Miele DA 216-2 EXT User manual

Operating and installation instructions
Cooker hoods
DA 216-2, DA 216-2 EXT
DA 217-2
DA 219-2, DA 219-2 EXT
It is essential to read these
operating instructions before GiWOZ
installing or using the machine,
to avoid the risk of accidents
or damage to the machine. M.-Nr. 05 609 490

Contents
Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Functional description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operation
Main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
To switch the fan on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Selecting the power level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Run-on option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
To switch the fan off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Switching the lighting on 12
To switch the lighting off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter operating hours counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Reading the filter operating hours counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Altering the filter operating hours counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning and care
Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Grease filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Fitting / replacing the active charcoal filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Changing a light tube. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Appliance dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installation
Assembly parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Retaining plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Canopy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Motor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Control unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Air extraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Recirculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Extension piece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Fitting the tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connection for air extraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Condensate trap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
After Sales Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Contents

Caring for the environment
Disposal of pac ing material
The transport and protective packing
has been selected from materials
which are environmentally friendly for
disposal and can normally be recycled.
Ensure that any plastic wrappings,
bags etc. are disposed safely and kept
out of the reach of babies and young
children. Danger of suffocation!
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
Old appliances may contain material
which can be reclaimed or recycled.
Please contact your dealer, your local
waste collection centre or scrap mer-
chant about potential recycling
schemes.
Ensure that the appliance presents no
danger to children while being stored
for disposal.
See the appropriate section in the
Warning and Safety instructions.
Caring for the environment
3

Warning and Safety instructions
This appliance conforms to current
safety requirements. Incorrect use
can lead to injury and damage to
the appliance.
Before installation and before using
for the first time read the operating
instructions carefully. They contain
important information on safety, use
and maintenance of the appliance.
This way you will avoid the risk of
accidents and damage to the ap-
pliance.
Keep these operating instructions in
a safe place and pass them on to
any future user.
Correct usage
The appliance is intended for
domestic use only.
The manufacturer cannot be held
responsible for damage caused by
improper use of the appliance.
Technical safety
Before connecting the appliance
to the mains supply, make sure
that the voltage and frequency details
on the data plate correspond with the
on-site electricity supply. This data
must correspond in order to avoid risk
of damage to the appliance. Consult a
qualified electrician if in doubt.
The electrical safety of this ap-
pliance can only be guaranteed
when continuity is complete between
the appliance and an effective earthing
system which complies with local and
national regulations. It is most import-
ant that this basic safety requirement is
tested by a qualified electrician. The
manufacturer cannot be held respon-
sible for the consequences of an inade-
quate earthing system (e.g. electric
shock).
Installation work and repairs may
only be carried out by suitably
qualified and competent persons to en-
sure safety. Repairs and other work by
unqualified persons could be dan-
gerous and the manufacturer will not
be held responsible.
This equipment is not designed for
maritime use or for use in mobile in-
stallations such as caravans, aircraft
etc. However, it may be suitable for
such usage subject to a risk assess-
ment of the installation being carried
out by a suitably qualified engineer.
Warning and Safety instructions
4

The appliance is only completely
isolated from the electricity supply
when:
– it is switched off at the wall socket
and the plug removed. (Do not pull
on the cable, only on the plug), or
– the fuse from the fused spur connec-
tion unit is withdrawn or,
– the mains fuse is withdrawn, or
– the screw-out fuse is removed in
countries where this is applicable.
Ensure power is not supplied to
the appliance while maintenance
or repair work is being carried out.
Do not connect the appliance to
the mains electricity supply by an
extension lead.
Extension leads do not guarantee the
required safety of the appliance, (e.g.
danger of overheating).
Use
Do not let small children play with
the appliance or its controls or
operate it. Supervise its use by the el-
derly or infirm.
Never use an open flame beneath
the cooker hood. To avoid the
danger of fire, do not flambé or grill
over an open flame.
When switched on, the cooker hood
could draw flames into the filter. Fat par-
ticles drawn into the cooker hood pres-
ent a fire hazard.
When using the cooker hood over
a gas hob ensure that any burners
in use are always covered by a pan.
Otherwise flames could be drawn up
by the suction of the cooker hood,
parts of which could then be damaged.
Always switch the cooker hood on
when using the hob, otherwise con-
densation may collect in the hood,
which could cause corrosion.
When cooking with oil or fat, chip
pans and deep fat fryers etc, do
not leave the pans unattended. Never
leave an open grill unattended when
grilling. Overheated oil and fat can ig-
nite and could set the cooker hood on
fire.
Do not use the cooker hood with-
out the grease filters in place.
This way you will avoid the risk of
grease and dirt getting into the ap-
pliance and hindering its smooth oper-
ation.
The filters should be regularly
cleaned or changed as appropri-
ate. Saturated filters are a fire hazard.
Under no circumstances use a
steam cleaner to clean this ap-
pliance. Pressurised steam could
reach the electrical components and
cause a short circuit.
In countries where there are areas
which may be subject to infesta-
tion by cockroaches or other vermin,
pay particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any dam-
age which may be caused by cock-
roaches or other vermin will not be
covered by the appliance guarantee.
Warning and Safety instructions
5

