Midea SIDE BY SIDE MDRS791MIE45 User manual

Refrigerator
SIDE BY SIDE SERIES
MDRS791MIE45
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
Download the app
& activate product
MSmartHome
PLACEHOLDER
FOR QR CODE

01
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance offers in a safe way.
CONTENTS
THANK YOU LETTER ---------------------------------------------------- 01
SPECIFICATIONS --------------------------------------------------------- 02
PRODUCT OVERVIEW -------------------------------------------------- 03
PRODUCT INSTALLATION --------------------------------------------- 05
OPERATION INSTRUCTIONS------------------------------------------ 12
APP SETUP AND OPERATION ---------------------------------------- 17
CLEANING AND MAINTENANCE------------------------------------- 19
TROUBLESHOOTING ---------------------------------------------------- 20

02
SPECIFICATIONS
Product model
Fresh food compartment Volume
Freezer compartment Volume
Rated Defrost Power
Lamp Rated Power
Refrigerant,Amount
Rated Voltage/Frequency
Rated Current
Product Overall Dimensions (W x D x H) 910 x 698 x 1775mm
1.9A
220-240V~/50Hz
5W
197W
213L
379L
R600a,74g
Temperature Rise Time
Freezing Capacity
7h
12kg/24h
MDRS791MIE45

03
PRODUCT OVERVIEW
Names of components
Normal type
1Door tray 4Door Tray
2Glass Shelf 5Fruits And Vegetables Box
3Drawer
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor

04
Dispenser type
1Door tray 4Door tray
2Glass Shelf 5Water dispenser (Optional)
3Drawer 6Fruits And Vegetables Box
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor

05
PRODUCT INSTALLATION
Install Instruction
For refrigerating appliances with climate class
• Depending on the climate class, This refrigerating appliance is intended to be
used at ambient temperatures range as specied following table.
• The climate class can be found on the rating plate. The product may not
operate properly at temperatures outside of the specic range.
• You can nd the climate class on the product label.
Effective temperature range
• The product is designed to operate normally in the temperature range
specied by its class rating.
Class Symbol Ambient temperature range °C
IEC 62552 (ISO 15502) ISO 8561
Extended temperate SN + 10 to + 32 + 10 to + 32
Temperate N + 16 to + 32 + 16 to + 32
Subtropical ST + 16 to + 38 + 18 to + 38
Tropical T + 16 to + 43 + 18 to + 43
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation
of freezing capability and increased electricity costs. Allow over 100 mm of
clearance from each adjacent wall when installing the appliance.
>100mm >100mm
>100mm
>100mm
>100mm
>100mm
Top View
Required space
for air circulation
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor

06
Space requirement diagram (when the door is open and when the door is closed)
B
AC
C1
E
B
125 °
D
Width Overall
Height Depth Without door
Depth
doors open
125o
Width
doors open
125o
A B C C1 D E
910 1775 698 617 1010 1470
Notice: All dimensions in mm

07
Leveling feet
To avoid vibration, the unit must be leveled.
If required, adjust the leveling screws to compensate for the uneven oor.
The front should be slightly higher than the rear to aid in door closing.
Leveling screws can be turned easily by tipping the cabinet slightly.
Turn the leveling screws counterclockwise to raise the unit, clockwise to
lower it.
Leveling doors
If the doors are not at the same height, the door can be adjusted with a spanner.
A- To raise the door, turn the nut (1) anticlockwise.
B- To lower the door, turn the nut (1) clockwise.
C- When the door is correctly aligned, x it with the nut (2).
Fixed shaft
Adjusting nut
Locking nut
Levelling feet
Moving the appliance
1. Remove all food from inside the appliance.
2. Pull the power plug out, insert and x it into the power plug hook at the rear or
on top of the appliance.
3. Tape parts such as shelves and the door handle to prevent from falling off
while moving the appliance.
4. Move the appliance with more than two people carefully. When transporting
the appliance over a long distance, keep the appliance upright.
5. After installing the appliance, connect the power plug into a socket out to
switch on the appliance.
ATTENTION
Precautions before operation:
Before making changes the refrigerator must be disconnected from power.
precautions should be taken to prevent any personal injury.

