Miele KM 451 User manual

Operating Instructions
Ceramic Cooktop
KM 451
To prevent accidents and
machine damage,
read these instructions
before installation or use.
UV
M.-Nr. 05 361 900

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Help protect our environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disposal of packing materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disposal of an old appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Gui e to the cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cooking zone controls and displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cooking zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Clean the cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Heat the cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Touch controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Using the cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Turning on the cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Turning on a burner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cooking without auto heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cooktop settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Auto heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Turning on an extended cooking zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Turning off a cooking zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To turn off the cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Safety locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Child safety lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Safety cut-out feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Overheating protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Selecting cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
The cooking surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
To set the timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Automatically turning off a cooking zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Cooktop care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Frequently aske questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Technical Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Contents
2

READ THE OPERATING
INSTRUCTIONS CAREFULLY
BEFORE USING THE
COOKTOP
WARNING -
This appliance is only inten e
for resi ential cooking. The
manufacturer can not be hel
responsible for amage or
injury cause by improper use
or for uses other than those for
which this appliance is
inten e .
When using your appliance, follow
basic safety precautions including
the following:
Installation
Be certain your appliance is
properly installed and grounded by
a qualified technician in accordance
with national and local safety
regulations. The manufacturer cannot be
held responsible for damage caused by
an incorrect installation or connection.
To guarantee the electrical safety
of this appliance, continuity must
exist between the appliance and an ef-
fective grounding system. It is impera-
tive that this basic safety requirement is
met. If there is any doubt, have the
electrical system of the house checked
by a qualified electrician.
The manufacturer cannot be held
responsible for damages caused by the
lack, or inadequacy of, an effective
grounding system.
Do not connect the appliance to
the main electrical supply using an
extension cord. Extension cords do not
meet the safety requirements of this
appliance.
Before servicing, disconnect the
power supply by either shutting off
the power main or manually "tripping"
the circuit breaker.
IMPORTANT SAFETY INSTRUCTIONS
3

Do not install the cooktop directly
above a dishwasher, refrigerator or
freezer. Heat radiated by the cooktop
may damage them.
If the cooktop is installed above an
oven, keep the cooktop’s power
cord from contacting the oven.
Because of the heat radiated it is
not recommended to install the
cooktop above a drawer. It should only
be installed above a cabinet base unit
with a dummy drawer front and an
additional protective base between the
appliance and the cabinet.
This equipment has not been
designed for maritime use or for
use in mobile installations such as
aircraft or recreational vehicles.
However, under certain circumstances
it may be possible for an installation in
these applications. Please contact the
nearest Miele Dealer or the Miele
Technical Service Department with
specific requirements.
Use
Do not use the appliance until it is
properly installed in the countertop.
This appliance is equipped with an
overheating protection feature.
See, "Overheating protection" for
information.
Never use the appliance to warm
or heat the room. Due to the high
temperatures radiated objects left near
the appliance could catch fire.
IMPORTANT SAFETY INSTRUCTIONS
4

Protection from amage
Do not drop anything on the
ceramic surface of the cooktop.
Although the ceramic glass is shock
and scratch resistant, it is not shock or
scratch proof.
Do not use pots or pans with
pronounced edges or ridges on
the ceramic cooktop. These could
scratch the cooktop permanently. See
"Selecting cookware" for more
information. Grains of salt and sand can
also scratch. Make sure that the bases
of any pots and pans are clean, free of
any fat or oils and are dry.
Do not allow either solid or liquid
sugar, pieces of plastic or foil to fall
on the burners when they are hot. If
these residues are allowed to cool on
the ceramic surface pitting or even
cracking could occur.
Any spills should be removed as
quickly as possible to prevent them
from burning on and becoming difficult
to remove.
Do not use a steam cleaner to
clean the appliance. Steam could
penetrate electrical components and
cause a short circuit.
Never place hot pots or pans over
the touch controls, as the
underlying electronics may be
damaged.
To prevent damage to the cooktop
do not use pans with thin bases on
this cooktop. Never heat an empty pan
unless the pan manufacturer states that
you can do so.
IMPORTANT SAFETY INSTRUCTIONS
5

