Miele CVA 3660 User manual

Operating and installation instructions
Built-in coffee machine
CVA 3660
To avoid the risk of accidents
or damage to the machine,
it is essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 318 490
en - AU, NZ

Guide to the machine ..............................................5
Caring for the environment..........................................7
Warning and safety instructions .....................................8
Brief description .................................................12
Using the coffee machine - first steps ................................13
Controls .........................................................13
Display ..........................................................13
Before using for the first time.........................................14
Switching on ...................................................14
Switching off ...................................................15
Filling the machine with water and coffee capsules ....................16
Filling the water container ...........................................16
Filling the capsule carousel ..........................................17
Taking capsules out of the capsule carousel ............................18
Making coffee ....................................................19
Switching on .....................................................19
Before preparing the first drink .......................................20
Filling the system with water .........................................20
Espresso or Coffee ................................................20
Double portion .................................................21
Cancelling preparation ...........................................21
Hot milk, milk froth and cappuccino ...................................21
Dispensing froth directly into the cup / Cappuccino ....................23
Frothing milk in the cappuccinatore .................................24
Hot milk .......................................................25
After preparing milk / Interim cleaning ...............................25
User profile drinks .................................................26
After use.........................................................27
Contents

Settings: Customising your machine ................................28
Selecting a language...............................................29
Time of day ......................................................30
Display .......................................................30
Setting the timer...................................................31
Switch on at: ...................................................31
Switch off after: .................................................32
Switch off at: ...................................................33
Activate .......................................................33
Automatic rinsing ..................................................34
Steam system ....................................................35
Lighting .........................................................35
INFO: No. of drinks and No. of portions until descaling ....................36
Safety (System lock) ...............................................36
Setting the water hardness ..........................................38
Display ..........................................................39
Volume ..........................................................40
Factory default ....................................................40
Factory default settings (the coffee machine is delivered with the following
settings) ......................................................41
Allocating and saving a coffee type..................................42
Allocating the types of coffee (Allocate type) ............................42
Chamber symbols in the display ...................................42
How to allocate the types of coffee .................................42
Select type ....................................................43
Rename type...................................................43
Change type ...................................................45
Delete type ....................................................45
Setting up user profiles............................................46
Selecting a user profile ...........................................46
Setting a user profile.............................................47
Changing a user profile ..........................................48
Deleting a user profile............................................48
Revert ........................................................48
Contents

Manual .......................................................49
After each use..................................................49
When switched on ..............................................49
Programming the amount (Setting the portion sizes) ...................50
Programming the amount with the OK sensor .........................50
Programming the amount via "Settings" ..............................51
Programming the amount for different user profiles .....................52
Cleaning and care ................................................53
Rinsing ..........................................................53
Water container ...................................................54
Waste container ...................................................54
Drip tray ........................................................55
Grille with drip tray cover............................................57
Capsule carousel and carousel runners ................................57
Coffee outlet cover.................................................58
Interior and machine door ...........................................59
Capsule plate.....................................................59
Steam valve ......................................................60
Cappuccinatore (milk frother) ........................................61
Machine front .....................................................62
Maintenance .....................................................63
Descaling the machine ............................................65
Problem solving guide ............................................68
After sales service ................................................78
Electrical connection..............................................79
Installation ......................................................80
Building-in and combination options ...................................80
Installation .......................................................81
Contents

Exterior view
aOn/Off sensor for switching the coffee machine on and off
bDisplay
cLeft sensor arrow, for scrolling through the various programme options
dOK sensor, for confirming the selection of a programme option and for saving a
setting
eRight sensor arrow, for scrolling through the various programme options
fDrinks selection sensor for selecting the type of coffee (coffee or espresso)
gDoor handle
hPlastic grille
iMetal drip tray cover
jSpout
kInset for Cappucinatore (Milk frother)
lValve for steam and hot water
Guide to the machine
5

