Miele CVA 7370 User manual

Operating and Installation
Instructions
Built-in Coffee Machine
Always read the operating instructions before setting up, installing,
and commissioning the appliance.
This prevents both personal injury and damage to the appliance.
en-CA M.-Nr. 11 823 010

Contents
2
Warnings and safety instructions .................................................................... 5
Preparing your appliance for an extended vacation....................................... 13
Guide to the appliance ..................................................................................... 16
Controls and indicators .................................................................................... 18
Using the appliance........................................................................................... 20
Symbols in the display ........................................................................................ 22
Initial commissioning ........................................................................................ 23
Miele@home ........................................................................................................ 23
Before using for the first time.............................................................................. 24
Switching on for the first time ............................................................................. 24
Filling the bean containers ............................................................................... 26
Filling the water container................................................................................ 27
Switching on and off ......................................................................................... 28
Spout adjustment .............................................................................................. 29
Preparing drinks ................................................................................................ 30
Making coffee with and without milk................................................................... 30
Milk preparation................................................................................................... 31
Making a coffee drink.......................................................................................... 32
Cancelling a drink................................................................................................ 32
DoubleShot.......................................................................................................... 32
Making2portions (sensor button) ................................................................. 32
Coffee jug ............................................................................................................ 33
Tea....................................................................................................................... 33
TeaTimer......................................................................................................... 34
Making tea...................................................................................................... 34
Tea pot............................................................................................................ 35
Dispensing warm or hot water ............................................................................ 36
............................................................................................................................ 37
Grinder setting................................................................................................... 38
Parameters......................................................................................................... 39
Displaying and changing parameters.................................................................. 39
Portion size.......................................................................................................... 39
Quantity of coffee................................................................................................ 40
Brewing temperature ........................................................................................... 40

Contents
3
Pre-brewing the ground coffee............................................................................ 40
Profiles................................................................................................................ 41
Creating a profile ................................................................................................. 41
Changing drinks within a profile.......................................................................... 41
Making drinks stored in a profile ......................................................................... 41
Editing profiles..................................................................................................... 41
Setting when the profile should change......................................................... 41
Changing the name ........................................................................................ 42
Deleting a profile ............................................................................................ 42
MobileStart......................................................................................................... 43
Settings .............................................................................................................. 44
Displaying and changing Settings....................................................................... 44
Language............................................................................................................. 44
Time of day.......................................................................................................... 44
Date ..................................................................................................................... 44
Timer ................................................................................................................... 44
On at............................................................................................................... 44
Off at............................................................................................................... 45
Off after .......................................................................................................... 45
TeaTimer.............................................................................................................. 45
Volume................................................................................................................. 45
Display brightness............................................................................................... 45
Lighting................................................................................................................ 45
Info (display information) ..................................................................................... 45
Altitude ................................................................................................................ 45
Performance Mode.............................................................................................. 45
Eco Mode ....................................................................................................... 46
Barista Mode .................................................................................................. 46
Latte Mode ..................................................................................................... 46
Party Mode ..................................................................................................... 46
Water hardness ................................................................................................... 46
System lock.................................................................................................... 47
Miele@home ........................................................................................................ 48
Remote control.................................................................................................... 48
RemoteUpdate .................................................................................................... 48
Software version.................................................................................................. 49
Showroom program (demo mode) ...................................................................... 49
Factory default settings....................................................................................... 49
Cleaning and care ............................................................................................. 50
Overview of cleaning intervals............................................................................. 50

Contents
4
Cleaning by hand or in the dishwasher............................................................... 51
Unsuitable cleaning agents ................................................................................. 52
Cleaning the drip tray and grounds container..................................................... 53
Cleaning the drip tray cover ................................................................................ 54
Cleaning the water container .............................................................................. 55
Cleaning the central spout .................................................................................. 55
Cleaning the cup rim sensor ............................................................................... 57
Cleaning the milk container with lid .................................................................... 57
Cleaning the milk valve (daily) ............................................................................. 58
Removing and cleaning the milk valve (once a month)....................................... 58
Cleaning the bean containers.............................................................................. 61
Cleaning the interior, inside of the appliance door, and drip tray........................ 62
Cleaning the appliance front ............................................................................... 63
Maintenance programs........................................................................................ 63
Rinse appliance................................................................................................... 63
Rinse milk pipework ............................................................................................ 64
Degreasing the brew unit and cleaning the interior............................................. 64
Descaling the appliance ...................................................................................... 67
Frequently Asked Questions ............................................................................ 69
Messages in the display...................................................................................... 69
Unusual performance of the coffee machine ...................................................... 72
Unsatisfactory results.......................................................................................... 75
Service and warranty ........................................................................................ 77
Contact in the event of a fault ............................................................................. 77
Warranty .............................................................................................................. 77
Accessories ....................................................................................................... 78
Caring for the environment .............................................................................. 79
Installation.......................................................................................................... 80
Electrical connection ........................................................................................... 80
Installation dimensions........................................................................................ 81
Building in the coffee machine............................................................................ 83