Injury prevention
Do not touch the cooktop or the
surrounding areas during or
immediately after use. The cooktop may
be hot even though it is dark in color.
Areas near it may become hot enough
to cause burns. Do not touch, or let
clothing or other flammable materials
touch the cooktop or areas near it until
they have cooled. Wait until the residual
heat indicators go out.
Children should not be left alone or
unattended in an area where a
cooktop is in use. Never allow children
to sit or stand on any part of the
cooktop.
Caution: Do not store items of interest
to children in cabinets above a
cooktop. Children climbing on the
cooktop to reach these items could be
injured.
Protect your hands with insulated
gloves or potholders when using
the appliance. Use only dry, heat
resistant potholders. Moist or damp
potholders used on hot surfaces can
result in steam burns. Do not let the
potholder touch the hot heating
element. Do not use towels or other
bulky items near the appliance.
To prevent burns and breathing
difficulty, allow the cooktop to cool
before cleaning. Some cleaners may
produce toxic fumes if applied to a hot
surface.
Keep all pans out of reach of
children. Danger of burns!
Pot and pan handles should be
turned inward and not extend over
the countertop to reduce the risk of
burns, ignition of flammable materials,
and spills.
Use the proper pan size. Select
cookware having flat bottoms large
enough to cover the heating element.
Using undersized cookware will expose
a portion of the heating element to
direct contact and may result in ignition
of clothing or handles becoming hot.
The proper size pot or pan will also
improve effeciency.
Before using glass, glass/ceramic,
ceramic, earthenware or other
glazed cookware on the cooktop, verify
that they can be used on a cooking
surface.
Do not heat unopened food
containers. Built-up pressure may
cause the container to burst and result
in injury.
At higher settings, be cautious of
splattering grease or boiling over
liquids, which may produce smoke.
IMPORTANT SAFETY INSTRUCTIONS
6

Before removing pots and pans, be
sure to turn off the burners.
Do not store items on the cooktop
when not in use. Items could melt
or catch fire from residual heat or if the
cooktop is turned on inadvertently.
Never cover the cooktop with a
cloth. A fire could result.
Never leave a cooktop unattended
when cooking with oil or fat.
Overheated oil could ignite. Always
heat oil slowly, monitoring it as it heats.
Do not use water on grease fires.
Smother any fire or flame, or use a
dry chemical or foam-type extinguisher.
When frying food, make sure that
the food is as dry as possible
before placing it in the oil. Moisture can
cause hot oil to splatter and boil over.
Do not flambé under an exhaust
hood. Flames could be drawn up
into the hood by the suction or the
grease filters may ignite.
Do not let cooking grease or other
flammable materials accumulate
on the appliance.
Be aware of loose fitting or hanging
garments when operating the
cooktop, they may present a fire
hazard.
Flammable materials should not be
stored on or near the appliance.
If there is a drawer directly
underneath the appliance without
any wooden base in between, ensure
that no aerosols, combustible liquids or
other easily flammable materials are
kept in it. If cutlery inserts are to be
placed in the drawer, they must be
made of heat-resistant material.
IMPORTANT SAFETY INSTRUCTIONS
7

Appliance safety
In the event of any damage to the
appliance, it must be turned off
immediately and disconnected from the
electricity supply by either shutting off
the power main or manually "tripping"
the circuit breaker. Contact Technical
Service.
Do not use the appliance until it has
been repaired. Ensure power is not
supplied to the appliance until repair
work is completed.
Do not cook on a broken cooktop.
Any breakages or cracks in the
ceramic surface of the appliance are
defects and must be treated as such. If
the cooktop should break, cleaning
solutions and spills may penetrate the
broken cooktop and create a risk of
electric shock.
Do not use the appliance until it has
been repaired.
Repairs should only be performed
by qualified technicians to ensure
safety. Repairs and other work by
unqualified persons could be
dangerous. Under no circumstances
open the outer casing of the appliance.
While the appliance is under
warranty repairs should only be
performed by an authorized service
technician. Otherwise the warranty is
void.
Further safety notes
Make certain that the power cords
of small appliances do not come in
contact with the cooktop. Danger of
electric shock!
Always make sure food is cooked
thoroughly before eating.
Only use cookware suitable for the
range-top. Unsuitable cookware
may break due to sudden temperature
changes.
Do not use plastic or aluminium
containers. They will melt at high
temperatures. Fire hazard!
Do not allow children to operate or
play with or near the cooktop.
If a pet hops onto the cooktop, a
touch control sensor could be
activated turning on a burner. Keep
pets away from the cooktop at all times
and activate the child safety lock.
Before discarding an old
appliance, remove the power cord
to prevent hazards.
SAVE THESE INSTRUCTIONS AND
REVIEW THEM PERIODICALLY
IMPORTANT SAFETY INSTRUCTIONS
8

