MODEL:360484Read all instructions and explanations forthe installation before use. Follow theinstructions carefully. Keep the operationinstructions handy for later use. If theappliance is sold or passed on, ensurethat the new owner always receives this operation instructions.delete installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the product is sold or passed on then ensure that the new owner always receives thismanual.MODEL:

CONTENTS1Safety Instructions Safety Instructions ..................................................Installation Product Description ................................................ Installation ...........................................................Operations Quick Start ............................................................. Before Each Washing .............................................. Detergent Dispenser ............................................... Control Panel ......................................................... Option.................................................................... Programmes .......................................................... Washing Programmes Table .....................................Maintenances Cleaning and Care ................................................. Trouble Shooting .................................................... Technical Specifications ......................................... Testing methods .....................................................2891213141516202122252627

For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life.Explanation of the symbols:

This combination of symbol and signal word indicates a potentially dangerous situation which may result in death or serious injuries unless it’s avoided.Warning!This combination of symbol and signal word indicates a potentially dangerous situation which may result in slight or minor injuries.Note!This combination of symbol and signal word indicates a potentially dangerous situation which may result in slight or minor injuries or damage to property and the environment.Caution!SAFETY INSTRUCTIONSSafety InstructionsWarning!If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent.2

• The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.• Before any maintenance the device, unplug the appliance from the mains.• Always unplug the machine and turn off the water supply after use. The max. inlet water pressure, in pascals. The min. inlet water pressure, in pascals.• To ensure your safety, power plug must be inserted into an earthed three-pole socket. Check carefully and make sure that your socket is properly and reliably earthed.• Make sure that the water and electrical devices must be connected by a qualified technician in accordance with the manufacturer's instructions and local safety regulations. Risk to children!• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.• Children of less than 3years should be supervised to ensure that they do not play with appliance.• Animals and children may climb into the machine. Check the machine before every operation.• Children should be supervised to ensure that they do not play with the appliance.SAFETY INSTRUCTIONSThe electric shock!Warning!3

• Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result.• Glass door may be very hot during the operation. Keep kids and pets far away from the machine during the operation very wet rooms as well as in the rooms with explosive or caustic gas.• Plug must be accessible after installation.Risk of explosion!• • Do not wash or dry articles that have been cleaned in, washed in, soaked in, or dabbed with combustible or explosive substances( such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents, kerosene, etc.) This may result in fire or explosion.Before hand thoroughly rinse items of washing by hand.SAFETY INSTRUCTIONS4

• This washing machine is for indoor use only. • The maximum inlet water pressure:1.0Mpa.• The minimum inlet water pressure:0.05Mpa.• It isn't intended to be built-in using.• The openings must not be obstructed by a carpet.• Washing machine shall not be installed in bath room or very wet rooms as well as in the rooms with explosive or caustic gases.• The washing machine with single inlet valve only can be connected to the cold water supply. The product with double inlet valves should be correctly connected to the hot water and cold water supply.• Plug must be accessible after installation.Installing the product!Caution!• Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result.5SAFETY INSTRUCTIONS

Risk of damaging appliance!• Your product is only for home use and is only designed for the textiles suitable for machine washing.• Do not climb up and sit on top cover of the machine.• Do not lean against machine door.• Cautions during Handling Machine: 1.Transport bolts shall be reinstalled to the machine by a specialized person. 2.The accumulated water shall be drained out of the machine. 3.Handle the machine carefully. Never hold each protruded part on the machine while lifting. Machine door can not be used as the handle during the conveyance. 4.This appliance is heavy. Transport with care. • Please do not close the door with excessive forces. If it is found difficult to close the door, please check if the clothes are put in or distributed well.• It is forbidden to wash carpets.Operating the appliance!• The maximum mass of dry cloth in kilograms: 8.0kg.• Before washing the clothes at first time, the product shall be operated in one round of the whole procedures without the clothes inside.• Flammable and explosive or toxic solvents are forbidden. Gasoline and alcohol etc.Shall not be used as detergents. Please only select the detergents suitable for machine washing, especially for drum.SAFETY INSTRUCTIONS6

• Make sure that all pockets are emptied. Sharp and rigid items such as coin,brooch,nail,screw or stone etc. may cause serious damages to this machine.• Please check whether the water inside the drum has been drained before opening its door.Please do not open the door if there is any water visible.• Be careful of burning when the product drains hot washing water.• Never refill the water by hand during washing.• After the program is completed, Please wait for two minutes to open the door. This marking indicates that this product should not be disposed with other household wastes throughout the EU.To prevent possible harm to the environment or human health from uncontrolled waste disposal,recycle it responsibly to promote the sustainable reuse of material resources.To return your used device, please use the collection systems or contact the retailer where the product was purchased. They return and can take this product for environmental safe recycling.

