Migali C-02RM User manual



DISPLAY COOLER
Model No.:

Warning
◆This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concern-
ing use of the appliance in a safe way and understand the
hazards involved
◆ Children shall not play with the appliance
◆Cleaning and user maintenance shall not be made by chil-
dren without supervision
◆-The instructions concerning persons (including children
with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge and children playing
with the appliance are not required.
Please read this manual carefull , and
make sure to keep this manual in the
place accessible b the user at an time

◆- Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
◆-- Keep ventilation openings, in the appliance enclosure or
in the built-in structure, clear of obstruction.
◆-- If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.

The&above&picture&onl &for&reference,&refer&to&the&real&product.
 !"#$%
Model name 

Climatic Class N
Anti-shock pro-
tection Class I
Storage Tempe-
rature (℃)0~10
Capacit (L) 58
Rated Voltage AC110-120V/60Hz
Input power 82W
Refrigerant R600a
Vesicant C5H10
The above specifications are subject to improvements.
&"!'#$%
1.This unit uses AC220V-240V/50Hz or AC110V-120V/60Hz, there
should be a 500va stabilizer if the voltage fluctuation exceed 198V-
264V/50Hz or 98V-127V/60Hz respectivel .
2.The user should hold the plug when the power is on/ off, dragging or
pulling the power cord is prohibited.
3.Do not remove the power cord or plug.
4. Must use dependent socket and reliable ground wire. Ground wire
must not connect with the null line of the gas pipe, warm gas pipe,
water pipe and must be single power.
5.Never splash water on the unit directl .

6.Keep awa from explosive, hazardous goods such as ether, gas, alco-
hol, bonding agents, gunpowder etc.
7.Keep awa from spra of inflammables such as paints, coating mate-
rials etc.
8.After the unit is switched off, it should not be restarted within 5 mi-
nutes.
9.Do not leave the power cord under an heav objects including the
unit itself.
10.Do not drill holes or install other objects on the casing.
11.This cooler is not suitable for storage pharmaceutical products.
()#!$%#!
1.Keep the unit vertical when carr ing the unit, the angle to the hori-
zontal line should not be over 50 °，otherwise it will damage the
compressor and affect normal operation of the unit.
2.The unit should be place on a solid and firm ground, take awa the
bottom pack to lower the shock and noise.
3.Leave at least 20 cm of distance between the back of the unit and the
wall for ventilation and leave a space with an open angle of 160 ° for
the door.
4.Keep the unit awa from heat sources and avoiding direct sunlight.
5.Never place the unit on a location where water can reach or with high
moisture. Splashed water and dirt should be wiped off in time b
using a soft cloth.
6.Do not place the unit in the environment cold enough to be iced.
7.Adjust the height with all the four feet adjusted.
*)! #$
1.Remove the carton and packing foam (including the bottom foam)
before using.

2.Clean the unit before using.
3.Adjust the foot to make the unit stead according to the ground
condition to lower the noise.
4. After moving the unit, place the unit for 30 minutes before switching
it on.
5. Running: close the door and connect the power, turn on the light
switch on the casing back. The temperature should be suitable for
normal use after half hour.
6.After connecting the power, the unit should be kept empt for one
hour.
+!$$,%!$#"! !!
1.Adjust the storage temperature through the temperature controller
which is located on the back of the case (see the picture), adjust the
temperature according to the ambient temperature and the foodstuff.
2.See the following picture about the knob scale. The temperature ad-
justable capacit is from “1”-“5”, adjust the storage temperature b
turning the temperature controller clockwise. The “5” shows the lo-
wer of the storage temperature. The knob can turn freel but can’t
turn clockwise from “5” to“1”. Factor setting position is on “3” po-
sition.

