Miele WKR 771 WPS User manual

Operating instructions
for washing machines
To avoid the risk of accidents or damage to the machine, it is essential
to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 10 201 050

Contents
2
Caring for the environment .................................................................................. 6
Warning and Safety instructions ......................................................................... 7
Operating the washing machine ........................................................................ 14
Control panel......................................................................................................... 14
Standard display ................................................................................................... 16
Examples on how to operate the machine............................................................ 16
Before using for the first time ............................................................................ 17
Inserting detergent cartridges ............................................................................... 17
Setting the language ............................................................................................. 19
Removing the transit bars ..................................................................................... 19
Setting the time of day (if necessary) .................................................................... 19
Starting the calibration programme....................................................................... 20
TwinDos................................................................................................................ 21
Washing environmentally and economically .................................................... 22
EcoFeedback......................................................................................................... 23
1. Prepare the laundry......................................................................................... 24
2. Select a programme........................................................................................ 25
3. Load the washing machine............................................................................. 26
4. Select programme settings ............................................................................ 27
5. Add detergent .................................................................................................. 29
TwinDos................................................................................................................. 29
Detergent dispenser drawer .................................................................................. 30
CapDosing............................................................................................................. 31
6. Start the programme - the end of a programme .......................................... 33
Spinning................................................................................................................ 35
Delay start ............................................................................................................ 37
To select delay start .............................................................................................. 37
To change delay start ............................................................................................ 37
To cancel delay start and begin the programme straight away ............................ 38
To cancel delay start ............................................................................................. 38
Programme chart ................................................................................................ 39

Contents
3
Favourites............................................................................................................. 46
To create a favourite programme .......................................................................... 46
Mixed items.......................................................................................................... 48
Options ................................................................................................................. 49
ProgrammeManager.............................................................................................. 49
Intensive ........................................................................................................... 49
ECO .................................................................................................................. 49
Extra gentle ......................................................................................................49
Extra quiet ........................................................................................................ 49
AllergoWash ..................................................................................................... 49
Steam smoothing .............................................................................................. 50
Short...................................................................................................................... 50
Stains..................................................................................................................... 50
Further options ...................................................................................................... 50
Rinse hold......................................................................................................... 50
Pre-wash .......................................................................................................... 50
Water plus ........................................................................................................50
Extra rinse......................................................................................................... 50
Wash programme chart - ProgrammeManager..................................................... 51
Wash programme chart - Options......................................................................... 52
Wash programme chart - Further options ............................................................. 53
Programme sequence......................................................................................... 54
Garment care label symbols............................................................................... 57
Changing the programme sequence ................................................................ 58
Cancelling a programme ....................................................................................... 58
Interrupting a programme...................................................................................... 58
Changing a programme......................................................................................... 58
Adding or removing laundry after the programme has started ............................. 59
Safety lock............................................................................................................. 60
Detergent ............................................................................................................. 61
The correct detergent............................................................................................ 61
Water softeners ..................................................................................................... 61
Dispensing aids ..................................................................................................... 61
Fabric conditioner and liquid starch ...................................................................... 61
Miele recommended detergents ........................................................................... 62
Recommended detergents in accordance with Directive (EU) Nr. 1015/2010...... 63
Adding starch separately.................................................................................. 65

