Mightymast Leisure 7ft Revolver User manual

MULTI GAMES TABLE
7FT REVOLVER
7ft Multi games Table Incorporating
Air Hockey,Pool & Table Tennis
Please keep these instructions for future reference. Adult assembly required.
This table is not a toy & is intended for use by or under the
supervision of adults.
Tool required
Philips Screwdriver-not included
Standard( flat head ) Screwdriver-not included
Allen Key-included
Note:electric screwdrivers may be helpful during assembly however please set
a low torque & use extreme caution.
Assembly Tips
Make sure you understand the following before you begin to assemble your
game table.
1. READ THIS MANUAL all the way through before beginning assembly.
2. Some drawings or images in the manual may not look exactly like your
product.
3. you will need a second adult to assist with this assembly (indeally 4
adults needed for lifting).
4. Save all packing materials until the parts have been inspected & the
table is assembled
Unpack the pieces
1. Lay the box a flat surface (the floor). You may want this near your area
of assembly.
2. Unpack the boxes & parts bags. inspect & count the parts. The parts
identifier page can be uses to record your results.
3. Some parts on the parts identifier page are pre-assembled.
4. Not that some parts are stored inside the table top.

1
#1
Pool table 1set
#2
#3
AB
#4
Leg support 2pcs
#5
#6 #7 #8
#9 #10 #11
#12 #13 #14
Bolt 8pcs
#15
Bolt 4pcs
#16
Washer 12pcs
#17
Barrel nut 12pcs
Air hockey table 1set
Leg 2pcs Leg side panel 2pcs
Leg short panel 1pc Puck catcher 2pcs
Plastic tray A 1pc Plastic tray B 1pc Latches 4pcs
Leg leveler 4pcs Cue holder 2pcs
PARTS IDENTIFIER
1/4"x2-1/2"
1/4"x1-4/5" 1/4"BLACK FLAT
Table tennis surface 1pcs
2
#18 #19 #20
Round head screw 12pcs
#21 #23
Allen key tool 1pc
#24
Hockey striker 2pcs
#25
Hockey Puck 2pcs
#26
Billiard ball 1set
#27
Cue stick 2pcs
#28
Plastic brush 1pc
#29
Triangle rack 1pc
#30
Chalk 2pcs
#31
Table tennis paddle 2pcs
#32
Table tennis ball 3pcs
#33
Table tennis net 1set
#34 #35
Support Brace 1pc
Round head screw 24pcs Flat head screw 8pcs
Round head screw 18pcs
PARTS IDENTIFIER
T4x18mm T4x15mm F4x25mm
T4x40mm
Fan motor 1pc
#22
Round head screw 6pcs
T3.5x25mm

3
Instructions before assembly :
1. After opening the box, remove the ice hockey platform (#2) from the back of the pool table
and take out the parts box and the parts scattered on the back of the table.
Be careful to place the ice hockey table without damaging the fan on the back (#34).
2. Lift the pool table (#1) and take out the parts and other items in the pool.
3. Count all the parts and quantities according to the parts list to prepare the assembly below.
ASSEMBLY INSTRUCTIONS
WARNING: TWO ADULTS NEEDED ASSEMBLE POOL TABLE
Figure 1
#22
#19
please assemble this part
to match this hole
#22
#19
#2
#34
#21
#21
#2
#1
4
ASSEMBLY INSTRUCTIONS
WARNING: TWO ADULTS NEEDED ASSEMBLE POOL TABLE
Figure 2

AB
#20
#20 #12
#12
#3 #3
#4
#4
#11
#18
5
ASSEMBLY INSTRUCTIONS
WARNING: TWO ADULTS NEEDED ASSEMBLE POOL TABLE
Figure 3
Figure 4
6
ASSEMBLY INSTRUCTIONS
WARNING: YOU WILL NEED A SECOND ADULT TO ASSIST WITH
THIS ASSEMBLY (INDEALLY 4 ADULTS NEEDED FOR LIFTING)
Figure 5
#3
#3
#17
#15 #16
#17
#16
#14
#5
#6
#13
#13
#18
#18

7
ASSEMBLY INSTRUCTIONS
WARNING: TWO ADULTS NEEDED ASSEMBLE POOL TABLE
Figure 6
#3
#3
8
ASSEMBLY INSTRUCTIONS
WARNING: TWO ADULTS NEEDED ASSEMBLE POOL TABLE
Figure 7
#19
#19
#8
#9
#19
#19
#10

9
#7
#33
#35
Figure 8
ASSEMBLY INSTRUCTIONS
WARNING: TWO ADULTS NEEDED ASSEMBLE POOL TABLE
