Miele PG 8581 User manual

Operating instructions
Washer-disinfector
PG 8581
To prevent accidents and machine damage,
read these instructions before installation or
use.
en - CA
M.-Nr. 10 605 012

2

Contents
3
Notes about these instructions...................................................................................... 7
Definition of terms ............................................................................................................. 7
Intended use .................................................................................................................... 8
Guide to the machine...................................................................................................... 9
Overview............................................................................................................................ 9
Control panel..................................................................................................................... 10
LEDs in the buttons........................................................................................................... 11
User profiles..................................................................................................................... 12
Warning and Safety Instructions.................................................................................... 13
Symbols on the machine................................................................................................... 18
Operation.......................................................................................................................... 19
Display illustrations............................................................................................................ 19
Switching on...................................................................................................................... 20
Switching off...................................................................................................................... 20
Auto-off function ............................................................................................................... 20
Standby ............................................................................................................................. 20
User interface in the display.............................................................................................. 21
Menu operation ................................................................................................................. 21
Settings in the menu ......................................................................................................... 22
Symbols in the display ...................................................................................................... 23
Opening and closing the door........................................................................................ 24
Electronic door locking...................................................................................................... 24
Opening the door .............................................................................................................. 24
Closing the door................................................................................................................ 24
Opening the door using the emergency release .............................................................. 25
Water softener ................................................................................................................. 26
Water hardness ................................................................................................................. 26
Setting the water hardness level ....................................................................................... 26
Filling the salt reservoir...................................................................................................... 28
Add salt reminder .............................................................................................................. 30
Application technology ................................................................................................... 31
Wash carts, baskets, modules and inserts ....................................................................... 31
Upper basket height adjustment....................................................................................... 32
Wash pressure measurement............................................................................................ 34
Test point for measuring wash pressure ....................................................................... 34
Loading the machine......................................................................................................... 35
Recontamination ........................................................................................................... 37
Protein test .................................................................................................................... 37
Instruments........................................................................................................................ 38
Transmission instruments.................................................................................................. 38
Mouth specula................................................................................................................... 39
Mouth rinse cups............................................................................................................... 39
Chemical processes and technology ............................................................................ 40

Contents
4
Adding and dispensing process chemicals .................................................................. 43
Dispensing systems .......................................................................................................... 43
Labelling of the suction lances...................................................................................... 43
DOS modules .................................................................................................................... 44
Connecting a DOS module ........................................................................................... 44
Rinse aid............................................................................................................................ 45
Adding rinse aid ............................................................................................................ 45
Refill indicator................................................................................................................ 46
Dispensing rinse aid ...................................................................................................... 46
Neutralizing agent.............................................................................................................. 47
Refilling neutralizing agent ............................................................................................ 47
Refill indicator................................................................................................................ 48
Dispensing neutralizing agent ....................................................................................... 48
Instrument care products .................................................................................................. 48
Detergent........................................................................................................................... 49
Replenishing liquid cleaning agent................................................................................ 49
Refill indicator................................................................................................................ 50
Dispensing liquid process chemicals ............................................................................ 50
Dispensing powder cleaning detergents....................................................................... 51
Operation.......................................................................................................................... 53
Selecting a program .......................................................................................................... 53
Starting a program ............................................................................................................ 53
Starting a program using delay start ............................................................................. 53
Drying assistance .......................................................................................................... 55
Program sequence indicator ............................................................................................. 56
End of program.................................................................................................................. 56
Cancelling a program ........................................................................................................ 57
Program cancelled due to a fault .................................................................................. 57
Cancelling a program manually..................................................................................... 57
System messages ............................................................................................................. 58
Cleaning the filter combination and tubular filter .......................................................... 58
Low fill levels ................................................................................................................. 59
Wash pressure and spray arm monitoring ........................................................................ 59
Settings ......................................................................................................................... 60
Delay start ......................................................................................................................... 61
Drying (drying assistance) ................................................................................................. 62
DOS venting ...................................................................................................................... 63
Language ....................................................................................................................... 64
Time of day........................................................................................................................ 65
Volume............................................................................................................................... 68
Additional settings ......................................................................................................... 69
PIN code............................................................................................................................ 71
Entering the PIN code ................................................................................................... 71
Date ................................................................................................................................... 73
Log book ........................................................................................................................... 75
Report................................................................................................................................ 76
Temperature unit................................................................................................................ 76
Program settings ............................................................................................................... 76
Program release ................................................................................................................ 77

