Miele H6260BP User manual

fold here fold here fold here fold here fold here
fold herefold herefold herefold herefold here
fold here
fold here
Settings overview
Settings Status
  Time of day display   *
 
on
off
  Signal tones volume  
  to  
off
on (  *)
  Keypad tone   *
 
on
off
  Clock format  *

24-hour format
12-hour format
  Temperature unit ° *
°
Degrees Celsius
Degrees Fahrenheit
  Display brightness   to   minimum brightness to maximum brightness (
 *)
  Lighting   *
 
on for 15 seconds
on
  Demo mode   *
 
deactivated
activated
* factory setting
Most minor problems which may occur during daily operation, you can remedy yourself. Contact Miele if you cannot identify the cause of a problem or resolve it yourself.
Problem Cause Remedy
The display is dark. – The time of day display is deactivated.
– There is no power to the oven.
– Check the settings for the time of day and change them if necessary.
– Check if the circuit breaker has tripped.
If it has, contact a qualified electrician or Miele.
A function has been selected and
the time of day and the symbol
are still showing in the display.
The system lock  is switched on. Switch off the system lock (see "System lock").
The oven does not heat up. Demo mode is activated.  appears in the display. Deactivate Demo mode (see "Operating and installation instructions").
 appears withflashing un-
der the  symbol.
The power supply was interrupted for longer than
200 hours.
Reset the time of day (see "Using for the first time").
A function has been selected but
the oven is not working.
There has been a power cut. This has caused the
current cooking process to stop.
Turn the function selector to  and switch the oven off.
Restart the programme.
 appears unexpectedly in the
display andis flashing at the
same time. The buzzer might be
sounding.
The oven has been operating for an unusually long
time and this has activated the safety switch-off
function.
Turn the function selector to  and switch the oven off.
The oven is ready for use again immediately.
  appears in the display. A fault has occurred that you cannot resolve. Call Miele.
  or   appears in the display. The Pyrolytic cleaning programme door lock is not
locking ( ) or not opening ( ).
Turn the function selector to  and select the Pyrolytic cleaning programme again. If the
problem occurs again, contact Miele.
The rack and other accessories
make a noise when being pushed
into or pulled out of the oven.
The pyrolytic resistant surface of the shelf runners
creates friction when accessories are being pushed
into or pulled out of the oven.
To reduce the friction, add a few drops of heat resistant cooking oil to some paper tow-
elling and use this to lubricate the shelf runners. Repeat this after each Pyrolytic clean-
ing programme.
A noise can be heard after a cook-
ing process.
The cooling fan is switched on. It switches off automatically after a certain period.
No water is being taken in with the
Moisture Plus function.
– Demo mode is activated.
– The pump for the steam injection system is faulty.
– Deactivate Demo mode (see "Operating and installation instructions").
– Call Miele.
 and appear in the display. Moisture Plus cannot be used. Carry out the descaling process (see "Operating and installation instructions"). All other
oven functions can still be used.
The oven has switched itself off. Energy save mode Switch the oven back on.
There is soiling in the oven after
the Pyrolytic cleaning programme.
The Pyrolytic cleaning programme burns off soiling in
the oven and leaves it as ash.
– Remove the ash using a damp microfibre cloth or with a clean sponge and a solution
of hot water and washing-up liquid.
– If there is still coarse soiling left in the oven after the Pyrolytic cleaning programme,
start the programme again, selecting a longer duration.
Cakes and biscuits are not suffi-
ciently baked after following the
times given in the baking chart.
– The ingredient quantities used are different from
those given in the recipe.
– A different temperature from the one given in the
recipe is used.
– Check whether there has been a change to the recipe. The addition of more liquid or
more eggs makes a moister mix which would take longer to cook.
– Select the temperature required for the recipe.
Browning is uneven. – The material or colour of the baking tin is not suita-
ble for the oven function.
– The wrong temperature or shelf level was selected.
– With Conventional Heat  light coloured, shiny tins are less suitable. Use matt, dark
coloured baking tins.
– If the unevenness is pronounced, check whether the correct temperature and shelf
level have been selected.
There will always be a slight unevenness.
The oven lighting does not switch on. The halogen lamp is faulty and needs replacing. Replace the lamp with a new halogen bulb (see "Operating and installation instructions").
Oven mode: Moisture Plus
Use only fresh tap water when cooking
with the Moisture Plus function.
Use the recipes as a guide.
ĺFill a suitable container with the amount
of water required:
– Automatic burst of steam
 approx. 100 ml
– Manual burst of steam



