Miele TEJ 665 WP User manual

Operating instructions
Heat pump dryer
To avoid the risk of accidents or damage to the appliance it is essen-
tial to read these instructions before it is installed and used for the
first time.
en-GB M.-Nr. 12 032 440

Contents
2
Caring for the environment ............................................................................. 6
Warning and Safety instructions ..................................................................... 7
Operating the tumble dryer .............................................................................. 19
Control panel....................................................................................................... 19
Operating the sensor controls............................................................................. 21
Display................................................................................................................. 21
Examples on how to operate the appliance........................................................ 21
Before using for the first time .......................................................................... 22
Miele@home ........................................................................................................ 22
Wash2Dry ............................................................................................................ 23
Requirements for use ..................................................................................... 23
Downtime after installation.................................................................................. 24
Energy saving tips ............................................................................................. 26
Energy saving tips ............................................................................................... 26
Feedback............................................................................................................. 27
1. Notes on correct laundry care ..................................................................... 28
Points to note regarding washed laundry............................................................ 28
Preparing the laundry before drying.................................................................... 28
Drying .................................................................................................................. 29
Care label symbols ......................................................................................... 29
Select the correct drying level........................................................................ 29
2. Selecting a programme ................................................................................ 30
Switching on the tumble dryer ............................................................................ 30
3. Loading the tumble dryer ............................................................................. 33
Loading the laundry............................................................................................. 33
4. Selecting programme settings..................................................................... 34
Programme settings ............................................................................................ 34
Selecting the drying level for a drying level programme ................................ 34
Other programmes and timed drying programmes........................................ 34
Selecting an extra option..................................................................................... 35
 Delay start/SmartStart ................................................................................... 35
5. Starting a programme................................................................................... 37
Starting the programme ...................................................................................... 37
6. End of programme - unload the drum......................................................... 38
End of programme............................................................................................... 38
Unloading the drum............................................................................................. 38

Contents
3
Programme chart .............................................................................................. 39
Programmes on the control panel ....................................................................... 39
Further programmes............................................................................................ 42
Extras.................................................................................................................. 45
Gentle tumble...................................................................................................... 45
Freshen up........................................................................................................... 45
Anti-crease .......................................................................................................... 45
Buzzer.................................................................................................................. 45
Drying programme overview - Extras.................................................................. 46
Changing the programme sequence .............................................................. 47
Adding or removing laundry ................................................................................ 47
Condensed water container ............................................................................. 48
Emptying the condensed water container .......................................................... 48
Fragrance flacon................................................................................................ 49
FragranceDos ...................................................................................................... 49
Removing the protective seal from the fragrance flacon..................................... 49
Inserting the fragrance flacon.............................................................................. 50
Opening the fragrance flacon.............................................................................. 51
Closing the fragrance flacon ............................................................................... 51
Removing/replacing the fragrance flacon ........................................................... 52
Cleaning and care ............................................................................................. 53
Fluff filters............................................................................................................ 53
Removing the fragrance flacon ...................................................................... 53
Removing visible fluff ..................................................................................... 53
Cleaning the fluff filters and air flow openings thoroughly ............................. 54
Cleaning the fluff filters with water ................................................................. 55
Cleaning the plinth filter....................................................................................... 56
Removing the plinth filter ............................................................................... 56
Cleaning the plinth filter.................................................................................. 57
Cleaning the plinth filter access panel ........................................................... 58
Cleaning the dryer ............................................................................................... 58
Problem solving guide ...................................................................................... 59
The display indicates the following messages or faults...................................... 59
Unsatisfactory drying results............................................................................... 62
The drying cycle duration is very long................................................................. 63
General problems with the tumble dryer ............................................................. 64
Replacing the plinth filter..................................................................................... 65
Reactivating the plinth filter................................................................................. 67

Contents
4
Checking the heat exchanger.............................................................................. 67
Service................................................................................................................ 68
Contact in the event of a fault ............................................................................. 68
Optional accessories........................................................................................... 68
Warranty .............................................................................................................. 68
Installation.......................................................................................................... 69
Front view ............................................................................................................ 69
Rear view............................................................................................................. 70
Transporting the tumble dryer ............................................................................. 70
Transporting the tumble dryer to its installation site ...................................... 70
Installation ........................................................................................................... 71
Levelling the dryer .......................................................................................... 71
Downtime after installation............................................................................. 71
Ventilation....................................................................................................... 71
Before moving the tumble dryer again (e.g. when moving house)................. 71
Additional installation requirements .................................................................... 72
External condensed water outlet......................................................................... 73
Installation conditions requiring a non-return valve ....................................... 73
Arranging the drain hose ................................................................................ 74
Examples........................................................................................................ 74
Electrical connection ........................................................................................... 76
Technical data.................................................................................................... 77
Data sheet for household tumble driers .............................................................. 78
EU Conformity declaration .................................................................................. 80
UK Conformity declaration.................................................................................. 80
Consumption data............................................................................................. 81
Settings .............................................................................................................. 82
Accessing the settings menu .............................................................................. 82
Language ......................................................................................................... 83
Drying levels ........................................................................................................ 83
Cooling down temp............................................................................................. 83
Welcome tone ..................................................................................................... 83
Keypad tone ........................................................................................................ 84
Buzzer volume..................................................................................................... 84
Airways indicator ................................................................................................. 84
Conductivity ........................................................................................................ 85
Consumption....................................................................................................... 85
Code.................................................................................................................... 86