3.Check if the knob is on an appropriate position before using, frequent
adjustment is not appropriate when using. Normall in summer, the
ambient temperature is high, anti clockwise turn the knob to -5.,
while in winter, the ambient temperature is low, clockwise turn the
knob to -1..
4. Position “0” means stop running.
/#!#"!%
1.Do not put large amount of articles into the unit at one time, ou
should leave some space around the foodstuff to let cold air inside
the cabinet counter to flow. Keep bottled articles awa from the
walls of interior cabinet so as not to freeze it until broken.
2.Shelves can be adjusted according to different applications
3.Do not put warm food into the unit directl until the are cooled un-
der normal temperature, it will facilitate to lower its energ
consumption and prolong service life of the compressor.
0$!$$!1
%#$$!2! #3!% '4!"#!$!$$!"#2!2$!5

1.Keep the door gasket clean, remove it from the door and wash it. Dr
and seal it as before. Putting some talcum powder on the magnetic
surface would prolong its service life.
2.Light replacement:remove the top cover, take out the light, replace
with a new light, then mount it again.. The power of light is 6W,the
Voltage is AC220V/50Hz or AC110V/60Hz, Model&: T4
3.If there is heav frost on the evaporator after long usage, take out the
stuff inside the case, disconnect the power, the frost will melt auto-
maticall , clean up the water and connect the power again.
4.Use a soft cloth and dip some water or soap (Non-caustic, neutral de-
tergent is also available) to clean the unit. Dr the unit after cleaning
to avoid rust.
5.Do not use organic liquid, boiled water, washing powder or acid stuff
to clean the unit. Rinsing the case b water is not allowed&; don’t use
hard brush, steel brush to clean the case.
6.If the unit will not be used for a long time, disconnect the power,
clean it b following the above steps, wipe off the water inside the
case with a soft cloth.
6#$
1.The unit is not suitable for storage of blood, pharmaceutical products
and biological products.
2.Do not place heav articles on the top of the unit.
3.In case of trouble, please ask professional person for service, do not
dismantle the unit without prior authorit to avoid hazard.
#)2!$#!$

1. Sometime hear light sound of water flowing in the unit, this is the
sound of refrigerant flowing inside the pipe.
2. Compressor, condenser and the part of the unit near door is warm or
too hot.
3. In a humidit place, there is dew on the casing or the door, it can
dr b dr cloth.
#4!%2##$!
problems Possible cause Wa s to solve pro-
blems
The units does not
work
Bad connection of
plug
Unplug the plug and
re-connect the plug
to power suppl .
Abnormal operation
of the compressor or
has buzz sound
The power voltage is
out of the rated
range.
Disconnect the po-
wer suppl immedia-
tel and reconnect
with it after normal
voltage. It is necessa-
r to have a voltage
stabilizer in case of
poor power suppl .
Compressor operates Refrigeration s stem Send the unit to ser-

too long time and no
frost on the surface
of the evaporator
is at fault (leakage or
blocked)
vice department for
repair
There is frost or ice
on the walls of the
inner cabinet and too
low internal tempera-
ture, the compressor
operates never stop.
Thermostat does not
work
Ask service depart-
ment for repair
The internal
temperature is too
high and the
compressor operates
never stop
Bad heat dissipation
and ventilation of ca-
sing, the ambient
temperature is too
high
Improve ventilation
and lower the am-
bient temperature.
Too much warm food
was put in at one
time
Take out some food
Door open frequentl
and long time door
opening
Decrease number and
time of door opening.
Too high noise The unit is not level Adjust the adjustable

feet
The fastener of the
unit is loose
Fasten the loose
fastener
Pipes are touching
the compressor
Careful separate the
touched pipes
Light is not on The light is burned
out Replace the light
Warning: Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
Warning: Do not use mechanical devices, or other means to accelerate
the defrosting process.
Warning: Do not use electrical appliances inside the food storage com-
partments of the appliance.
#$7%$$2!$4'$#$ #"!%%#$
%""% #24!83%!29
)!%!:!! 2! #%3'"#2!"!#%
#3$%4%$!4!"#!'#% #%!2!!"!#
REQUESTING ASSISTANCE OR SERVICE
If the problem is not due to one of the items listed in Troubleshoot-
ing, Contact the dealer or authorized Service Company.
'Correct Disposal of this pro uct：

This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the re-
turn and collection systems or contact the retailer where the prod-
uct was purchased. They can take this product for environmental
safe recycling.
