Miele ESW 6114 User manual

Operating and installation instructions
Food warming drawer
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 09 572 120

Contents
2
Warning and Safety instructions .......................................................................... 4
Caring for the environment ................................................................................. 11
Overview ............................................................................................................... 12
ESW 6114 / ESW 6214 .......................................................................................... 12
ESW 6129 / ESW 6229 .......................................................................................... 13
Accessories supplied............................................................................................. 14
Controls ................................................................................................................ 15
Using for the first time......................................................................................... 16
Cleaning the drawer for the first time..................................................................... 16
Heating up the drawer for the first time ................................................................. 16
Operation .............................................................................................................. 17
Operation ............................................................................................................... 17
Functions ............................................................................................................... 18
Duration.................................................................................................................. 18
Temperature settings ............................................................................................. 18
Keeping food warm.............................................................................................. 20
Warming crockery................................................................................................ 22
Tips ........................................................................................................................ 22
Heating up times.................................................................................................... 22
Capacity................................................................................................................. 22
ESW 6114 / ESW 6214 ..................................................................................... 23
ESW 6129 / ESW 6229 ..................................................................................... 24
Low temperature cooking ................................................................................... 25
Other uses ............................................................................................................ 32
Combination with a CVA coffee machine .......................................................... 33
Cleaning and care................................................................................................ 34
Problem solving guide ......................................................................................... 36
Optional accessories........................................................................................... 38
Safety instructions for installation ..................................................................... 39
Installation notes.................................................................................................. 40
Building-in dimensions ESW 6114 / ESW 6214 ................................................. 41

Contents
3
Building-in dimensions ESW 6129 / ESW 6229 ................................................. 45
Installation ............................................................................................................ 49
Electrical connection........................................................................................... 50
After sales service, data plate ............................................................................ 52

Warning and Safety instructions
4
This drawer complies with all relevant safety requirements. Inap‐
propriate use can, however, lead to personal injury and damage to
property.
To avoid the risk of accidents or damage to the appliance, please
read these instructions carefully before installation and before us‐
ing it for the first time. They contain important notes on installa‐
tion, safety, use and maintenance.
Miele cannot be held liable for damage caused by non-compli‐
ance with these Warning and Safety instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.

Warning and Safety instructions
5
Correct application
 The drawer is intended for domestic use and use in other similar
environments.
 The drawer is not intended for outdoor use.
 It is intended for domestic use only as described in these operat‐
ing instructions. Any other usage is not supported by the manufac‐
turer and could be dangerous.
 People with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge who are not able to use the draw‐
er safely on their own must be supervised whilst using it. They may
only use it unsupervised if they have been shown how to use it safe‐
ly and recognise and understand the consequences of incorrect op‐
eration.

Warning and Safety instructions
6
Safety with children
 Children must be kept away from the drawer unless they are con‐
stantly supervised.
 Children 8 years and older may only use the drawer unsupervised
if they have been shown how to use it in a safe way and can recog‐
nise and understand the consequences of incorrect operation.
 Children must not be allowed to clean the drawer unsupervised.
 Please supervise children in the vicinity of the drawer, and do not
let them play with it.
 The warming drawer gets hot when in use and remains hot for a
while after being switched off. Keep children well away from the
warming drawer until it has cooled down and there is no danger of
burning.
 Danger of suffocation. Packaging, e.g. plastic wrappings, must be
kept out of the reach of babies and children. Whilst playing, children
could become entangled in packaging or pull it over their head and
suffocate.

Warning and Safety instructions
7
Technical safety
 Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and re‐
pairs must only be carried out by a Miele authorised technician.
 A damaged drawer can be dangerous. Always check for visible
signs of damage. Never use a damaged appliance.
 Reliable and safe operation of the drawer can only be assured if it
has been connected to the mains electrical supply.
 The electrical safety of this drawer can only be guaranteed when
correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt please have the electrical installation tested
by a qualified electrician.
 Before connecting the drawer to the mains supply, ensure that the
connection data on the data plate (voltage and frequency) match the
mains electricity supply.
This data must correspond in order to avoid the risk of damage to
the drawer. Consult a qualified electrician if in any doubt.
 Do not connect the drawer to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and
do not guarantee the required safety of the appliance.
 For safety reasons, this drawer may only be used when it has
been built in.
 This drawer must not be used in a non-stationary location (e.g. on
a ship).
 Never open the casing of the drawer.
Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.

Warning and Safety instructions
8
 While the appliance is under guarantee, repairs should only be un‐
dertaken by a Miele authorised service technician. Otherwise the
guarantee is invalidated.
 Miele can only guarantee the safety of the appliance when genu‐
ine original Miele replacement parts are used. Faulty components
must only be replaced by Miele spare parts.
 If the plug is removed from the connection cable or if the cable is
supplied without a plug, the drawer must be connected to the elec‐
trical supply by a suitably qualified electrician.
 If the connection cable is damaged, it must be replaced by a suit‐
ably qualified electrician with a specialist connection cable of type H
05 VV-F (pvc insulated), available from Miele.
 During installation, maintenance and repair work, the drawer must
be disconnected from the mains electricity supply.