Interior view
mMaster switch
nCapsule plate (replaced with the descaling funnel when descaling is carried
out)
oBrew unit
pCapsule carousel
qCarousel runners
rWater container
sDrip tray with grid
tWaste container
Guide to the machine
6

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for
disposal, and can normally be
recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Dispose of or recycle all packaging
materials safely as soon as possible.
Rather than just throwing these
materials away, please ensure that they
are recycled.
Disposal of your old machine
Electrical and electronic machines
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your machine.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre, or contact your Dealer or
Chartered Agent for advice. Ensure that
it presents no danger to children while
being stored for disposal.
It should be disconnected from the
mains electricity supply by a competent
person.
Caring for the environment
7

This machine conforms with all
relevant legal safety requirements.
Improper use can, however, lead to
personal injury and damage to
property.
To avoid the risk of accidents and
damage to the machine, please
read these instructions carefully
before using it for the first time.
They contain important notes on the
installation, safety, operation and
care of the machine.
Keep these instructions in a safe
place and pass them on to any
future owner.
Correct application
~The machine is intended for
domestic use only for the preparation of
espresso, cappuccino and coffee. Any
other usage is not supported by the
manufacturer and could be dangerous.
The manufacturer cannot be held liable
for damage resulting from incorrect or
improper use or operation.
~This coffee machine is not intended
for use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience or knowledge, unless they
are supervised whilst using it or have
been given instruction concerning its
use by a person responsible for their
safety.
Safety with children
~Keep children away from the
machine at all times. It is not a toy! To
avoid the risk of injury do not allow
children to play on or near it or to play
with its controls. Supervise children
whilst you are using it. Children's skin is
very sensitive, and reacts to hot
temperatures. Danger of scalding.
~Older children may only use the
coffee machine when its operation has
been clearly explained to them and
they are able to use it safely,
recognising the dangers of misuse.
Remember that coffee and espresso
are not suitable drinks for children.
Technical safety
~Before setting up the machine,
check it for any externally visible
damage. Never install or attempt to use
a damaged machine. Danger of injury.
~To avoid the risk of damage to the
machine, make sure that the rating on
the data plate corresponds to the
voltage and frequency of the household
supply, before connecting the machine
to the mains supply. Consult a qualified
electrician if in any doubt.
~The electrical safety of this machine
can only be guaranteed when
continuity is complete between it and
an effective earthing system which
complies with local and national safety
regulations. It is most important that this
basic safety requirement is present and
tested regularly, and where there is any
doubt, the household wiring system
should be inspected by a qualified
electrician.
Warning and safety instructions
8

The manufacturer cannot be held liable
for damage or injury caused by the lack
of or inadequacy of an effective
earthing system (e.g. electric shock).
~The machine must only be operated
when built in, to ensure that all
electrical components are shielded.
Ensure power is not supplied to the
machine until after installation, repair
work or maintenance work has been
carried out.
~Do not connect the machine to the
mains electricity supply by a
multi-socket unit or an extension lead.
These do not guarantee the required
safety of the machine (e.g. danger of
overheating).
~The machine is not suitable for use
in the open air, even when installed in a
mobile unit (optional extra).
~This equipment may only be used in
mobile installations such as ships,
caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
~Installation work and repairs may
only be carried out by suitably qualified
and competent persons in strict
accordance with current local and
national safety regulations. Repairs and
other work by unqualified persons
could be dangerous and the
manufacturer will not be held liable.
~While the machine is under
guarantee, repairs should only be
undertaken by a service technician
authorised by the manufacturer.
Otherwise the guarantee will be
invalidated.
~Faulty components must only be
replaced by genuine Miele original
spare parts. The manufacturer can only
guarantee the safety of the appliance
when Miele replacement parts are
used.
~The machine is only completely
isolated from the electricity supply
when:
–the mains fuse is disconnected,
–the screw-out fuse is removed (in
countries where this is applicable),
–it has been switched off at the wall
socket and the plug has been
withdrawn.
~Never open the outer casing of the
machine. Tampering with electrical
connections or components and
mechanical parts is highly dangerous
to the user and can cause operational
faults or electric shock.
~If the coffee machine is to be built in
above another appliance, there must
be a full-width, closed shelf between
them (except when it is combined with
a Miele built-in plate warming drawer).
~In areas which may be subject to
infestation by cockroaches or other
vermin, pay particular attention to
keeping the machine and its
surroundings in a clean condition at all
times. Any damage which may be
caused by cockroaches or other vermin
will not be covered by the guarantee.
Warning and safety instructions
9