Packaging/Old appliance

SAFETY INSTRUCTIONS7

AccessoriesProduct DescriptionTransport plughole Supply hosecold water

• The product line chart is for reference only, please refer to real product as standard.

Note!Drum Power supply cordControl panel

Detergent dispenser

Service filterDoor

Water supply hose

Top cover Drain hoseOwner’s manualINSTALLATION8

Installation Before installing the machine, the location characterized follows shall be selected:1.Rigid, dry, and level surface 2.Avoid direct sunlight3.Sufficient ventilation4.Room temperature is above 0℃ 5.Keep far away from the heat resources such as coal or gas.as Unpacking the washing machine1. Remove the cardboard box and styrofoam packing.2. Lift the washing machine and remove the base packing.3. Remove the tape securing the power supply cord and drain hose.4. Remove the inlet hose from the drum.Make sure the small triangle foam is removed with the bottom one together. If not, lay the unit down with side surface, then remove the small foam from the unit bottom manually.Please take the following steps to remove the bolts:1.Loosen 4 bolts with spanner and then remove them.2.Stop the holes with transport hole plugs.3.Keep the transport bolts properly for future use.Remove transport bolts•• Stability is important to prevent the product from wandering!Make sure that the product should not stand on the power cord.Warning!• • Packaging material (e.g. Films, Styrofoam) can be dangerous for children. There is a risk of suffocation ! Keep all packaging well away from children.Warning!

• •product you You must remove the transport bolts from the backside before using the product. You’ll need the transport bolts again if you move the , so make sure keep them in a safe place.

Warning!INSTALLATIONwwW> 20mmInstallation area9

91.Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts.2.Loosen the lock nut turn the feet until it closely contacts with the floor. 3.Adjust the legs and lock them with a spanner, make sure the machine is steady.Levelling the washing machine

• The lock nuts on all four feet must be screwed tightly against the housing.

Connect Water Supply HoseConnect the inlet pipe as indicated, There are two ways to connect the inlet pipe.1.Connection between ordinary tap and inlet hose. • To prevent leakage or water damage, follow the instructions in this chapter Do not kink, crush, modify or sever . !•water inlet hose•For the model equips hot valve,connect it to hot water tap with hot water supply hose. Energy consumption will decrease automatically for some program.2341RaiseLowerLock nutfootWarning!Warning!INSTALLATIONLoosen clamp nut and four boltsTighten clamp nutPress slide bushing, insert inlet hose into connecting base

slide bushing

2341Connection finished

clamp nut

Tap with threads and inlet hoseSpecial tap for washing machine2.Connection between screw tap and inlet hose.

slide bushing

Warning!Drain HoseThere are two ways to place the end of drain hose:1.Put it into the water trough.2.Connect it to the branch drain pipe of the trough.

•• If drain hose is too long, do not force it into washing machine as it will cause abnormal noises. When installing drain hose, fix it properly with a rope.

• •Position drain hose properly ,otherwise damage might result of water leakage.Do not kink or protract the drain hose.

Water trough

Min.60cm100cmMax.

Warning!INSTALLATION

water supply hose

water Inlet valveConnect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly clockwise.11

Before washing, please make sure it’s installed properly. Before washing at first time, the washing machine shall be operated in one of the whole procedures without clothes in as follows. • • round

1. Before WashingBuzzer beep or “End” on display.

Open tap

Load

Close door

Plug in

Add detergent

Quick Start3. After Washing• Detergent only need to be added in "case I "after selecting pre-washing for machines with this function.123452. Washing

Power On

Select Programme

Select function ordefault

Start up

1234• 1.The function button line chart is for reference only, please refer to real product as standard.If default is selected, step 3 can be skipped. 2.Note!Note!Caution!OPERATIONS12

Knot the long strips,zip or button • When washing a single clothes, it may easily cause great eccentricity and give alarm due to great unbalance. Therefore it is suggested to add one or two more clothes to be washed together so that draining can be done smoothly. • Don’t washing the clothes touching with kerosene, gasoline, alcohol and other flammable materials. • The working condition of the washer should be(0-40)°C.If used under 0°C,the inlet valve and draining system may be damaged. If the machine is placed under condition of 0°C or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use. • Please check the labels and the explanation of using detergent before wash. Use non-foaming or less-foaming detergent suitable for machine washing properly. Take out the items out of the pockets Put small clothes into the pillow slip Check the labelBefore Each Washing

