Miele PT 8407 D User manual

Installation Plan
Tumble dryer
PT 8407
D (Steam Heated)
en – US
23.15 M.-Nr. 10 002 520

It is essential to read the operating and installation instructions before
installing, commissioning or using the machine.
This avoids the risk of accidents or damage.
All rights reserved
U.S.A.
Miele, Inc.
National Headquarters
9 Independence Way
Princeton, NJ 08540
Phone:
Fax:
www.mieleusa.com
Technical Service & Support
Nationwide
Phone:
800-991-9380
Fax: [phone]
[email protected]
800-991-9380
609-419-4241
2

35 5/8
35 7/16 3/4 3/4
55 1/8
2 1/2
25 5/8
41 7/8 25 1/4
45 7/8
41 11/162 5/8 1 1/2
24 3/4
23 3/8
3/4
63
PT 8407 D - measurements in inches
3

<
45 7/8
41 11/16
63
~2
5 7/8
6 1/4
6 3/8
PT 8407 D - measurements in inches
4

24 3/8 11
1 7/8
25 3/4
17 3/8
5 7/8
5
12
63
7 7/8
63
25 3/4
17 3/8
12
5
2 5/8
PT 8407 D - measurements in inches
5

55 1/8
3/4
55 1/8>2
3/4
2 1/8 2 1/8
31 1/8
15 1/2
63
41 11/16
42
35 7/16
21
> 35 1/2
> 2 1/8> 2 1/8
63
> 47 1/4
15 1/2
31 1/8
42
~2
3/8
~2
~2
3/8
>2
~2
PT 8407 D - measurements in inches
6
Standard installation Option: Installation on concrete base (BS)

PT 8407 D - measurements in millimeters
7

<
PT 8407 D - measurements in millimeters
8

PT 8407 D - measurements in millimeters
9

PT 8407 D - measurements in millimeters
10
Standard installation Option: Installation on concrete base (BS)

Technical datasheet
Tumble dryer:
Heating:
PT 8407
Steam (D)
Legend: Abbreviations in bold type:
Connection required
en - US
Abbreviations in circle with dashes:
Connection optional or required depending on model version
Optional extras:
BS Concrete base Quality and density of concrete must comply with load.
Concrete base must be firmly secured to floor!
Recommended height
3 15/16“
100 mm
Minimum height
1 31/32“
50 mm
Minimum width
35 7/16“
900 mm
Minimum depth
47 1/4“
1200 mm
DAV Steam
connection
valve
The steam connection valve to regulate the steam supply
must be provided on site.
The following valves can be ordered separately as electric
steam valves or as pneumatic steam valves.
Pneumatic steam valve (PND)
Regulatable steam pressure
0 - 145 psi
0 - 1000 kPa
Connection gauge
½“
Supply point and pneumatic valve controls must be
provided on site.
Machine connections:
Electrical
connection
(convertible)
Standard voltage
3 AC 208V
Frequency
60 Hz
Rated load
4438.8 BTU/h
1.3 kW
Fuse rating
3 x 10 A
Connection cable, min. cross-section
4 x AWG 16
4 x 1.5 mm²
Connection cable to be ordered separately
Convertible to
3 AC 220-240V
Frequency
60 Hz
Rated load
4439 BTU/h
1.3 kW
Fuse rating
3 x 10 A
Connection cable, min. cross-section
4 x AWG 16
4 x 1.5 mm²
Connection cable to be ordered separately
Electrical connection must comply with national regulations.
Connection using multi-pole wall socket in compliance with IEC/EN 60309 and IEC/EN 60947 is
recommended in order to simplify electrical tests.
If machines are hard-wired, a multi-pole switch must be provided on site.
A wall socket or isolator must be accessible after installation.
Installation plan: PT 8407 D
Date: 16-Oct-2014 Page: 11