Contents
5
Brightness ........................................................................................................... 86
Display............................................................................................................ 86
Buttons active ................................................................................................ 86
Buttons inactive.............................................................................................. 86
Disp. switch-off stat. ........................................................................................... 87
Memory ............................................................................................................... 87
Anti-crease .......................................................................................................... 87
Programme info................................................................................................... 88
Miele@home ........................................................................................................ 88
Remote control.................................................................................................... 89
SmartGrid ............................................................................................................ 89
Wash2Dry ............................................................................................................ 90
RemoteUpdate .................................................................................................... 90
Running a RemoteUpdate.............................................................................. 90

Caring for the environment
6
Disposal of the packing mater-
ial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electrical and electronic appliances of-
ten contain valuable materials. They
also contain specific materials, com-
pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu-
man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local com-
munity waste collection / recycling
centre for electrical and electronic ap-
pliances, or contact your dealer or
Miele for advice. You are also respons-
ible for deleting any personal data that
may be stored on the appliance being
disposed of. Please ensure that your
old appliance poses no risk to children
while being stored prior to disposal.

Warning and Safety instructions
7
 It is essential to read these instructions.
This tumble dryer complies with all current local and national
safety requirements. However, inappropriate use can lead to per-
sonal injury and damage to property.
Read the operating instructions carefully before using the tumble
dryer. They contain important information on safety, installation,
use and maintenance. This prevents both personal injury and dam-
age to the tumble dryer.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the tumble dryer as well as the safety instruc-
tions and warnings.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.
Keep these operating instructions in a safe place and pass them
on to any future owner.
Correct application
 This tumble dryer is intended for use in domestic households and
similar working and residential environments.
 This tumble dryer is not intended for outdoor use.
 It must be used only as a domestic appliance to dry items which
have been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. If us-
ing dry cleaning kits, do so at your own risk, and follow the instruc-
tions provided on the packaging.
Any other applications may be dangerous. Miele cannot be held li-
able for damage resulting from incorrect or improper use or opera-
tion.

Warning and Safety instructions
8
 This tumble dryer can only be used by people with reduced phys-
ical, sensory or mental capabilities, or lack of experience or know-
ledge, if they are supervised whilst using it or have been shown how
to use it in a safe way and understand and recognise the con-
sequences of incorrect operation.
Safety with children
 Children under 8 years of age must be kept away from the tumble
dryer unless they are constantly supervised.
 Children 8 years and older may only use the tumble dryer unsu-
pervised if they have been shown how to use it safely and recognise
and understand the consequences of incorrect operation.
 Children must not be allowed to clean or maintain the tumble
dryer unsupervised.
 Please supervise children in the vicinity of the tumble dryer and do
not let them play with it.

Warning and Safety instructions
9
Technical safety
 Please observe the instructions in “Installation” and the “Technical
data”.
 Before setting up the tumble dryer, check it for any externally vis-
ible damage.
Do not install or use a damaged tumble dryer.
 Before connecting the tumble dryer, ensure that the connection
data on the data plate (fuse rating, voltage and frequency) match the
mains electricity supply. If in any doubt, consult a qualified electri-
cian.
 Reliable and safe operation of this tumble dryer can only be as-
sured if it has been connected to the mains electricity supply.
 The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is essential that this standard safety re-
quirement is met. If in any doubt, please have the household wiring
system tested by a qualified electrician. Miele cannot be held liable
for the consequences of an inadequate earthing system (e.g. electric
shock).
 Do not connect the appliance to the mains electricity supply by an
extension lead, multi-socket adapter or similar. These can overheat
and are a fire hazard.