Contents
5
Moving a program: allocating program selection buttons................................................. 78
Test program ..................................................................................................................... 79
Filter maintenance ............................................................................................................ 79
Cleaning the filters in the wash cabinet ........................................................................ 79
Activating and setting the interval ................................................................................. 79
Interface ............................................................................................................................ 81
Water hardness ................................................................................................................. 84
Display: Temperature......................................................................................................... 84
Display: brightness and contrast....................................................................................... 85
Switch off after .................................................................................................................. 86
Ready for operation (standby) ....................................................................................... 86
Auto-Off function........................................................................................................... 86
Switching off after activating......................................................................................... 87
Software version................................................................................................................ 87
Program settings ............................................................................................................. 88
Adjusting program settings ............................................................................................... 88
Program structure.............................................................................................................. 88
Program header............................................................................................................. 88
Program blocks ............................................................................................................. 89
Opening the menu............................................................................................................. 90
Resetting a program.......................................................................................................... 91
Altering a program ............................................................................................................ 92
Allocating wash blocks.................................................................................................. 92
Changing water quantity ............................................................................................... 93
Increasing drainage time ............................................................................................... 94
Drying assistance .......................................................................................................... 95
Process documentation.................................................................................................. 96
Outputting batch protocols retrospectively....................................................................... 99
External software........................................................................................................... 99
Report printer ................................................................................................................ 99
Maintenance .................................................................................................................... 100
Service............................................................................................................................... 100
Routine checks.................................................................................................................. 101
Cleaning the filters in the wash cabinet ............................................................................ 101
Cleaning the spray arms.................................................................................................... 103
Cleaning the machine ....................................................................................................... 105
Cleaning the control panel ............................................................................................ 105
Cleaning the door and the door seal............................................................................. 105
Cleaning the wash cabinet ............................................................................................ 105
Cleaning the front.......................................................................................................... 105
Preventing re-soiling...................................................................................................... 105
Checking wash carts, baskets, modules and inserts........................................................ 106
Performance qualification.................................................................................................. 107
Problem solving guide .................................................................................................... 110
Technical faults and messages ......................................................................................... 110
Dispensing/dispensing systems........................................................................................ 111
Insufficient salt/water softener .......................................................................................... 112
Cancel with fault number .................................................................................................. 113
Process-related faults and messages ............................................................................... 118

Contents
6
Door................................................................................................................................... 119
Unsatisfactory cleaning and corrosion.............................................................................. 119
Spray arm monitoring/wash pressure ............................................................................... 122
Water inlet and drainage ................................................................................................... 123
Noises................................................................................................................................ 123
Printer/serial interface ....................................................................................................... 124
Maintenance .................................................................................................................... 125
Cleaning the drain pump and non-return valve................................................................. 125
Clean the water intake filters ............................................................................................. 126
Retrofitting the large-surface filter................................................................................. 126
After sales service........................................................................................................... 127
Contacting Miele Service .................................................................................................. 127
Notification of serious incidents ........................................................................................ 127
Software version................................................................................................................ 128
Installation........................................................................................................................ 129
Installation and levelling .................................................................................................... 129
Building under a continuous worktop ............................................................................... 130
Removing the lid........................................................................................................... 130
Electromagnetic compatibility (EMC) ................................................................................ 131
Electrical connection ...................................................................................................... 132
Equipotential bonding connection .................................................................................... 132
Peak-load negotiation ....................................................................................................... 133
Water connection ............................................................................................................ 134
Connecting the water supply ............................................................................................ 134
Retrofitting the large-surface filter................................................................................. 135
Connecting the water drain ............................................................................................... 136
Technical data.................................................................................................................. 137
Program guide ................................................................................................................. 138
Caring for the environment ............................................................................................ 140
Disposal of the packing material ...................................................................................... 140

