Miele T 7634 User manual

Operating instructions
for vented tumble dryer
T 7634
To avoid the risk of accidents
or damage to the machine
it is essential to read these
instructions before it is installed
and used for the first time.
G
M.-Nr. 06 737 030

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation!
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person. The plug must be
rendered useless and the cable cut off
directly behind it to prevent misuse.
See the "Warning and Safety" section of
this booklet for further details.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
– Load according to the optimum
amount of laundry recommended for
the programme being used (see
"Programme chart").
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
–Make sure the room in which the
dryer is located is well ventilated.
–Make sure the fluff filter is clean
before using the dryer.
–Check all parts of the ventilation
system on a regular basis and
remove any build up of fluff etc.
–The vent ducting should be as short,
straight and smooth as possible to
minimise any resistance to the air
throughflow.
This helps to reduce running times
and energy consumption levels.
Caring for the environment
2

Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Disposal of the packing material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Disposal of your old appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Energy saving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating the tumble dryer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Notes on laundry care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Care symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Tips on drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
How to dry correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Additional options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Low temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Delay start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Changing the programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing a programme while it is running . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cancelling a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Interrupting a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Adding or removing laundry after a programme has started . . . . . . . . . . . . . . . . 19
Electronic system lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning the fluff filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning the grilles in the door opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Cleaning the tumble dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Check and fault messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Other problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Changing the lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Repairs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Future updates (PC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Contents
3

Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Installation site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Transporting the machine to its installation site . . . . . . . . . . . . . . . . . . . . . . . . 31
Washer-dryer stack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Levelling the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Room ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Electrical connection U.K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Installation - venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Calculating the effective duct length: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Installation to the rear, left or right side of the machine . . . . . . . . . . . . . . . . . . . . . 36
Venting systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
aFlexible ducting hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
bPlastic piping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
cConnect directly to a wall vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Washer-dryer stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Programmable functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Extending the range of the drying levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Altering the volume of the buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Extending the cooling down time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Clean out airways indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Keypad tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Adjusting the dryer's electronics for very soft water . . . . . . . . . . . . . . . . . . . . . . . 51
Contents
4

To avoid the risk of accidents and
damage to the machine please read
these instructions carefully before
using it for the first time. They
contain important information on its
safety, installation, use and
maintenance.
Keep these instructions in a safe
place and ensure that new users are
familiar with the content. Pass them
on to any future owner of the
machine.
Correct use
The tumble dryer is only intended
for drying fabrics which have been
washed in a water solution, marked on
the manufacturer's care label as being
suitable for tumble drying.
"Dry cleaning kits" for freshening up
garments in a tumble dryer are
increasingly available on the market. If
using, do so at your own risk, and
follow the instructions provided on the
packaging.
Any other applications may be
dangerous. The manufacturer is not
liable for damage resulting from
improper use or operation.
Technical safety
Before setting up the machine,
check it for any externally visible
damage.
Do not install or use a damaged
machine.
Before connecting the machine,
ensure that the connection data on
the data plate match the mains
electricity supply. If in any doubt,
consult a qualified electrician.
The electrical safety of this
machine can only be guaranteed
when continuity is complete between it
and an effective earthing system which
complies with local and national safety
regulations. It is most important that this
basic safety requirement is present and
regularly tested, and where there is any
doubt the household wiring system
should be inspected by a qualified
electrician. The manufacturer cannot be
held liable for the consequences of an
inadequate earthing system (e.g.
electric shock).
Do not connect the machine to the
mains electricity supply by an
extension lead. Extension leads do not
guarantee the required safety of the
appliance (e.g. danger of overheating).
Warning and Safety instructions
5

The machine is built in accordance
with current safety requirements.
Unauthorised repairs could result in
unforeseen dangers for the user, for
which the manufacturer cannot accept
liability. Repairs should only be
undertaken by a Miele approved
technician.
Ensure current is not supplied to the
machine until after maintenance or
repair work has been carried out.
Faulty components must only be
replaced by genuine Miele original
spare parts. Only when these parts are
fitted can the safety standards of the
machine be guaranteed.
If the connection cable is faulty it
must only be replaced by a Miele
approved service technician to protect
the user from danger.
In countries where there are areas
which may be subject to infestation
by cockroaches or other vermin, pay
particular attention to keeping the
machine and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the machine guarantee.
Warning and Safety instructions
6

