Miele G 5690 User manual

Operating instructions
Dishwasher
To avoid the risk of accidents or damage to the appliance, it is essential
to read these instructions as well as the installation sheet before it is in-
stalled and used for the first time.
en-GB M.-Nr. 11 522 040HG07

Contents
3
Warning and safety instructions ...................................................................... 6
Guide to the appliance...................................................................................... 15
Appliance overview ............................................................................................. 15
Control field......................................................................................................... 16
Display functions................................................................................................. 17
Caring for the environment .............................................................................. 18
Before using for the first time .......................................................................... 19
Opening the door ................................................................................................ 19
Closing the door.................................................................................................. 19
Basic settings...................................................................................................... 20
Setting the language ...................................................................................... 20
Setting the water hardness level .................................................................... 20
Dishwasher salt ................................................................................................... 22
Filling the salt reservoir................................................................................... 23
Refilling the salt .............................................................................................. 24
Rinse aid.............................................................................................................. 25
Adding rinse aid ............................................................................................. 26
Filling the rinse aid reservoir........................................................................... 26
Caring for the environment .............................................................................. 27
Economical dishwashing..................................................................................... 27
EcoFeedback consumption indicator.................................................................. 28
Loading the dishwasher.................................................................................... 29
General information............................................................................................. 29
Upper basket....................................................................................................... 31
Adjust the upper basket ...................................................................................... 33
Lower basket....................................................................................................... 34
Cutlery tray .......................................................................................................... 35
Loading the cutlery tray.................................................................................. 35
Loading examples ............................................................................................... 36
Dishwashers with cutlery tray......................................................................... 36
Detergent ........................................................................................................... 38
Active ingredients ............................................................................................... 38
Detergent dispensing .......................................................................................... 39
Adding detergent................................................................................................. 40
Operation............................................................................................................ 41
Switching on the dishwasher .............................................................................. 41
Selecting a programme ....................................................................................... 41
Display of programme duration........................................................................... 42

Contents
4
Starting the programme ...................................................................................... 42
End of programme............................................................................................... 43
Energy management ........................................................................................... 43
Switching off the dishwasher .............................................................................. 44
Unloading the crockery ....................................................................................... 44
Interrupting a programme.................................................................................... 45
Cancelling or changing a programme ................................................................. 45
Options ............................................................................................................... 46
Timer.............................................................................................................. 46
Programme overview ........................................................................................ 48
Further programmes ...................................................................................... 52
Programme options........................................................................................... 53
Selecting programme options ............................................................................. 53
Express...................................................................................................... 53
IntenseZone.............................................................................................. 53
Cleaning and care ............................................................................................. 54
Cleaning the wash cabinet .................................................................................. 54
Cleaning the door and the door seal................................................................... 54
Cleaning the control panel .................................................................................. 55
Cleaning the reflector panel ................................................................................ 55
Cleaning the appliance front ............................................................................... 55
Cleaning the spray arms...................................................................................... 56
Checking the filters in the wash cabinet ............................................................. 58
Cleaning the filters............................................................................................... 58
Cleaning the water inlet filter............................................................................... 60
Cleaning the drain pump..................................................................................... 61
Problem solving guide ...................................................................................... 63
Technical problems ............................................................................................. 63
Fault messages ................................................................................................... 64
Door release ........................................................................................................ 65
Water inlet fault ................................................................................................... 66
Water drainage fault ............................................................................................ 67
General problems with the dishwasher ............................................................... 68
Noises.................................................................................................................. 69
Unsatisfactory washing result ............................................................................. 70
Service................................................................................................................ 74
Contact in the event of a fault ............................................................................. 74
EPREL database ................................................................................................. 74

