MikroTik GPEN11 User manual

1.
2.
1.
2.
3.
GPEN11
This device allows powering a PoE capable device over the Ethernet, using the same voltage, as provided with the DC input jack.
Powering
The device accepts power from a direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-57 V DC.
Power output
The device supports PoE out from the Ethernet port located under the cover. You can power Mikrotik devices that support passive powering through
Ethernet.
Mounting
Step 1:
Remove the cover screw using a PH2 screwdriver;
Remove the cover to access mounting points.
Step 2:
Drill holes using drill bid;
Insert dowels if needed;
Attach the unit to the wall, using the wall, and secure with screws.

1.
2.
1.
2.
3.
Step 1.Step 2.
Step 3:
Plug-in the Ethernet cable going to the unit that will be powered;
Plug-in power source for the GPEN.
Outgoing Ethernet cable can be guided through position A or B for cable leading into the wall.
Step 4:
Re-attach cover;
Secure cover using the screw;
Use the sticker to cover the screw location.
Step 3.Step 4.
Accessories
When mounting on the wall, please ensure that the cable feed is pointing downwards.
The IPX rating scale of this device is IPX0. We recommend using Cat6 shielded cables.

The package includes the following accessories that come with the device:
K-62 screw kit
Specifications
For more information about this product, specifications, pictures, downloads please visit our web page: https://mikrotik.com/product/gpen11
https://i.mt.lv/cdn/product_files/GPEN_concept_200204.pdf
