT IS NOT ON..................................................................................................................................................... 48
11.6 FAN FAILURE........................................................................................................................................................... 49
11.7 DEFECTIVE DEFROST CIRCUIT ............................................................................................................................... 49
11.8 NOISE..................................................................................................................................................................... 50
11.9AIR DUCT NOT OPERATED....................................................................................................................................... 50
11.10 ICE MAKERNOT MAKE ICE（OPTION）................................................................................................................ 51
12. PRODUCT EXPLODED VIEW AND SPARE PARTS LIST.............................................................................52

Service Manual_2020-V1.0
5
1. Significant update notes (None)

Service Manual_2020-V1.0
6
2. Safety Warning
2.1 Warning for operation safety
Important Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within your freezer.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying your freezer.
WARNING
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this appliance near water.
6) Clean only with a damp cloth.
7) Do not block any ventilation openings.
8) Install in accordance with the manufacturer’s instructions.
9) Do not install near any heat sources, such as radiators, heat registers, stoves, or
other apparatus that produce heat.
10) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
11) Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the appliance.
12) Do not attempt to modify or extend the power cord of this appliance.
13) Unplug this appliance during lightning storms or when it will not be used for long
periods of time.
14) Make sure that the availableAC power matches the voltage requirements of this
appliance.

Service Manual_2020-V1.0
7
CONNECTING ELECTRICITY
Electrical Shock Hazard.
Plug into a grounded 3-prong outlet.
Do not remove the ground prong.
Do not use an adapter.
Failure to follow these instructions can
result in death, fire, or electrical shock.
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in electric shock, fire, or
death.
1) WARNING–Keep ventilation openings, in both the freezer and the built-in structure,
clear of obstruction.
2) WARNING–Do not touch the interior of the freezer with wet hands. This could result
in frost bite.
3) WARNING–Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
4) WARNING–Do not damage the refrigerant circuit.
5) WARNING–Do not damage the refrigerant tubing when handling, moving, or using
the freezer.
6) WARNING–DANGER–Never allow children to play with, operate, or crawl inside the
freezer. Risk of child entrapment. Before you throw away your old freezer:
6-1) Take off the doors
6-2) Leave the shelves in place so that children may not easily climb inside
7) Unplug the freezer before carrying out user maintenance on it.
8) This freezer can be used by children age eight years and older and persons with
reduced physical or mental capabilities or lack of experience and knowledge if they are
given supervision or instruction concerning the use of the freezer in a safe way and
understand the hazards involved. Children should not play with the freezer. Cleaning and
maintenance should not be performed by children without supervision.
9) If a component part is damaged, it must be replaced by the manufacturer, its service
agent, or similar qualified persons in order to avoid a hazard.
10) Please dispose of the freezer according to local regulations as the freezer contains
flammable gas and refrigerant.
11) Follow local regulations regarding disposal of the freezer due to flammable
refrigerant and gas. All refrigeration products contain refrigerants, which under the
guidelines of federal law must be removed before disposal. It is the consumer's
responsibility to comply with federal and local regulations when disposing of this product.
12) This freezer is intended to be used in household and similar environments.

Service Manual_2020-V1.0
8
13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this
freezer.
14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If
the power cord is too short, have a qualified electrician install an outlet near the freezer. Use
of an extension cord can negatively affect the freezer’s performance.
Grounding requirement
This freezer must be grounded. This freezer is equipped with a cord having a grounding
wire with a grounding plug. The plug must be inserted into an outlet that is properly installed
and grounded.
Improper use of the grounding plug can result in a risk of electric shock. Consult a
qualified electrician or service person if the grounding instructions are not completely
understood, or if doubt exists as to whether the freezer is properly grounded.
2.2 Safety instruction for refrigerant
Explosion Hazard.
Keep flammable materials and vapors, such as gasoline, away from freezer. Failure to do so
can result in fire, explosion, or death.
Safety instruction for refrigerant
DANGER–Risk of Fire or Explosion. Flammable Refrigerant Used. To Be Repaired Only By
Trained Service Personnel. Do Not Use Mechanical Devices. Do Not Puncture Refrigerant
Tubing. CAUTION–Risk of Fire or Explosion. Flammable Refrigerant Used. Consult Repair
Manual/Owner’s Guide Before Attempting To Service This Product.All Safety Precautions
Must be Followed. CAUTION–Risk of Fire or Explosion. Dispose of Properly InAccordance
With Federal Or Local Regulations. Flammable Refrigerant Used. CAUTION–Risk of Fire or
Explosion Due To Puncture Of Refrigerant Tubing; Follow Handling Instructions Carefully.
Flammable Refrigerant Used.

Service Manual_2020-V1.0
9
3. Installation and commissioning
3.1 Handling
Handling
1) Protect the refrigerator in moving it,Same as shown
as left photo, please move it by handcart with cushion
2) Remove all packing materials and bottom cushion,
the move into house for placement
3) After moving it to appropriate location, wait for 2 hou
rs before power on.
3.2 Door Disassembly and Assembly
When the whole refrigerator cannot enter the room, the door can be disassembled, then
assembled after entering separately.
3.3 Installation location
Installation location
Please select a ventilated place to place the refrigerator,
and reserve space according to the recommended size
in the picture, which is conducive to heat dissipation,
performance improvement and energy consumption
reduction.

