Miele PW 6131 D User manual

Installationsplan / Installation plan
Installatietekening
Plan d`installation
Pianta di installazione
Plano de instalación
Plano de instalação
Σχέδιο εγκατάστασης
Asennusohje
Installasjonsplan
Installationsplan UV
PW 6131 D
Materialnummer / Mat. no.: 06 563 440
Änderungsstand / Version: 01
Datum Zeichnung / Drawing date: 19.10.2007
Datum Legende / Legend date: 19.10.2007

Installation plan PW 6131 Steam
Date 19.10.2007 Page 7
Technical datasheet
Washer:
Heating:
PW 6131
Steam
Legend: Circled, bold-typed abbreviations:
Connection required
Abbreviations surrounded by broken circle:
Connection optional or required, depending on model
U
V
Options/Accessories:
UG/UO 6013Miele plinth (UG = Box plinth/UO = Open plinth)
UM Height Model 5 11/16" 144 mm
Width UG (UO) 31 1/2" (30 11/16") 800 (780) mm
Depth UG (UO) 37" (35 3/8") 939 (899) mm
Concrete platform Concrete platform optional (min. Quality B15)
Recommended height 5 7/8" 150 mm
BS Minimum height 4" 100 mm
Recommended width 35 7/16" 900 mm
Recommended depth 39 3/4" 1.010 mm
Ensure good anchorage!
WI Special product With integrated scale
Machine connections:
Electrical
connections USA CDN
Standard voltage (factory set) * 3 AC 220-240 V 3 AC 220-240 V
Frequency 50-60 Hz 50-60 Hz
Rated load 2.3 kW 2,3 kW
Fuse rating 3 × 15 A 3 × 15 A
Supply lead, wire size 14 AWG 4 × 1,5 mm²
* If power supply includes a stinger leg,
please call Technical Service at
USA 1-800-991-9380
CDN 1-800-643-5361
Alternative voltage 3 AC 208 V 3 AC 208 V
Frequency 60 Hz 60 Hz
Rated load 2.3 kW 2,3 kW
Fuse rating 3 × 15 A 3 × 15 A
Supply lead, wire size 14 AWG 4 × 1,5 mm²
U
V
reversible

Installation plan PW 6131 Steam
Date 19.10.2007 Page 8
USA CDN
Indirect steam (page 4)
Steam pressure 87 - 145 psi 87 - 145 psi
Steam pressure on dryer version 58 - 72 psi 58 - 72 psi
Boiling point 306 - 363 °F 152 - 184 °C
Heating capacity 37 kW 37 kW
Steam
connection
Steam supply capacity 147 lbs/h 67 kg/h
Connection thread (on-site) 1/2" MPT 1/2" MPT
Steam valve, steam filter and steam faucet must be
provided on-site.
Direct steam (page 5)
Steam pressure (High pressure) ≤58 psi ≤58 psi
Boiling point (High pressure) ≤306 °F ≤152 °C
Heating capacity (High pressure) 26 kW 26 kW
Steam supply capacity (High pressure) 101 lbs/h 46 kg/h
Steam pressure (Low pressure) ≤7.25 psi ≤7,25 psi
Boiling point (Low pressure) ≤84 °F ≤120 °C
Heating capacity (Low pressure) 18 kW 18 kW
Steam supply capacity (Low pressure) 68 lbs/h 31 kg/h
Connection thread (on-site) 1/2" MPT 1/2" MPT
Steam valve, steam filter, steam faucet and non-return
valve must be provided on-site.
Note installation instructions for steam-heated Miele
washer-extractors.
Condensate
connection Indirect steam (page 4)
Connection thread (on-site)
1/2" MPT 1/2" MPT
Steam valve, steam filter and steam faucet must be
provided on-site.
Min. flow pressure 14.5 psi 14,5 psi
Max. pressure 145 psi 145 psi
Cold water
(Soft water) Max. throughput (if hot water supply is not available) 6.9 (11) gal/min 26 (42) l/min
On-site connection thread 3/4" MPT 3/4" MPT
Length of connection hose
(supplied: 2 hoses and Y adapter) 59 1/16" 1.500 mm
Water requirements (average 140°F [60°C] program)
Standard connection (with hot water connection) 27.5 gal/h approx. 104 l/h
Additional requirements if hot water supply is not
available.
Max. temperature 158 °F 70 °C
Min. flow pressure 14.5 psi 14,5 psi
Hot water
Max. pressure 145 psi 145 psi
Max. throughput 4.2 gal/min 16 l/min
On-site connection thread 3/4" MPT 3/4" MPT
Length of connection hose (supplied) 59 1/16" 1.500 mm
Water requirements (average for 140°F [60°C] program)
Standard connection (with hot water connection) approx. 30 gal/h approx. 98 l/h
If no hot water supply, connect hose to cold water!
Min. flow pressure 14.5 psi 14,5 psi
Max. pressure 145 psi 145 psi
Max. throughput 8.45 gal/min 32 l/min
Mains water
(Raw water)
(Optional) On-site connection thread 3/4" MPT 3/4" MPT
Length of connection hose
(supplied: 2 hoses and Y adapter) 59 1/16" 1.500 mm
Water requirements (average for 140°F [60°C] program)
Standard connection (with hot water connection) approx. 16.4 gal/h approx. 62 l/h
If connected to raw water supply, subtract cold water
(soft) volume.
If no raw water supply, connect hose to cold water!