Contents
4
Cleaning and care ............................................................................................... 66
Cleaning the drum (Hygiene info) .......................................................................... 66
External casing and fascia panel........................................................................... 66
Cleaning the detergent dispenser drawer ............................................................. 66
Cleaning the TwinDos system ............................................................................... 68
Starting the maintenance programme.............................................................. 68
Cleaning the compartments............................................................................. 69
Cleaning the water inlet filter................................................................................. 70
Problem solving guide ........................................................................................ 71
The programme does not start.............................................................................. 71
The following fault messages appear in the display and the programme stops... 72
A message appears in the display at the end of the programme ......................... 73
A message appears in the display at the end of the programme ......................... 74
Problems with TwinDos ......................................................................................... 75
General problems with the washing machine ....................................................... 76
An unsatisfactory wash result ............................................................................... 78
The door will not open........................................................................................... 79
Opening the door in the event of a blocked drain outlet and/or power failure ..... 80
After sales service............................................................................................... 82
Repairs .................................................................................................................. 82
Guarantee: U.K. ..................................................................................................... 82
Guarantee: Other countries ................................................................................... 82
Optional accessories............................................................................................. 82
Installation and connection ................................................................................ 83
Front view .............................................................................................................. 83
Rear view............................................................................................................... 84
Installation surface ................................................................................................ 85
Transporting the washing machine to its installation site...................................... 85
Removing the transit bars ..................................................................................... 85
Re-fitting the transit bars....................................................................................... 87
Levelling the machine............................................................................................ 88
Screwing out and adjusting the feet................................................................. 88
Building under a continuous worktop/ in a kitchen run.................................... 89
Washer-dryer stack .......................................................................................... 89
The water protection system................................................................................. 90
Connection to the water supply ............................................................................ 92
Connection to the drainage system ...................................................................... 94
Electrical connection U.K. ..................................................................................... 95

Contents
5
Consumption data............................................................................................... 96
Note for test institutes ........................................................................................... 97
Technical data...................................................................................................... 98
Settings ................................................................................................................ 99
To exit Settings...................................................................................................... 99
Language ......................................................................................................... 100
TwinDos............................................................................................................... 100
Time of day.......................................................................................................... 102
Degree of soiling.................................................................................................. 103
Buzzer volume..................................................................................................... 103
Keypad tone ........................................................................................................ 103
Total consumption............................................................................................... 103
Code.................................................................................................................... 104
Temperature unit.................................................................................................. 104
Display brightness............................................................................................... 104
Display switch-off setting.................................................................................... 104
Machine switch-off setting .................................................................................. 105
Display maximum load ........................................................................................ 105
Memory ............................................................................................................... 105
Longer pre-wash Cottons.................................................................................... 105
Soak duration ...................................................................................................... 106
Gentle action ....................................................................................................... 106
Reduce temp....................................................................................................... 106
Water plus level ................................................................................................... 106
Maximum rinse level............................................................................................ 106
Suds cooling........................................................................................................ 107
Low water pressure ............................................................................................. 107
Anti-crease .......................................................................................................... 107
Delay start ........................................................................................................... 107
Optional accessories ........................................................................................ 108
Detergent............................................................................................................. 108
Specialist detergents........................................................................................... 108
Fabric care........................................................................................................... 109
Additives.............................................................................................................. 109

Caring for the environment
6
Disposal of the packing
material
The packaging is designed to protect
the washing machine from damage
during transportation. The packaging
materials used are selected from
materials which are environmentally
friendly for disposal and should be
recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposal of your old machine
Electrical and electronic machines often
contain valuable materials. They also
contain materials which, if handled or
disposed of incorrectly, could be
potentially hazardous to human health
and to the environment. They are,
however, essential for the correct
functioning of your machine. Please do
not therefore dispose of it with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your Dealer for
advice.
Ensure that it presents no danger to
children while being stored for disposal.

Warning and Safety instructions
7
This washing machine complies with current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the machine, please
read these instructions carefully before using it for the first time.
They contain important information on its safety, use and
maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future user.
Correct application
 This washing machine is intended for use in domestic households
and similar working and residential environments.
 The washing machine is not intended for outdoor use.
 It must be used only as a domestic appliance to wash items which
are specified by the manufacturer as being washable on the wash
care label. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation.
 The washing machine can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are supervised whilst using it or have been shown
how to use it safely and recognise and understand the
consequences of incorrect operation.