Warning and Safety instructions
10
 Faulty components must only be replaced by genuine Miele ori-
ginal spare parts. The manufacturer can only guarantee the safety of
the appliance when Miele replacement parts are used.
 Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician, otherwise any
subsequent damage will not be covered by the warranty.
 The accessibility of the plug must always be ensured, in order to
disconnect the tumble dryer from the mains.
 If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
 The tumble dryer must be isolated from the electricity supply in
the event of a fault and during cleaning and maintenance.

Warning and Safety instructions
11
 Heat pump technology and refrigerant:
this tumble dryer uses a gaseous refrigerant which is condensed by
the compressor. The refrigerant, which is brought to a higher temper-
ature level and liquefied by condensing, is led in a closed circuit
through the heat exchanger unit where heat exchange with the circu-
lating drying air takes place.
Damage to the tumble dryer by switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer wait for at least one hour before
switching it on.
- The humming noises caused by the heat pump during the drying
process are normal. They do not impair the efficient functioning of
the dryer.
- The refrigerant is not flammable or explosive.
- This tumble dryer contains fluorinated greenhouse gases. Her-
metically sealed.
Designation of refrigerant R134a R134a R450A
Refrigerant quantity 0.48kg 0.30kg 0.31kg
Ozone-depletion potential of
refrigerant
1430kg CO2 e 1430kg CO2 e 605kg CO2 e
Ozone-depletion potential of
appliance
686kg CO2 e 429kg CO2 e 188kg CO2 e
The designation and quantity of refrigerant that apply to this tumble dryer, and
the ozone-depletion potential, can be found on the data plate (at the back of the
tumble dryer).

Warning and Safety instructions
12
 Do not block the gap between the bottom of the tumble dryer and
the floor with plinth facings, deep pile carpet etc. This would hinder a
sufficient flow of air to the dryer.
 Make sure the dryer door can be opened without hindrance after
installation.
 This tumble dryer must not be used in a non-stationary location
(e.g. on a ship).
 Do not make any alterations to the tumble dryer, unless authorised
to do so by Miele.
 This tumble dryer is supplied with a special lamp to cope with
particular conditions (e.g. temperature, moisture, chemical resist-
ance, abrasion resistance and vibration). This special lamp must only
be used for the purpose it is intended for. It is not suitable for room
lighting. Replacement lamps may only be fitted by a Miele authorised
person or the Miele Service Department.

Warning and Safety instructions
13
Correct use
 Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and hoses.
 The maximum load for this tumble dryer is 9.0 kg (dry weight).
The maximum recommended loads for individual programmes are
given in the Programme chart.
 To prevent the risk of fire, do not connect the tumble dryer via a
controllable socket (e.g. a timer or a peak-load switch-off device).
If the drying programme is interrupted before the end of the cooling
down phase, this could cause the laundry to self-ignite.
 Warning: Do not switch the dryer off before the drying pro-
gramme has finished. If this is done, the laundry must be hung up or
spread out to cool it down.
 In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry self-ig-
niting). The programme is not finished until the cooling down phase
has been completed.
As soon as the programme has finished, remove all laundry from the
drum.

Warning and Safety instructions
14
 To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
- Items which have not been washed.
- Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other depos-
its (such as cosmetics, lotions etc). If items have not been thor-
oughly cleaned there is a danger that these might ignite when
heated, even after they have been removed from the dryer at the
end of the programme.
- Items (e.g. mops and floor cloths) which have been treated with
inflammable cleaning agents or which contain residues of acet-
one, alcohol, benzene, petrol, kerosene, stain remover, turpentine,
wax and wax remover or other chemicals.
- Items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items ensure that you use suffi-
cient detergent and select a high temperature. If in doubt, wash
the items several times.
 Remove all items from pockets (e.g. lighters, matches).

Warning and Safety instructions
15
 To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
- Items which have been cleaned using chemicals (e.g. professional
dry-cleaning agents).
- Items which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
- Damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of it
igniting in the dryer.
 Always close the door after use. This way you will avoid the
danger of:
- Children climbing onto or into the dryer or hiding things in it.
- Pets or other small animals climbing into it.
 Do not let anyone sit or lean on the door, as this can cause the
tumble dryer to tip up.
 The fluff filters must be cleaned after every drying cycle.
 The fluff filters or the plinth filter must be thoroughly dried after
cleaning. Wet fluff/plinth filters could cause operational faults while
drying.

Warning and Safety instructions
16
 The tumble dryer must not be used without fluff filters or
- with damaged fluff filters, or
- with a damaged plinth filter.
This would cause an excessive build-up of fluff which in turn would
cause a fault.
 If the water is drained externally through the drain hose instead of
being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.
 Condensed water is not drinking water.
It can cause health problems in both people and animals if con-
sumed.
 Always keep the area around the tumble dryer free of dust and
fluff.
Dust drawn into the tumble dryer can cause blockages in the heat
exchanger over time.
 The tumble dryer must not be hosed down.
 Fabric conditioner and similar products must be used according
to the instructions on the manufacturer's packaging.