Installation plan PW 6131 Steam
Date 19.10.2007 Page 9
USA CDN
Max. temperature 203 °F 95 °C
Machine drain connection (da× s × l) 3" x 1/16" x 3 9/16" 75×1,9×90 mm
On-site drain connection (di) 3" 75 mm
Drainage via
dump valve
Max. throughput 52.8 gal/min 200 l/min
Vented drainage required. If ventilation is insufficient, fit
Miele kit, Mat. no. 05238090.
Drain manifolds serving several machines must be of
sufficient cross-section.
Foam vent
A drainage system for foam escaping from the drain vent can be built using standard drain pipe sections.
A 87° branch with an end cap should be provided for
this purpose.
Miele plinth UG/UO 6013Fittings (supplied) 4 × metal angled brackets (to secure machine to plinth)
4 × screws (Diameter × length) 5/16" x 3 1/8" 8 × 80 mm
4 × wall anchors (Diameter × length) 1/2" x 2 3/8" 12 × 60 mm
Machine must be secured!
Fixing materials provided for securing to concrete floor
On concrete platform
2 × screws (Diameter × length) 5/16" x 3 1/8" 8 × 80 mm
2 × wall anchors (Diameter × length) 1/2" x 2 3/8" 12 × 60 mm
Machine must be secured!
Fixing materials provided for securing to concrete floor
Without plinth
2 × screws (Diameter × length) 5/16" x 3 1/8" 8 × 80 mm
2 × wall anchors (Diameter × length) 1/2" x 2 3/8" 12 × 60 mm
Machine must be secured!
Fixing materials provided for securing to concrete floor
On concrete platform
4 × screws (Diameter × length) 5/16“ x 3 1/8“ 8 × 80 mm
4 × wall anchors (Diameter × length) 1/2“ x 2 3/8“ 12 × 60 mm
Machine must be secured!
Fixing materials provided for securing to concrete floor
Without plinth
4 × screws (Diameter × length) 5/16“ x 3 1/8“ 8 × 80 mm
4 × wall anchors (Diameter × length) 1/2“ x 2 3/8“ 12 × 60 mm
Machine must be secured!
Special product
WI:
Fixing materials provided for securing to concrete floor
Machine data Width 31 5/8” 804 mm
Depth 35 13/16" 910 mm
Height 49 3/16" 1.250 mm
Knocked-down dimensions (Width) 31 7/8" 810 mm
Recommended clearance to rear wall
(to machine front edge) 63" 1.600 mm
Net weight 763 lbs 346 kg
Dynamic floor load during operation, max. 4,304 N 4.304 N
Static load, max. 3,801 N 3.801 N
Dynamic load max. 503 N 503 N
Drum frequency, max. 18.3 Hz 18,3 Hz
Average heat dissipation
(depending on room temperature and selected program) 1,470 W 1.470 W
Installation should only be carried out by authorized installers in accordance with all local and national regulations!
Observe installation instructions when installing machine! All rights reserved!