08
Changing the light
• Any replacement or maintenance of the LED lamps is intended to be made by
ATTENTION
(G).
Connecting the appliance
After installing the appliance, connect the power plug into a socket outlet.
ATTENTION
After connecting the power supply cord (or plug) to the outlet, wait 2 or 3 hours before you
put food into the appliance. If you add food before the appliance has cooled completely, your
food may spoil.
Tips for energy saving
• Do not place the appliance near cookers, radiators or other heat sources. If the
ambient temperature is high, the compressor will run more frequently and for
longer, resulting in increased energy consumption.
• ppliance, on the sides
of the appliance and at the back of the appliance. Never cover ventilation openings.
• Please also observe the spacing dimensions in the chapter “Installation”.
• The arrangement of drawers, shelves and racks as shown in the illustration offers the
s far as possible. All
drawers and shelves should remain in the appliance to keep the temperature stable
and save energy.
• To obtain a larger storage space (e.g. for large refrigerated/frozen goods), the
middle drawers can be removed. The top and bottom drawers and shelves should
be removed last if necessary.
• s to optimal energy
use. Therefore, avoid empty or half-empty compartments.
• Allow warm food to cool before placing it in the refrigerator/freezer. Food that has
• Allow frozen food to defrost in the refrigerator. The coldness of the frozen food
reduces the energy consumption in the refrigerator compartment and thus increases
• oss. Opening the door
• Setting the temperature no colder than necessary contributes to optimal energy
use. The optimum temperature in the refrigerator is +7°C. It should be measured as
far forward as possible in the top compartment of refrigerators.
• The door seals of your appliance must be perfectly intact so that the doors close
properly and energy consumption is not increased unnecessarily.

09
How to use the water dispenser (optional)
1. NOTE: Only puried and cold boiled water have access to this water dispenser, and
the two kinds must free from any impurity. Coke, apple juice and other soft drinks
that contain Carbon dioxide are forbidden.
2. It is not allowed to ll water when the water box is removed from the machine door.
3. Never ll more water than the maximum limit indicated on the water box.
4. Check out whether the water box is on its foundation bed if you are not able to get
water normally as usual.
5. When you are trying to move the water box, make sure that there is no water in it.
6. You are not allowed to remove any element of the water valve.
7. When you are using the machine for the rst time or it has been out of application
for a long time, remove and clean it up before you put it into application.
8. If water in this machine has been out of use for a long period, you should better
drain it out of the dispenser and add pure water, and then it can be used as usual.
9. It is suggested that the water dispenser tank should be cleaned up every three to
six months.
10. When you are cleaning the tank and if cleaning solution is used, you should better
put the water box to its original position, and ll the water box, then you shall drain
5 to 6 cups of water, in case there is any rudimental dirt of water dispenser after
you used cleaning solution.
11. When you are opening or closing the door of the water dispenser, try to avoid
overexerting to prevent water in the box to move and overow.
12. Do not touch the bottle frame above when adding water.
Instruction of Water Dispenser
Water box cover
Water box body
Seal ring
Water valve elements
Filling of Drinking Water
• Open the lid of water box, add water and close the
lid.
•Water shall be lled here

10
How to Get the Drinking Water
• Push the water shank inward by the cup
• When you put the hand shank inward, there will be some
water outow,when the hand shank is in its original
position,there is no water outow
How to Remove and Clean up the Water Dispenser
Step 1: Remove
• Take out the elements of the water box , stick to both
sides of the water box elements with both of your
hands,and draw out the elements of the water box
outwards through 45 degrees above. You can translate the
water box (to the side of the user) and get the elements
when the elements are out of water valve elements (when
you move the box,be sure that there is no water in it.)
• Take down the seal ring of the water box elements.
• Step to remove the elements of water valve : Use the
screwdriver and make the edge directs to the water
valve elements and then insert it in the free place that
highlights outskirt, rotates the screwdriver clockwise or
anticlockwise,with the screwdriver moving, when it tops
the penstock, extracts the water valve elements by hands
at the direction of above 45°(You can not remove the
elements of water valve)
Step 2: Clean up
• Remove the water box itself, and the water box cover, the
seal ring and the water valve elements.
• Clean up the elements of the water box with cold or warm
water.
• Wipe out the water with dry cloth.
ATTENTION
When you are cleaning the tank and if cleaning solution is used,
you should better put the water box to its original position, and
ll the water box, then you shall drain 5 to 6 cups of water, in
case there is any rudimentaldirt of water dispenser after you used
cleaning solution.

11
How to Get the Drinking Water
Step 3: Installation
• Installation of water valve elements: Put the guide
projecting platform directed to the guide groove, after
that,push it downside with 45° slantly at full tilt, until
you hear a crack.
• Installation of seal ring of the water box: Put the seal
ring to the bottom of the water box, and be sure that
the seal ring is in place. Avoid wrinkle of seal ring and
it’s placement in wrong place.
•The Installation of water box elements: Keep the
hanging slot of the water box elements direct to the
hangers on the door liner. The seal ring at the bottom of
the box shall directed to the entrance of the water valve
elements, insert it to the corresponding position along
with the 45° slantly.