Contents
5
Warranty .............................................................................................................. 75
Note for test institutes ......................................................................................... 75
Optional accessories ........................................................................................ 76
Installation.......................................................................................................... 78
The Miele Waterproof system.............................................................................. 78
Water inlet ........................................................................................................... 78
Water drainage .................................................................................................... 80
Electrical connection ........................................................................................... 82
Electrical connection ..................................................................................... 82
Technical data.................................................................................................... 83
Settings .............................................................................................................. 84
Opening the settings menu ................................................................................. 84
Changing settings ............................................................................................... 84
Closing the settings menu................................................................................... 84
Language......................................................................................................... 85
Water hardness ................................................................................................... 85
Rinse aid.............................................................................................................. 86
Consumption (EcoFeedback) .............................................................................. 86
Display brightness............................................................................................... 87
Buzzer.................................................................................................................. 87
Refill reminders.................................................................................................... 87
AutoOpen ............................................................................................................ 87
Extra clean........................................................................................................... 88
Extra dry .............................................................................................................. 88
Software version.................................................................................................. 88
Showroom ........................................................................................................... 88
Factory default..................................................................................................... 88

Warning and safety instructions
6
This dishwasher conforms to current safety requirements. Inappro-
priate use can, however, lead to personal injury and material dam-
age.
Please observe the installation sheet and read the operating in-
structions carefully before setting up the dishwasher and using it
for the first time. They both contain important information on its in-
stallation, safety, use and maintenance. This is to protect yourself
from injury and prevent damage to the dishwasher.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the dishwasher as well as the safety instruc-
tions and warnings.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.
Keep the installation sheet and the operating instructions in a safe
place and pass them on to any future owner.

Warning and safety instructions
7
Appropriate use
 This dishwasher is intended for use in domestic households and
similar working and residential environments.
 This dishwasher is not intended for outdoor use.
 This dishwasher is intended for use at altitudes of up to 4000m
above sea level.
 This dishwasher must only be used for cleaning domestic crock-
ery and cutlery. All other types of use are not permitted.
 The appliance can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
if they are supervised whilst using it, or have been shown how to use
it in a safe way and recognise and understand the consequences of
incorrect operation.

Warning and safety instructions
8
Safety with children
 Children under 8 years of age must be kept away from the dish-
washer unless they are constantly supervised.
 Children aged 8 and older may only use the dishwasher without
supervision if they have been shown how to use it in a safe manner.
Children must be able to understand and recognise the possible
dangers caused by incorrect operation.
 Children must not be allowed to clean or maintain the dishwasher
unsupervised.
 Children should be supervised in the vicinity of the dishwasher.
Never allow children to play with the dishwasher. There is a danger
that children might shut themselves in the dishwasher.
 If the automatic door opening mechanism is active (depending on
the model), keep young children away from the area in which the
door opens. There is a danger of injury in the unlikely event of a fault
with the opening mechanism.
 Danger of suffocation! Whilst playing, children may become en-
tangled in packaging material (such as plastic wrapping) or pull it
over their head and risk suffocation. Keep packaging material away
from children.
 Keep children away from detergents. Detergents cause severe
skin burns and severe eye damage. They can cause burning in the
mouth and throat, or inhibit breathing. It is therefore important to
keep children away from the dishwasher when the door is open. De-
tergent residues could still be present in the dishwasher. Seek med-
ical advice immediately if a child has swallowed or inhaled any deter-
gents.

Warning and safety instructions
9
Technical safety
 Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and re-
pairs must only be carried out by a qualified technician.
 Damage to the dishwasher can compromise your safety. Before
using the dishwasher, check it for any visible damage. Never use a
damaged dishwasher.
 The electrical safety of this dishwasher can only be guaranteed
when correctly earthed. It is most important that this basic safety re-
quirement is present. If in doubt, the electrical installation should be
checked by a qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
or lack of earthing system (e.g. electric shock).
 Reliable and safe operation of this dishwasher can only be as-
sured if it has been connected to the mains electricity supply.
 The dishwasher must only be plugged into the electricity supply
via a suitable socket and plug (e.g. a switched socket and fused 3-
pin plug in the UK). It must not be hard-wired. The electrical socket
must be easily accessible after the dishwasher is installed so that it
can be disconnected from the electricity supply at any time.
 There must be no electrical sockets behind the dishwasher be-
cause the building-in niche may be too small. Danger of overheating
and fire risk if the dishwasher were to be pushed up against a plug.
 The dishwasher must not be installed underneath a hob. The high
temperatures radiated by hobs could damage the dishwasher below.
For the same reason, the appliance must not be installed next to
open fires or other appliances that give off heat, such as heaters
etc., not normally found in a kitchen.