In the event of a fault or for
cleaning purposes, the machine is
only completely isolated from the
electricity supply when:
–it is switched off at the wall socket
and the plug is withdrawn, or
–it is switched off at the mains, or
–the mains fuse is withdrawn, or
–the screw-out fuse is removed (in
countries where this is applicable).
Use
This equipment may only be used
in mobile installations such as
ships, caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
This dryer must not be:
– connected to a chimney or vent flue
which is in use.
–used without exhaust ducting.
–used without the fluff filter in place or
if the fluff filter is damaged in any
way.
Check all parts of the extraction
system on a regular basis (e.g. wall
vent, external grille, bends in the
ducting etc.) and make sure they are all
free of any hindrance. A build-up of fluff
will prevent a free-flow of air through the
system. If the dryer is to be connected
to an existing ducting system this must
be checked for suitability beforehand.
Adequate ventilation is essential to
avoid the danger of asphyxia and
toxic fumes where another appliance
which also uses the room air (e.g. gas,
oil or coal fired heater, continuous flow
or other water heater) is installed in the
same or an adjacent room.
To ensure safe operation, and to
prevent gases given off by these
appliances being drawn back into the
room, an underpressure of 0.04 mbar is
the maximum permissible.
–Ventilation can be maintained by air
inlets which cannot be blocked, in
windows, doors and outside wall
vents, or by fitting a window contact
switch which ensures that the tumble
dryer can only be operated when the
window is opened wide enough.
If in doubt, the advice of a competent
builder, or for gas, a "Corgi" registered
installer (in the UK) must be sought.
The exhaust air must not be vented
into a chimney or vent flue which is
in use, nor should it be connnected to
ducting which ventilates rooms with
fireplaces. It would be dangerous if
smoke or exhaust fumes were drawn
back into the room.
Do not install the machine in a
room where there is a risk of frost
occurring. At temperatures around
freezing point the machine may not be
able to operate properly.
The ambient room temperature should
be between +2°C and +35°C.
Warning and Safety instructions
7

To prevent the risk of fire the
following textiles must not be
dried in this machine:
–fabrics which contain a large
proportion of rubber, foam rubber or
rubber like materials.
–items which contain damaged
padding or fillings (e.g. pillows,
jackets).
–items which have been treated with
inflammable cleaning agents.
–items which have been splashed with
hair lacquer, hair spray, nail varnish
remover or similar substances.
– items which have been soiled with
oils or residues containing grease
(kitchen oils, cosmetics etc.).
– items soiled with wax or other
chemicals (e.g. mops and floor
cloths).
– items which have not been
thoroughly cleaned and which are
still soiled with grease or oil, e.g.
workwear. Such clothing may require
a heavy duty detergent to get them
clean. If necessary consult the
detergent manufacturer for advice.
Do not let anyone sit or lean on the
door, as this can cause the
machine to tip up.
Always close the door after use.
This way you will avoid the danger
of:
–children climbing onto or into the
dryer or hiding things in it.
–pets or other small animals climbing
into it.
Safety with children
This machine is not a toy. To avoid
the risk of injury keep children
away from the machine at all times and
supervise them whilst you are using it.
Do not allow children to play on or near
it or to play with its controls. Supervise
its use by the elderly or infirm.
Using accessories
Accessory parts may only be fitted
when expressly approved by Miele.
If non-Miele parts are used with this
machine, guarantee, performance and
product liability claims may be
invalidated.
Disposal of your old machine
Before discarding an old machine,
switch it off at the wall socket and
unplug it. Render the plug useless and
cut off the cable directly behind the
machine. This should be done by a
competent person.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
8

Control panel
aDisplay
bDelay start button
This button is used for:
- Selecting the duration of the
Warm air and Cool air
programmes
- Delaying the start of a programme
cBuzzer button
An audible tone sounds at the end of
the programme.
dCheck lights
These indicator lights have various
functions. See "Problem solving
guide" / "After sales service" for
details.
eStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
The button flashes while a
programme is being selected and
then is on constantly when the
programme has started.
fLow temperature button
Delicate fabrics are dried at a lower
temperature.
gDrying level button
with indicator lights
hProgramme selector
with indicator lights
iDoor button
Pressing this button will open the
door even when the machine is
switched off at the mains.
jI-On/0-Off button
For switching the dryer on and off.
Operating the tumble dryer
9