Turn easy-pilling and long-pile fabric inside out

Separate clothes with

different texturesWarning!OPERATIONS13

Detergent DispenserOPERATIONSCaution!• Liquid detergent need to be added after selecting pre-washing for machines( )Powder detergent

ProgrammeCottonSyntheticMixBed LinenBaby CareDrum CleanRinse & SpinCotton ECO

Means must ○　Means optional

ProgrammeWoolSpin Only20℃

Quick 15’

Sterilization

Control Panel OPERATIONSPowerProduct is on/off.Start/PausePress the button to start or pause the washing cycle.ProgrammesAvailable according to the laundry type.Option This allows you to select an additionalfunction and will light when selected.113124DisplayThe display shows the settings, estimated time remaining, options, and status messages for your washer. The display will remain on through the cycle.5321145

Pre Wash

Child Lock

Display

AWash Time Delay Time Speed Error End Temp. AJC

Door Lock

Delay

Speed Wash

Night Wash

Extra Rinse

SpaCare

Pre Wash-Wash-Rinse-Spin

JBDEFGI15

Option OPERATIONSExtra Rinse: The laundry will undergo extra rinse once after you select it. Delay: Delay function can be set with this button, the delaying time is 0-24H.It can be set the spin speed to press the button repeatedlySpeed: The Prewash function can get an extra wash before main wash,it is suitable for washing the dust rises to surface of the clothes;You need to put detergent into the Case (I) when select it.Pre Wash:

Programme Default Speed(rpm) CottonSyntheticMixBed LinenBaby Care20℃Drum Clean

Programme Spin OnlyRinse & SpinWoolCotton ECOSterilizationQuick 15’

Default Speed(rpm)

--800800800100010001000

1400

100010006001000 800 800

1400

Spin SpeedWhen needed, the spinning speed can be adjusted pressing the Speed button in the following steps: 1400：0-400-600-800-1000-1200-1400 1500: 0-400-600-800-1000-1200-1400-1500

Spin

AUTO DOSEPress the [] buttonthe AUTO DOSE fucntion will be turned off.When press the power button to start the product,the screen will show “soft” or “dete” icon.When the light is flashing meansthe detergent or the softener is shortage and you need to add it.Open the detergent box cover add the detergent and softener.Filling amount does not exceed maximum line. AUTO DOSE,AUTO DOSE16

OPERATIONDelay2.Press the Delay button to choose the delaying time 0-24h3.Press [Start/Pause] to start the delay operation1. Select a programme

Choose programmeStartSetting timeDelay

To cancel the Delay function, press the “Delay” button before starting the program until the display shows 0 h. If the program has already started, switch the appliance off and afterwards on and select a new programme.Pre WashExtra washing function before the main washing cycle starts to increase the washing performance.Note: Detergent needs to be added to the compartment I.Extra RinseThe laundry will undergo an extra rinse after selecting this function.Speed WashThe function can decrease the washing time.My CycleAfter choosing the programme and setting the options, press [Spin] 3 sec. before start to wash.The default setting course is Cotton.To memory the frequently used programme.SpaCare function can be selected by choose “Cotton”,“Mix“”Bed Linen” and “Baby Care”. The customers can see the steam in the drum when operate SpaCare function. SpaCare17

OPERATION

When the Child Lock is activated, the display will alternately show “CL” and the remaining time.Pressing any other button will cause the Child Lock indicator to flash for 3 sec.When the program ends, “CL” and “END” will alternate on the display for 10 sec, then the indicator will flash for 3 sec.The Child Lock deactivates the function of all buttons except the On/Off button and the Child lock button!Only the simultaneous pressing of the two buttons [Spin] and [Function] can deactivate the Child Lock!Please deactivate the Child Lock before selecting a new program!

Caution!Child LockThis function is meant to keep children from misusing the controls.

Press [Spin] and [] simultaneously for 3 sec until the buzzer beep. The child lock indicator switches on.Function

Mute the buzzerTo act the buzzer function, press the button again for 3 seconds. The setting until the next reset. will be kept • MuAfter ting the buzzer function, the sounds will not be activated any more.Caution!