approx. 100 ml
approx. 200 ml
approx. 300 ml
ĺSelect the Moisture Plus function.
 will appear with the triangle flash-
ing under the  symbol.
ĺUse the rotary selector   to call up
the other burst of steam options , , 
(the function enables descaling).
The recommended temperature will ap-
pear in the display with the triangle 
flashing under the  symbol.
ĺUse the rotary selector  to change
the temperature if necessary.
ĺConfirm with OK.
The prompt to draw in water appears. The
triangle will flash under the  symbol.
ĺOpen the door and pull the intake pipe
forwards.
ĺImmerse the end of the water intake pipe
in the container with tap water.
ĺConfirm with OK.
The water intake process will begin.
ĺFold up the intake pipe and close the
door.
You briefly will hear the pump running.
Danger of injury!
Steam can cause scalding. Do not open
the door during a burst of steam.
If you have selected , the burst of
steam is injected automatically after the
heating-up phase.
ĺContinue cooking until the end of the
cooking duration.
If you have selected ,  or bursts of
steam, the number of bursts of steam
that can be injected appears in the dis-
play after the heating-up phase.
ĺTouch  to inject the burst of steam.
The sensor light goes out and the temper-
ature and the symbol appear in the dis-
play.
ĺProceed as described to inject further
bursts of steam.
After the last burst of steam, will go out
and the temperature will be displayed.
ĺContinue cooking until the end of the
cooking duration.
At the end of the cooking process:
ĺTurn the function selector to.
ĺTake the food out of the oven.
ĺSwitch the oven off.
Useful tip: When   appears in the dis-
play you can use Moisture Plus ten more
times before the steam injection system
must be descaled.
Cleaning the oven
Please refer to the Operating and in-
stallation instructions for more de-
tailed information on cleaning and
care.
All surfaces of this appliance are sus-
ceptible to scratching.
Remove any soiling immediately to pre-
vent a permanent discolouration or alter-
ation of the surface.
Surfaces of the oven cavity and differ-
ent accessories treated with PerfectClean
enamel are characterised by their excep-
tional non-stick properties and ease of
cleaning.
To clean them by hand, you can
– remove the door
– dismantle the door
– remove the FlexiClip telescopic runners
(if present)
– remove the shelf runners
– lower the top heat/grill element
Danger of burning!
Make sure the oven heating elements
are switched off. Make sure the oven
has cooled down.
The fibreglass seal around the front of
the oven should be handled carefully.
Do not rub and scour it.
If possible, you should avoid cleaning it.
ĺClean the oven front, the interior and the
door with a clean sponge and a solution
of warm water and washing-up liquid, or
with a clean, damp microfibre cloth.
ĺWipe dry using a soft cloth.
ĺLeave all parts to dry.
The accessories are not dishwasher-safe.
Pyrolytic cleaning
ĺCoarse soiling should be removed before
running the Pyrolytic cleaning programme.
ĺRemove accessories from the oven that
are not designed for Pyrolytic cleaning.
ĺSelect Pyrolytic cleaning .
ĺSelect the level of Pyrolytic cleaning re-
quired:  ,   or  .
ĺConfirm with OK.
The Pyrolytic cleaning programme will start.
appears in the display and flashes until the
door is locked. When has gone out and 
flashes, the Pyrolytic cleaning programme is
finished and the door has been released.
ĺTurn the function selector to.
Danger of burning! Wait until the oven has
cooled down before removing residual
soiling left in the oven compartment from
Pyrolytic cleaning.
ĺClean the oven interior and the inside of
the door with a clean, damp cloth.
Evaporating residual moisture
If a programme using the addition of
moisture is manually interrupted before
all the bursts of steam have been inject-
ed or if there is a power cut, the water for
these unused bursts of steam will remain
in the steam injection system. As soon as
you select the Moisture Plus function,
a time will appear, depending on the
amount of residual water present, and the
triangle  will flash under the symbol.
ĺConfirm with OK.
The residual moisture evaporation process
will start. Once the time has elapsed, 
will appear in the display.
ĺTurn the function selector to.
While the residual water is evaporating,
the moisture will condense on the door
and in the oven interior. It needs to be
wiped off after the oven has cooled down.
Changing settings
Your appliance is supplied with a number
of factory default settings.
A setting is changed by altering its sta-
tus .
ĺTurn the function selector to.
ĺSelect .
ĺIf necessary, use the rotary selector  
to move the triangle until it appears
under .
 °C
°:min

       