Notes about these instructions
7
Warnings
Information which is important for safety is highlighted in a thick
framed box with a warning symbol. This alerts to a potential danger
of injury to people or damage to property.
Read these warning notes carefully and follow instructions and
codes of practice as described.
Notes
Notes contain information that is particularly important to follow.
They are highlighted in a thick framed box.
Additional information and comments
Additional information and comments are contained in a box with a
simple frame.
Operating steps
Operating steps are indicated by a black square bullet point.
Example:
 Select an option using the arrow buttons and save your choice with
OK.
Display
Information given via the display are shown in display messages
using the same font as used in the display.
Example:
Menu Settings .
Definition of terms
Machine In these operating instructions, the PG8581 is referred to as “the
machine”.
Wash items The term “wash items” is used wherever the items to be reprocessed
are not defined in any further detail.
Wash water The term “wash water” is used for the mixture of water and process
chemicals.

Intended use
8
This Miele washer-disinfector is a Class II medical device in
accordance with Health Canada.
This Miele washer-disinfector can be used to clean, rinse, and
thermally disinfect a wide range of reprocessable medical devices for
dental use. Information issued by the manufacturers of medical
devices (ENISO17664) must be heeded.
Instruments such as dental instruments, suction instruments,
handpieces etc. can be reprocessed in this washer-disinfector.
Reprocessing items by machine achieves reproducible results and
should be used in preference to processing them by hand. Where
disinfection is required for the protection of staff and/or patients, a
thermal disinfection program, e.g. the Vario TD program should be
selected.
According to the A0 concept described in EN ISO 15883-1 (CAN/
CSA-Z15883), thermal disinfection occurs at 90°C (+ 5 °C, - 0 °C)
with 5 min holding time (A0 3000), depending on the disinfection
result required. The efficacy standard A0 3000 is suitable for
deactivating the HBV virus (Hepatitis virus).
Regional and/or other official directives may apply (e.g. CSA Z314.8
Decontamination of reusable Medical Devices in Canada). Refer to
your country's local and national health and safety regulations and
guidelines.
The cleaning program must be chosen according to the type of
soiling and load being processed. The processing chemicals used for
reprocessing the products should be selected to suit the level of
cleaning required.
The cleaning result must ensure that items can be disinfected
correctly, that subsequent sterilization can be carried out and that the
items can be used again safely.
Reusable medical devices are best processed using the Vario TD
program where applicable.
The use of a suitable carrier (basket, module, insert, etc.) is important
to ensure the adequate cleaning of the load. Examples are given in
the section “Areas of application”.
This washer-disinfector is programmed to carry out the final rinse with
mains water or with processed water of a quality to suit the
application (e.g. purified water, reverse osmosis water or
demineralized water).
This washer-disinfector complies with EN ISO 15883 (CAN/CSA-
Z15883).

Guide to the machine
9
Overview
aComfort door locking mechanism
bModule slot for a communication module
(Back, top right)
cTest point for validation
(Top, front right; only visible with lid
removed)
dUpper machine spray arm
eRails for baskets and wash carts
fLower machine spray arm
gData plate
hRinse aid reservoir
iSalt reservoir
jFilter combination
kToe kick cover
lOn the back:
– Second data plate
– Electrical and plumbing connections
– Suction lance(s) for external supply
containers
– Connections for external dispensing
modules (optional DOS modules)
mConnection point for wash carts and
baskets

Guide to the machine
10
Control panel
a On/off button
For switching the machine on and off.
b,,andbuttons
Program selection buttons.
The button assignment can be configured.
cProgram list button
For accessing the list of all programs for program selection.
dDisplay
User interface and program cycle display.
eandarrow buttons
For navigating in the user interface.
fCancel button
For cancelling a process in the user interface.
No program interruption.
gSettings button
For accessing the system settings menu.
hStart/Stop button
For starting or cancelling a program.
iDoor release button
For opening the door before or after a program.
j Drying assistance button
For switching drying assistance on and off.
kOK button
For selecting or confirming entries in the user interface
(acknowledge or save).
lService interface
Testing and transmission point for the Service department.