Equipotential
bonding
Connection with male thread
3/8“ x 1 3/8“
10 mm × 35 mm
Connection with washers and nut
3/8”
M 10
Accessories to be ordered separately
If necessary, equipotential bonding with good galvanic
contact must be provided in accordance with all
appropriate national and local regulations.
Steam
connection
Steam pressure
87 - 145 psi
600 - 1.000 kPa
Boiling point
329 - 363 °F
165 - 184 °C
Steam supply capacity
108 lbs/h
49 kg/h
Connection thread (on site)
½" internal thread
Steam valve, steam filter and steam faucet must be
provided on site.
Supply lead Steam valve Length
19 11/16“
500 mm
The supply lead for the electric steam valve is included.
The steam valve should be installed close to the steam
connection.
Note installation instructions for steam-heated Miele
tumble dryers.
Condensate
connection
Connection thread (on site)
½" internal thread
Steam valve, steam filter and steam faucet must be
provided on-site.
Installation of the steam trap needs to allow complete
drainage of the heater element during machine downtime.
This means, no condensate is left in the heater element.
Installation of an inverted bucket steam trap is recom-
mended.
Vented
Max. nominal air flow in vented mode
26486 cfh
750 m³/h
Max. permissible pressure loss
0.04 psi
300 Pa
Connection on machine side (ext. diameter)
5 29/32”
150 mm
Connection pipe provided on site (int. diameter)
5 29/32”
150 mm
Max. temperature
176 °F
80 °C
As relative humidity inside the vent ducting can be as high
as 100%, suitable measures must be taken to prevent a
backflow of condensate into the machine.
Air intake
Standard connection: Air intake from installation site
Unobstructed air intake into room recommended
(corresponding to 3 times the vent cross-section of
machine)
82.31 in²
531 cm²
A sufficient supply of fresh air should be ensured to
replace the air extracted.
Alternative connection: Ducted air intake (from outside
building)
Connector on machine (int. diameter)
6 11/32”
161 mm
Connection pipe provided on site (ext. diameter)
6 5/16”
160 mm
Lid removal exposes live components! For safety reasons,
the pipe connected for central air intake should be at least
35 7/16” [900 mm] long and secured using two screws.
Installation plan: PT 8407 D
Date: 16-Oct-2014 Page: 12

Fittings
(supplied)
Without base:
2 × clamps
2 × screws DIN 571 (Ø × length)
1/4“ x 1 9/16“
6 mm × 40 mm
2 × rawl plugs (Ø × length)
3/8“ x 1 31/32“
10 mm × 50 mm
Machine must be bolted to the floor!
Fixing materials for floor screed have to be provided on
site.
On concrete platform:
2 × clamps
2 × screws DIN 571 (Ø × length)
1/4“ x 1 9/16“
6 mm × 40 mm
2 × rawl plugs (Ø × length)
3/8“ x 1 31/32“
10 mm × 50 mm
Machine must be bolted to the floor!
Fixing materials for floor screed have to be provided on
site.
Machine data
Width
35 21/32“
906 mm
Depth
45 27/32“
1164 mm
Height
55 1/8“
1400 mm
Casing width
35 7/16“
900 mm
Casing depth
41 11/16“
1059 mm
Minimum width of delivery access to installation site
36 7/32“
920 mm
Recommended rear wall gap (measured to front of
machine)
63“
1600 mm
Min. wall gap (to rear edge of lid)
19 11/16“
500 mm
Net weight
476.2 lbs
216 kg
Dynamic floor load, max.
2413 N
Average heat dissipation
(depends on ambient room temperature and selected
program)
2508 BTU/h
735 W
A Noise level
72.8 dB (A)
A Sound pressure level
(measured at a distance of 39 3/8” [1 m] from the
machine and at a height of 63” [1.6 m])
60 dB (A)
Installation should only be carried out by authorized installers in accordance with all local and national regulations.
Follow installation instructions when installing machine! All rights reserved.
Installation plan: PT 8407 D
Date: 16-Oct-2014 Page: 13