Warning and Safety instructions
8
Safety with children
 Children under 8 years of age must be kept away from the
washing machine unless they are constantly supervised.
 Children 8 years and older may only use the washing machine
unsupervised if they have been shown how to use it safely and
recognise and understand the consequences of incorrect operation.
 Children must not be allowed to clean or maintain the washing
machine unsupervised.
 Please supervise children in the vicinity of the washing machine
and do not let them play with it.
Technical safety
 Please observe the instructions in "Installation and connection"
and "Technical data".
 Before setting up the washing machine, check it for any externally
visible damage. Do not install or use a damaged machine.
 Before connecting the communication module, ensure that the
connection data on the data plate (fuse rating, voltage and
frequency) match the mains electricity supply. If in any doubt,
consult a qualified electrician.
 Reliable and safe operation of this washing machine can only be
assured if it has been connected to the mains electricity supply.

Warning and Safety instructions
9
 The electrical safety of this washing machine can only be
guaranteed when correctly earthed.
It is essential that this standard safety requirement is met. If in any
doubt, please have the wiring system of the building tested by a
qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
earthing system (e.g. electric shock).
 Do not connect the washing machine to the mains electricity
supply by a multi-socket adapter, extension lead or similar. These do
not guarantee the required safety of the machine (fire hazard due to
the risk of overheating).
 Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can Miele
guarantee the safety standards of the machine.
 The electrical socket must be easily accessible after installation so
that the machine can be disconnected from the electricity supply if
necessary.
 Unauthorised repairs could result in unforeseen dangers for the
user, for which the manufacturer cannot accept liability. Repairs
should only be undertaken by a Miele authorised service technician,
otherwise any subsequent damage will not be covered by the
guarantee.
 If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.

Warning and Safety instructions
10
 The machine must be isolated from the electricity supply when
cleaning and maintaining the machine and in the event of a fault.
 The Miele "Water protection system" protects from water damage
provided the following conditions are met:
– the machine is correctly plumbed in and connected to the
electricity supply.
– if a fault or damage has been identified, the machine must be
examined by a competent person before further use, and repaired
if necessary.
 The water flow pressure must be at least 100kPa and should not
exceed 1000kPa.
 In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the machine and its
surroundings in a clean condition at all times. Any damage which
may be caused by cockroaches or other vermin will not be covered
by the guarantee.
 The machine must not be used in a non-stationary location (e.g.
on a ship).
 Do not make any alterations to the machine, unless authorised to
do so by Miele.
 This washing machine is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical
resistance, abrasion resistance and vibration). This special lamp
must only be used for the purpose it is intended for. It is not suitable
for room lighting. Replacement lamps may only be fitted by a Miele
authorised person or the Miele Service Department.

Warning and Safety instructions
11
Correct use
 Do not install the washing machine in a room where there is a risk
of frost. Frozen hoses may burst or split. The reliability of the
electronic control unit may be impaired at temperatures below
freezing point.
 Before using the machine for the first time, check that the transit
bars at the rear of the machine have been removed (see "Installation
and connection - Removing the transit bars"). During spinning, a
transit bar which is still in place may result in damage to both the
machine and adjacent furniture or appliances.
 Turn off the stopcock if the machine is to be left for any length of
time (e.g. holiday), especially if there is no floor drain (gully) in the
immediate vicinity.
 Flooding danger.
If hooking the drain hose into a wash basin, check that the water can
drain off quickly enough to prevent the sink from overflowing. Make
sure the drain hose is secure, so that the force of the water flowing
out of the hose does not dislodge it.
 Take care to ensure that foreign objects (e.g. nails, pins, coins,
paper clips) do not find their way into the machine with the laundry.
These may damage components of the machine (e.g. suds
container, drum), which in turn can result in damage to the laundry.