Warning and Safety instructions
17
Using a fragrance flacon (optional accessory)
 Only use genuine Miele original fragrance flacons.
 The fragrance flacon must be stored in its packaging so please
make sure you retain this.
 Caution. The fragrance can leak out of the flacon. Make sure that
you always keep the flacon, or the fluff filter with the flacon inserted
in it, in a horizontal position when carrying and do not tip or place
down on any surface.
 Use an absorbent cloth to wipe up any fragrance which has
leaked out of the flacon onto the floor, the dryer or any dryer com-
ponents (e.g. the fluff filter) immediately.
 If fragrance which has leaked out of a flacon: comes into contact
with the skin - wash the skin thoroughly with soap and water; comes
in contact with the eyes - rinse the eyes with clean water for at least
15minutes; is swallowed - rinse out the mouth thoroughly with
clean water. Seek medical advice in the case of contact with the
eyes or if fragrance has been swallowed.
 If fragrance which has leaked out of a flacon comes in contact
with clothing, change the clothing immediately. Wash the clothing or
any cloths used for mopping up fragrance thoroughly with plenty of
water and detergent.
 There is the risk of fire or damage to the tumble dryer if the follow-
ing instructions are not observed:
- Never refill a flacon with fragrance.
- Never use a faulty fragrance flacon.
 Dispose of an empty fragrance flacon with the household waste
and never use it for any other purpose.
 Please also observe the information supplied with the fragrance
flacon.

Warning and Safety instructions
18
Accessories
 Only use genuine Miele original spare parts and accessories with
this appliance. If non-Miele parts are used, warranty, performance
and product liability claims will be invalidated.
 The tumble dryer can be combined with a Miele washing machine
in a washer-dryer stack. The appropriate “WTV” stacking kit (avail-
able to order) to match your tumble dryer and washing machine is
required.
 If you order a plinth for this tumble dryer (available from Miele as
an optional accessory - depending on country), make sure it is the
correct one.
Miele cannot be held liable for damage caused by non-compli-
ance with these Warning and Safety instructions.

Operating the tumble dryer
19
Control panel
aControl field
The control field consists of a dis-
play and various sensor controls.
The individual sensors are explained
in the following sections.
bDisplay
The following values are shown on
the display and/or selected from it:
1. The programme names, the drying
level, and the duration of the se-
lected programme.
2. The individual values for selected
extras and settings.
cSensor controls 
Values shown in the display can be
changed with the  sensors. The
 sensor increases the value or
moves up the list; the  sensor de-
creases the value or moves down
the list.
dOK sensor
The OK sensor is used for confirm-
ing selected values.
ePerfectDry indicator
The PerfectDry indicator flashes
after the programme has started and
switches off when the programme
running time is displayed. The Per-
fectDry system measures the resid-
ual moisture of the laundry. In pro-
grammes with selectable drying
levels, PerfectDry dries the laundry
precisely, although the result is also
influenced by the calcium content of
the water.
The PerfectDry indicator lights up to-
wards the end of the programme
once the selected drying level has
been reached.
Nothing is indicated for programmes
that do not have a selectable drying
level.

Operating the tumble dryer
20
fOptical interface
This is used by the Service depart-
ment as a transmission point.
gSensors for extra options
You can select extra options to aug-
ment drying programmes.
If a drying programme has been se-
lected, the sensor controls for the
possible extra options light up dimly.
hsensor
You can use the  sensor to call up
an energy consumption forecast for
the selected drying programme.
See “Washing environmentally and
economically”, section
“EcoFeedback” for more informa-
tion.
i sensors
The  sensor starts the delay start
function. With the delay start func-
tion, you can choose when you want
the programme to start. The start of
the programme can be delayed from
15minutes up to a maximum of 24
hours. This allows you to make use
of night-time economy electricity
rates, for example.
For further information see “4. Se-
lecting programme settings”
jStart/Add laundry sensor control
Touching the Start/Add laun-
drysensor control starts a pro-
gramme. The current programme
can be interrupted to add laundry.
The programme can be started when
the sensor control is flashing on and
off. The sensor control lights up con-
stantly once the programme has
started.
kProgramme selector
This is used for selecting pro-
grammes and for switching off. The
tumble dryer is switched on by se-
lecting a programme and switched
off by turning the programme se-
lector to the position.
Under Further programmes/ you
will find:
– The Wash2Dry function as well as
additional programmes
– The option to change Settings