Guide to the machine
11
LEDs in the buttons
The buttons on the control panel have LEDs. These indicate the status of the machine.
Button LED Status
Button ON The machine is switched on.
FLASHES The machine is ready for use.
OFF The machine is switched off.
Program
selection
buttons ,
 and 
ON The respective program has been selected. At the
end of the program the LED will remain lit until a
different program is selected.
OFF The program is not selected or the program settings
are being changed.
Button ON A program has been selected from the program list.
At the end of the program the LED will remain lit until
a different program is selected.
OFF No program has been selected from the list or the
program settings are being changed.
Button ON The additional “Drying Assistance” function has been
activated for the selected program (not available for
all programs; see “Program chart”).
OFF The additional “Drying Assistance” function has been
deactivated.
Start/Stop
button
ON A program is running.
FLASHES
GREEN
A program has been selected, but not yet started.
FLASHES RED A fault has occurred (see “Problem solving guide”).
OFF A program has finished.
Button ON The door is closed (locked) and there is no program
running.
FLASHES A program has finished and the door is closed
(locked).
OFF A program is running or the door is open (unlocked).

User profiles
12
Daily operators
For day-to-day use, operators must be instructed on the basic
functions and how to load the machine and must also be trained
regularly. They must have knowledge of machine reprocessing of
medical devices.
Day-to-day work is carried out using the user level and in the Settings
 menu. The menu is freely accessible to all users.
Administration
More advanced tasks, e.g., interrupting or cancelling a program,
require more detailed knowledge about the machine reprocessing of
medical devices.
Alterations to the reprocessing process or adaptations to the
machine, e.g., to accessories used or on-site conditions, require
additional specific knowledge of the machine.
Validation processes assume specialized knowledge about machine
reprocessing of medical devices, the processes involved, and
applicable standards and legislation.
The Additional settings menu incorporates all administrative
processes and settings. This is protected from unauthorized access
by a PIN code.

Warning and Safety Instructions
13
This machine complies with all statutory safety requirements.
Inappropriate use can, however, lead to personal injury and
material damage.
Read these instructions carefully before using it for the first time to
avoid the risk of accidents and damage to the machine.
Keep these instructions in a safe place and make sure they are
available at all times to any user of the machine.
Correct application
 Use of the machine is only approved for the applications stated in
the operating instructions. Conversions, modifications, and any other
use are not permitted and could be dangerous.
The cleaning and disinfection processes are only designed for
medical devices which are designated as reprocessable by the
instrument manufacturer. Instructions issued by load item and
instrument manufacturers must be heeded.
 This machine is intended for indoor use in a stationary location
only.
Risk of injury
Please pay attention to the following notes to avoid injury!
 The machine may only be installed, commissioned, repaired, and
maintained by Miele Service or a suitably qualified service technician.
A Miele service contract is recommended to ensure full compliance
with the normative and regulatory provisions. Incorrect repairs can
cause considerable danger to users.
 Do not install the machine in an area where there is any risk of
explosion or of freezing conditions.
 In order to reduce the risk of water damage, the area around the
machine should be limited to furniture and fittings that are designed
for use in commercial environments.
 Some metal parts pose a risk of injury/being cut. Wear cut-
resistant protective gloves when transporting and setting up the
machine.
 If the machine is built under, it must only be installed under a
continuous worktop run which is firmly secured to adjacent units to
improve stability.
 The electrical safety of this machine can only be guaranteed when
it is correctly grounded. It is essential that this standard safety
requirement is met. If in any doubt, please have the electrical
installation tested by a qualified electrician. Miele cannot be held
liable for the consequences of an inadequate earthing system (e.g.
electric shock).