Warning and Safety instructions
12
 Take care when opening the drum door after using the steam
function. Danger of burning due to escaping steam and the high
temperature of the surface of the drum as well as the porthole glass.
Stand back away from the machine and wait until the steam has
dissipated.
 The maximum load for this washing machine is 9 kg (dry weight).
See the "Programme chart" for the maximum recommended loads
for individual programmes.
 If the correct amount of detergent is dispensed, the machine
should not need to be descaled. If, however, you do wish to descale
it, only use a proprietary natural citric acid based descaling agent.
Miele recommends using Miele descaling agent which is available to
order online at www.miele-shop.com or from Miele. Strictly observe
the instructions on the packaging.
 Textiles which have been pre-treated in solvent based cleaning
agents must be thoroughly rinsed in clean water before being
washed in the machine.
 Do not use solvent based cleaning agents, e.g. those containing
benzine, in this machine, as this may result in damage to component
parts and create toxic fumes. Such agents also pose a fire and
explosion hazard.
 Do not use solvent based cleaning agents, e.g. those containing
benzine, to clean the surfaces of the machine. They can cause
damage to plastic surfaces.
 Only use dyes specified by the manufacturer as being suitable for
use in a domestic washing machine. Always observe the
manufacturer's instructions carefully.

Warning and Safety instructions
13
 Colour run and dye removers contain sulphur compounds which
can cause damage such as corrosion. Do not use these products in
this machine.
 If detergent comes into contact with the eyes, rinse them
thoroughly with lukewarm water immediately. If swallowed, seek
medical assistance immediately and retain the packaging or label for
reference. Those with skin problems or sensitive skin should avoid
their skin coming into contact with detergent.
Accessories
 Accessory parts may only be fitted when expressly approved by
Miele. If other parts are used, guarantee, performance and product
liability claims will be invalidated.
 A Miele tumble dryer can be stacked on top of a Miele washing
machine using the appropriate stacking kit (available as an optional
accessory). Please make sure you order the correct one for the Miele
washing machine and Miele tumble dryer.
 If installing the machine on a Miele plinth, (available as an optional
accessory, depending on country), please make sure you order the
correct one for this washing machine.
Miele cannot be held liable for damage caused by non-compliance
with these Warning and Safety instructions.

Operating the washing machine
14
Control panel
aDisplay with sensors
See the next page for more
information.
bStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
cTemperature button
For selecting the temperature.
dSpin speed button
For selecting the spin speed.
eDelay start button
For selecting delay start.
fOption buttons
Various options can be added to the
wash programme.
gProgramme selector
For selecting the wash programme.
hOptical interface PC
For service technicians.
i button
For switching the washing machine
on and off.
To save energy the washing machine
will switch off automatically 15
minutes after the end of the
programme/anti-crease phase or
after being switched on if no other
selection is made.

Operating the washing machine
15
j sensor
Scrolls down the list to the next
option or decreases a value.
kOK button
Confirms the programme selected, a
value set or opens a sub-menu.
l sensor
Scrolls up the list to the next option
or increases a value.
m Dos sensor
Switches on automatic detergent
dispensing.
n Cap sensor
Activates cap dosing via the
detergent dispenser drawer.
oEcoFeedback sensor
Provides information about the
energy and water consumption of
the programme. Please also refer to
"Washing environmentally and
economically - EcoFeedback".
Sensors  to  light up when the
display can be operated via the
sensors.
Programme duration
After the programme has started the
programme duration will appear in the
display in hours and minutes.
If delay start has been selected, the
programme duration will appear at the
end of the delay start time.
Delay start
The delay start time selected will
appear in the display.
After the programme has started the
delay start time will begin to count
down.
Once the delay start time has elapsed,
the estimated programme duration will
appear in the display.

Operating the washing machine
16
Standard display
Cottons 10:30
 1600 rpm
Duration2:59 h
The standard display shows the
following from left to right:
– the programme selected
– the time of day
– the programme duration
– the selected wash temperature
– the selected spin speed
Examples on how to operate
the machine
Scrolling through and selecting
options from a single option list
The  on the right hand side of the
display shows you that a list is
available. The option currently selected
is highlighted in white.
Further programmes
Automatic plus
Freshen up
Dark garments


Touching the  sensor scrolls down the
list to the next option and touching the
 sensor scrolls up the list to the next
option. The OK sensor is used to
activate the option highlighted in white.
The beginning or end of the list is
marked by a dotted line. The bar on the
right hand side moves with you as you
scroll through the list to show which
option you have reached in the list.
Scrolling through and selecting
options from a multiple option list
Further extras
Soak
Water plus
Pre-wash





An option which has been activated will
have a tick  next to it.
Setting numerical values
Finish at
10 : 00
A numerical value is highlighted in
white. Touching the  sensor
decreases the value and touching the 
sensor increases it. The OK sensor is
used to activate the value highlighted in
white.
Exiting a sub-menu
Select Back  to exit a sub-menu.

