Miele KM 6002 User manual

Operating and Installation Instructions
Ceramic cooktops
To avoid the risk of accidents or damage to the appliance it is
imperative that you read these instructions before
installing the appliance and using it for the first time
.
en-CA M.-Nr. 10 171 920

Contents
2
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 4
Caring for the environment ................................................................................ 12
Overview............................................................................................................... 13
Cooktop................................................................................................................. 13
Burner data............................................................................................................ 14
Initial commissioning .......................................................................................... 15
Cleaning the cooktop for the first time.................................................................. 15
Turning on the cooktop for the first time ............................................................... 15
How the burners work ........................................................................................ 16
Cookware ............................................................................................................. 17
Energy saving tips .............................................................................................. 18
Power setting ranges .......................................................................................... 19
Operation.............................................................................................................. 20
Burner control knobs............................................................................................. 20
Switching on.......................................................................................................... 20
Switching off.......................................................................................................... 20
Residual heat indicator.......................................................................................... 20
Switching on second heating zones ..................................................................... 21
Overheat protection ............................................................................................ 22
Cleaning and care ............................................................................................... 23
Frequently Asked Questions .............................................................................. 25
Optional accessories .......................................................................................... 27
Safety instructions for installation..................................................................... 28
Safety clearances ................................................................................................ 29
Bottom cover panel............................................................................................. 32
Instructions for installation ................................................................................ 33
Installation dimensions....................................................................................... 34
Installation............................................................................................................ 35
Connecting the cooktop ..................................................................................... 37

Contents
3
Electrical connection .......................................................................................... 38
Service.................................................................................................................. 39
Contact in case of a fault ...................................................................................... 39
Data plate .............................................................................................................. 39
Warranty ................................................................................................................ 39

IMPORTANT SAFETY INSTRUCTIONS
4
This appliance conforms to current safety requirements. However,
improper use can result in personal injury and damage to property.
To prevent accidents and damage to the cooktop, please read
these instructions carefully before using the cooktop for the first
time. They contain important notes on installation, safety, use and
maintenance.
Miele cannot be held liable for damage occurring as a result of
non-compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owners.

IMPORTANT SAFETY INSTRUCTIONS
5
Intended use
 This cooktop is intended for domestic use and use in other similar
environments.
 This cooktop is not intended for outdoor use.
 The cooktop is intended to prepare food and keep it warm in
domestic use only. Any other use may be hazardous.
 Persons who are unable to safely operate the cooktop due to
limited physical, sensory or mental abilities or because they lack
experience or knowledge may only use the appliance if they are
supervised while doing so. These persons may only use the cooktop
without supervision if they have been shown how to use it in a safe
manner, and if they are able to recognize and understand the
potential risks of improper use.

IMPORTANT SAFETY INSTRUCTIONS
6
Safety with children
 Children under 8 years of age must be kept away from the
cooktop unless they are constantly supervised.
 Children ages 8 and up may only use the cooktop without
supervision if they have been shown how to use it in a safe manner,
and if they are able to recognize and understand the potential risks
of improper use.
 Children must not be allowed to clean the cooktop without
supervision.
 Be sure to supervise any children in the vicinity of the cooktop,
and do not let them play with it.
 The cooktop gets hot when in use and remains hot for some time
after being switched off. Keep children away from the cooktop until it
has cooled down and is no longer a burn hazard.
 Burn hazard.
Keep the spaces above and behind the cooktop clear of any items
that could draw the attention of children. Otherwise, they can be
tempted into climbing onto the appliance.
 Risk of burning or scalding.
Turn all handles away from the front of the cooktop so that children
cannot pull pots and pans down and burn themselves.
 Risk of suffocation. Children may be able to wrap themselves in
packaging material or pull it over their heads and risk suffocation.
Keep children away from all packaging materials.