Installation
The distance between the top of
the cooker/hob and the bottom of
the cooker hood must measure at least:
– 450 mm above electric hobs and
cookers
– 650 mm above gas hobs and
cookers
– 650 mm above an open grill from our
range
When fitted above an open grill the
cooker hood must not be used in recir-
culation mode.
For non-Miele cooking appliances
maintain the safety distance as recom-
mended by the manufacturer in their
Installation and Operating instructions.
If more than one appliance is fitted be-
neath the cooker hood and they have
different minimum safety distances to
the cooker hood, select the greater
distance.
Safety regulations prohibit the
fitting of a cooker hood over solid
fuel stoves.
All ducting, pipework and fittings
must be of non-flammable ma-
terial. These can be obtained from the
Miele Spare Parts department or from
builders’ merchants.
The appliance must not be con-
nected to a chimney or vent flue
which is in use. Neither should it be
connected to ducting which ventilates
rooms with fireplaces.
If exhaust air is to be extracted into
a chimney or ventilation duct no
longer used for other purposes, seek
professional advice.
Warning and Safety instructions
6

When using the cooker hood in
extraction mode at the same time
as another heating appliance which de-
pends on the air in the room, (e.g. gas,
oil or coal fired heaters, continuous flow
or other water heaters, gas cooker, gas
hob or gas oven) special care must be
taken, as the action of the cooker hood
extracts air from the room, which these
types of heater need for combustion.
They could also draw exhaust air back
in from chimneys or ducting in con-
travention of fire safety regulations.
In order to ensure safe operation, and to
prevent gases given off by the heating
appliances from being drawn back into
the room when the extractor and the
heater are in operation simultaneously,
an underpressure in the room of 0.04
mbar (4 pa) is the maximum permissible.
Ventilation can be maintained by air in-
lets which cannot be blocked, in win-
dows, doors and outside wall vents, or
by other technical measures, such as
ensuring that the extractor can only be
switched on when the heating ap-
pliance is switched off or vice-versa.
N.B: The overall ventilation condition of
the dwelling must be taken into ac-
count. If in any doubt, the advice of a
competent builder or, for gas, a "Corgi"
installer must be sought.
If the cooker hood is operated in recir-
culation mode (with active charcoal
filter) then the above restrictions do not
apply.
Appliances with external fans
For appliances with an external fan
motor fitted (EXT models) the con-
nection of the two units must be made
using the connection cable and the
plug connectors. Make sure the correct
combination of the two appliances has
been selected.
Separate instructions are supplied with
the external fan.
Disposal of your old appliance
Before discarding an old ap-
pliance, switch off and disconnect
it from the power supply. Cut off and
render any plug useless. Cut off the
cable directly behind the appliance to
prevent misuse.
This should be done by a competent
person.
The manufacturer cannot be held
liable for damage caused by non-
compliance with these Warning and
Safety instructions.
Warning and Safety instructions
7

