Midland BT Remote User manual

midlandusa.com
Midland BT Remote - Page 1
Main features� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Charging batteries� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Unit and mounting system description � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Switching your Midland BT Remote on and o� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Operative mode� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Pairing the BT Remote � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Reset pairing � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
FCC compliance information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Other products� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Midland BT product order form� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Table of Contents

midlandusa.com
Midland BT Remote - Page 2
MIDLAND BT Remote
Advanced Remote Control System
Thank you for purchasing the Midland BT Remote advanced wireless remote control system for your Midland intercom.
The Midland BT Remote can be mounted to the handlebar of your motorcycle and control all the functions of your BT intercom devices.
Main features
›Adjustable mounting system
›3 main function buttons and 2 volume buttons
› Mini USB plug for charging
›Waterproof
If the red LED is ashing and the unit is not plugged into a charger, it means the
battery is low� Please recharge the unit as soon as possible�
BT Remote description
The BT Remote has ve buttons on the front; the three main buttons are multi
function buttons: the“Forward”button(on the top), the“Middle”button and the
“Back”button(on the bottom)� The two small rounded buttons on the front are the
“Volume +”and“Volume -”�
Ensure the BT Remote is fully charged before use� Charge the unit by inserting the
mini USB cable in the charging plug (lift the rubber cover to insert the plug)� You
can use any USB wall charger or use the USB port of your PC� The red LED light
will turn on during charging� When the unit is fully charged, the red LED light will
turn o�
Please note:
Every time the mini USB charging plug is inserted (or detached),
the device is automatically turned o� To use the BT Remote while it is charging, you
should turn the device on when the plug is already inserted�
Low battery indication
Charging batteries
Unit and mounting system description
6- Midland BT Remote
UK
MIDLAND BT Remote
Advanced Remote Control System
Thank you for purchasing Midland BTRemote wireless remote control system for your Midland intercom.
Midland BTRemote can be fixed on the handlebar of your motorbike to control all the functions of your BTNext, BTX1 and BTX2 intercom devices.
Main features
›Adjustable fixing system
›3 main function buttons + 2 for volume up and down
›MiniUSB plug for recharging
›Water resistant
Charging batteries
Make sure that the unit is fully charged before use. Charge the unit by inserting
the miniUSB cable in the charging plug (lift the rubber cover to insert the plug).
You can use any USB wall charger like the one in the BTNext, BTX1 or BTX2 box or
use the USB port of your PC. The red LED light will be on during all the charging
time.When the unit is fully charged, the red LED light will be o.
Please note: every time the mini USB recharging plug is inserted (or detached),
the device is automatically turned o. To use it while it is in charge, you should
turn the device on when the plug is already inserted.
Low battery indication
If the red LED is flashing and the unit is not plugged to a charger, it means the
battery is low. Please recharge the unit as soon as possible
Unit and xing system description
BT Remote description
The BTRemote has five buttons on the front; the main three big buttons are multi
function buttons: the Forward (on the top), the Middle button and the Backward
(on the bottom). The two small rounded buttons on the top are the Volume +
and Volume -
Fixing system description
Midland BTRemote is very easy to fix, just open it and place it on the left handle.
Close it until is quite firm on the handle. To remove it just lift the lock point and
open it.
In the box you will find two extra rubber spacers to be replaced in case your
handle has a dierent size
LED Light
Volume up
Volume down
Forward
Middle
Back
Interchangeable
rubber spacer
Mounting system description
The Midland BT Remote is easy to mount, just open and place it on the handle of
your motorcycle� Close until it is rmly secured to the handle� To remove it, lift the
lock point to open it�
6- Midland BT Remote
UK
MIDLAND BT Remote
Advanced Remote Control System
Thank you for purchasing Midland BTRemote wireless remote control system for your Midland intercom.
Midland BTRemote can be fixed on the handlebar of your motorbike to control all the functions of your BTNext, BTX1 and BTX2 intercom devices.
Main features
›Adjustable fixing system
›3 main function buttons + 2 for volume up and down
›MiniUSB plug for recharging
›Water resistant
Charging batteries
Make sure that the unit is fully charged before use. Charge the unit by inserting
the miniUSB cable in the charging plug (lift the rubber cover to insert the plug).
You can use any USB wall charger like the one in the BTNext, BTX1 or BTX2 box or
use the USB port of your PC. The red LED light will be on during all the charging
time.When the unit is fully charged, the red LED light will be o.
Please note: every time the mini USB recharging plug is inserted (or detached),
the device is automatically turned o. To use it while it is in charge, you should
turn the device on when the plug is already inserted.
Low battery indication
If the red LED is flashing and the unit is not plugged to a charger, it means the
battery is low. Please recharge the unit as soon as possible
Unit and xing system description
BT Remote description
The BTRemote has five buttons on the front; the main three big buttons are multi
function buttons: the Forward (on the top), the Middle button and the Backward
(on the bottom). The two small rounded buttons on the top are the Volume +
and Volume -
Fixing system description
Midland BTRemote is very easy to fix, just open it and place it on the left handle.
Close it until is quite firm on the handle. To remove it just lift the lock point and
open it.
In the box you will find two extra rubber spacers to be replaced in case your
handle has a dierent size
LED Light
Volume up
Volume down
Forward
Middle
Back
Interchangeable
rubber spacer
In the box you will nd two additional sized rubber spacers to use if your handle
bar has a dierent size�

midlandusa.com
Midland BT Remote - Page 3
Press and hold the“Middle”button for 3 seconds until the LED indicator turns blue�
Turning your Midland BT Remote on and o
Turning the unit on:
Press and hold the“Middle”and“Back”buttons together for 3 seconds until the LED
indicator ashes red 3 times�
Turning the unit o:
Operative mode
The Midland BT Remote duplicates the same exact functions as the 5 buttons
available on the BT intercom units, therefore you can refer to the intercom manual�
Pairing the BT Remote
The Midland BT Remote can be paired to any Midland BT intercom unit�
The BT Remote is ready to be paired right out of the box:
›
Turn on the BT Remote (Press and hold the“Middle”button for 3 seconds,
the blue LED will start ashing)
›
Turn on the Midland intercom unit�
›
Press any button on the BT Remote (must be within 3 minutes after you
turn on the Midland intercom unit)�
The two devices will search for each other and will automatically pair�
Once the pairing procedure is completed, it does not need to be repeated again�
If the pairing procedure fails, repeat the procedure again� If the pairing still
does not work, perform the pairing reset procedure (see the “Reset the pairing”
paragraph) and then repeat the“First time pairing”procedure�
First time pairing
To use the BT Remote, switch it on and press any button (make sure your Midland
intercom is on) to ensure connection� As soon as the blue LED starts double
ashing, you can begin using your BT Remote�
Using the BT Remote
You may nd it necessary to delete all paired devices stored in the BT Remote:
›
Turn o the unit�
›
Press and hold down the“Middle”and“Volume +”buttons together, until
the blue LED turns on�
›Release the buttons and the blue LED will start ashing� Now all the pairing
information is deleted and it is possible to start a new pairing session (as explained
in the paragraph“First time pairing”):
›
While the blue LED is ashing, turn on the Midland intercom unit�
›
Press any button on the BT Remote (must be within 3 minutes after you
turn on the Midland intercom unit)�
The two devices will search for each other and will automatically pair�
Reset the pairing

midlandusa.com
Midland BT Remote - Page 4
FCC statement
This device complies with Part 15 of the FCC Rules� Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation�
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment�
This device complies with Industry Canada license-exempt RSS standard(s)�
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device�
This equipment complies with Industry Canada radiation exposure limits set
forth for an uncontrolled environment�

midlandusa.com
Midland BT Remote - Page 5
Check out these and other great products at
midlandusa.com
CB Radios
Emergency Crank Radios
Marine Radios
HD Wearable Video Cameras
Bluetooth Headsets
Weather Radios
2-Way Radios

midlandusa.com
Midland BT Remote - Page 6
Midland BT Product Order Form
Please send Money Order or ll in theVisa/Master Card information and mail to the address below�
Please DO NOT send cash or checks� Make Money Order to Midland Radio Corporation�
Name:____________________________________________________________________
Address: __________________________________________________________________
City: ______________________________State: ___________ Zip Code:__________________
Telephone: __________________________E-mail: __________________________________
Credit Card# _________________________Type: ___________ Exp:_____________________
QTY ITEM DESCRIPTION PRICE TOTAL
BTNCT Twin Multi Rider Intercom $449�99
BTNCS Single Multi Rider Intercom $249�99
BTX2FMT Twin Advanced Intercom $349�99
BTX2FMS Single Advanced Intercom $199�99
BTX1FMT Twin Basic Intercom $249�99
BTX1FMS Single Basic Intercom $149�99
BTREMOTE Handlebar Remote Control $99�00
XTA110 Mini USB Cable $10�00
XTA111 USB DC Adapter $19�99
XTA112 USB AC Adapter $19�99
Mail To:
Midland Radio Corporation
Consumer Dept�
5900 Parretta Drive
Kansas City, MO 64120
_______________
Or Call 816�241�8500
Sub-total _______________________
Tax (MO, FL,WA Only) _______________________
S&H $ ___________________ 14�95
(Applies to Domestic US only�
For Hawaii, Alaska, and Puerto
Rico S&H will be $38�25 for 1 lb�
and $64�25 for 2 lb� or more)�
Total $ ______________________
To order online go to midlandusa�com