Display
The following are selected via the
display:
–Delay start
–Duration of the Cool air and Warm air
programmes
–Programmable functions
The display also shows:
–Programme duration
–Programme stage
Drying
Cooling down
Finish
– Check and fault messages
Programme duration / Estimated time
remaining
When a programme is selected, the
estimated duration (time remaining) will
appear in the display. Please be aware
that it is only an estimate!
The following factors all affect the
estimated time remaining: residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics continually assess
conditions in the machine and adjust
the estimated time remaining for a more
accurate reading. Because of this, the
time displayed can alter during the
course of a programme.
In the same way, the Woollens
handcare and Smoothing programmes
can finish earlier than expected if a
certain temperature is reached. This
can happen with particularly fine
fabrics, very small loads or if items
were partly dry beforehand.
Delay start
The delay start time selected will
appear in the display.
After the Start/Stop button has been
pressed, the delay start time will start
counting down.
Once the delay start time has elapsed,
the programme will begin and the
estimated programme duration will
appear in the display.
Programmable functions
The programmable functions can be
used to tailor drying programmes to suit
your individual requirements. In
programming mode, the display will
show the function selected.
Operating the tumble dryer
10

Care symbols
Before drying check the drying symbol
on the care label. If there are no
symbols, dry at your own risk!
q. . . . . . . . . Dry at normal temperature
r. . . . . . . . . . . . Dry at low temperature
s. . . . . . . . . . . . . . . Do not tumble dry
Tips on drying
–Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
– Do not put soaking wet items into the
tumble dryer. Spin them thoroughly
after washing using the appropriate
spin speed.
–For delicates and fabrics with the
following care label rselect
Low
temperature
.
–Use the
Automatic programme for
drying mixed loads of cottons and
minimum iron fabrics.
–Open jackets so that they can dry
evenly.
–Woollens and wool blends tend to
become matted and shrink if dried in
a tumble dryer. They can, however,
be partially dried using the
Woollens
handcare
programme.
–Down-filled garments have linings
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Smoothing programme.
–Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough. They can
be partially dried using the
Smoothing programme.
–Loopknit garments (e.g. T-shirts and
underwear) tend to shrink depending
on their quality. Do not over-dry these
textiles. When purchasing these
garments it is advisable to take their
shrinkage properties into account.
– For garments made from very fine
weave fibres, such as shirts or
blouses, only use the
Shirts or
Delicates programme to avoid
creasing. If in doubt, reduce the load
or use the
Smoothing programme.
–Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–New dark coloured garments should
be washed and dried separately
from light coloured garments to avoid
the danger of colours running and
discolouring other garments or even
plastic components in the machine.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
Notes on laundry care
11

Brief instructions
The headings numbered (A,B,C...)
show the operating sequence and can
be used as a brief guide to using your
machine.
ASort the laundry
To ensure an even drying result
separate out the washed laundry and
sort it according to: . .
. . . the drying level required
. . . the type of fibre or weave
. . size
. . the moisture content after spinning.
,Make sure that objects e.g.
detergent dispensing balls have
been removed from the laundry.
They could melt, and cause damage
to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
– Fasten duvet covers and pillow
cases to prevent small items from
being trapped inside them.
–Fasten hooks and eyes etc.
–Tie fabric belts and apron strings.
–Sew in or remove underwiring from
bras.
BTurn on the tumble dryer
^Switch the dryer on by pressing the
I-On/0-Off button in.
The tumble dryer may be switched on
after loading, saving energy as the light
will not come on.
CLoad the tumble dryer
^Press the
Door button to open the
door.
^Load the laundry loosely into the
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause unnecessary
wear and tear to the laundry and
give a disappointing drying result.
^Before closing the door make sure
the fluff filter is correctly positioned.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^Shut the door either with a gentle
swing, or lean against it and push it
shut.
How to dry correctly
12

DSelect a programme
^Select the programme you want.
The indicator light for the programme
selected will light up.
A drying level or additional option(s)
indicator light may also light up, or a
time may appear in the display
(Memory function).
Select a drying level
(Programmes with drying levels:
Cottons, Minimum iron, Delicates,
Automatic, Shirts and Denim
)
^Press the Drying level button
repeatedly until the indicator light for
the drying level you want lights up.
–Any of the drying levels can be
selected for the
Cottons programme.
A more limited range is available
when using other programmes.
Important: Please note that the
programme duration shown in the
display will vary according to the
programme selected (see "Programme
duration / Estimated time remaining").
You cannot alter the drying level of the
and Smoothing
programmes.
Select the duration for the Cool air
and Warm air programmes
The indicator light for the
Delay start
button will flash when the Cool air or
Warm air programme is selected.
^Press the
Delay start button
repeatedly until the required duration
shows in the display.
You can select a duration of 20 minutes
up to 2 hours in 10 minute steps.
ESelect any additional options
^The
Low temperature, Buzzer, and
Delay start
additional options are
selected by pressing the appropriate
button (see "Additional options" for
more details).
N.B.: It is not possible to select Delay
start when using the
Warm air or Cool
air
programme.
How to dry correctly
13

