Midland DUALMIKE User manual

EN
PTT CBTALK
Push and talk into CBTalk
CHANGE ACHANNELONCBTALK
Channel down
Channel up
Turning ON:
Blue led 3 sec.
Turning OFF:
Red led 3 sec.
Pairing:
Red and blue leds alternated
Pairing with Smartphone:
Blue led blinking 3 times
Smartphone’s pairing not
successful: red led blinking 3 times
Full charge:
Blue led blinks once
While charging:
Red led blinks once
Default color:
Steady blue (it will be set through
the CBTalk APP)
Incoming call:
Steady white
Low battery:
blinking red
PTT pressed:
Steady yellow
Download the CBTalk APP Android/iOs
DUAL MIKE WIRELESS WITH CBTALK APP
To download the complete user manual and for information about the warranty
please visit www.midlandeurope.com
QUICK GUIDE
Prodotto o importato da:
CTE INTERNATIONAL srl
Via. R.Sevardi 7 42124 Reggio Emilia - Italia.
Prima dell’uso leggere attentamente le istruzioni.
Produced or imported by:
CTE INTERNATIONAL srl
Via. R.Sevardi 7 42124 Reggio Emilia - Italy.
Read the instructions carefully before installation and use.
Vertrieb durch: ALAN ELECTRONICS GmbH
Daimlerstraße 1K - D-63303 Dreieich Deutschland.
Vor Benutzung Bedienungsanleitung beachten.
Importado por: MIDLAND IBERIA, SA
C/Cobalt, 48 - 08940 Cornellà de Llobregat, Barcelona - España.
Antes de utilizar, lea atentamente el manual de uso.
Importé par: ALAN FRANCE S.A.R.L.
5, Rue Ferrie, Zac les Portes du Vexin 95300 Ennery - France.
Avant l’utilisation, lire les instructions.
BLUETOOTH MICROPHONE
DUALMIKE
WIRELESS
LED LIGHT RING

3
sec.
1 2 3
4
5
6
7
8
10
9
3
sec. 3
sec.
3
sec. VOL+VOL-
Device A
DualMike
Device B
3
sec.
11
3
sec.
220V
DUALMIKE WIRELESS OVERVIEW
POWER ON
Power On
Led steady blue 3 sec.
POWER OFF
Power O
Led steady red 3 sec.
PAIRING WITH SMARTPHONES
1. Volume -
2. Led
3. Volume + (Power O - 3 sec.)
4. Emergency key (or customizable)
5. Channel up; Channel down (CBTalk)
6. Speaker
7. USB charging port/FW upgrade port
8. Light ring
9. Secondary PTT
10. PTT CBTalk (Power On - 3 sec.)
11. DUAL MIKE WIRELESS is supplied with a metallic plate very useful for magnetic fixing
of the microphone and wireless recharge. To use it remove the plastic support fixed with
a screw*.
PAIRING WITH OTHER BLUETOOTH DEVICES
STEP 1
Pairing
Red and blue leds alternately
blink
PRESS TOGETHER
secondary PTT and VOL+
STEP 2
Bluetooth connected
Blue led blinks 3 times
HAND-FREE PHONE CALLS
AUDIO VOLUME
To answer/to end a call
White light ring
To reject an incoming call
White light ring
To make a voice dial Bop (max vol. Beep)
RECHARGE
WIRELESS
RECHARGE
Through DK-DUAL,
optional Docking
Station
(The plastic support
must be removed,
see point 11*)With USB cable (included)
STEP 2
Telephone connected
Blue led blinks 3 times
STEP 1
Pairing
Red and blue leds alternately
blink
PRESS TOGETHER
PTT CBTALK and VOL+

3
sec.
1 2 3
4
5
6
7
8
10
9
3
sec. 3
sec.
3
sec. VOL+VOL-
Device A
DualMike
Device B
3
sec.
11
3
sec.
220V
DUALMIKE WIRELESS OVERVIEW
POWER ON
Power On
Led steady blue 3 sec.
POWER OFF
Power O
Led steady red 3 sec.
PAIRING WITH SMARTPHONES
1. Volume -
2. Led
3. Volume + (Power O - 3 sec.)
4. Emergency key (or customizable)
5. Channel up; Channel down (CBTalk)
6. Speaker
7. USB charging port/FW upgrade port
8. Light ring
9. Secondary PTT
10. PTT CBTalk (Power On - 3 sec.)
11. DUAL MIKE WIRELESS is supplied with a metallic plate very useful for magnetic fixing
of the microphone and wireless recharge. To use it remove the plastic support fixed with
a screw*.
PAIRING WITH OTHER BLUETOOTH DEVICES
STEP 1
Pairing
Red and blue leds alternately
blink
PRESS TOGETHER
secondary PTT and VOL+
STEP 2
Bluetooth connected
Blue led blinks 3 times
HAND-FREE PHONE CALLS
AUDIO VOLUME
To answer/to end a call
White light ring
To reject an incoming call
White light ring
To make a voice dial Bop (max vol. Beep)
RECHARGE
WIRELESS
RECHARGE
Through DK-DUAL,
optional Docking
Station
(The plastic support
must be removed,
see point 11*)With USB cable (included)
STEP 2
Telephone connected
Blue led blinks 3 times
STEP 1
Pairing
Red and blue leds alternately
blink
PRESS TOGETHER
PTT CBTALK and VOL+

3
sec.
1 2 3
4
5
6
7
8
10
9
3
sec. 3
sec.
3
sec. VOL+VOL-
Device A
DualMike
Device B
3
sec.
11
3
sec.
220V
DUALMIKE WIRELESS OVERVIEW
POWER ON
Power On
Led steady blue 3 sec.
POWER OFF
Power O
Led steady red 3 sec.
PAIRING WITH SMARTPHONES
1. Volume -
2. Led
3. Volume + (Power O - 3 sec.)
4. Emergency key (or customizable)
5. Channel up; Channel down (CBTalk)
6. Speaker
7. USB charging port/FW upgrade port
8. Light ring
9. Secondary PTT
10. PTT CBTalk (Power On - 3 sec.)
11. DUAL MIKE WIRELESS is supplied with a metallic plate very useful for magnetic fixing
of the microphone and wireless recharge. To use it remove the plastic support fixed with
a screw*.
PAIRING WITH OTHER BLUETOOTH DEVICES
STEP 1
Pairing
Red and blue leds alternately
blink
PRESS TOGETHER
secondary PTT and VOL+
STEP 2
Bluetooth connected
Blue led blinks 3 times
HAND-FREE PHONE CALLS
AUDIO VOLUME
To answer/to end a call
White light ring
To reject an incoming call
White light ring
To make a voice dial Bop (max vol. Beep)
RECHARGE
WIRELESS
RECHARGE
Through DK-DUAL,
optional Docking
Station
(The plastic support
must be removed,
see point 11*)With USB cable (included)
STEP 2
Telephone connected
Blue led blinks 3 times
STEP 1
Pairing
Red and blue leds alternately
blink
PRESS TOGETHER
PTT CBTALK and VOL+