Warning and Safety instructions
9
Correct use
 You could burn yourself on a hot drawer or on hot crockery. Pro‐
tect your hands with heat-resistant pot holders or gloves when
working with the hot appliance. Do not let them get wet or damp, as
this causes heat to transfer through the material more quickly with
the risk of scalding or burning yourself.
 Do not store any plastic containers or inflammable objects in the
drawer. They could melt or catch fire when the appliance is switched
on, causing a fire hazard.
 Due to the high temperatures radiated, objects left near the draw‐
er when it is in use could catch fire. Do not use the drawer to heat
up the room.
 Never replace the anti-slip mat supplied with the appliance with
paper kitchen towel or similar.
 The telescopic runners can support a maximum load of 25 kg.
Overloading or leaning or sitting on the drawer will damage the tele‐
scopic runners.
 If the drawer is installed behind a furniture panel (e.g. a door), en‐
sure that the door is never closed whilst the drawer is in use. Heat
and moisture can build up behind a closed furniture panel and cause
subsequent damage to the drawer, the housing unit and the floor.
Do not close the door until the drawer has cooled down completely.
 The underside of the drawer gets hot when switched on. Be care‐
ful not to touch it when the drawer is open.
 The anti-slip mat is heat-resistant up to 200 °C.
It is possible for the bottom of cookware to exceed this temperature,
especially after it has been used to sear food. Allow the cookware to
cool down for a minute or two before placing it in the drawer.
 Cookware made of plastic or aluminium foil will melt at high tem‐
peratures. When keeping food warm, use only heat-resistant cook‐
ware made of porcelain, glass, etc.

Warning and Safety instructions
10
 Liquids that get inside the drawer can cause the appliance to
short-circuit. Open and close a loaded drawer carefully to prevent
liquids from spilling.
 The "Keep food warm" function is designed to keep hot food
warm and not to warm up cold food. Ensure food is really hot when
placed inside the drawer.
 Bacteria can develop on the food if the temperature is too low.
Make sure that you set a high enough temperature to keep food
warm.
Cleaning and care
 Do not use a steam cleaning appliance to clean the drawer.
The steam could reach electrical components and cause a short cir‐
cuit.

Caring for the environment
11
Disposal of the packing mate‐
rial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur‐
ing process and also reduces the
amount of waste in landfill sites.
Disposal of your old appliance
Electrical and electronic appliances of‐
ten contain valuable materials. They al‐
so contain materials which, if handled
or disposed of incorrectly, could be po‐
tentially hazardous to human health and
to the environment. They are, however,
essential for the correct functioning of
your appliance. Please do not therefore
dispose of it with your household
waste.
Please dispose of it at your local com‐
munity waste collection / recycling cen‐
tre or contact your Dealer for advice.
Ensure that it presents no danger to
children while being stored for disposal.

Overview
12
ESW 6114 / ESW 6214
aAnti-slip mat
bControl panel
cPush/pull opening mechanism
The drawer can be opened and
closed by pressing lightly in the mid‐
dle of the drawer front.

Overview
13
ESW 6129 / ESW 6229
aAnti-slip mat
bControl panel
cAir vents
dRack

Overview
14
Accessories supplied
The accessories supplied with your ap‐
pliance as well as a range of optional
ones are available to order from Miele
(see "Optional accessories").
Rack
For increasing the loading area (ESW
6*29)
Anti-slip mat
For keeping crockery secure.
Miele Low temperature cookbook
A selection of the best recipes from the
Miele test kitchen.

Controls
15
Sensor controls
Sensor Description
On/Off button
For selecting the function
For setting the temperature
For setting the duration
Display
Display Description
For warming cups and glasses
Warming plates and dishes function
For keeping food warm
Low temperature cooking function
     Temperature display with segment bars
1h Duration 1 hour
2h Duration 2 hours
3h Duration 3 hours
4h Duration 4 hours

Using for the first time
16
Please stick the extra data plate for
the appliance supplied with this doc‐
umentation in the space provided in
the "After sales service, data plate,
guarantee" section of this booklet.
Remove any protective wrapping and
stickers.
Cleaning the drawer for the
first time
Remove the anti-slip mat and the
rack, if present, from the drawer and
clean them with warm water and a lit‐
tle washing-up liquid applied with a
clean sponge or clean, damp microfi‐
bre cloth.
Dry the mat and the rack with a soft
cloth.
Wipe the drawer inside and out with a
damp cloth to remove any dust or
left-over packaging
Dry all surfaces with a soft cloth.
Replace the anti-slip mat and the
rack (if applicable) in the drawer.
Heating up the drawer for the
first time
Heat the empty drawer for at least two
hours.
Switch the drawer on by touching the
On/Off sensor.
Touch the sensor repeatedly until
the symbol lights up.
Touch the sensor repeatedly until
the segment on the far right hand
side of the temperature display lights
up.
Touch the sensor repeatedly until
2h lights up.
Close the drawer.
The drawer will switch itself off auto‐
matically after two hours.
The drawer is fitted with a contact
switch, which ensures that the heating
element and fan in the appliance only
work when the drawer is closed.
The metal components have a protec‐
tive coating which may give off a slight
smell when the drawer is heated up for
the first time. The smell and any va‐
pours will dissipate after a short time,
and do not indicate a faulty connection
or appliance. Ensure that the kitchen is
well ventilated.