IMPORTANT SAFETY INSTRUCTIONS
7
Technical safety
 Installation, maintenance and repair work should only be
performed by a Miele authorized service technician. Installation,
maintenance and repair work by unqualified persons can cause
considerable danger to users.
 A damaged cooktop can be dangerous. Always check for visible
signs of damage. Never use a damaged appliance.
 Reliable and safe operation of the cooktop can only be
guaranteed if it is connected to the public power supply.
 The electrical safety of this cooktop can only be guaranteed when
it is properly grounded. Compliance with this essential safety
requirement is absolutely necessary. If in any doubt, please have the
building's electrical system checked by a qualified electrician.
 To avoid damaging the cooktop, make sure that the connection
data (voltage and frequency) on the data plate correspond to the
building's power supply before connecting the appliance.
When in doubt, consult a qualified electrician.
 The cooktop may only be combined with the ovens specified by
Miele. The manufacturer cannot guarantee trouble-free operation if
the cooktop is used in combination with any other appliances. Doing
so will void the warranty.
 For safety reasons, the cooktop may only be used when it has
been fully installed.
 This cooktop must not be used in non-stationary locations (e.g. on
a ship).
 Any contact with live connections or tampering with the electrical
or mechanical components of the cooktop will endanger your safety
and may lead to cooktop malfunctions.
Do not open the casing of the cooktop under any circumstances.

IMPORTANT SAFETY INSTRUCTIONS
8
 Any repairs not performed by a Miele authorized service
technician will void the warranty.
 Miele can only guarantee the safety of the appliance if genuine
Miele spare parts are used. Defective components must only be
replaced by genuine Miele spare parts.
 The appliance is not intended for use with an external timer switch
or a remote control system.
 The cooktop must be connected to the oven by a qualified
electrician (see "Electrical connection").
 During installation, maintenance, and repair work, the cooktop
must be completely disconnected from the household electricity
supply. It is only completely isolated from the electricity supply
when:
– The main circuit breaker has been tripped, or
– The plug fuses have been fully unscrewed (where applicable).
 Danger of electric shock!
Do not use the cooktop if it is faulty, or if the ceramic surface is
cracked, chipped, or damaged in any way. Switch it off immediately.
Disconnect the cooktop from the electrical power supply. Contact
Miele Technical Service.
 If the cooktop is installed behind a cabinet door, do not close the
door while the cooktop is in operation. Heat and moisture can build
up behind the closed door. This can result in damage to the cooktop,
cabinet carcase, and floor. Do not close the door until the residual
heat indicators go out.

IMPORTANT SAFETY INSTRUCTIONS
9
Proper use
 The cooktop gets hot when in use and remains hot for a while
after being turned off. A burn hazard is present until the residual heat
indicators go out.
 When in use, the cooktop emits a significant amount of heat,
which could cause objects in the vicinity to catch fire.
Never use the cooktop to heat the room.
 Oil and fat can catch fire if overheated. Never leave the cooktop
unattended when cooking with oil and fat. If the oil or fat catches
fire, do not attempt to put the flames out with water.
Turn off the cooktop and smother the flames using a lid or a suitable
fire blanket.
 The flames could set the grease filters of a ventilation hood on fire.
Do not flambé under a hood.
 Spray canisters, aerosols and other flammable substances can
ignite when heated. Therefore, do not store such items or
substances in a drawer under the cooktop. Any cutlery inserts must
be heat-resistant.
 Never heat empty cookware.
 Do not heat or can food in closed containers, such as tins or
sealed jars, on the cooktop, as pressure will build up in the container
and cause it to explode.
 If the cooktop is covered, there is a risk that the material of the
cover will ignite, explode or melt if the cooktop is still hot or if it is
turned on inadvertently. Never cover the appliance with a cover,
cloth or protective foil.
 If the cooktop is on or accidentally turned on, or if it is still hot,
metal objects on the cooktop can heat up. Other items may melt or
catch fire. Damp lids can become attached to the cooktop by
suction. Do not store items on the cooktop. Always turn the burners
off after use.