FStart the programme
The
Start/Stop button will flash when a
programme is being selected. The
flashing indicates that a programme
can be started.
^Press the
Start/Stop button.
The
Start/Stop button will now light up
constantly.
Drying will appear in the display and
the time remaining will start counting
down.
Memory
Settings selected for a programme can
be stored in memory, so that they are
automatically selected when this
programme is chosen again. See
"Programmable functions - Memory
function".
Before the end of a programme
There is a cooling down phase at the
end of the drying sequence (
Cooling
down
will light up in the display). The
programme will not finish until the
cooling down phase has been
completed.
There is no cooling down phase at the
end of the following programmes:
Woollens handcare, Smoothing.
GRemove the laundry when the
programme has finished
0 and Finish will appear in the display
to indicate that the programme has
finished. The buzzer (if selected) will
sound at intervals.
The drum will continue to rotate at
intervals to prevent laundry creasing,
if you do not wish to remove it
immediately (anti-crease). The
anti-crease phase lasts for an hour.
There is no anti-crease phase at the
end of the
Woollens handcare
programme.
^Press the
Door button.
^Open the door.
^Remove the laundry.
Check that all items have been
removed from the drum. If items are
left in the dryer, they could be
damaged by overdrying when the
dryer is next used.
If the dryer is switched on at the mains
and the door is opened, the drum
lighting will come on. It will go out a few
minutes later to save energy.
^Switch the dryer off by pressing the
l-On/0-Off button.
^After every cycle, remove the fluff
from the fluff filter in the door.
^Close the door.
How to dry correctly
14

Low temperature
For drying delicates and fabrics with
the rsymbol on the care label at a
lower temperature.
–For all delicate or minimum iron
fabrics with the rsymbol on the
care label (e.g. acrylic garments).
–The programme duration is longer.
–On some programmes
Low
temperature
is a standard part of the
programme and so cannot be
deselected.
Buzzer
A buzzer sounds (at intervals for a
maximum of 1 hr) to let you know the
programme has finished.
The buzzer will still sound if there is a
fault, even if it has been switched off.
Delay start
The start of a programme can be
delayed by up to 24 hours (24^).
After selecting a programme:
^Press the
Delay start button
repeatedly until the required delay
period shows in the display.
–The
Delay start indicator light will
flash.
–Times of:
up to 10^ are selected in 30 minute
steps
more than 10^ in 1 hour steps
–If you keep the
Delay start button
pressed in, the time will continue to
increase up to 24^.
To begin delay start
^Press the
Start/Stop button.
–The
Delay start indicator light will
light up constantly.
The delay start time counts down
towards the start of the programme as
follows:
–more than 10^ by the hour
–less than 10^ in minutes
The drum will turn briefly every hour to
help prevent creasing.
While the delay start time is counting
down, you can still add laundry to the
drum:
^Switch the dryer off.
^Open the door and add the laundry.
^Close the door and switch the dryer
back on again.
To cancel/alter delay start
^Press the
Start/Stop button.
This cancels delay start.
^Press the
Delay start button
repeatedly until the required delay
period shows in the display.
^Press the
Start/Stop button.
The altered delay start time will start
counting down from the beginning
again.
Additional options
15

Cottons Max. load: 6 kg*
Extra dry, Normal**
Fabric type Single and multi-layered cotton fabrics such as towelling,
jerseywear, T-shirts, underwear.
Notes –Select
Extra dry for multi-layered and very thick fabrics.
–Do not use
Extra dry for jersey fabrics (e.g. T-shirts,
underwear), as they have a tendency to shrink.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
Hand iron**, Machine iron
Fabric type Cottons or linen fabrics, e.g.: table linen, bed linen, starched
laundry.
Note –To prevent laundry from drying out it should be rolled up
until you are ready for ironing.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
Minimum iron Max. load: 3 kg*
Extra dry, Normal**, Hand iron
Fabric type Minimum iron items made of cotton, synthetic or blended
fabrics, e.g.: shirts, blouses, skirts and table cloths.
Notes –Select
Hand iron for delicate fabrics and to reduce
creasing even more, reduce the load to 1.5 kg*.
–In the Minimum iron programme with the
Hand iron drying
level, items are dried with very little creasing, depending
on fabric type and amount of laundry.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
Delicates Max. load: 2 kg*
Normal, Hand iron
Fabric type Delicate items made of synthetic fibres, easy care cotton or
blended fabrics, e.g. shirts, blouses and evening wear with
sequins and beading.
Low temperature Low temperature cannot be deselected.
* Weight of dry laundry
** Note for test institutes: Use this programme without selecting Low temperature
for testing according to EN 61121 Standard.
Programme chart
16