ĺConfirm with OK.
A setting will appear, e.g.  .
ĺIf you wish to change another setting,
use the rotary selector   to select the
appropriate number.
ĺConfirm with OK.
 °C
°:min

       

The setting is selected and the current
statusappears, e.g. .
To change the status:
ĺUse the rotary selector   to select
the status you want.
ĺConfirm with OK.
The selected status is saved and the set-
ting appears again.
ĺTo change further settings, proceed in
the same way.
ĺSelect if you do not want to change
a setting and wish to switch to another.
ĺIf you do not want to change any further
settings, select .
Energy saving tips
ĺRemove any accessories that you are
not using from the oven before starting
the cooking process.
ĺPre-heat the oven only if instructed to
do so in the recipe or the cooking chart.
ĺTry not to open the door during a cook-
ing process. This will prevent heat from
escaping unnecessarily.
ĺIn general, if a range of temperatures is
given in a recipe or chart, it is best to
select the lower temperature and check
the food after the shortest duration.
ĺFan Plus: For baking and roasting
on different levels at the same time. A
lower temperature can be selected than
with Conventional Heat .
ĺFan Grill: Lower temperatures can
be used than when using the Grill 
function.
ĺGentle Bake: Energy-efficient bak-
ing with optimal use of heat (see "Over-
view of functions").
ĺReduce energy consumption by utilising
residual heat:
Cooking programmes using tempera-
tures above 140°C which take longer than
30minutes:
Turn down to the lowest possible temper-
ature about 5minutes before the end of
cooking. The cooling fan remains switched
on. Do not switch the oven off completely.
Whenever possible bake several dishes
at the same time or immediately one after
the other.
A Pyrolytic cleaning programme is best
started immediately after a cooking pro-
gramme.
ĺEnergy saving mode: The oven will
switch itself off automatically to save
energy if a programme is not being run
and no controls are being operated.
ĺMonitoring the cooking time: Whenever
possible set a cooking duration, or use
a roast probe.
ĺUse dark coloured baking tins and con-
tainers with a matt finish made from
non-reflective materials. Do not cover
the oven floor or the rack with heat-re-
flecting aluminium foil.
ĺEnergy-saving settings:
Select Status   for  .
Select Status   for  .
Tips on baking, roasting and
grilling
Baking
Bake on different levels at the same time
using the Fan Plus function:
– 1 tray: Shelf level 2
– 2 trays: Shelf levels 1+3/2+4
– 3 trays: Shelf levels 1+3+5 (not suita-
ble for moist cakes and tarts)
Roasting
Browning: Browning only occurs towards
the end of the roasting time. Remove the lid
about halfway through the roasting time if a
more intensive browning result is desired.
Standing time: At the end of the pro-
gramme, take the roast out of the oven,
wrap in aluminium foil and leave to stand
for about 10minutes. This helps retain
juices when the meat is carved.
Roasting poultry: For a crisp skin, baste
the poultry 10minutes before the end of
the cooking time with slightly salted water.
Grilling
If the surface of a thicker cut of meat is
browned but the centre is still raw, move
the food to a lower level or reduce the tem-
perature and continue cooking. This will
stop the surface from becoming too dark.
Quick Start Guide
H6260BP
These short instructions are not a substitute for the Operating and installation
instructions. It is essential to familiarise yourself with the oven before using it for the
first time. Please read the Operating and installation instructions carefully and pay
particular attention to the Warning and Safety Instructions.
en – AU, NZ M. No. 10 864 610
TIPS / SETTINGS PROBLEM SOLVING GUIDE MOISTURE PLUS / CLEANING AND CARE
Moisture Plus Cleaning and care Tips Settings Problem solving guide