Operation
17
Operation
The On/Off sensor must be kept
clean. Soiling or liquid on the sensor
could cause it to fail to react or to
switch on the appliance unintention‐
ally.
Liquids that get inside the drawer
can cause a short-circuit.
Open and close a loaded drawer
carefully to prevent liquids from spill‐
ing.
Open the drawer.
Touch the sensor to switch the
drawer on.
Touch the sensor repeatedly until
the required function lights up.
Touch the sensor repeatedly until
the segment for the required temper‐
ature lights up in the temperature dis‐
play.
Touch the sensor repeatedly until
the required duration (in hours) lights
up.
Close the drawer.

Operation
18
Functions
The following functions are available:
–Warming cups/glasses
–Warming dishes and plates
–Keeping food warm
–Low temperature cooking
The last function selected is automati‐
cally activated the next time the draw‐
er is switched on, and this is shown in
the display.
The appliance has a fan which distrib‐
utes the warm air evenly through the
drawer. The fan runs
– continuously when the Warm‐
ing cups/glasses and Warming
plates/dishes functions are in use.
– It tacts on and off with the
Keeping food warm and
Low temperature cooking func‐
tions.
The drawer can be used to keep food
warm at the same time as warming
plates and dishes. Use the Keeping
food warm function for this.
Caution.
The plates and dishes will take lon‐
ger to warm up with this function
than in the Warming plates and
dishes function, but can get very hot.
Duration
Do not leave the drawer unattended
for too long in continuous operation
mode. Keeping food warm for a long
time can result in it drying out or
even self-igniting.
Your drawer is fitted with a safety
switch-off mechanism which
switches it off after a maximum of
12 hours' continuous operation.
The drawer is set for continuous opera‐
tion mode. (Exception: Low temperature
cooking).
A limited duration can be selected by
touching the sensor. One touch for 1
hour (1h), two touches for 2 hours (2h)
etc, up to a maximum of 4 hours.
Continuous operation is restored by
touching the sensor a fifth time.
Temperature settings
Each function has its own temperature
range. The factory-set recommended
temperatures are printed in bold. The
temperature can be altered in 5° steps
by touching the sensor.
The last temperature selected is auto‐
matically activated the next time the
drawer is switched on, and this is
shown in the display. (Exception: Low
temperature cooking).

Operation
19
Temperature
display Temperature [°C] *
   
     40 60 65 65
     45 65 70 70
     50 70 75 75
     55 75 80 80
     60 80 85 85
* Approximate temperature values, measured in the middle of the drawer when empty

Keeping food warm
20
In order to ensure that the tempera‐
ture does not drop below the mini‐
mum required for keeping food warm
(65 °C), select the function only.
This function is for keeping food
which has just been cooked and is still
hot. It is not for reheating food that
has gone cold.
Select the function.
Select the desired time setting.
Pre-heat the drawer for 15 minutes to
ensure that it has reached the required
temperature.
Whilst the appliance is heating up,
place the empty dishes in the drawer.
Remove the pre-heated dishes from
the drawer after 15 minutes and fill
them with the hot food. Use oven
gloves to remove the dishes from the
drawer.
Then place the dishes in the drawer
and close it carefully to prevent any
liquid food from spilling.
Tips
– Place the hot food in pre-heated
dishes. To pre-heat dishes, place
them in the drawer while it is heating
up.
– Do not cover roast or fried food
which you want to keep crisp. These
types of food need to be kept warm
at a higher temperature.
– Cover food with a high moisture con‐
tent and liquid and food which can
develop a skin, with aluminium foil or
a plate.
– To avoid spillages, do not overfill
dishes.
– Freshly cooked food is hotter than
food which is being kept warm. Serve
food which is being kept warm on
pre-heated plates.
– Nutrients are lost when food is
cooked, and continue to diminish
when food is kept warm. The longer
food is kept warm for, the greater the
loss of nutrients. Try to ensure that
food is kept warm for as short a time
as possible.
– We do not recommend food being
kept warm for too long, as it will con‐
tinue to cook.
– Food may cool down if the drawer is
opened and closed too often.
– Do not slam the drawer open or shut.
Liquids could spill over and get into
the vents or into the inner parts of the
drawer.