Warning and safety instructions
10
 Ensure that the connection data on the dishwasher’s data plate
(fuse rating, frequency and voltage) match the mains electricity sup-
ply. This data must correspond in order to avoid the risk of damage
to the dishwasher. Compare these before connecting the appliance
to the mains. If in any doubt, consult a qualified electrician.
 Do not connect the dishwasher to the mains supply until it has
been fully installed and any adjustment has been made to the door
springs.
 The dishwasher may only be operated if the door opening mech-
anism is working correctly. Otherwise there could be a risk of danger
whilst the automatic door opening mechanism (depending on the
model) is active.
To check that the door opening mechanism is working correctly:
- The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the
door cannot fall open.
- The door locking pins automatically retract when the door opens
at the end of the drying phase.
 Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (fire hazard). Do not connect the
dishwasher to the mains electricity supply using a multi-socket ad-
apter or an extension lead.
 The dishwasher must not be used in a non-stationary location
(e.g. on a ship).
 Do not install the dishwasher in a room where there is a risk of
frost occurring. Frozen hoses are at risk of tearing or bursting. The
reliability of the electronic control unit may be impaired at temperat-
ures below freezing point.
 To avoid any damage to the dishwasher, it must only be operated
when it is connected to a fully vented plumbing system.

Warning and safety instructions
11
 The plastic housing of the water connection contains a solenoid
valve. The housing must not be dipped in water.
 There are live wires in the water inlet hose. Do not cut the hose,
even if it is too long.
 The integrated Waterproof system offers protection from water
damage, provided that the following conditions are met:
- Installation has been carried out correctly
- The dishwasher is properly maintained and parts are replaced
where this is noticeably required
- The stopcock is turned off during longer absences from the home
(e.g. whilst on holiday).
The Waterproof system will work even when the dishwasher is
switched off. However, the dishwasher must remain connected to
the electricity supply.
 The water-connection pressure needs to be between 50 and
1,000kPa.
 A damaged dishwasher could be dangerous. If the dishwasher
gets damaged, switch it off at the mains immediately and call your
Miele dealer or Miele Service.
 While the appliance is under warranty, repairs should only be un-
dertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
 We recommend replacing defective components with original
spare parts. If original Miele spare parts are installed correctly, Miele
ensures full compliance with safety requirements and the warranty
remains valid.
 During installation, maintenance and repair work, the dishwasher
must be disconnected from the mains electricity supply (switch it off
and withdraw the plug from the socket).

Warning and safety instructions
12
 If the connection cable is damaged it must be replaced with a
special cable of the same type (available from Miele). For safety reas-
ons this work must be carried out by a Miele authorised service
technician only.
Correct installation
 The dishwasher must be installed and connected in compliance
with the supplied installation sheet.
 Be careful before and while installing the dishwasher.
Some metal parts pose a risk of injury/being cut. Wear pro-
tective gloves.
 The dishwasher must be correctly aligned horizontally to ensure
problem-free operation.
 In order to ensure stability, built-under and integrated dishwashers
must only be installed under a continuous worktop that is secured to
adjacent cabinetry.
 The dishwasher must only be built into a tall unit if additional
safety precautions are taken. In order to safely install the appliance
in a tall unit, please use the Tall unit installation set and observe the
installation sheet provided. Otherwise there is the danger of the unit
tipping over.
 The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the door
cannot fall open.
The appliance must only be operated with properly adjusted door
springs.
If the door cannot be adjusted properly, contact the Miele Customer
Service Department.
The maximum weight of the front panel that can be aligned with the
factory fitted door springs is 7–9kg (depending on model).