Description of the appliance
Description of the appliance
8

bExtension piece
cTower
dCanopy
eControl panel
f Main switch
gRecirculation grilles
hHob lighting
iGrease filters
jTouch control for
the hob lighting
kOn-Off touch control for
the fan
l Controls to select the
Fan power level
mTouch control for
the run-on option
This control activates the run-on option.
The fan is switched off automatically
after either 5 or 15 minutes.
n Touch control for the
grease filters
The indicator light above the grease
filter touch control lights up when the
grease filters need to be cleaned.
The touch control is used:
–to reset the operating hours counter
after cleaning the grease filters (see
"Cleaning and Care").
–to show how long the grease filter
has been in use (see section on
"Operation / Filter operating hours
counter").
–to alter the number of hours counted
by the filter operating hours counter
(see section "Operation / Altering the
filter operating hours counter").
oTouch control for
the active charcoal filters
The indicator lamp above the active
charcoal filter touch control lights up
when the recirculation mode active
charcoal filters need to be replaced.
The touch control is used:
–to reset the operating hours counter
after replacing the active charcoal
filters (see "Cleaning and Care").
–to show how long the active charcoal
filters have been in use (see section
on "Operation / Filter operating hours
counter").
–to alter the number of hours counted
by the filter operating hours counter
(see section "Operation / Altering the
filter operating hours counter").
Description of the appliance
9

Functional description
The cooker hood works with
. . . air extraction
The air is drawn in and cleaned by the
grease filters and directed outside.
The cooker hood is fitted with a
non-return flap.
This flap is closed when the cooker
hood is switched off. No exchange of
room air and outside air can take
place. When the cooker hood is
switched on, the non-return flap opens
for the cooking vapours to be blown di-
rectly outside.
. . . air recirculation:
The air is drawn in and cleaned first by
grease filters and then cleaned by ac-
tive charcoal filters. The cleaned air is
then recirculated back into the kitchen
through a vent in the top of the cooker
hood extension piece.
Before using the cooker hood for
the first time, ensure that the active
charcoal filters are in place, see
section on "Cleaning and care".
. . . an external fan
The EXT models are designed to be
connected to an external fan located
outside the room.
The external fan is connected to the
cooker hood by means of a control
cable and is operated by the control
panel on the cooker hood.
Functional description
10

Operation
Main switch
Switch the main switch to "I". The fan
and the lighting can now be operated.
If the appliance is not going to be used
for a longer period of time (e.g. whilst
on holiday) switch the appliance off by
turning the main switch to "0".
The next time it is switched on the
cooker hood will operate at the level
previously used.
To switch the fan on
Press the On/Off touch control.
The fan runs at power level "lI".
The indicator light above the touch
control lights up.
Selecting the power level
Use the –/+controls to select the
power level required.
Touch control + = higher setting
Touch control –= lower setting
Depending on the intensity of cooking
vapours levels "I" to "III" (green indica-
tor lamp) are usually sufficient for nor-
mal cooking.
Intensive setting
When frying or cooking food with a
strong aroma you may wish to select
the Intensive setting (yellow indicator
lamp) for a short period.
Run-on option
If the air still needs to be cleared after
cooking, the cooker hood can be set to
continue running.
The fan is switched off automatically
after either 5 or 15 minutes.
Press the run-on option touch control
whilst the fan is still running.
Press once = The fan switches off
after 5 minutes.
(left hand indicator lamp)
Press twice = The fan switches off
after 15 minutes.
(right hand indicator lamp)
To switch the run-on option off, press
the run-on option touch control again.
Operation
11

To switch the fan off
Press the On/Off touch control to
switch the fan off.
The indicator lamp above the control
goes out.
Switching the lighting on
The hob lighting can be switched on
and off independently of the fan.
Briefly press the lighting touch con-
trol to switch on the hob illumination.
The indicator lamp above the touch
control lights up.
To switch the lighting off
Briefly press the hob illumination con-
trol to switch the lighting off.
The indicator lamp above the control
goes out.
Safety cut-out
Should the cooker hood have been left
switched on, the fan will switch off auto-
matically after 10 hours. The lighting re-
mains on.
Pressing the On/Off touch control will
switch the fan back on again.
Operation
12