Disposal of packing materials
The cardboard box and packing
materials are biodegradable and
recyclable. Please recycle.
Disposal of an ol appliance
Old appliances contain materials that
can be recycled. Please contact your
local recycling authority about the
possibility of recycling these materials.
Before discarding an old appliance,
disconnect it from the gas and
electrical supply and cut off the
power cord to prevent it from
becoming a hazard.
Help protect our environment
9

Cooktop
abd Single zone
cExtended zone
eVariable zone
fControl panel
Gui e to the cooktop
10
u
u
s
s
s
s
s
o
a
b
aedf
c

Control panel
Touch controls for:
gCooking zone controls
(see section "Cooking zone controls
and displays")
iChild safety lock
jCooktop ON/OFF
kTimer
(see "Cooking zone controls and
displays")
In icator for:
hChild safety lock, indicator
Gui e to the cooktop
11

Cooking zone controls an
isplays
Touch controls:
lCooktop ON/OFF
mfor selecting the power settings and
turning on the outer circle of the
variable zone or extended zone
Displays
nExtended cooking zone on
o0= Ready for use
1-12 = Power setting
~,|or #= Residual heat
F= Fault (see, "Safety
cut-out feature")
pLight ring: the number of segments lit
corresponds to the selected power
setting
(exception: see "Cooking with
Auto-heat").
Timer:
Kitchen timer or automatic shut off for
rear left wand front left yzones
qTime display
rTouch controls for setting the timer
Gui e to the cooktop
12
s
o
m
n
p
o
q
s
o

Cooking zones
Cooking
zone
KM 451
ø in inches (cm) Rating in watts
y53/4(14.5) 1200
w81/4(21) 2000
x63/4(17) /
63/4x 10 1/2(17 x 26.5)
1400 /
2200
z53/4(14.5) 1200
v43/4(12) /
71/16 (18)
700 /
1700
Total: 8300
All cooking zones have the auto heat and safety cut-out feature.
Gui e to the cooktop
13

Clean the cooktop
Before using for the first time, clean the
cooktop with a damp cloth and then dry
with a soft cloth.
Heat the cooktop
The metal components of the cooktop
have a protective coating which may
give off a slight odor the first time the
appliance is heated.
The smell will dissipate after a short
time and does not indicate a faulty
connection or appliance defect.
Touch controls
This cooktop has electronic touch
controls activated by a finger. There is a
separate touch control for each burner.
A tone sounds to indicate that contact
has been made with a control.
Keep the control area clean and do not
rest things on it. The touch control
sensors could mistake an item or debris
for a finger tip contact, turning the
cooktop on or off.
To prevent damage to the
electronics never place hot pans on
the control panel.
Before using for the first time
14

Turning on the cooktop
The cooktop must be turned on before
any of the burners can be used.
^Touch the s"ON / OFF" touch control
for the cooktop.
A horizontal bar will appear in each of
the burner displays and 00 will appear
in each timer display.
The cooktop is now on and the burners
are ready for use. The burners will not
heat until a power setting has been
chosen.
If a setting is not chosen within 30
seconds the cooktop will turn itself off
as a safety measure.
Turning on a burner
^Once the cooktop is turned on, touch
the s"ON/OFF" control of the burner
you wish to use.
A0will appear in the burner display.
^Select the desired setting between 1
and 12 by touching the -or +touch
controls.
Make sure to touch only one of the
controls at a time or they will not
respond.
When turning on the cooktop you can
decide whether you want to cook with
auto heat (see, "Auto heat" for more
information) or not:
Turn on with + to:
Cook without auto heat
Turn on with – to:
Cook with auto heat
Using the cooktop
15