IMPORTANT SAFETY INSTRUCTIONS
10
 You can burn yourself on a hot cooktop. When cooking on the
cooktop, protect your hands by using heat-resistant pot holders or
oven mitts. Only use dry pot holders and oven mitts. Wet or damp
textiles conduct heat more effectively and produce steam, which
poses a burn hazard.
 When using an electrical appliance, e.g. a hand mixer, near the
cooktop, make sure that the power cable does not come into
contact with the hot cooktop. The cable's insulation could become
damaged.
 Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get onto pan bottoms. Make sure that the
ceramic surface and pan bottom are clean before placing any pans
on the cooktop.
 Even light objects (such as a salt shaker) can cause damage to
the ceramic cooktop in certain circumstances. Do not drop anything
on the ceramic surface.
 Hot objects on the residual heat indicators can cause damage to
the electronics underneath. Do not place hot pans in these areas.
 Do not allow solid or liquid sugar, or pieces of plastic or aluminum
foil, to get on the cooktop when it is hot, as they can damage the
ceramic surface when it cools down. If this should occur, turn off the
appliance immediately and scrape off all the sugar, plastic or
aluminum residues while still hot using a scraper blade. Wear oven
mitts when doing so. Allow the burners to cool down and clean them
with a suitable ceramic cleaning agent.
 Pans that boil dry can damage the ceramic surface. Never leave
the cooktop unattended during use.
 Pots and pans with rough bottoms can scratch the ceramic
surface. Only use pots and pans that are smooth on the bottom.
 Lift pans into position on the cooktop. Sliding them into place can
cause scuff marks and scratches.

IMPORTANT SAFETY INSTRUCTIONS
11
 Cookware made of plastic or aluminum foil will melt at high
temperatures. Do not use any plastic or aluminum foil cookware.
 The cooktop trim or edge (in the case of bevelled cooktops) can
become hot due to the following factors: operating time, high output
settings, large cookware, and number of burners in use.
 Cookware that is made of aluminum or has an aluminum bottom
can leave behind shiny metallic spots. These spots can be removed
with ceramic and stainless steel cleaner (see "Cleaning and care").
 If spills or splatters are allowed to remain on the cooktop for any
length of time, they can bake onto the cooktop, and it may not be
possible to remove them. Remove spills and splatters immediately.
Also make sure that the bottom of any cookware is clean, dry, and
free of grease before placing it on the cooktop.
Cleaning and care
 Do not use a steam cleaner to clean the cooktop.
The steam could reach electrical components and cause a short
circuit.

Caring for the environment
12
Disposal of the transport
packaging material
The packaging material protects the
appliance from transport damage. The
packaging materials used are selected
from materials which are
environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also the
amount of waste. You can return the
packaging to your Miele dealer.
Disposal of your old appliance
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for their correct
functioning and safety. These could be
hazardous to your health and to the
environment if disposed of with general
waste or if handled incorrectly. Please
do not, therefore, dispose of your old
appliance with general waste.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle
electrical and electronic appliances in
your local community, dealer, or with
Miele. By law, you are solely
responsible for deleting any personal
data from the appliance prior to
disposal. Ensure that it presents no
danger to children while being stored
for disposal.

Overview
13
Cooktop
aVariable burner
bStandard burner
cStandard burner
dStandard burner
eDisplay with residual heat indicators

Overview
14
Burner data
Burner ØRating in watts
in cm in inch 208/240V
12.0 / 21.0 4³/ ₄" / 8¹/₄" 750 / 2200
14.5 5¹¹/₁₆ 1200
18.0 7¹/₈" 1800
14.5 5¹¹/₁₆ 1200
Total: 6400

Initial commissioning
15
Please stick the extra data plate for
the appliance supplied with this
documentation in the space provided
in the "After sales service" section of
this manual.
Remove any protective foil and
stickers from the cooktop.
Cleaning the cooktop for the
first time
Before using it for the first time, wipe
down the cooktop with a damp cloth
and then wipe it dry.
Turning on the cooktop for the
first time
The cooktop's metal components are
protected by a conditioning agent.
Smells and vapor may occur when the
appliance is used for the first time.
The smell and any vapors that may
occur do not indicate a faulty
connection or defective appliance and
are not harmful to your health.