Warning and Safety Instructions
14
 A damaged or leaking machine can pose a threat to your safety.
Always switch off a damaged or leaking machine immediately and
call Miele Service.
 Label machines which have been taken out of operation and lock
them to prevent them being switched on again without authorization.
The machine may only be put back into operation once it has been
successfully repaired by Miele Service or by an appropriately qualified
specialist.
 Personnel operating the machine should be trained on a regular
basis. Untrained personnel must not be allowed access to the
machine or its controls.
 Only use process chemicals which have been approved by their
manufacturer for the relevant application. The manufacturer of the
process chemicals is liable for any negative influences on the material
of the load items and the machine.
 Always exercise caution when handling the process chemicals for
this machine. These products may contain irritant, corrosive or toxic
ingredients.
Always comply with safety requirements and the manufacturer's
safety instructions (see safety data sheets)!
Use protective eyewear and gloves!
 The machine is designed to operate with water and the
recommended process chemicals only. Organic solvents or
flammable liquid agents must not be used in it!
This could cause an explosion, property damage due to the
destruction of rubber and plastic components, and the resulting
leakage of liquids.
 The water in the cabinet must not be used as drinking water.
 Do not lift the machine by protruding parts such as the control
panel or the opened service flap as these could be damaged or torn
off.
 Do not sit or lean on the opened door. This could cause the
machine to tip or become damaged.
 Be careful when sorting load items with sharp, pointed ends.
Position them in the machine so that you will not hurt yourself or
create a danger for others.
 Broken glass can result in serious injury when loading or
unloading. Broken glass items must not be processed in the machine.
 When operating the washer-disinfector, bear in mind the possibility
of high temperatures. If the door is opened bypassing the safety lock,
there is a danger of burning, scalding and chemical burns.

Warning and Safety Instructions
15
 Should personnel accidentally come into contact with toxic
vapours or processing chemicals, consult the manufacturer's safety
data sheets for emergency procedures.
 Always allow wash carts, baskets, modules, inserts, and loads to
cool down before unloading. Any water remaining in concave items
could still be very hot. Empty them into the wash cabinet before
taking them out.
 Never clean the machine or surrounding area with a water hose or
a pressure washer.
 The machine must be disconnected from the mains electricity
supply before any maintenance or repair work is carried out.
Quality assurance
The following points should be observed, to assist in maintaining
quality standards when reprocessing medical devices, in order to
protect patients, and to avoid damage to property.
 If it is necessary to interrupt a program in exceptional
circumstances, this may only be done by authorised personnel.
 The standard of cleaning and disinfection in the disinfection
programs must be routinely confirmed by the user. The process
should be regularly tested and documented, both thermo-electrically
and through inspection.
 For thermal disinfection, use temperatures and holding times to
achieve the required infection prophylaxis in accordance with current
health and safety regulations.
 Make sure items being washed are suitable for machine
processing and are in good condition. Plastic items must be thermally
stable. Nickel plated items and anodised aluminum items can be
machine processed using special procedures only.
Items containing iron, and soiling containing residual rust must not be
placed in the cabinet.
 Under certain circumstances, process chemicals can cause
damage to the machine. Users are urged to follow the
recommendations issued by manufacturers of process chemicals.
Contact Miele Service in the event of damage and any suspicion of
material incompatibility.
 Instrument care products based on paraffin oils (white oils) can
damage elastomers and plastics in the machine. Such care products
may not be dispensed as chemical agents in these machines even if
they are recommended for machine use by the care product
manufacturer.

Warning and Safety Instructions
16
 Abrasive substances must not be placed in the machine as they
could cause damage to the mechanical components of the water
supply. Any residues of abrasive substances on items to be washed
must be removed without trace before reprocessing in the machine.
 Pre-treating (e.g. with cleaning agents or disinfectants), some
types of soiling and the interaction of certain processing chemicals
can cause foaming. Foam can have an adverse effect on the cleaning
and disinfection results obtained.
 The process must be set so that no foam escapes the wash
compartment. Escaping foam jeopardizes the safe operation of the
machine.
 The process must be checked regularly in order to detect any
foaming.
 To avoid the risk of damage to the machine and its accessories
caused by process chemicals, soiling and any reaction between the
two, please read the notes in “Chemical processes and technology”.
 Even when a chemical additive (e.g. cleaning chemical) is
recommended on technical application grounds, the machine
manufacturer takes no responsibility for the effect of such chemicals
on the material of the items being cleaned.
Note that formulation changes, storage conditions, etc., that are not
disclosed by the chemical manufacturer may adversely affect the
cleaning results obtained.
 When using process chemicals, always consult the instructions
issued by individual manufacturers. Process chemicals must only be
used for the purpose for which they are designed by the
manufacturer to avoid any material damage or the occurrence of very
strong chemical reactions.
 Always follow the relevant manufacturer's instructions on storage
and disposal of process chemicals.
 Particles ≥0.8mm are removed by the filters in the wash chamber.
Smaller particles may find their way into the circulation system. For
this reason, processing of wash loads with narrow openings requires
additional filtering of the wash water.
 In critical applications where very stringent requirements have to
be met, it is strongly recommended that all the relevant factors for the
process (detergent, water quality, etc.) are discussed with Miele.
 The carts, baskets, modules and inserts that hold the wash load
must be used only as intended.
Hollow items must be thoroughly cleaned, internally and externally.
 Secure small and light items with cover nets or place in a mesh
tray for small items, so that they do not block the spray arms.