Cooking without auto heat
Procee as follows:
^If 0is showing in the display, keep
the +touch control pressed until the
desired power setting shows in the
display, e.g. 4:
The same number of segments, p, will
show in the light ring, i.e. if setting 4is
selected four segments will light up.
Using the cooktop
16
q
4

Cooktop settings
The range of settings is the same for all cooking zones:
Cooking process Settings
Melting butter, chocolate etc.
Dissolving gelatin
1 - 2
Thickening sauces containing egg yolk and butter
Warming small quantities of food/liquid
Warming sticky foods
Cooking rice
1 - 3
Warming liquid and half-set foods
Thickening sauces, e.g. Hollandaise
Cooking rice pudding
Preparing omelettes, lightly fried eggs
Steaming fruit
3 - 5
Defrosting deep frozen food
Steaming vegetables, fish
Cooking dumplings, potatoes, soups
Cooking broths
4 - 6
Boiling and continued cooking of large
quantities of food
7
Gentle braising (without overheating the fat) of meat, fish,
vegetables, fried eggs etc.
8 - 9
Frying pancakes etc. 9 - 11
Boiling large quantities of water 11 - 12
These setting recommendations are only intended as a guide. With deep pans,
large quantities or without the lid on, a higher setting is needed. With smaller
quantities select a lower setting.
Using the cooktop
17

Auto heat
When auto heat has been activated, the
cooking zone turns on automatically at
the highest setting and then changes to
the continued cooking setting which
you have previously selected. The
"heat-up" time depends on which
continued cooking setting has been
chosen (see table).
Continue
cooking setting
Heat-up time
in minutes
1 0.5
2 2.0
3 2.5
4 3.0
5 4.0
6 6.0
7 9.0
8 2.0
9 2.0
10 2.5
11 2.5
12 -
How to activate auto heat:
^If 0shows in the display, touch the -
touch control until the continued
cooking setting you want appears in
the display e.g. 3.
The 12 segments show in the light ring,
p, during the auto heat time. When the
heat-up time has finished only the
number of segments, for the relevant
continue cooking setting which has
been chosen, show in the light ring.
Example:
during the auto heat time:
during the continued cooking time:
You can increase or decrease the
continued cooking setting at any time
during the auto heat time with the +or -
touch controls. The heat-up time will
adjust accordingly.
How to turn off auto heat before the
heat-up time has finishe :
^Set the display to 0.
^Then select the setting you want to
continue using by pressing the +
touch control.
Using the cooktop
18
3
s
q
3
s
q

Turning on an exten e
cooking zone
The second circle of a variable cooking
zone or the extended cooking zone can
be turned on to extend the cooking
area for cooking with larger pans.
Procee as follows:
^Turn on the cooking zone and select
a power setting.
^Press the -and +touch controls
simultaneously.
When 0appears in the cooking zone
display the extended cooking zone can
be turned on by pressing the -and +
touch controls simultaneously and
then selecting a power setting.
A short segment ,n, will appear in the
top left of the ring to indicate that the
extended cooking zone has been
turned on.
To turn the extended cooking zone off,
press the -and +touch controls
simultaneously. The short segment,
n, will then go out.
Turning off a cooking zone
^Touch the ON / OFF control sof the
cooking zone you want to turn off.
If the cooking zone is still hot, the
residual heat indicator will remain lit
until the zone has cooled (see "Residual
heat indicator").
Using the cooktop
19
5
s
o
o

To turn off the cooktop
The cooktop can be turned off at any
time.
^Touch the ON / OFF touch control s
of the cooktop.
This turns off all cooking zones. The
residual heat indicator will light up in
the display of any cooking zone that is
still hot.
Resi ual heat in icator
After the cooking zones or the cooktop
have been turned off, the residual heat
of the cooking zones which may still be
hot are indicated by three stacked
horizontal bars in the display:
The bars go out one after another as
the cooking zones cool down. The last
bar only goes out when the cooking
zones are safe to touch.
If there is an interruption to the
power supply the residual heat
indicators will flash on and off.
Using the cooktop
20