How the burners work
16
Standard burners have one heating
band, and variable burners and
casserole areas have two heating
bands. Depending on the model, the
heating bands may be separated by a
ring.
Each burner features overheat
protection (internal temperature limiter),
which prevents the ceramic surface
from overheating (see "Overheat
protection").
When a power level is set, heating is
activated and the heating band is
visible through the ceramic surface. The
heat output of the burners depends on
the power level set and is controlled
electronically. This causes the "cycling"
of a burner: the heating is turned on
and off.
Standard burner
aOverheat protection
bHeating band
Variable burner
aTechnical requirement, not a defect
bOverheat protection
cOuter heating band
dInsulating ring
eInner heating band

Cookware
17
The most suitable cookware is metal
pots and pans with thick bases that,
when cold, bulge inwards slightly. On
warming, the base expands and rests
flat on the cooktop; this conducts the
heat optimally.
Cold Hot
Glass, ceramic, or stoneware is less
suitable. These materials do not
conduct the heat well.
Cookware made of plastic or aluminum
is not suitable. These melt at high
temperatures.
Cookware that is made of aluminum or
has an aluminum base can leave behind
shiny metallic spots. These spots can
be removed with ceramic and stainless
steel cleaner (see "Cleaning and care").
The composition of the pan base can
affect the evenness of the cooking
results (e.g. when making pancakes).
– To make optimum use of the cooking
zones, choose pans with a suitable
base diameter (see chapter "Cooking
zones").
– Use only pots and pans with smooth
bases. Rough bases can scratch the
ceramic glass.
– Always lift the pans to move them.
This will help prevent scratching.
– The maximum diameter indicated by
manufacturers will often refer to the
diameter of the top rim of the pot or
pan. The diameter of the base
(generally smaller) is more important.

Energy saving tips
18
– Make sure that the bottoms of pots or
pans either match the size of the
burner or are somewhat larger. This
ensures that heat from the burner is
not wasted.
– Whenever possible, keep pots and
pans covered while cooking. Doing
so will prevent unnecessary heat loss.
– For small quantities, select a small
pan. A small pan on a small burner
uses less energy than a large, only
partially filled pan on a large burner.
– Cook with as little water as possible.
– Once food has come to a boil or the
pan is hot for frying, reduce the heat
to a lower power setting.
– When cooking for a longer amount of
time, turn the burner off at least 5 to
10 minutes before the end of the
cooking time. This makes use of the
residual heat.
– Use a pressure cooker to reduce the
cooking time.

Power setting ranges
19
Setting range
Melting butter, chocolate, etc.
Dissolving gelatin
Preparing yogurt
1-2
Thickening sauces containing only egg yolk and butter
Warming small quantities of liquid
Keeping food warm that sticks easily
Cooking rice
1-3
Warming liquid and semi-solid foods
Thickening sauces, e.g. Hollandaise
Making porridge
Preparing omelettes, lightly fried eggs
Steaming fruit
3–5
Thawing frozen foods
Steaming vegetables, fish
Cooking pasta, pulses
Cooking grains
4–6
Boiling and continuing to cook large quantities of food 7
Gently frying fish, cutlets, sausages, fried eggs, etc. (without
overheating the fat)
8–9
Frying pancakes, etc. 9–11
Boiling large quantities of water
Bringing food to a boil
11–12
These settings, which are based on approx. 4 normal-sized servings, should only be taken
as a guide. With deep pans, larger quantities or when cooking without a lid, a higher setting
is required. For smaller quantities, select a lower setting.

Operation
20
Fire hazard.
Do not leave the appliance
unattended while cooking.
Burner control knobs
The oven is equipped with different
control knobs:
– Knobs with a stop. These must not
be turned past the stop to 0.
– Knobs without a stop. These can be
turned a full 360°.
Switching on
Turn burner knobs with a stop
clockwise to the desired power
setting.
Turn burner knobs without a stop
clockwise or counter-clockwise to the
desired power setting.
Switching off
Turn the burner knobs with a stop
counter-clockwise to 0.
Turn the burner knobs without a stop
clockwise or counter-clockwise to 0.
Residual heat indicator
When a specified temperature is
reached after a burner, for example the
left front, has been turned on, the
corresponding residual heat indicator
lights up:
When the burner cools down to a
specified temperature after being
switched off, the residual heat indicator
goes out.
If extremely hot cookware remains
on the burner for a longer amount of
time after the burner is switched off,
the burner may still be hot, even
though the residual heat indicator is
no longer on.
Danger of burning!
Do not touch the cooking zones
while the residual heat indicators are
on.
Hot objects on the residual heat
indicators can damage the
electronics underneath.
NEVER place hot pots or pans in this
area.
