Operating and installation instructions
Gas hobs
KM 2014
KM 2034 / 2035
KM 2052
KM 2054
To avoid the risk of accidents
or damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 181 160
en-GB

GThis appliance can be used in countries other than those specified on the
appliance. It is, however, set up for connection to the gas and electricity
supplies in the countries specified. For use in other countries please contact
the Miele spare parts or customer service department in your country.
DDas Gerät ist auch für den Gebrauch in anderen als auf dem Gerät
angegebenen Bestimmungsländer zugelassen. Die landesspezifische
Ausführung und die Anschlussart des Gerätes haben wesentlichen Einfluss auf
den einwandfreien und sicheren Betrieb. Für den Betrieb in einem anderen als
auf dem Gerät angegebenen Bestimmungsland wenden Sie sich bitte an den
für das Land zuständigen Kundendienst.
EEl aparato está autorizado para el uso en países diferentes a los países de
destino indicados. La ejecución específica para cada país y el tipo de
conexión del aparato influyen de forma decisiva en el funcionamiento correcto
y seguro. Para el funcionamiento en un país diferente al país de destino
indicado en el aparato, consulte al Servicio Post-venta autorizado para el país.
FCet appareil est également homologué dans des pays différents de ceux
mentionnés sur l’appareil. Pour que l’appareil fonctionne parfaitement et en
toute sécurité, il est important de disposer de l’exécution spécifique au pays et
du type de raccordement approprié. Pour le fonctionnement dans un pays
autre que celui spécifié sur l’appareil, veuillez vous adresser au service
après-vente du pays où sera installé l’appareil.
IL’apparecchio può essere usato anche in paesi diversi da quello indicato
sull’apparecchio stesso. Tuttavia, le varianti specifiche di un determinato paese
e il tipo di allacciamento alla rete hanno un’importanza fondamentale per il suo
sicuro e corretto funzionamento. Per questo se si vuole usare l’apparecchio in
un paese diverso rivolgersi al servizio di assistenza tecnica Miele del paese in
cui si intende usarlo.
MHet apparaat is ook toegelaten voor gebruik in andere landen dan de landen
die op het apparaat vermeld staan. De specifieke uitvoering en de aansluitwijze
zijn van groot belang voor het goed en veilig functioneren. Neem daarom
contact op met de Technische Dienst van de fabrikant in uw land als u het
apparaat in een land wilt gebruiken dat niet op het apparaat vermeld staat.
2

Gas-heated appliances
Safety precautions to take if you smell gas
ßTurn off the gas emergency control valve immediately.
This is usually located near the gas meter.
ßEliminate all sources of ignition in a safe manner.
Do not smoke, light cigarette lighters or matches.
ßDo not operate electrical lights or switches, i.e. do not switch them "On" or "Off".
ßOpen all doors and windows to ventilate the area.
ßIf the smell of gas persists, evacuate the building.
In the UK you must now:
ßCall the Gas Emergency Contact Centre (Tel: [phone])
For any gas work in the UK always use a Gas Safe registered engineer.
In other countries please follow relevant country specific procedures on gas.
3

Guide to the appliance .............................................5
Models ...........................................................5
Burner ...........................................................9
Warning and Safety instructions ....................................10
Caring for the environment.........................................17
Before using for the first time.......................................18
Operation .......................................................19
Switching on .....................................................20
Regulating the flame ...............................................21
Switching off .....................................................21
Suitable pans ....................................................22
Safety cut-out ....................................................24
Cleaning and care ................................................25
Problem solving guide ............................................29
Optional accessories..............................................31
Safety instructions for installation...................................32
Appliance and building-in dimensions ...............................35
Installation ......................................................38
Electrical connection..............................................40
Gas connection ..................................................42
Burner ratings ...................................................44
Conversion to another type of gas...................................46
Jet table .........................................................46
Changing the jets..................................................47
To change the main jets ..........................................47
To change the small jets..........................................48
After changing the jets..............................................50
After sales service, data plate ......................................51
Contents
4

Models
KM 2014
aWok burner
bSmall burner
cd Medium burners
Controls:
eFront right
fRear right
gRear left
hFront left
Guide to the appliance
5

KM 2034 / KM 2035
aLarge burner
bSmall burner
cd Medium burners
eWok burner
Controls:
fFront right
gRear right
hMiddle
iRear left
jFront left
Guide to the appliance
6

KM 2052
aWok burner
bSmall burner
cLarge burner
de Medium burners
Controls:
fFront right
gRear right
hMiddle
iRear left
jFront left
Guide to the appliance
7

KM 2054
ad Wok burners
bSmall burner
cLarge burner
eMedium burner
Controls:
fFront right
gRear right
hMiddle
iRear left
jFront left
Guide to the appliance
8

Burner
Wok burner Small, medium and large burners
aBurner ring
bBurner cap
cBurner head
dBurner base
eIgnition safety device
fIgnitor
Guide to the appliance
9

This appliance complies with all
relevant local and national safety
requirements. Improper use of the
appliance can, however, present a
risk of both personal injury and
material damage.
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before installation and using it for
the first time. They contain important
notes on installation, safety,
operation and care.
Keep these instructions in a safe
place and ensure that new users are
familiar with the content. Pass them
on to any future owner.
Correct application
~This gas hob is not designed for
commercial use. It is intended for use in
domestic households and in similar
working and residential environments
such as:
–Shops
–Offices and showrooms
and by residents in establishments
such as:
–Hostels and guest houses.
~It is intended for domestic use only
to cook food and keep it warm.
Any other usage is not supported by
the manufacturer and could be
dangerous. Miele cannot be held liable
for damage resulting from incorrect or
improper use or operation.
~The gas hob is not intended for
outdoor use.
~This appliance is not intended for
use by people with reduced physical,
sensory or mental capabilities, or lack
of experience and knowledge, unless
they are supervised whilst using it, or
have been shown how to use it by a
person responsible for their safety.
Warning and Safety instructions
10
