Miele T 8402 C User manual

Operating instructions
for condenser tumble dryer
T 8402 C
To avoid the risk of accidents
or damage to the appliance
it is essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 868 870
en-GB

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and should be recycled.
Ensure that any plastic wrappings,
bags, etc are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose it with
your household waste.
Please dispose of it at your local
community waste recycling centre or
contact your dealer for advice. Ensure
that it presents no danger to children
while being stored for disposal.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
–Load according to the optimum
amount of laundry recommended for
the programme being used (see
Programme chart).
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
– Make sure the room in which the
dryer is located is well ventilated.
– Make sure the fluff filters are clean
before using the dryer.
– Check the condenser unit from time
to time and clean it when necessary.
Caring for the environment
2

Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Notes on laundry care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Care symbols.....................................................14
Tips on drying ....................................................14
How to dry correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Brief instructions ..................................................15
Low temperature................................................16
Changing the programme sequence ..................................17
Changing a programme once it has started...........................17
Cancelling a programme once it has started and then selecting a different
programme ....................................................17
Cancelling a programme once it has started and then removing the laundry . 17
Adding or removing laundry after a programme has started ..............17
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Emptying the condensed water container...............................20
Cleaning the fluff filters .............................................21
Cleaning them whilst dry .........................................21
Cleaning them with water .........................................22
Cleaning the tumble dryer ...........................................23
Cleaning the condenser unit .........................................24
Removing the condenser unit......................................24
Checking the condenser unit ......................................25
Cleaning the condenser unit.......................................25
Replacing the condenser unit......................................26
Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
General problems .................................................27
Check and fault messages ..........................................30
Changing the lamp ................................................31
After Sales service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Repairs..........................................................32
Future updates (PC) ...............................................32
Appliance guarantee ...............................................32
Optional accessories ...............................................32
Contents
3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Front view........................................................33
Rear view ........................................................34
Installation site ....................................................34
Transporting the tumble dryer to its installation site .....................34
Building under a continous worktop / in a kitchen run ...................34
Levelling the tumble dryer ........................................35
Room in which the dryer is located .................................35
Washer-dryer stack..............................................35
Before moving the tumble dryer again (e.g. when moving house) .........35
External condensed water outlet ......................................36
Arranging the drain hose .........................................36
External drainage via a sink or gully ................................37
Installation conditions requiring a non-return valve .....................37
Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Programmable functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Altering the residual moisture level in the Cottons programmes..............42
Altering the residual moisture level in the Minimum iron programme ..........43
Anti-crease ......................................................44
Activating and deactivating the buzzer .................................45
Altering the standard drying level in the Automatic programme..............46
Extending the cooling down time .....................................47
Standby .........................................................48
Contents
4

~It is essential to read these instructions.
This tumble dryer conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
~This tumble dryer is not designed for commercial use. It is
intended for use in domestic households and similar working and
residential environments.
~The tumble dryer is not intended for outdoor use.
~It must only be used as a domestic appliance to dry items which
have been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. If
using dry cleaning kits, do so at your own risk, and follow the
instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation.
Warning and Safety instructions
5

~The tumble dryer can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are are supervised whilst using it or have been
shown how to use it in a safe way and understand the hazards
involved.
Safety with children
~Children under 8 years of age must be kept away from the tumble
dryer unless they are constantly supervised.
~Children 8 years and older may only use, clean or maintain the
tumble dryer without supervision if they have been shown how to do
so in a safe way and understand the hazards involved.
~The tumble dryer is not a toy! To prevent the risk of injury, do not
allow children to play with it or near it, or to play with the controls.
Warning and Safety instructions
6

Technical safety
~Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
~Before connecting the tumble dryer, ensure that the connection
data on the data plate (voltage and frequency) match the mains
electricity supply. If in any doubt, consult a qualified electrician.
~The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician. Miele cannot be held liable for the
consequences of an inadequate earthing system (e.g. electric
shock).
~Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads do not guarantee the required
safety of the tumble dryer (e.g. danger of overheating).
~If the electrical connection cable is faulty it must only be replaced
by a Miele approved service technician to protect the user from
danger.
~Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician, otherwise any
subsequent damage will not be covered by the guarantee. Ensure
current is not supplied to the tumble dryer until after maintenance or
repair work has been carried out.
Warning and Safety instructions
7

~Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
~The tumble dryer must be isolated from the electricity supply in
the event of a fault and during cleaning and maintenance.
~The tumble dryer must not be used in a non-stationary location
(e.g. on a ship).
~Do not make any alterations to the tumble dryer, unless
authorised to do so by Miele.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the tumble dryer
and its surroundings in a clean condition at all times. Any damage
which may be caused by cockroaches or other vermin will not be
covered by the guarantee.
Warning and Safety instructions
8

Correct use
~To prevent the risk of fire, the following textiles must not be dried
in this appliance:
–items which have not been washed.
–items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
deposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned there is a danger that
these might self-ignite when heated, even after they have been
removed from the dryer at the end of the programme.
– items (e.g. mops and floor cloths) which have been treated with
inflammable cleaning agents or which contain residues of
acetone, alcohol, benzine, petrol, kerosene, stain remover,
turpentine, wax and wax remover or other chemicals.
– items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items, ensure that you use
additional detergent and select a high temperature. If in doubt,
wash the items several times.
~Remove all items such as lighters and matches from pockets.
~Warning: Do not switch the tumble dryer off before the drying
programme has finished. If this is done, the laundry must be hung
up or spread out to cool it down.
Warning and Safety instructions
9

~Danger.
This tumble dryer must not be connected to a controllable socket
(e.g. a timer switch or a peak load shut-off device).
If the dryer programme were to be interrupted before the end of the
cooling down phase, the laundry could self-combust.
~To prevent the risk of fire, the following must not be tumble dried:
–items which have been cleaned using chemicals (e.g.
professional dry-cleaning agents).
–fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of
igniting in the dryer.
~In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
~Fabric conditioner and similar products must be used according
to the instructions on the manufacturer's packaging.
~Do not let anyone sit or lean on the door, as this can cause the
tumble dryer to tip up.
~Always close the door after use. This way you will avoid the
danger of:
–children climbing into the dryer or hiding things in it.
–pets or other small animals climbing into it.
Warning and Safety instructions
10

~The dryer must not be used without the fluff filters in place or if
the fluff filters are damaged in any way.
~The fluff filters must be cleaned regularly.
~The dryer must not be used without the condenser unit in place.
~The fluff filters must be thoroughly dried after cleaning. Damp or
wet filters could cause operational faults.
~Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and in the
drain hose. The ambient room temperature should be between +2°C
and +35°C.
~If the water is drained externally instead of being collected in the
condensed water container, make sure the drain hose is securely
attached if you hang it in a sink or basin to avoid the hose slipping
and the water causing damage.
~Condensed water is not drinking water.
It can cause health problems in both people and animals.
~Always keep the area around the tumble dryer free of dust and
fluff. Dust drawn into the tumble dryer can cause blockages in the
condenser unit over time.
~The tumble dryer must not be hosed down.
Warning and Safety instructions
11

Accessories
~Only use genuine Miele original spare parts and accessories with
this tumble dryer.
If non-Miele parts are used, guarantee, performance and product
liability claims may be invalidated.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Warning and Safety instructions
12

aProgramme selector
The programme selector can be
turned clockwise or anti-clockwise.
bProgramme sequence and check
lamps
cStart button
Press the Start button to start a
programme.
The Start indicator lamp will flash as
soon as a programme can be
started. It lights up constantly once
the programme has started.
dI-On/0-Off button
To switch the appliance on or off / to
interrupt a programme.
The Finish/Anti-crease lamp will light
up as confirmation that the tumble
dryer has been switched on.
eDoor Button
To open the door / to cancel a
programme.
Pressing this button will open the
door even when the appliance is
switched off at the mains.
If the appliance is switched on at the
mains and the door is opened the
drum lighting will come on. It will go
out a few minutes later to save
energy.
Control panel
13