Filter operating hours counter
The number of hours the appliance has
been in operation for is stored in mem-
ory.
The indicator lamp above the grease fil-
ter control will light up after 30 hours of
operation. The grease filters must then
be cleaned.
After the grease filters have been
cleaned and put back in place, the fil-
ter operating hours counter must be re-
set.
Press the grease filter touch control
for about 3 seconds.
The indicator lamp will go out.
With recirculation mode:
For recirculation mode the operating
hours counter needs to be set to the re-
quired time:
The indicator lamp above the active
charcoal filter control will light up after
the cooker hood has operated for the
number of hours set. The active char-
coal filters must then be replaced with
new ones.
After new active charcoal filters have
been put in place, the filter operating
hours counter must be re-set.
Press the active charcoal filter touch
control for about 3 seconds.
The indicator lamp will go out.
Reading the filter operating hours
counter
To check the percentage of time set
already used:
Press the On/Off touch control to
switch the fan on.
Press the grease filter / active char-
coal filter touch control.
One or several of the indicator lamps
above the –/+touch controls will flash.
The number of flashing lamps shows
the percentage of the operating time
which has already been used up.
1 lamp = 25 %
2 lamps = 50 %
3 lamps = 75 %
4 lamps = 100 %
The operating hours completed remain
in memory, even when the machine is
switched off or there is a power cut.
Operation
13

Altering the filter operating hours
counter
The operating hours counter for the
grease filters is set to 30 hours. This
can be lengthened or shortened to suit
the type of cooking you do. You can
choose from 20, 30, 40 or 50 hours.
–Select a short time if you roast or fry
a lot.
–If you use very little fat for cooking,
select a longer time.
–If, however, you only cook occasion-
ally we recommend that you select a
short time because grease which
has built up gradually over a long
period of time will harden on the
grease filters and make cleaning
more difficult.
Procedure:
Press the On/Off touch control to
switch the fan off.
Press the run-on option touch control
and the grease filter touch control at
the same time.
The indicator lamp above the grease fil-
ter touch control and one of the lamps
above the –/+touch controls will flash.
The –/+touch control lamps show the
time which has been set:
1st lamp from the left = 20 hours
2nd lamp from the left = 30 hours
3rd lamp from the left = 40 hours
4th lamp from the left = 50 hours
Use the –/+touch controls to select
the desired time.
Confirm the selection by pressing
the grease filter touch control.
If the procedure is not confirmed
within 4 minutes of programming
the steps, the cooker hood will auto-
matically revert to the "old" data.
Operation
14

Setting/altering the active charcoal
filter operating hours counter
The active charcoal filters are only
used for cooker hoods which are set
up for recirculation mode. They are not
required for vented extraction.
On delivery the operating hours
counter for the active charcoal filters is
set to unlimited.
For recirculation mode the operating
hours counter needs to be set to the re-
quired time:
Press the On/Off touch control to
switch the fan off.
Press the run-on option touch control
and the active charcoal filter touch
control at the same time.
The indicator lamp above the active
charcoal filter touch control and one of
the lamps above the –/+touch controls
will flash.
The –/+touch control lamps show the
time which has been set:
1st lamp from left = 120 hours
2nd lamp from left = 180 hours
3rd lamp from left = 240 hours
4th lamp from left = unlimited
Use the –/+touch controls to select
the desired time.
Confirm the procedure by pressing
the active charcoal filter touch con-
trol.
If the procedure is not confirmed
within 4 minutes of programming
the steps, the cooker hood will auto-
matically revert to the "old" data.
Operation
15

Cleaning and care
Before any cleaning or maintenance
work the cooker hood must be dis-
connected from the mains supply.
Ensure that:
–it is switched off at the wall socket
and the plug has been withdrawn
(do not pull on the cable, only on
the plug), or
–the fuse has been withdrawn from
the fused spur connection unit, or
–the mains fuse is withdrawn, or
–the screw-out fuse is removed (in
countries where this is applicable).
Housing
Warning: The surfaces and controls
are susceptible to scratches and ab-
rasion. Please observe the following
cleaning instructions:
All external surfaces and controls
can be cleaned using warm water
with a little washing up liquid applied
with a soft sponge.
Wipe dry using a soft cloth.
Do not use too much water when
cleaning the controls. Water could
penetrate into the electronics and
cause damage.
Avoid:
–cleaning agents containing soda,
acids or chlorides,
–abrasive cleaning agents, e.g. pow-
der cleaners or cream cleaners,
–abrasive sponges, e.g. pot scourers
or sponges which have been pre-
viously used with abrasive cleaning
agents.
These will damage the surface material.
Stainless steel
Stainless steel surfaces can be
cleaned using a proprietary non-ab-
rasive cleaning agent designed specifi-
cally for use on stainless steel.
To help prevent re-soiling, proprietary
conditioning agents for stainless steel
can also be used.
Apply sparingly with an even pressure.
E-Cloth
A microfibre "E-Cloth" is available from
the Miele UK Spare Parts Department,
Part Number 98013530, which is suit-
able for cleaning surfaces such as
stainless steel, glass, plastic and
chrome.
Stainless steel coloured controls
These controls may suffer discolour-
ation or damage if soiling is left on
them for too long.
Remove any soiling straight away.
Do not use stainless steel cleaning
agents on these types of controls.
Cleaning and care
16