Warnings and safety instructions
This coffee machine complies with all current local and national
safety requirements. Inappropriate use can, however, lead to
personal injury and material damage.
Read the operating instructions carefully before using the coffee
machine. They contain important notes on installation, safety,
operation, and maintenance. This prevents both personal injury
and damage to the coffee machine.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises you to read and follow the instructions in the
chapter on installing the coffee machine as well as the safety
notes and warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating instructions in a safe place and pass them
on to any future owner.
5

Warnings and safety instructions
Appropriate use
 This coffee machine is intended for home use.
 The coffee machine is not suitable for outdoor use.
 This coffee machine must not be used at altitudes above 2,000m.
 The machine is intended only for domestic use and for the
preparation of drinks such as espresso, cappuccino, latte macchiato,
tea, etc. All other types of use are not permitted.
 This coffee machine can only be used by people with reduced
physical, sensory, or mental capabilities or lack of experience and
knowledge if they are supervised whilst using it.
They may only use the coffee machine without supervision if they
have been shown how to use it in a safe manner. They must be able
to recognize and understand the possible consequences of incorrect
operation.
6

Warnings and safety instructions
Safety with children
Danger of burning and scalding on the dispensing spouts.
Children’s skin is far more sensitive to high temperatures than that
of adults.
Ensure children do not touch hot surfaces of the coffee machine or
place parts of their body under the dispensing spouts.
 Install the coffee machine where it is out of the reach of children.
 Children under 8years of age must be kept away from the coffee
machine unless they are constantly supervised.
 Children aged 8and older may only use the coffee machine
without supervision if they have been shown how to use it in a safe
manner.
Children aged 8and older must be aware of the potential dangers
caused by incorrect operation.
 Children should be supervised in the vicinity of the coffee
machine. Never allow children to play with the appliance.
 Keep in mind that espresso and coffee are not suitable drinks for
children.
 Danger of suffocation. While playing, children may become
entangled in packaging material (such as plastic wrapping) or pull
the packaging material over their head, presenting the risk of
suffocation. Keep packaging material away from children.
7

Warnings and safety instructions
Technical safety
 Installation work or repairs should only be carried out by a Miele
authorized technician. Unauthorized or incorrect installation work or
repairs can pose considerable danger to users.
 Damage to the coffee machine can compromise your safety.
Before installing the appliance, check it for visible signs of damage.
Do not use the appliance if it is damaged.
 Before connecting the coffee machine, make sure that the
connection data on the data plate (voltage and frequency) matches
that of the domestic electrical supply.
This data must match to prevent the coffee machine from being
damaged. Consult a qualified electrician if in any doubt.
 The electrical safety of this coffee machine can only be
guaranteed when correctly grounded. It is essential that this basic
safety requirement is fulfilled. If in doubt, the electrical installation
should be checked by a qualified electrician.
 Reliable and safe operation of the coffee machine can only be
guaranteed if it is connected to the domestic electrical supply.
 Do not connect the coffee machine to the domestic electrical
supply using a multi-socket adapter or an extension cord. These do
not guarantee the required safety of the appliance (risk of fire).
 The coffee machine may not be used in mobile installations such
as ships.
 For safety reasons, this machine may only be used when it has
been built in.
 Unplug the coffee machine from the domestic electrical supply
immediately if you notice any damage or smell scorching, for
example.
 Ensure that the power supply cable will not be pinched or
damaged by any sharp edges.
8