Care symbols
Before drying check the drying symbol
on the care label. If there are no
symbols, dry at your own risk!
q.........Dryatnormal temperature
r..........Dryatalowtemperature
s...............Donottumble dry
–For delicates and fabrics with the
following care label rselect Low
temperature.
Tips on drying
– Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
– Do not put soaking wet items into the
tumble dryer. Spin them thoroughly
after washing using the appropriate
spin speed.
–Use the Automatic programme for
drying mixed loads of cottons and
minimum iron fabrics.
–Open jackets so that they can dry
evenly.
–Woollens and wool blends tend to
become matted and shrink if dried in
a tumble dryer. They can, however,
be partially dried using the Woollens
handcare programme.
–Down-filled garments have linings
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Smoothing programme.
–Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough. It can be
partially dried using the Smoothing
programme.
–Loopknit garments (e.g. T-shirts and
underwear) tend to shrink depending
on their quality. Do not over-dry
these textiles. When purchasing
these garments it is advisable to take
their shrinkage properties into
account.
– Minimum iron fabrics tend to crease
more, the greater the load. This is
also the case for garments made
from very fine weave fabrics, such as
shirts or blouses.
If in doubt, reduce the load or use
the Minimum iron - Hand iron
programme.
–Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–New dark coloured garments should
be washed and dried separately
from light coloured garments to avoid
the danger of colours running and
discolouring other garments or even
plastic components in the appliance.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
Notes on laundry care
14

Brief instructions
The headings numbered (A,B,C...)
show the operating sequence and can
be used as a brief guide to using your
dryer.
ASort the laundry
To ensure an even drying result
separate the washed laundry and sort it
according to:
. . . the drying level required
. . . the type of fibre or weave
. . . size
. . . the moisture content after spinning.
,Make sure that objects e.g.
detergent dispensing balls have
been removed from the laundry.
They could melt, and cause damage
to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
– Fasten duvet covers and pillow
cases to prevent small items from
being trapped inside them.
–Fasten hooks and eyes etc.
–Tie fabric belts and apron strings.
–Sew in or remove underwiring from
bras.
BTurn on the tumble dryer
^Switch the dryer on by pressing the
jk button.
The tumble dryer may be switched on
after loading, saving energy as the
lighting will not come on.
CLoad the tumble dryer
^Press the Door button to open the
door.
^Load the laundry loosely into the
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause unnecessary
wear and tear to the laundry and
give a disappointing drying result.
^Before closing the door make sure
the fluff filter is correctly positioned.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^Shut the door either with a gentle
swing, or lean against it and push it
shut.
How to dry correctly
15

DSelect a programme
^Turn the programme selector to the
required programme.
Low temperature
^For drying particularly sensitive
fabrics (care symbol r) e.g. acrylics
turn the programme selector to the
Low temperature position.
Because the heater rating is reduced
for the Low temperature setting, clothes
dry more slowly thus lengthening drying
times.
EStart the programme
^Press the Start button.
The indicator lamp for the Start button
will then change from flashing to being
on constantly.
The drying cycle begins.
Depending on the programme
selected, the drying stage reached is
shown by the sequence indicator lamps
on the right hand side of the control
panel.
Before the end of a programme
The cooling down phase takes place
before the end of a programme so that
the garments are not too hot to handle
(the Cool air indicator lamp will come
on). The programme is not finished until
the cooling down phase is complete.
The Woollens handcare and Smoothing
programmes do not include a cooling
down phase.
At the end of a programme
The Finish/Anti-crease indicator lamp
comes on.
The drum will continue to rotate at
intervals to prevent laundry creasing, if
you do not wish to remove it immediate-
ly. The anti-crease phase lasts for an
hour. There is no anti-crease phase on
the Woollens handcare programme.
During the anti-crease phase...
. . . (depending on the programme
selected) the indicator lamp for the
drying stage reached will also light up.
. . . the buzzer will sound at intervals.
How to dry correctly
16