Correct use
Caution. Danger of scalding. The
liquids dispensed are very hot.
Never look directly at the lighting or
use optical instruments to look at it.
~Do not reach into the brew unit when
the machine is connected to the
electricity supply. Danger of inury.
~The water piping and the
Cappuccinatore (milk frother) must be
rinsed through and the machine
cleaned thoroughly before the first drink
is prepared.
~Only cold, fresh tap water should be
used to fill the water container. Warm or
hot water or other liquids could damage
the machine. Change the water every
day to prevent a build-up of bacteria.
~Do not on any account use mineral
water. Mineral water will cause serious
limescale deposits to build up in your
machine and damage it.
~Never put anything other than
Nespresso coffee capsules in the
capsule carousel. Other manufacturers'
capsules etc. would damage the
machine.
~The coffee capsules must be intact
before use. Do not use coffee capsules
which are damaged, broken or dented.
These could become jammed in the
machine and damage it.
~Do not use milk with additives.
Sugar additives will adhere to the milk
pipework and damage the coffee
machine and the cappuccinatore.
~Never place a drink with ignited
alcohol under the spout of the coffee
machine. The flames could ignite
plastic components and cause fire
damage.
~Hot water and steam could cause
scalding. Be very careful when using
these functions. Make sure you do not
come into contact with steam or hot
water. The machine must not be used
for cleaning objects.
~Always switch the coffee machine
off with the master switch before
cleaning the interior. Danger of inury.
~Do not clean the inside of the
capsule plate opening. Danger of inury.
~Do not use a steam cleaner to clean
this machine. Pressurised steam could
reach the electrical components and
cause a short circuit.
~Clean the machine every day to
prevent a build-up of bacteria. All parts
except the capsule plate and the
plastic grille are dishwasher safe.
~Water in the drip tray can be very
hot. Take great care when emptying it.
Danger of scalding.
~The machine should be descaled
regularly, depending on the hardness
of the water, with the descaling tablets
supplied. The harder the water, the
more often the machine must be
descaled. The manufacturer cannot be
held liable for damage arising from
insufficient descaling.
Warning and safety instructions
10

~Only use the descaling tablets
supplied by Miele and follow the
instructions on the packet carefully.
Use the exact proportions
recommended. Otherwise the machine
will be damaged.
~How quickly the capsule plate
becomes soiled will depend on the fat
content of the coffee used. We
recommend that you clean the capsule
plate every 1 to 2 months with a
cleaning tablet.
~Never swing from or hang anything
on the door when it is open as this
could damage the machine.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and safety instructions.
Warning and safety instructions
11

