MikroTik RouterBOARD 1000 User manual

RouterBOARD 1000
Quick Setup Guide and Warranty Information
Assembling the Hardware
First use of the board:
●In most cases you do not need to use any additional boot devices, as you can boot the RouterBOARD from the
onboard NAND memory. You can also install one or t o CompactFlash modules or Microdrive hard drives, hich you
can use as an alternative boot device (Not for RouterOS. In J4 slot only) or additional storage media (in any or both
slots);
●Install the board in a case
●Connect other peripherals and cables.
Powering
The board accepts po ering from the po er jack only, 12V is supported.
Booting process
First, RouterBOOT loader is started. It displays some useful information
on the onboard RS232C asynchronous serial port. The serial port is set by
default to 115200bit/s, 8 data bits, 1 stop bit, no parity. Note that the
device does fully implement hard are (RTS/CTS) flo control. The loader
may be configured to boot the system from the onboard NAND, and/or
from net ork. See the respective section of User's manual on ho to
configure booting sequence and other BIOS parameters.
DHCP or BOOTP (configurable in loader) protocols allo the RouterBOARD
1000 series board to get an initial IP address, and provide the address of
a TFTP server to do nload an ELF boot image from. It is especially useful
for soft are installation. See the User's manual for more information and
protocol details. Note that you must connect the RouterBOARD you ant
to boot and the BOOTP/DHCP and TFTP servers to the same broadcast
domain (i.e., there must not be any routers bet een them – they must be on the same Ethernet s itch).
Extension Slots and Ports
●Four Gigabit Ethernet ports, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either
straight or cross-over cables for connecting to other net ork devices.
●DB9 RS232C asynchronous serial port.
●SODIMM memory slot, populated ith 512MB DDR2 667MHz SODIMM memory, supports up to 2Gb RAM modules that
match these specifications. Due to a hard are limitation, only 1.5Gb ill be used from a 2Gb module.
See .routerboard.com for more information. Contact [e-mail] for support questions. rev. C (11-Jan-2010)

Operating System Support
Currently tested operating system is MikroTik RouterOS (starting from version 3.0rc1).
Copyright and arranty Information
Copyright and Trademarks. Copyright MikroTikls SIA. This manual contains information protected by copyright la . No
part of it may be reproduced or transmitted in any form ithout prior ritten permission from the copyright holder.
RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered
trademarks appearing in this manual are the property of their respective holders.
Hardware. MikroTikls SIA arrants all RouterBOARD series equipment for the term of one year from the shipping date to be
free of defects in materials and orkmanship under normal use and service, except in case of damage caused by
mechanical, electrical or other accidental or intended damages caused by improper use or due to ind, rain, fire or other
acts of nature.
If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all arranty and
repair issues, the follo ing instructions apply ONLY if you purchased your equipment directly from MikroTik Latvia
To return failed unit or units to MikroTikls you must perform the follo ing RMA (Return Material Authorization) procedure.
Follo the instructions belo to save time, efforts, avoid costs, and improve the speed of the RMA process. Take into account
that all goods have one year arranty.
Instructions are located on our ebpage here: http://rma.mikrotik.com
Manual. This manual is provided “as is” ithout a arranty of any kind, expressed or implied, including, but not limited to,
the implied arranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to
ensure the accuracy of the contents of this manual, ho ever, it is possible that it may contain technical inaccuracies,
typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect,
incidental, consequential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data
or profits. Please report any inaccuracies found to [e-mail]
See .routerboard.com for more information. Contact [e-mail] for support questions. rev. C (11-Jan-2010)