Service Manual_2020-V1.0
10
3.4 Leveling of the refrigerator
Leveling of the refrigerator
If the refrigerator cannot be placed steadily, adjust the
footing to level it. Turn the feet clockwise to raise the
refrigerator; turn the feet counterclockwise to lower the
refrigerator.
3.5 Left or right open door reversal
Door reversal
1) Power off and remove all food from the fridge.
2)Dismantle the upper hinge cover, screws and upper hinge
from the right top, and remove the cover plate from the left
top.
3)Take off the freezer door.
4)Unscrew the three screws holding the center hinge,
remove the hinge, then lift the refrigerator door up and away
from bottom hinge.

Service Manual_2020-V1.0
11
5)Remove the bottom hinge and screws.
6) Unscrew the hinge shaft from the right side of the
bottom hinge and move it to the left side,
then secure the bottom hinge to the bottom left side of
the refrigerator.
7) Dismantle the sleeves, hole cap, screws and door
stopper on the refrigerator door, and assemble them on
the other side.
8) Dismantle the sleeves, and assemble them on the
other side.
9）Remove the freezer door self-locking block and
stopper, save the to reuse. Take out the left self-locking
block and stopper from the accessory plastic bag in the
refrigerator and installed on the left of door.

Service Manual_2020-V1.0
12
10)Put down the refrigerator door on the bottom hinge,
take out the middle hinge of the other side from the
accessory plastic bag, then assemble the middle hinge.
11)Put down the freezer door on the middle hinge, then
take out the top hinge and cover of other side from the
accessory plastic bag. Then assemble the left top hinge,
hinge cover and hole cover.
3.6 Installation of handle（Option）
Installation of handle
1)Remove the hole covers on the front of the door.
2)Take out the door handle, bolts and screw covers from
the accessory plastic bag.

Service Manual_2020-V1.0
13
3）Fix the bolts①in the screw hole on the front of the
door.
4）Install the door handle②onto the bolts.
5）Tighten the Allen screws③in the door handle hole.
6）Install the screw cover④on the screw of the door
handle.

Service Manual_2020-V1.0
14
4. Main parts and external dimension
4.1 Main parts
(The picture is only for reference, and specific appearance and configuration are subject to the real
product)

Service Manual_2020-V1.0
15
4.2 External dimension
Description
Code
Size (mm)
Height to top of Cabinet
A
1677
Width
B
750
Depth w/Cabinet
C
705
Depth w/Door
D
784.5
Depth w/Handle
E
\
Depth (Door open 90 deg. w)
F
1485.5
Depth (Door open 135 deg. w)
G
1288.5
Width (Door open 135 deg. w)
H
1270
(The picture is only for reference)
4.3 Midea product serial number and location
1）Product Serial Number —Including order number, production date and other information.When the
product occur problem, it needs to be recorded or photographed and provided to us.

Service Manual_2020-V1.0
16
2）Paste location
Some products also have S/N on the lower part of the right side of the Cabinet.

Service Manual_2020-V1.0
17
5. Electric control system
5.1 Electrical parts parameters
Applicable Model
HD-663FWEN
Product Model
UR-BCD510WE-SQ
Product code
22031020006981
Rated Voltage
115V、60Hz
Item
Specification
Specification
Refrigerant
R600a
Compressor
EZ65H1A (GMCC)
(Part code : 11101010012233)
Starting device type
Fixed Speed
The COP of compressor
1.72(W/W)
The max cooling capacity of
compressor
133 W
Winding resistance of compressor
wiring terminal (20℃)
Rmc:7.07Ω±7%
Rsc:6.07Ω±7%
Rms = Rmc + Rsc
Winding resistance picture
Starter(PTC)
QP2-4R7(Part co:
12031000001584)
Overload protector(OLP)
DRB33T61A1(Part code :
12031000001301)
Integrate PTC+OLP
None
Variable frequency driver board
None
Capacitor
None
Power filter (EMI)
None
Power reactor (EU EMC)
None
Motor
Fan motor of the freezing chamber
DC12V、4.0 W、1850r/min
Fan motor of the refrigerating
chamber
None
Electric damper
None
Lights
Lights inside the refrigerating
chamber
125V、40W
None
Lights inside the freezing chamber
None
None
Others Lights
None
None

Service Manual_2020-V1.0
18
Switch of the light
■Mechanical switch
□Magnetism control switch
None
Defrosting parts
Defrosting sensor
NTC B3839 ( B5/25=3839K±2% )
Fuse in freezing chamber
230V、73(0 ～-5) ℃
Defrost heater in freezing chamber
115V、180W

Service Manual_2020-V1.0
19
5.2 Circuit diagram
F: Freezer R: Refrigerator

Service Manual_2020-V1.0
20
5.3 Main PCB terminal connection diagram
Connecting terminals
Connecting terminals
1、Compressor
2、Freezing frost heater
3、Ice maker
4、Freezing fan motor
5、Ambient temperature sensor
6、Freezing defrost sensor
7、Refrigeration sensor