Warning and safety instructions
13
Correct use
 Do not use solvents in the dishwasher. Risk of explosion.
 Dishwasher detergents can cause burning on the skin and in the
eyes, nose, mouth and throat. Avoid contact with detergents. Do not
inhale powder detergents. Do not swallow dishwasher detergents.
Seek medical attention immediately if detergent has been swallowed
or inhaled.
 Avoid leaving the dishwasher door open unnecessarily. You could
injure yourself on the open door or trip over it.
 Do not sit or lean on the open door. The dishwasher could tip
over. This could injure you or damage the dishwasher.
 Crockery may be very hot at the end of the programme. Allow the
dishes to cool until they are comfortable enough to handle before
unloading them.
 Only use detergent and rinse aid formulated for domestic dish-
washers. Do not use washing-up liquid.
 Do not use any commercial or industrial detergents. These may
cause material damage, and there is a risk of a severe explosive
chemical reaction (such as an explosive oxyhydrogen gas reaction).
 Do not fill the rinse aid reservoir with powder or liquid detergent.
This will cause damage to the reservoir.
 Do not fill the AutoDos (depending on model) with powder or li-
quid detergent. Loose detergent will damage the AutoDos.
 Do not fill the salt reservoir with powder or liquid detergent. Deter-
gent will damage the water softener.
 Only use special coarse-grained dishwasher salt or other pure kit-
chen salt for reactivation. Other salts may contain insoluble additives
that can impair the functioning of the water softener.

Warning and safety instructions
14
 In dishwashers with a cutlery basket (depending on model), knives
and forks should be placed with the handles upwards in the basket
for safety reasons. Knives and forks placed with the handles down-
wards pose a danger of injury. However, cutlery placed handle down
in the basket will come out cleaner and drier.
 Plastic items that cannot withstand being washed in hot water,
such as disposable plastic containers or plastic cutlery, should not
be cleaned in the dishwasher. The high temperatures in the dish-
washer may cause them to melt or lose shape.
 If you use the timer option (depending on model), the detergent
compartment must be dry. If it is not, wipe it until dry. The detergent
will clump together if the detergent compartment is not dry, and this
may mean that it is not fully rinsed out.
 Please observe the information given in the “Technical data”
chapter regarding the capacity of the dishwasher.
Accessories and spare parts
 Only use original Miele accessories. If other parts are used, war-
ranty, performance and, if applicable, product liability claims will be
invalidated.
 Miele will guarantee to supply functional spare parts for 15years
following the discontinuation of your dishwasher.
Transport
 Only transport the dishwasher in an upright position so that no
water flows into the electrical controls, as this would cause faults.
 If you wish to transport the dishwasher, empty it and securely
fasten all loose parts such as baskets, hoses and cables.

Guide to the appliance
15
Appliance overview
aTop spray arm
bCutlery tray (depending on model)
cUpper basket (depending on model)
dMiddle spray arm
eAeration valve
fBottom spray arm
gFilter combination
hSalt reservoir
iData plate
jRinse aid reservoir
kDetergent compartment

Guide to the appliance
16
Control field
aOptical in-operation indicator light
For indicating an ongoing wash pro-
gramme when the door is closed.
bProgramme selection
ECO50°C = ECO50°C
Auto = Auto45–65°C
45°C = Gentle45°C
65°C = QuickPowerWash65°C
75°C = Intensive75°C
= Further programmes/
settings
cTimer button
For selecting a later programme start.
dOK button
To select menu options and values
displayed.
To confirm messages.
ebuttons
For programme selection.
For changing the values displayed.
For scrolling to other menu pages.
fDisplay
For further information, see “Guide to
the appliance” in the “Display func-
tions” section.
gBack button
For navigating back to the previous
menu or deleting values that have
been set previously.
hProgramme options button
Express: For reducing the pro-
gramme running time.
IntenseZone: For increasing the
cleaning performance in the lower
basket.
iProgramme selection button
For programme selection.
jON/OFF button
For switching the dishwasher on and
off.