Warnings and safety instructions
 To reduce the risk of injury, do not drape cord over the counter
top or table top where it can be pulled on by children or tripped over
unintentionally.
 Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or has been damaged in any
manner. Return appliance to the nearest authorized service facility
for examination, repair or adjustment.
 To protect against fire, electric shock and injury to persons do not
immerse cord or plugs in water or other liquid.
 To reduce the risk of fire:
- Do not place any heating or cooking appliance beneath the
appliance without a shelf in between.
- Do not mount unit over or near any portion of a heating or
cooking appliance without a shelf in between.
- Do not mount over a sink.
- Do not store anything directly on top of the appliance surface
when the appliance is in operation.
 If the coffee machine is to be built in above another appliance,
there must be a full-width, closed shelf between them (except when
it is combined with a suitable built-in dishware/food warming
drawer).
 Do not place on or near a hot gas or electric burner, or in a heated
oven.
 Only use the coffee machine in rooms where the ambient
temperature is between +60°F (16°C) and + 100°F (38°C).
 A minimum installation height of 850mm must be observed.
 This coffee machine must not be installed behind a closed cabinet
door front. Heat and moisture can build up behind the cabinet door
front when closed. This can result in damage to the machine and/or
cabinetry.
9

Warnings and safety instructions
 For repairs, the coffee machine must be disconnected from the
domestic electrical supply.
The coffee machine is only disconnected from the domestic
electrical supply if
- the circuit breaker has been tripped.
- the fuse is removed.
- the power supply cable has been unplugged.
To do this, pull only the plug, not the power supply cable.
 While the coffee machine is under warranty, repairs should only
be undertaken by a service technician authorized by Miele Service.
Otherwise the warranty will be invalidated.
 Do not open the coffee machine housing under any
circumstances. Any contact with live connections or tampering with
the electrical or mechanical components of the coffee machine will
endanger your safety and may lead to appliance malfunctions.
10

Warnings and safety instructions
Correct use
Danger of burning and scalding on the dispensing spouts.
The liquids and steam dispensed are very hot.
Keep away from the area underneath the spouts when hot liquids
and steam are being dispensed.
Do not touch hot components.
Hot liquid or steam could spatter from the nozzles. Ensure that the
central spout is clean and installed correctly.
Before opening the door, remove any containers from the drip tray
in the door.
Water in the drip tray can also be very hot. Take care when
emptying it.
Risk of injury to the eyes!
Never look directly at the lighting or use optical instruments (e.g.,
magnifying glass) to look at it.
 Please note the following regarding water:
- The water quality must conform to the requirements for drinking
water in the country in which the coffee machine is being used.
- Only use cold, fresh tap water to fill the water container. Hot or
warm water or other liquids can damage the coffee machine.
- Change the water every day to prevent a build-up of bacteria.
- Do not use sparkling water.
 Only put roasted coffee beans in the bean containers. Do not
place coffee beans which have been treated with additives or ground
coffee inside the bean containers.
 Do not fill the bean containers with any type of liquid.
11

Warnings and safety instructions
 Do not use green (unroasted) coffee beans or mixtures of coffee
beans which contain green coffee beans. Green coffee beans are
very hard and still contain residual moisture. These can damage the
coffee machine grinder as soon as grinding begins.
 Do not use coffee beans that have been treated with sugar,
caramel, or other substances and do not put liquids containing sugar
in the coffee machine. Sugar will damage the appliance.
 The milk used must not contain any additives. Most additives
contain sugar which would stick to the milk pipework.
 If using dairy milk make sure that it has been pasteurized.
 When making tea, please follow the instructions on the tea
packaging.
 Do not place flaming alcohol mixtures underneath the central
spout. The flames could ignite plastic components and cause them
to melt.
 Do not hang on to the open appliance door or place any objects
on it as this will damage the hinges of the coffee machine.
 Do not use the coffee machine to clean any other objects.
12

Warnings and safety instructions
Preparing your appliance for an extended vacation
 If you elect to turn off the water to your home for an extended
period of time, please note that this may not be enough to reduce
the risk of a leak. To be completely safe, you must turn off the water
supply to each individual appliance. This means under the sink for a
dishwasher, at the laundry bib for your washer, etc.
Accessories and spare parts
 Only use original Miele accessories. If other parts are used,
warranty, performance, and/or product liability claims will be
invalidated.
 The use of accessory attachments not recommended by the
appliance manufacturer may result in fire, electric shock or injury to
persons.
 Miele can only guarantee the safety of the appliance when original
Miele parts are used. Faulty components must only be replaced with
genuine Miele replacement parts.
 Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the
discontinuation of your coffee machine.
Cleaning and care
 Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking off parts, and before cleaning the
appliance.
 Clean the coffee machine and the milk container daily, particularly
before using for the first time.
 Ensure that all components in which milk is transported are
cleaned carefully on a regular basis. Milk naturally contains bacteria
that rapidly multiply if the milk pipework is not cleaned properly.
13