Before using for the first time
17
Removing the detergent
cartridges from the drum
There are two cartridges containing
UltraPhase1 and UltraPhase2 detergent
for automatic detergent dispensing in
the drum.
Reach under the door grip and pull
the door open.
Take the two cartridges out of the
drum.
Shut the door with a gentle swing.
Inserting detergent cartridges
The detergent cartridges removed from
the drum are components of the Miele
2-phase system consisting of:
1. UltraPhase 1 (base detergent)
2. UltraPhase 2 (detergent enhancer)
These detergent cartridges are for
single use only. Replacement
detergent cartridges are available to
order from Miele or via the internet at
www.miele-shop.com (see end of this
booklet for details). Empty cartridges
should be disposed of via your local
recycling system.
Remove the caps from the detergent
cartridges.

Before using for the first time
18
Press the TwinDos access panel.
The panel will spring open.
Drop the panel down.
Push the UltraPhase1 cartridge into
compartment1 and the
UltraPhase2 cartridge into
compartment2, until they lock into
position.
The TwinDos system is now ready for
use.
Removing the protective foil
and stickers
Remove
– the protective foil from the door.
– any stickers from the front and the
lid.
Please do not remove any labels
(e.g. the data plate), visible when you
open the door.
This washing machine has undergone
a complete functional test at the
factory and there will be some residual
water in the drum from this process.

Before using for the first time
19
Before using the machine for the
first time ensure that it is correctly
installed and connected. See
"Installation and connection". Also
check that the drain filters are
securely tightened to prevent the risk
of water leaks during use.
Switch on the washing machine
Press the  button.
The welcome screen will light up.
Setting the language
You will be asked to select the language
you want for the display. It is possible
to change the language at any time via
the Settings menu.
Sprache
deutsch
english (AUS)
english (GB)


Touch the  or  sensor until the
language you want is highlighted in
white.
Confirm your selection of the
language by touching the OK sensor.
Removing the transit bars
A reminder to remove the transit bars
will appear in the display.
Failure to remove the transit bars
can result in damage to the washing
machine and to adjacent cabinetry or
appliances.
Remove the transit bars as described
in "Installation and connection".
Confirm the removal of the transit
bars with the OKsensor.
Setting the time of day (if
necessary)
The display for setting the time will then
appear. First you have to select the
clock format.
Clock format
24 h clock
12 h clock


Touch the  sensor if you would like
a 12 hour clock display.
Confirm your choice for the clock
format with the OK sensor.
The display will switch automatically to
the time of day selection.
Set the time of day
00 : 00
Touch the  sensor to decrease or
the  sensor to increase the hour.
Confirm the hour selected with the
OK sensor. Then set the minutes in
the same way.
Tip: If you have selected the 12 hour
clock format you can then select am or
pm.

Before using for the first time
20
Starting the calibration
programme
The following message appears in the
display:
Open the stopcock and run the Cottons
90°C programme without laundry.
Confirm the message with the
OKsensor.
For optimum water and energy
consumption and excellent wash
results, it is important to calibrate the
washing machine.
To do this the Cottons 90°C must be
started without laundry and without
detergent.
No other programmes can be started
until calibration has been carried out.
Open the stopcock.
Turn the programme selector to
Cottons.
Cottons 10:30
90°C 1600 rpm
Duration 1:55h
Press the Start/Stop button.
The calibration programme has started.
This will take approx. 2hours.
At the end of the programme the
following message will be displayed:
Set up completed
Reach under the door grip and pull
the door open.
Tip: Leave the door slightly open to
allow the drum to dry.
Switch the washing machine off with
the  button.