fold here fold here fold here fold here fold here fold here
fold herefold herefold herefold herefold herefold here
Before using for the first time
Before using the oven for the first time,
ensure that it is correctly installed and
connected.
It is essential to read the separate
Operating and installation instructions
supplied with the appliance.
ĺPress and release the function and rota-
ry selectors   if they are retracted.
The function selector must be pointing to .
After connecting the oven to the electric-
ity supply  will appear in the display
and the triangle  will flash under the 
symbol.
The time of day is shown in the 24-hour
format.
ĺUse the rotary selector   to enter the
time of day.
ĺConfirm with OK.
The time of day is now saved.
The time of day display is switched off by
default (see "Settings –   ").
The display appears dark if the oven is
switched off. The time of day continues to
run in the background.
Clean the oven interior and the accesso-
ries and rinse the steam injection system
before using the oven for the first time.
Take all accessories out of the oven, se-
lect Moisture Pluswith automat-
ic burst of steam and heat up the empty
oven at 250°C for at least one hour (see
"Moisture Plus").
Ensure that the kitchen is well ventilated.
Overview of functions
These short instructions are intended to
give you a quick overview.
Please refer to the separate Operating
and installation instructions supplied
with your oven for detailed information on
how to use the appliance.
– Safety instructions
– Features and accessories
– Operation
– Moisture Plus
– Tips on baking, roasting and grilling
– Cooking charts
– Notes on low temperature cooking and
further applications like defrosting, bot-
tling, drying food, and Gentle Bake
– Cleaning and care
– After sales service
– Installation and connection
– Recipes for baking, roasting and
MoisturePlus
aOn/Off sensor 
– is recessed
– reacts to touch
– for switching the oven on and off
bFunction selector
– can be retracted in the position by
pushing it in
– can be turned clockwise and an-
ti-clockwise
– for selecting oven functions:
Conventional Heat
Bottom Heat
Grill
Gentle Bake
Moisture Plus
Rapid Heat-up
Fan Plus
Intensive Bake
Fan Grill
Pyrolytic cleaning
cDisplay
Displays the time of day and settings
dRotary selector  
– for setting temperatures and times
– increase values by turning it clock-
wise
– decrease values by turning it an-
ti-clockwise
– for highlighting functions
– can be retracted in any position by
pushing it in
eOK sensor
For confirming settings and instructions
f sensor
To go back one step at a time
g sensor
For setting the minute minder
h sensor
For switching the oven interior lighting
on and off
i sensor
For calling up functions
j sensor
For injecting bursts of steam
kOptical interface
(for Miele Service technicians only)
Fitting and removing the Flexi-
Clip telescopic runners
(Optional accessory)
Danger of burning!
Make sure the oven heating elements
are switched off. Make sure the oven
has cooled down.
The FlexiClip telescopic runners are fitted in be-
tween the two rails that make up a shelf level.
The FlexiClip telescopic runner with the
Miele logo is fitted on the right.
When fitting or removing the telescopic
runners do not extend them. If the tele-
scopic runners are difficult to pull out af-
ter fitting, you may need to pull firmly on
them once to release them.
Fitting the FlexiClip telescopic runners:
Removing the FlexiClip telescopic runners:
Features
Oven overview
aOven controls
bDoor lock for Pyrolytic cleaning
cTop heat/grill element
dSteam inlet openings
eWater intake pipe for the steam in-
jection system
fAir inlet for the cooling fan with
ring heating element behind it
gShelf runners with 5 shelf levels
hOven floor with bottom heat ele-
ment underneath it
iFront frame with data plate
jDoor
Accessories supplied
– Baking tray* with anti-tip safety
notches
– Universal tray* with anti-tip safe-
ty notches
– Rack** with non-tip safety notches
– Shelf runners**
* PerfectClean treated surfaces
** Pyrolytic accessories
Setting the minute minder
The minute minder can be used to time any
activity in the kitchen (for a maximum of 99
minutes and 55 seconds).
If you have switched the clock display off,
you will need to switch the oven on before
you can set a minute minder duration.
ĺSelect .
 appears withflashing under the 
symbol.
ĺUse the rotary selector  to set the min-
ute minder time you require.
ĺConfirm with OK.
The minute minder is saved and will count
down in seconds. The symbol indicates
that the minute minder has been set.
At the end of the minute minder time
– flashes.
– The time counts upwards.
– A buzzer will sound if the buzzer is
switched on.
ĺSelect .
Changing the time set for the
minute minder
ĺSelect .
The minute minder time selected appears.
ĺUse the rotary selector  to change the
minute minder time.
ĺConfirm with OK.
The changed minute minder is saved and will
count down in seconds.
Cancelling the minute minder du-
ration
ĺSelect .
ĺUse the rotary selector  to reduce the
minute minder time to .
ĺConfirm with OK.
The minute minder is now cancelled.
Minute minder
Oven function Recom-
mended
tempera-
ture 1)
Tempera-
ture range
2)
Recommendation Note
Baking/
Cook-
ing
Roast-
ing
Grill-
ing
Fan Plus 160 °C 30–250 °C   – For baking and roasting on different levels at the same time
A lower temperature can be selected than with 
Moisture
Plus
160 °C 130–250 °C   – For baking and roasting with moisture injection
First  will appear and the triangle will flash under the  symbol.The recommended temperature will appear after the number of bursts of steam has been selected.
Intensive
Bake
170 °C 50–250°C – – For baking dishes with a moist topping
Conven-
tional Heat
180 °C 30–280 °C   –For baking and roasting traditional recipes, cooking soufflés and
cooking at low temperatures. If using an older recipe or cook- book, set the oven temperature 10°C lower than that recom- mended. This will not change cooking times.
Bottom
Heat
190 °C 100-280 °C – – – Use this function towards the end of cooking to brown the
base of the food.
Grill 240 °C 200-300°C – – For grilling thin cuts (e.g. steak) and browning baked dishes Fan Grill 200 °C 100-260 °C – – For grilling larger items
(e.g. rolled meat, poultry)
Gentle
Bake
190 °C 100-250 °C – – Suitable for small amounts, e.g. frozen pizzas, bake-off rolls,
biscuits and for meat dishes and roasts. Energy-efficient thanks to optimal utilisation of heat. When cooking on a single level, up to 30% less energy is used with comparatively good cooking results.
Rapid
Heat-up
160 °C 100-250 °C – – – For pre-heating the oven quickly.
The oven function required must then be selected.
1) As soon as you call up a function, the recommended temperature will appear in the display. 2) You can change the recommended temperature within the temperature range. Confirm with OK.
Basic operation
ĺSelect the required oven function with
the function selector.
The recommended temperature will ap-
pear.
ĺUse the rotary selector   to change
the temperature if necessary.
The current temperature and temperature
indicator lightwill appear after a short
time.
ĺWhen the cooking programme is fin-
ished, turn the function selector to .
ĺTake the food out of the oven.
ĺSwitch the oven off.
The cooling fan will continue to run and
then switch off automatically.
Further functions
Cooking programmes (maximum cook-
ing time 12 hours) can be set to switch on
and off automatically once you have se-
lected the function and the temperature.
Cooking duration
The oven switches off automatically when
the cooking duration has elapsed.
Cooking duration and finish time 
The cooking programme switches on and
off automatically.
When the cooking duration has
elapsed:
–  appears in the display.
– flashes.
– A buzzer will sound if the buzzer is
switched on.
ĺTurn the function selector to .
ĺTake the food out of the oven.
ĺSwitch the oven off.
Display
The display shows the time of day or your
settings.
   °C °F
h min