Warning and Safety Instructions
17
 Empty all containers and hollow utensils before loading them into
the machine.
 The amount of residual solvents and acids on items going into the
cabinet should be minimal.
There should be no more than a trace of any solvents with a flash
point of below 21°C (70°F).
 Chloride solutions, in particular hydrochloric acid, must not be
placed in the cabinet.
 To avoid corrosive damage, make sure the stainless steel housing
does not come into contact with solutions or steam containing
hydrochloric acid.
 After any plumbing work the water pipework to the machine will
need to be vented. If this is not done, components can be damaged.
 The gaps between a built-in machine and adjacent cabinetry must
not be filled with silicone sealant as this could compromise the
ventilation of the circulation pump.
 Follow the installation instructions in the operating instructions and
in the installation instructions.

Warning and Safety Instructions
18
Using components and accessories
 Only use original spare parts and accessories from the
manufacturer, which are suitable for the application they are required
for. Model designations are available from Miele.
 Only use Miele wash carts, baskets, modules and inserts with this
machine. Using wash carts, baskets and inserts made by other
manufacturers, or making modifications to Miele accessories can
cause unsatisfactory cleaning results, for which Miele cannot be held
liable. Any resultant damage would not be covered by the warranty.
Symbols on the machine
Attention:
Observe the operating instructions!
Attention:
Danger of electric shock!
Warning: Hot surfaces:
It can be very hot inside the wash chamber
when the door is opened!
Risk of being cut:
Wear cut-resistant protective gloves when
transporting and setting up the machine!
Disposing of your old appliance
 Please note that the machine may contain contamination from
blood and other bodily fluids, pathogens, and facultative pathogens,
and must be decontaminated before disposal.
For environmental and safety reasons, dispose of all process
chemical residues in accordance with safety regulations (wear safety
goggles and gloves).
Remove or disable the door lock prior to disposal of the machine, so
that children cannot become trapped inside. Then make appropriate
arrangements for safe disposal of the machine.

Operation
19
Control panel
The machine is operated exclusively by the buttons located on the
stainless steel surfaces either side of the display. The display is not a
touch screen.
A light touch on the relevant button is sufficient to operate the
functions. The buttons can also be pressed and held for approx. 20
seconds.
Display illustrations
All display illustrations shown in these operating instructions are
examples which can be different from the actual display screens
shown.
Vario TD Dental
Temperature
Duration Min50
55 °C
The control buttons are shown next to the display. The ,  and
Start/Stop buttons are not shown.

Operation
20
Switching on
The machine must be connected to the electrical supply.
Press the button until the button’s LED lights up.
After that, the display will show the following:
PG 8581
As soon as the machine is ready for operation, the display changes to
show the last selected program, e.g.:
Vario TD Dental
Temperature
Duration Min50
55 °C
If the machine is being used for the first time, or if the factory default
settings have been reinstated, some basic parameters, e.g.
language, date, time, etc., must first be set. To enable this, the
display automatically changes to the relevant screen.
Switching off
Press the button.
Auto-off function
To save energy, the machine has an automatic switch-off function
(Auto-off function). If the machine has not been used for a specific
time period, it switches itself off automatically, see “Further settings/
Switch off after”.
Use the button to switch the machine on again.
Standby
When it is on standby, the machine remains switched on, the
button flashes, and the time is shown on the display. Pressing any
button reactivates the machine. Standby can be switched on and off
as required, see “Further settings/Switch off after”.