12
OPERATIONINSTRUCTIONS
Control panal
B
D E
A C
Display Button
1Super Cooling icon ATemperature down button
2Super Freezing icon BTemperature zone selection
button
3Vacation icon CTemperature up button
4Refrigerating compartment
temperature Dbutton
5Freezer compartment temperature ELock/Unlock button
6Wireless Network icon
7Temperature display icon
8Lock icon
ATTENTION
The actual control panel may differ from model to model.
The control panel will turn off automatically for energy saving.
le cleaning it,the button function
may operate.

13
Lock / unlock
• In the unlocked state, long press the button for 3 seconds, enter the lock
state;In the locked state, long press the button for 3 seconds, the lock
icon disappears and enters the unlock state. All the following functions must
be operated in the unlocking status.
Vacation mode
• Click the button to enter the vacation mode. Icon lights up, the
vacation mode will start after locking the control panel.
• Under vacation mode,the refrigerating compartment is turned off and
temperature area display -the freezer compartment temperature is set at -18 ℃.
Super Cooling mode
• Click the button to enter the quick cooling mode. Icon lights up, the
quick refrigerating mode will start after locking the control panel. Quick cool
exits for 6h.
Super Freezing mode
• Click the button to enter the quick freezing mode. Icon lights up, the
quick freezing mode will start after locking the control panel. Quick freeze
exits for 24h.
Temperature setting of refrigerating compartment
• Click temperature zone selection button , refrigerating compartment
temperature will blink. Then click the button or again to set the
temperature, and will hear one beep. Setting scope is between 2°C and 8°C.
Every time you click the button, the temperature will be changed 1°C. After
adjusting,the digital tube will keep blinking for 5 seconds. New temperature
setting will take effect after locking the control panel.
Temperature setting of freezer compartment
• Click temperature zone selection button , freezer compartment
temperature will blink .Then click the button or again to set the
temperature, and you will hear one beep. Setting scope is between -16°C
and -24°C. Every time you click the button, the temperature will be changed
1°C. After adjusting, the digital tube will keep blinking for 5 seconds. New
temperature setting will take effect after locking the control panel.
ATTENTION
Recommended setting: Refrigerated chamber 5°C, freezing chamber - 18°C.
The quick-freezing function is designed to maintain the nutritional value of the food in the
freezer. It can freeze the food in the shortest time. If a large amount of food is frozen at one
time, it is recommended that the user turn on the quick-freezing function and put the food in.
At this time, the freezing speed of the freezer compartment is increased, which can quickly
freeze the food, effectively lock the nutrition of the food, and facilitate storage.

14
Wireless network setting-AP configuration
• Please start AP mode before connecting to the mobile app. Whether in the
locked or unlocked state, press and hold the mode button for 3s to force
the refrigerator wireless module to set to AP mode, and then the temperature
display area will display AP; After the module is successfully congured to
enter the AP mode, it will automatically exit the AP mode, and the temperature
display area will return to normal temperature display; After setting the AP
mode, if the module is not congured successfully for 10s, it will forcibly exit
the AP mode and restore the normal temperature display.
Storage upon power failure
• In case of power failure, the instant working state will be locked and
maintained till re-electrication.
Opening warning and alarm control
• when open the refrigerator doors, the opening music will play. If the door is
not closed in two minutes, the buzzer will sound once every minute until the
door is closed. Press anyone button to stop the buzzer alarm.
ATTENTION
Disable the door opening tone: Press and hold thecombination key and for 3 seconds
to disable or enable the door opening tone (the tone is enabled by default).
Disable the door opening alarm sound: Not possible
Error code
• The following warnings appearing on the display indicate corresponding faults
of the refrigerator. Though the refrigerator may still have cold storage function
with the following faults, the user shall contact a maintenance specialist for
maintenance, so as to ensure optimized operation of the appliance.
Fault Code Fault Description
E1 Temperature sensor failure of refrigerating chamber
E2 Temperature sensor failure of freezing chamber
E5 Freezing defrost sensor detection circuit error
E6 Communication error
E7 Ambient temperature sensor error

