Miele PWM 909 GB User manual

Operating and installation instructions
Commercial washing machine
PWM 909 GB
Always read the operating instructions before
setting up, installing and commissioning the ma-
chine. This prevents both personal injury and
damage to the machine.
en-GB
M.-Nr. 12 072 370

Caring for the environment
2
Disposal of the packaging material
The packaging is designed to protect the washing machine against
transport damage. The packaging materials used are selected from
materials which are environmentally friendly for disposal and can
therefore be recycled.
Recycling the packaging material reduces the use of raw materials in
the manufacturing process and also reduces the amount of waste in
landfill sites. Your dealer will take the packaging material away.
Disposing of your old machine
Old electrical and electronic machines often contain valuable materi-
als. However, they also contain harmful substances which were es-
sential for their correct functioning and safety. These could be haz-
ardous to human health and to the environment if disposed of with
household waste or if handled incorrectly. Please do not, therefore,
dispose of your old machine with household waste.
Please dispose of it at your local community waste collection/recyc-
ling centre. Consult your dealer if necessary. Please ensure that your
old machine poses no risk to children while being stored for disposal.
Energy saving tips
Energy and water
consumption
- To get the most out of your machine, load the maximum dry load
size for the wash programme you are using.
Energy and water consumption is most efficient when a full load is
washed.
Detergent - Do not exceed the amounts of detergent recommended by the
manufacturer on the packaging.
- Reduce the amount of detergent for smaller load sizes.
When drying with
a tumble dryer
Select the highest possible spin speed for the wash programme to
save energy in the subsequent tumble dryer cycle.