FRemove the laundry
^Press the Door button.
^Open the door.
^Remove the laundry.
Check that all items have been
removed from the drum. If items are
left in the dryer, they could be
damaged by overdrying when the
dryer is next used.
^Switch the dryer off by pressing the
l-On/0-Off button.
^Clean the fluff filters.
^Close the door.
^Empty the condensed water
container (unless the dryer has been
connected for external drainage).
^The condenser unit should be
checked and cleaned on a regular
basis (see "Cleaning and care").
Changing the programme
sequence
Changing a programme once it has
started
You cannot change to another
programme once a programme has
started (this prevents unintentional
alterations).
If you try and change a programme the
Finish/Anti-crease light will start
flashing.
You will need to cancel the current
programme before you can select a
new one.
Cancelling a programme once it has
started and then selecting a different
programme
^Turn the programme selector to
Finish.
^Press the Door button.
^Close the door.
^Select another programme and start
it.
Cancelling a programme once it has
started and then removing the
laundry
^Proceed as described in "Adding or
removing laundry after a programme
has started" below.
^Switch the dryer off after closing the
door.
Adding or removing laundry after a
programme has started
^Press the Door button.
^Open the door.
,Danger of burning:
Do not touch the back of the drum
when adding or removing items. The
drum and the items can get very hot.
^Add or remove items as required.
^Close the door.
^Press the Start button.
How to dry correctly
17

Cottons Max. load: 6 kg*
Normal+, Normal**, Low temperature
Fabric type Single and multi-layered cottons fabrics such as towelling,
jerseywear, underwear, flannelette bed linen.
Note –Select Low temperature for fabrics with the rsymbol. Laundry
is dried at a lower temperature.
Hand iron, Machine iron
Fabric type Cottons and linen fabrics, e.g. table linen, bedlinen, starched
laundry.
Note To prevent laundry from drying out it should be rolled up until you
are ready for ironing.
Minimum iron Max. load: 3 kg*
Normal, Low temperature, Hand iron
Fabric type Minimum iron items made of cotton, synthetic or blended fabrics,
e.g. shirts, blouses, skirts and table cloths.
Notes – Select Low temperature for fabrics with the rsymbol (e.g.
acrylic garments). Laundry is dried at a lower temperature.
– Select Hand iron for delicate fabrics and to reduce creasing
even more, reduce the load to 1.5 kg*.
– In the Minimum iron Hand iron programme, items are dried with
very little creasing, depending on fabric type and amount of
load.
* Weight of dry laundry
** Note for test institutes:
Test programme in accordance with Regulation 392/2012/EU for energy
labelling measured in accordance with EN 61121
Programme chart
18

Automatic Max. load: 3.5 kg*
Fabric type Mixed load of garments suitable for Cottons and Minimum iron
programmes.
Timed drying Max. load: 6 kg*
Warm air
Fabric type –Multi-layered fabrics whose layers have different drying
characteristics, e.g. jackets, pillows.
–For drying individual items, e.g. bath towels, swimwear,
tea-towels.
Cool air
Fabric type Any item which only needs airing.
Woollens handcare Max. load: 2 kg*
Fabric type Woollen fabrics
Notes – To refresh and fluff up woollen garments quickly. Woollen
fabrics are not dried completely by this programme.
– Remove garments as soon as the programme has finished and
leave to finish drying at room temperature.
Smoothing Max. load: 3 kg*
Fabric type – Cottons and linen fabrics.
– Minimum iron mixed fibre, cotton or synthetic items, e.g.
trousers, jackets, shirts.
Notes – Smooths out creasing caused during the spin cycle in the
washing machine.
–Fabrics are not completely dried in this programme. Remove
garments as soon as the programme has finished and leave to
finish drying at room temperature.
* Weight of dry laundry
Programme chart
19

Emptying the condensed water
container
The condensed water will be collected
in the condensed water container
unless the tumble dryer has been fitted
with a drain hose (see installation).
The condensed water container
should be emptied after every
drying cycle or as soon as the
Empty out container indicator lamp
comes on.
The drying programme will be
interrupted if the maximum level of the
condensed water container is reached.
The Empty out container indicator lamp
comes on and the buzzer sounds.
^Grip the container firmly with both
hands, as shown, and pull it out
slightly towards the right-hand side.
^Hold the container with both hands
and carry it in a horizontal position.
^Open the shutter and empty out the
water.
^To replace the container hold it at a
slight angle (as when removing it)
and push it in gently until you feel it
click into position.
^Before starting a new programme,
first switch the tumble dryer off and
then on again. The Empty out
container indicator lamp will go out.
Condensed water should not be
consumed. It could lead to health
problems for people and animals.
Condensed water can be put to
household use (e.g. used in a steam
iron or humidifier). To ensure that any
residual particles of fluff in the
condensed water are removed before
use, pass it through a fine sieve or
paper filter first.
Cleaning and care
20