Guide to the appliance
17
Display functions
The display is used to select or set the
following:
- The programme
- The timer
- The Settings 
The display can show the following:
- The programme stage
- The estimated time left for the pro-
gramme to run
- The energy and water consumption
(EcoFeedback)
- Any relevant fault messages and in-
formation
To save energy, the dishwasher
switches off after a few minutes if you
do not press any buttons during this
time.
Press the button to switch the dish-
washer back on.
The OKbutton is used to confirm mes-
sages or settings and also to move to
the next menu or another menu level.
Under Further programmes/settings,
a scroll bar will appear in the right of
the display. This offers further options.
These options can be shown using the
buttons.
You can alter the dishwasher’s controls
to suit changing requirements in the
Settings menu (see “Settings” chapter).
The option that is selected will have a
tick next to it.
To exit a sub-menu again, press the
Backbutton.
If you do not press any buttons for sev-
eral seconds, the display will revert to
the previous menu. You may then have
to enter your settings again.

Caring for the environment
18
Disposal of the packing mater-
ial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electrical and electronic appliances of-
ten contain valuable materials. They
also contain specific materials, com-
pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu-
man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local com-
munity waste collection / recycling
centre for electrical and electronic ap-
pliances, or contact your dealer or
Miele for advice. You are also respons-
ible for deleting any personal data that
may be stored on the appliance being
disposed of. Please ensure that your
old appliance poses no risk to children
while being stored prior to disposal.

Before using for the first time
19
Every dishwasher is tested at the fact-
ory. There will be residual water in the
appliance from this test. It is not an in-
dication that the dishwasher has been
used previously.
Opening the door
In some programmes the door automat-
ically opens slightly to assist the drying
process.
This function can be deactivated, if pre-
ferred (see “Settings” chapter,
“AutoOpen” section).
Pull the handle to open the door.
Open the door fully to disengage the
locking mechanism.
At the end of the programme, if the
AutoOpen function is on, the door lock-
ing pins automatically retract.
To prevent a technical fault, do not
hold the door locking pins firmly
when they are retracting.
If the door is opened during operation
all wash functions are automatically in-
terrupted.
Risk of scalding due to hot wa-
ter.
During operation, water in the dish-
washer may be very hot.
During operation, only open the door
with extreme caution.
Risk of injury due to door open-
ing automatically.
The door may open automatically at
the end of a programme.
Keep the area around the door free
of obstructions.
Closing the door
Push the baskets right in.
Raise the door upwards until the
catch engages.
Risk of crushing due to the door
closing.
When closing the door, you are at
risk of shutting your fingers in it.
Do not put your hand inside the door
as it is closing.

Before using for the first time
20
Basic settings
Switching on the dishwasher
Open the door.
Switch the dishwasher on with the
button.
The welcome screen will appear when
the dishwasher is switched on.
For further information about the dis-
play functionality, see the “Display
functions” section in the “Guide to the
appliance” chapter.
Setting the language
The display will then change automatic-
ally to the screen for setting the lan-
guage.
Select the language you want as well
as the country, if applicable, using
the buttons and confirm with OK.
For further information on setting the
language, see the “Language” section
in the “Settings” chapter.
A tick will appear next to the lan-
guage that has been set.
Setting the water hardness level
The display will change to the screen
for setting the water hardness.
- You should programme the dish-
washer to the correct water hardness
for your area.
- Your local water authority will be able
to advise you of the water hardness
level in your area.
- Where the water hardness fluctuates
e.g. between 1.8 and 2.7mmol/l (10 -
15 °dH - German scale) always pro-
gramme the dishwasher to the higher
value (2.7mmol/l or 15 °dH in this ex-
ample).
In the event of a fault, it will help the
service technician if you know the hard-
ness of your local water supply.
Therefore, please enter the water hard-
ness:
____________°dH or mmol/l
The dishwasher is programmed at the
factory for a water hardness level of
2.5mmol/l (14°dH – German scale).
Set the water hardness level in your
area and confirm using OK.
See the “Settings” chapter, “Water
hardness” section for more informa-
tion.