Grease filters
Re-usable metal filters are fitted which
remove solid particles (oil, dust, etc.)
from the kitchen vapours, preventing
soiling of the cooker hood.
The filters should be cleaned regularly
(at least every 3-4 weeks) to avoid a
build-up of fat, but always clean as
soon as the grease filter touch control
lamp comes on.
An over saturated filter is a fire
hazard.
To take out the grease filters press
the locking clips in towards the
middle of the filter. Holding carefully,
lower and remove the filter.
Clean the filters
–by hand: with a nylon brush warm
water with a little washing up liquid.
–in a dishwasher: place the filters
with the short side upright in the
lower basket, ensuring the spray arm
is not obstructed.
Depending on the cleaning agent
used, cleaning the grease filters in
a dishwasher can cause permanent
discolouration to the surface of the
filters.
However, this will not affect the func-
tioning of the grease filters in any
way.
After cleaning, leave the filters to dry
on an absorbent surface before put-
ting them back in place.
When removing the filters for clean-
ing also clean off any residues of oil
or fat from the now accessible hous-
ing to prevent the risk of these catch-
ing fire.
When replacing the grease filters, en-
sure the locking clips are visible facing
down towards the hob.
Should the grease filters be put back
upside down:
insert a small screwdriver into the slits
to disengage them. Do not let them
drop on to the hob below.
After replacing the grease filters,
press the grease filter touch control
for approx. 3 seconds to re-set the
operating hours counter. The indica-
tor lamp will go out.
If the grease filters are cleaned be-
fore the operating hours counter has
reached its maximum, the grease fil-
ter touch control should be pressed
for approx. 6 seconds to reset the
counter to zero.
Cleaning and care
17

Fitting / replacing the active
charcoal filters
If the cooker hood is connected for re-
circulation, two active charcoal filters
must be inserted in addition to the
grease filters. These filters absorb nor-
mal kitchen odours.
They are fitted in the canopy above the
grease filters.
Active charcoal filters can be ob-
tained from your dealer or the Miele
Spare Parts Department.
Refer to the section "Technical data"
for type and reference number.
Before fitting or replacing the active
charcoal filters, the grease filters
must first be taken out, (see previous
section for instructions on how to do
this).
The filters are supplied with fitting in-
structions. Ensure these are carefully
followed.
When fitting for the first time:
Set the operating hours counter to
suit your requirements, (see "Oper-
ation - Altering the filter operating
hours counter").
Always replace the filters immediately if
the lamp for the active charcoal filter
touch control comes on, or if they are
no longer effective in absorbing kitchen
odours.
They should, however, be replaced at
least every 6 months.
After fitting new active charcoal fil-
ters, press the active charcoal filter
touch control for approx. 3 seconds
to re-set the operating hours counter.
The indicator lamp will go out.
If the active charcoal filters are re-
placed before the operating hours
counter has reached its maximum,
the active charcoal filter touch con-
trol should be pressed for approx. 6
seconds to reset the counter to zero.
Cleaning and care
18

Changing a light tube
Disconnect the cooker hood from
the mains supply. Ensure that:
–it is switched off at the wall socket
and the plug has been withdrawn
(do not pull on the cable, only on
the plug), or
–the fuse has been withdrawn from
the fused spur connection unit, or
–the mains fuse is withdrawn; or
–the screw-out fuse is removed (in
countries where this is applicable).
Unscrew the fixing screw of either
the right or left hand holder for the
glass cover.
When doing this, push the glass
cover upwards so that it does not fall
on the hob surface.
Take off the glass cover holder.
Then take out the glass cover, guid-
ing it downwards at an angle.
Carefully lower the light tube down-
wards and pull out.
Change the light tube and push
back upwards into place.
Put the glass cover back in place
and secure with the glass holder.
Cleaning and care
19

Appliance dimensions
Appliance dimensions
20