       

Symbols in the display
Depending on the position of the function
selectorand/or whether a sensor has
been pressed, the following symbols ap-
pear:
Symbols in the display/
allocated function

Minute minder Any
Temperature indicator
light
Oven
function
Temperature
Duration
Finish time
Water intake process
 Descaling
Bursts of steam
Setting 
 Time of day
System lock
You can only set or change a function if
the function selector is in the correct po-
sition.
System lock
The oven is delivered with the system lock
deactivated.
The setting for the system lock can be
changed by altering its status :
–   = Off
–   = On
The status of the system lock can only
be altered when the oven is switched on
and the rotary selector is at •.
Activating the system lock
ĺSelect .
ĺIf necessary, use the rotary selector  
to move the triangle until it appears
under .
The currently set status   appears.
ĺConfirm with OK.
ĺUse the rotary selector   to select
status .
ĺConfirm with OK.
ĺSelect .
The current time of day will appear.
ĺSwitch the oven off.
The system lock is switched on.
When the appliance is switched on again,
the symbol will appear in the display to
remind you that the system lock has been
activated.
Deactivating the system lock
Deactivating the system lock for a cook-
ing process:
ĺSwitch the oven on.
The and symbols and the current
time of day will appear.
ĺTouch OK until goes out.
You can use the oven for a cooking pro-
gramme or generally deactivate the sys-
tem lock.
ĺSelect .
ĺUse the rotary selector  to move the
triangle until it appears under .
ĺConfirm with OK.
The currently set status   appears.
ĺUse the rotary selector   to select
status  .
ĺConfirm with OK.
ĺSelect .
The system lock is switched off. The 
symbol disappears.
Safety features
– The system lock  prevents the
oven from being used unintention-
ally, for example by children.
– The cooling fan cools down the
hot air in the oven before it exits
between the door and the control
panel.
– The ventilated door helps to keep
the outer glass pane of the door
cool.
– The door lock prevents the door
from being opened during the
Pyrolytic cleaning programme.
OPERATION / SYSTEM LOCK FEATURES / MINUTE MINDER IMPORTANT INFORMATION / OVEN CONTROLS
Important information Oven controls Operation Overview of functions
M. No. 10 864 610 / 01en – AU, NZ
System lock
