MikroTik RouterBOARD Series User manual

See www.routerboard.com for more information. Contact [e-mail] for support questions. 27-Jul-2011
RouterBOARD 411UAHL
Quick Setup Guide and Warranty Information
The RB411UAHL has one miniPCI slot and one Ethernet port. It has a
Level4 RouterOS which allows it to be used as a wireless CPE or AP
device.
Assembling the Hardware
First use of the board:
Insert the miniPCI card. There is one miniPCI slot available
Connect antenna cables to the miniPCI card
Install the board in a case
Plug in power cable or a passive PoE powered Ethernet cable to
turn on the device
Powering
The board accepts powering from Ether1 Ethernet port:
Eter1 port accepts 8-30V DC input (at the board; higher voltage needed to compensate for power loss on
long cables; at least 18V suggested) from non-standard (passive) Power over Ethernet injectors (no power
over datalines). The board does not work with IEEE802.3af compliant 48V power injectors.
DC power jack (5.5mm outside and 2mm inside diameter, female, pin positive plug) accepts 8-30V DC
Booting process
RouterOS is the operating system of all RouterBOARD routers. Please see detailed configuration guide here:
http://wiki.mikrotik.com/wiki/Category:Manual#list
This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet
cable, using the MikroTik Winbox utility. Winbox should be used to connect to the default IP address of
192.168.88.1 with the username admin and no password.
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button
of the device when starting it until the LED light turns off, and Groove will start to look for Netinstall servers.
In case IP connection is not available, Winbox can also be used to connect to the MAC address of the device. More
information here: http://wiki.mikrotik.com/wiki/First_time_startup
Extension Slots and Ports
One Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use ei-
ther straight or cross-over cables for connecting to other network devices. The Ethernet port accepts 8-30V
DC powering from a passive PoE injector.
One MiniPCI Type IIIA/IIIB port with 3.3V power signaling.

See www.routerboard.com for more information. Contact [e-mail] for support questions. 27-Jul-2011
Operating System Support
Currently tested operating system is MikroTik RouterOS (starting from v5).
Copyright and Warranty Information
Copyright and Trademarks. Copyright MikroTikls SIA. This manual contains information protected by copyright
law. No part of it may be reproduced or transmitted in any form without prior written permission from the copy-
right holder. RouterBOARD, RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks
and registered trademarks appearing in this manual are the property of their respective holders.
Hardware. MikroTikls SIA warrants all RouterBOARD series equipment for the term of fifteen (15) months from
the shipping date to be free of defects in materials and workmanship under normal use and service, except in
case of damage caused by mechanical, electrical or other accidental or intended damages caused by improper use
or due to wind, rain, fire or other acts of nature.
If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all
warranty and repair issues, the following instructions apply ONLY if you purchased your equipment directly from
MikroTik Latvia
To return failed unit or units to MikroTikls you must perform the following RMA (Return Material Authorization)
procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA
process. Take into account that all goods have one year warranty.
Instructions are located on our webpage here: http://rma.mikrotik.com
Manual. This manual is provided “as is” without a warranty of any kind, expressed or implied, including, but not
limited to, the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has
made every effort to ensure the accuracy of the contents of this manual, however, it is possible that it may con-
tain technical inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this
publication, nor for direct or indirect, incidental, consequential or other damages that may result from such an
inaccuracy, including, but not limited to, loss of data or profits. Please report any inaccuracies found to sup-
[email protected]om