Woollens handcare Max. load: 2 kg*
Fabric type Woollen fabrics
Notes –This programme only fluffs up woollen garments. They are
not dried completely by this programme.
–Remove garments as soon as the programme has finished
and leave to finish drying at room temperature.
Low temperature Low temperature cannot be deselected.
Smoothing Max. load: 3 kg*
Fabric type –Cotton and linen fabrics.
–Minimum iron items made of mixed fibres, cottons or
synthetics, e.g.: trousers, jackets, shirts.
Notes –Smooths out creasing caused during the spin cycle in the
washing machine.
–Fabrics are not completely dried in this programme.
Remove garments as soon as the programme has finished
and leave to finish drying at room temperature.
Low temperature Low temperature cannot be deselected.
Automatic Max. load: 3.5 kg*
Normal, Hand iron
Fabric type Mixed loads of garments suitable for the
Cottons and
Minimum iron programmes. Sort according to colour.
Shirts Max. load: 2 kg*
Normal, Hand iron
Garments Shirts and blouses.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
Denim Max. load: 3 kg*
Normal, Hand iron
Fabric type Denim garments, e.g. jeans, jackets, skirts, shirts.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
* Weight of dry laundry
Programme chart
17

Cool air Max. load: 6 kg*
Fabric type –Any item which only needs airing.
Warm air Max. load: 6 kg*
Fabric type –"Voluminous" and multi-layered fabrics whose layers have
different drying characteristics, e.g. jackets, pillows.
–For drying individual items, e.g. bath towels, bathing
costumes, tea-towels and small loads.
Note Do not select the longest drying time to start with. Check the
items as you are drying them to find the optimum time.
Tip You can use the
Warm air programme to help remove odours
from cotton clothing which has been worn but it still clean
(select a duration of between 1/2 and 1 hour). Items must be
suitable for drying in a tumble dryer. Dampen the garments a
little beforehand or add a fabric conditioner sheet. The Warm
air programme will not be as effective at removing odours
from any parts of the garments which are made of synthetic
fibres.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
* Weight of dry laundry
Programme chart
18

Changing a programme while it
is running
You cannot change to another
programme once a programme has
started (this prevents unintentional
alterations).
You will need to cancel the current
programme before you can select a
new one.
Cancelling a programme
^Press the
Start/Stop button.
The items will be cooled down,
depending on the temperature
reached and how long they have
been dried for.
If you press the
Start/Stop button
again during the cooling down
phase,
Finish will light up in the
display.
^Switch the dryer off and then on
again.
^You can now select a different
programme.
Interrupting a programme
^Switch the dryer off.
To continue drying
^Switch the dryer on.
The programme will continue, as long
as the cooling down phase has not
been reached.
Adding or removing laundry
after a programme has started
^Press the
Door button.
^Open the door.
,Do not touch the back of the
drum when adding or removing
items. The drum could be very hot -
danger of burning.
^Add or remove items as required.
^Close the door.
^Press the
Start/Stop button.
Note
The time remaining shown in the
display may now vary from the actual
drying time.
Changing the programme sequence
19

The system lock prevents your
machine being used without your
knowledge.
It can be activated if wished.
The dryer's electronics are then locked.
The dryer can still be switched on but a
programme cannot be started.
–If an attempt is made to start a
programme, the indicator light for the
Low temperature button will come on
and a key symbol 0-§ will appear in
the display.
The door is not locked and can be
opened at any time.
To activate the lock
Before you begin, first ensure that:
– The tumble dryer is switched off.
– The door is closed.
APress the
Low temperature button
and keep it pressed in whilst carrying
out steps Bto E.
BPress the
I-On/0-Off button in.
The
Automatic indicator light will come
on.
CSlowly turn the programme selector
three positions stage by stage in a
clockwise direction.
Each of the three programme
indicator lights must come on one
after the other.
DNow slowly turn the programme
selector six positions stage by stage
in an anti-clockwise direction.
Each of the six programme indicator
lights must come on one after the
other.
The indicator light for the
Low
temperature
button will flash and a key
symbol 0-§ will appear in the display.
ERelease the
Low temperature button.
The electronics have now been locked.
^Switch the dryer off.
To deactivate the lock
Before you begin, first ensure that:
– The tumble dryer is switched off.
– The door is closed.
^The procedure is the same as for
activating the lock. Carry out steps A
to Eas described previously.
At step Ethe indicator light for the
Low
temperature
button will stop flashing
and the key symbol 0-§ will go out.
The electronics are no longer locked.
Electronic system lock
20
