Miele H4881BP User guide

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010807
Product and Cut-out Dimensions
30" Single Oven
H4881BP
24" min.
26 1/2 "
23 1/2"
29 13/16"
1"
28 5/8"
O
28 1/4"
A
28 1/2"
5 foot electrical main with pigtail
connects upper rear right side
208 - 240 Volt - 30Amp connection
box with 4 wires (2 lives / N / ground)
Location must be accessible
Height to base of oven
Locate 30" - 33" from floor
Based on user height of 5'6" to 5'10"
E -
O -
A -
Location Codes
28 3/8"
E
• All installations must be done in
accordance with local codes.
Notes
See
Info Box
IMPORTANT INFORMATION
For proper heat ventilation
a 12" x 2" opening (24 sq inch)
must be placed to the rear
of the platform under the oven
1 1/2"
1 1/8"
