NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 011105
Product and Cut-out Dimensions
Convection Steam Oven
DG4080
22 1/16" min.
17 9/ 16"
17 1/2"
23 7/ 16"
7/ 8"
17 15/ 16"
O
17 5/ 8" - 17 3/ 4"
22 1/ 16" - 22 3/ 8"
See NOTES
E -
O -
Location Codes
Notes
• Width with optional EBA Trim Kits:
EBA4470 26" - 26 1/4"
EBA4476 28 3/8" - 28 1/2"
• All installations must be done in
accordance with local codes.
21 7/16"
E
5 foot electrical main with plug
connects upper rear right side
208 - 240 Volt - 15 Amp 3 wire
connection with NEMA 6-15R.
Location must be accessible