15
Tips on storing food
Freezer compartment
• The freezer is designated for the storage of food frozen at very low temperature,
long-term storage of frozen food, and for the production of ice.
• Only use the shelves in the door of the freezer to store frozen food, not for storing
hot food designated for freezing.
• Do not put fresh and frozen food next to each other. The frozen food may thaw.
•When freezing fresh food (such as meat, fish or chopped meat), cut them into parts
that can be used at the same time.
• Storing frozen food: instructions are usually stated on the packages, which must be
followed. If there is no information on the packaging, food should not be stored for
longer than three months from the date of purchase.
• When purchasing frozen food, make sure that it was frozen at a suitable
temperature and that the packaging is not damaged.
• Frozen food should be kept in suitable packages to retain the quality and should be
returned to the freezer compartment as soon as possible.
• If a package of frozen food shows moisture or abnormal bulging, it is probable that
it was stored at the wrong temperature and the content is spoiled.
• The storage period for frozen food depends on the room temperature, the
thermostat setting, the frequency of opening the door of the freezer, the type of
food and the time of transporting the product from the shop to the household.
Always follow the instructions printed on the packaging and never exceed the
maximum storage time stated on the package.
Refrigerating compartment
• To reduce moisture and subsequent ice build-up, never put liquid into the
refrigerator in unsealed containers. Frost tends to concentrate in the coolest parts
of the evaporator. Storing uncovered liquids results in a more frequent need for
defrosting.
•Never put warm foods in the refrigerator. These should first cool down at room
temperature and then be placed so as to ensure adequate air circulation in the
refrigerator.
• Foods or food containers should not touch the back wall of the refrigerator because
they could freeze to the wall. Do not keep regularly opening the door of the
refrigerator.
•Meat and clean fish (packed in a package or plastic foil) can be placed in the
refrigerator, which can be used in 1–2 days.
• Fruit and vegetables without packaging can be placed in the part designated for
fresh fruit and vegetables.
Recommended Temperature
The optimal temperature setting for food storage:
• Fridge: 5 °C , Freezer: -18 °C
ATTENTION
The optimal temperature setting of each compartment depends on the ambient temperature.
Above optimal temperature is based on the ambient temperature of 25 °C.

16
Order Compartments
TYPE
Target
storage
temp. [°C]
Appropriate food
1 Fridge +2 ≤+8
Eggs, cooked food, packaged food, fruits and
vegetables, dairy products, cakes, drinks and
other foods are not suitable for freezing.
2 (***)*-Freezer ≤-18
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and nutrition),
suitable for frozen fresh food.
3 ***-Freezer ≤-18
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and nutrition),
suitable for frozen fresh food.
4 **-Freezer ≤-12
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and nutrition),
suitable for frozen fresh food.
5 *-Freezer ≤-6
Seafood (sh, shrimp, shellsh), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and nutrition),
suitable for frozen fresh food.
6 0-star -6 ≤0
Fresh pork, beef, sh, chicken, some packaged
processed foods, etc. (Recommended to eat
within the same day, preferably no more than 3
days).
Partially encapsulated processed foods (non-
freezable foods).
7 Chill -2 ≤+3
Fresh/ frozen pork, beef, chicken, freshwater
aquatic products, etc. (7 days below 0°C and
above 0°C is recommended for consumption
within that day, preferably no more than 2
days).Seafood (less than 0 for 15 days, it is not
recommended to store above 0°C.
8 Fresh food 0 ≤+4
Fresh pork, beef, sh, chicken, cooked food,
etc.(Recommended to eat within the same day,
preferably no more than 3 days)
9 Wine +5 ≤+20 Red wine, white wine, sparkling wine, etc.
ATTENTION
please store different foods according to the compartments or target storage temperature of
your purchased

17
APP SETUP AND OPERATION
Download the MSmarthome App
On an app market (Google Play Store, Apple App
Store), search for “MSmartHome” and nd the
MSmartHome app. Download and install it on your
phone. You can also download the app by scanning the
QR code below. Download the app
& activate product
MSmartHome
Register and log in
Open the MSmartHome app, and create a new account
to start (you can also register through a third-party
account). If you already have an existing account, use
the account to log in.
Connect your devices to MSmarthome
1. Please make sure your mobile phone is connected
to a wireless network. If it is not, go to Settings
and enable wireless networks and Bluetooth.
2. Please power on your devices.
3. Open MSmarthome App on your phone.
4. If a message of "Smart devices discovered
nearby" appears, click to add.
Washing machine
...
5. If no message appears, select “+” on the page and
select your device in the list of nearby devices
available. If your device is not listed, please add
your device manually by the device category and
device model.
6. Connect your device to the wireless network
according to instructions on app. If the
connection fails, please follow the instructions
provided by the app to continue with the
operation.
Add device
8:88

18
NOTE
1. Make sure your devices are powered on.
2. Keep your mobile phone close enough to your device when you are connecting
your device to the network.
3. Connect your mobile phone to the wireless network at home, and make sure
you know the password of the wireless network.
4. Check if your wireless router supports 2.4 GHz band and turn it on. If you are
not sure whether the router supports 2.4 GHz band, please contact the router
manufacturer.
5. The device cannot connect to the wireless network that requires authentication,
and it usually appears in public areas such as hotels, restaurants, etc. Please
connect to a wireless network that does not require authentication.
6. Turn off the WLAN+ (Android) or WLAN Assistant (iOS) function of your
mobile phone when connecting your device to the network.
7. In the case that your device connected to a wireless network before but it
needs to reconnect, please click “+” on the app Home page, and add your
device again by the device category and model according to the instructions
on app.