Warnings and safety instructions
 Degrease the brew unit regularly with the cleaning tablets.
Depending on the natural oil content of the coffee used, the brew
unit can become blocked quite quickly.
 Do not use a steam cleaner to clean the appliance. The steam
could reach live electrical components and cause a short circuit.
 The espresso/coffee grounds must be disposed of in the organic
waste or compost, not in the sink. The drain can clog up as a result.
14

Warnings and safety instructions
For coffee machines with stainless steel surfaces:
 Do not use sticky notes, adhesive tape, or other types of adhesive
on the stainless steel surfaces. These will damage the stainless steel
surfaces, causing them to lose their dirt-repellent protective coating.
 The finish on stainless steel surfaces is susceptible to scratching.
Even magnets can cause scratches.
SAVE THESE INSTRUCTIONS
15

Guide to the appliance
Exterior view
aOn/Off button
bControl panel
cDoor handle
dHeight-adjustable central spout with lighting
eDrip tray cover
fMilk container
16

Guide to the appliance
Interior view
aBean container
bMilk valve
cHeight-adjustable central spout with lighting
dGrinder setting
eBean container
fFan outlet
gWater container
hDrip tray with lid
iBrew unit
jGrounds container
kMaintenance container
lDrip tray
17

Controls and indicators
18
6
aOn/Off button
For switching coffee machine on and
off
bDrink buttons
For making drinks
cDisplay
For showing information about the
current action or status
dsensor button
– For making other drinks, e.g.,
ristretto, cappuccino italiano
– For making a pot of tea or coffee
–Settings  menu
eProfiles sensor button
For creating and managing profiles
fMaintenance sensor button
Maintenance programs, e.g.,Descale
gParameters sensor button
For displaying or changing drink
settings
hOKsensor button
For confirming display messages and
saving settings
iNavigation area with arrow
buttons
For scrolling through lists, selecting
entries, or changing values
j“Back”sensor button
For returning to the previous menu
and cancelling unwanted actions
k“2portions”sensor button
For dispensing 2portions of a drink
at once
l“DoubleShot”sensor button
For making a particularly strong and
aromatic coffee by using twice as
much ground coffee but the same
amount of water
mOptical interface
(for Miele Service only)

Controls and indicators
19
Drink button symbols
Espresso
Coffee
Long coffee
Cappuccino
Latte macchiato
Caffè latte
Hot milk
Milk froth
Tea water

Using the appliance
20
Sensor buttons
To operate the coffee machine, tap the
sensor buttons with your finger.
An audible signal is generated each
time a button is tapped. You can
adjust the volume of the signal tones
or switch the tones off (see “Settings –
Volume”).
Drinks menu
When the following appears in the
display, you are in the drinks menu:
Select drink.
Select drink
Miele 12:00
You can find more drinks in the
Additional menu (sensor button).
Navigation area
To select a menu option, keep pressing
the arrow buttons and until the
option you want is highlighted.
To scroll more quickly through the
options, swipe your finger right or left in
the area between the arrows.
As soon as you reach a confirmable
value, message, or setting, the
OKsensor button will light up orange.
Touch theOK sensor button to confirm
your selection.
Selecting a menu and
navigating within a menu
To select a menu, tap the relevant
sensor button, e.g., the sensor
button.
Ristretto
Cappuccino Italiano
Settings 
Miele 12:00
You will then be able to start an action
or change settings in the menu. A scroll
bar at the right of the display shows
that additional options or text are
available.
The setting which is currently selected
in a list will have a check beside it.
Exiting a menu or cancelling an
action
To exit the current menu, touch the
sensor button.
Alternatively, tap the lit orange sensor
button again to return to the drinks
menu.
Entering a name
Letters and numbers are entered via the
navigation area. You can choose
between upper and lower case letters.