The capsule carousel can hold up to 20
coffee capsules. These 20 coffee
capsules are divided between 5
chambers. This means that the capsule
carousel can be filled with 5 different
types of coffee. These 5 different types
are programmed into the machine so
that the type required can be selected
from the display.
If the machine is used by various
people with different tastes and
preferences, you can programme
specific settings for up to nine
individual users (User profiles) in
addition to the Standard profile.
There is no need to remove each
individual spent capsule, as the used
coffee capsules drop down
automatically into a waste container.
The coffee capsules can be disposed
of with your normal household waste.
The size of cup can be programmed in
so that the correct amount is
dispensed. If the cup being used has a
smaller capacity than the programmed
portion size, preparation can be halted
at any time by touching the OK sensor.
Ifadouble portion of coffee or
espresso is required, a double portion
can be selected in the display. The
machine will then prepare two portions,
one after the other.
The machine features a system lock to
prevent children from operating the
machine.
The easy to use programming facility
allows, amongst other things, the
language in the display to be changed
and the water hardness to be
programmed in.
To ensure that the flavour can develop
fully and be maintained for longer the
machine has an additional function for
automatically rinsing the system
when the machine is cold. The same
function is used to flush coffee remains
out of the system and the spout after
use.
The machine can be programmed to
switch to standby mode so it is always
ready for operation but does not
consume unnecessary electricity. This
can be programmed to happen
between 15 minutes and 9 hours after
coffee was last dispensed. It is
therefore important to set the correct
time of day.
You can also programme the machine
to switch on and off at a particular
time every day.
Brief description
12

The following notes should help you get to know your coffee
machine before starting to use it.
Controls
This machine has sensors controls which react to touch. To
operate the machine you only need to touch the relevant
sensor. There are five sensors:
–sOn/Off sensor for switching the coffee machine on
and off
–< Left arrow, for scrolling through the various
programme options
–OK sensor, for confirming the selection of a
programme option and for saving a setting
– > Right arrow, for scrolling through the various
programme options
–/Drink selection sensor (coffee or espresso)
Display
COSI oEspresso
K1K2K3K4K5LonGkC
The basics are shown in the display, such as:
–Drink selection: Up to 5 different coffee types K, Steam L
and Hot water o.
–User profile nfor up to 9 different users,
–Important maintenance programmes: Rinsing Gand
Descaling k,
–Selecting Settings Cfor customising your machine.
^The arrow sensors are used to select a programme option
in the display. Touch the OK sensor when the option you
want appears highlighted in the display.
This makes it easy to use the coffee machine.
Using the coffee machine - first steps
13

Before using for the first time
The machine must be correctly installed and connected
(see "Electrical connection " and "Installation") before it is
used for the first time.
Remove any protective foil from the front of the machine.
Switching on
^Touch the On/Off sensor sto switch on the machine.
When the machine is being switched on for the first few times
with the master switch, a welcome screen and some other
messages will appear briefly. The welcome screen will be
displayed each time the machine is switched on until 5 drinks
have been prepared.
Míele Willkommen
When you use the machine for the very first time instead of
the time of day appearing after the welcome screen you will
be prompted to select a language.
^Touch the right or left arrow sensor until the language you
want appears in the display.
^Touch the OK sensor.
The language you have chosen is now set.
The request to set the clock format will then appear.
^Touch one of the arrow sensors until the clock format you
want (12 or 24 hours) is highlighted and then touch the OK
sensor.
^Enter the time of day: First set the hour with the arrow
sensors and then touch the OK sensor. Then set the
minutes in the same way.
Using the coffee machine - first steps
14

^Now decide when you want the time of day to be
displayed:
"On" = the display will always show the time of day (even
when the machine is switched off),
"On for 60 seconds" = the display will show the time for
60 seconds and then go dark after the machine is switched
off,
"Not displayed" = the display will only show the time of
day when the machine is switched on and will go dark
when it is switched off.
If everything has been entered correctly, Set up successful
will appear in the display.
^Confirm this message by touching the OK sensor.
To get the best out of your coffee machine, and to
set it up for your specific requirements please
continue to work through these operating
instructions. It really is worthwhile doing this as you will then
be able to use your coffee machine to the best advantage.
Switching off
To switch the machine off:
^touch the On/Off sensor s.
If automatic rinsing is switched on, providing that coffee
has actually been dispensed from the machine, the rinsing
process will begin. After this the machine will switch off
automatically.
Using the coffee machine - first steps
15

The coffee machine must be cleaned thoroughly (see
"Cleaning and care") before you fill it with water and coffee
capsules.
It is vital that you programme the water hardness level
of your water (see "Settings: Water hardness").
Filling the water container
The quality of the water plays an important part in
the overall quality of the coffee. The water
container should therefore be emptied and filled
with fresh tap water every day.
Hot water and other liquids could damage the machine.
Only use cold, clean tap water and fill the machine every
day. Do not on any account use mineral water. Mineral
water will cause serious limescale deposits to build up in
your machine and damage it.
^Open the machine door.
^Lift the water container and pull it forwards to remove it.
Filling the machine with water and coffee capsules
16

^Fill the water container with cold, clean tap water up to the
"Max." marker.
A valve at the front of the water container will ensure that
water cannot escape.
^Push the water container fully back into the machine.
Filling the capsule carousel
Do not put anything other than Nespresso coffee capsules
in the capsule carousel.
Do not use coffee capsules which are damaged, broken,
dented or bent up at the edges. They can get stuck in the
machine.
The capsule carousel has five chambers, each
holding four capsules. It is important to allocate
the chambers correctly (see "Allocating type").
You can fill all the chambers with the same type of coffee, if
wished.
Some of the chambers are allocated a type of coffee at the
factory. Fill the chambers with the appropriate type of coffee
or re-allocate the chamber for a different type of coffee (see
"Allocating and saving coffee types"). The machine will then
dispense the type of coffee you select.
^Pull the carousel runners aout as far as possible.
^Fill the chambers cin the capsule carousel bwith
capsules. Make sure you put them in correctly with the foil
facing downwards. You can take the capsule carousel out
by lifting it upwards to fill it.
Filling the machine with water and coffee capsules
17

Please note that the individual capsules sit loosely in the
capsule carousel to prevent them from becoming jammed.
^If you have removed the capsule carousel, place it onto the
carousel runners before putting it back into the machine.
You do not have to position it in a particular way, as the
machine will automatically guide it into position.
^Push the carousel runners fully back into the machine.
^Close the door.
The machine will now align the capsule carousel. You will be
able to hear this happening.
Taking capsules out of the capsule carousel
If you want to change the capsules in the carousel:
^Pull the carousel runners out.
^Lift the capsule carousel upwards to remove it.
^Push upwards on the ring underneath the magazine and
then remove the capsules.
Filling the machine with water and coffee capsules
18

Important: the water piping must be rinsed through every
day and the machine cleaned thoroughly before the first
drink of coffee is prepared. Rinsing will take place
automatically if the Automatic rinsing programme option
has been set to "On" and the machine is cold. Hot water
will run out of the spout into the drip tray once the machine
has heated up.
If the Rinsing programme option has been set to "Off",
select "Rinsing" in the display to rinse out the system (see
"Cleaning and care").
Switching on
To switch the machine on:
^touch the On/Off sensor s.
The following message will then appear:
Heating-up phase
If the automatic rinsing programme option has been set to
"On" (factory default setting), the following will appear after
the machine has heated up:
Rinsing
Water will run out of the spout.
You will hear the capsule carousel moving into position.
The main menu will then appear in the display:
COSI oEspresso
K1K2K3K4K5LonGkC
Making coffee
19

Before preparing the first drink
Filling the system with water
The machine is emptied completely before it leaves the
factory. You must allow water to be pumped through the
system before the first drink of coffee or hot water is
prepared.
Hot water
K1K2K3K4K5LonGkC
^Select "Hot water" with one of the arrow sensors.
^Touch the OK sensor.
^Run some hot water into the cup.
^Touch the OK sensor again to switch the water off.
The system is now filled with water, and the machine is ready
to use.
Espresso or Coffee
^Place a cup under the spout.
COSI oEspresso
K1K2K3K4K5LonGkC
^Select the type of coffee with one of the arrow sensors.
^Use the drink selection sensor to select espresso or coffee.
The type of coffee you have chosen will appear in the top
line of the display on the right.
^Touch the OK sensor once.
The drink you want will then run out of the spout.
Making coffee
20
