Millennia Media NSEQ-2 Quick Start Guide
030322
page 1 of 2
Millennia
NSEQ-2 Quick Start Guide
NSEQ-2 Front Panel
1. Band In/Out Switch "IN" —places its associated EQ
band in circuit or out of circuit
2. Frequency Select Switch —selects fixed high and low
band frequencies
3. Peak/Shelf Select —When LED is on, EQ is shelving at
6 dB per octave. When LED is off, EQ is peaking with a
fixed "Q" of 1.0.
4. Boost/Cut Control —+18 dB of boost and -18 dB of
cut. Boost/Cut potentiometer has 21 detented positions
for accurate repeatability and session logging.
5. Parametric Frequency Control –selects EQ center
frequency.
6. Parametric Frequency Range Select Switch "10X"
—When LED is on, frequencies as shown on front panel
legend are multiplied by 10X. When LED is off,
frequencies are as shown on front panel legend.
7. Parametric Q Control –EQ bandwidth.
8. Master Equalizer In/Out Select Switch —"EQ IN"
places EQ in the signal path. Hardwired relay bypass
when out.
9. Twin Topology —Select J-FET (LED illuminated) or
Vacuum Tube circuitry.
10. Gain Range —+/- 18dB or +/- 9dB
11. Power Indicator —when illuminated shows the NSEQ-
4 is powered up and active.
12. Power Switch —turns power on and off.
.
GROUND LIFT
PUSH PUSH
115
IN 2
OUT2
IN 1
OUT1
NSEQ-2 Rear Panel
1. Inputs —In 1 (Left), In 2 (Right) Conventional 3-pin female
XLR input jacks for all balanced or unbalanced line level signals..
2. Outputs —Out 1 (Left), Out 2 (Right) Conventional 3-pin
male XLR output jacks.
3. Earth/Audio Ground Jumper —A barrier terminal which ties
earth ground to audio ground. If ground "hum" loops are
experienced when using the NSEQ-4, removing this jumper may
help. Using this jumper, the integrity of the chassis/earth ground
connection is never compromised. Do not defeat the earth
grounding pin on the AC plug.
4. AC Voltage Mains Selection —The fuse block contains two
fuses; one fuse is in series with the hot power line while the other
fuse is in series with the neutral power line. Both fuses must be
installed.
To change the mains voltage selection, remove IEC power
connector and assure that the NSEQ-4 is not connected to mains
power. With a non-conductive tool, gently pry the fuse block away
from the power entry module. Slide out the internal PC Board,
turn it over, and reinsert the PCB so that the desired AC mains
voltage appears in the viewing window. Double check that the
fuses installed correspond to the AC mains voltage range which
appears in the viewing window. Gently push the fuse block back
until flush and snug.
Fuses: For 100-120 VAC mains, use two 5 x 20 mm, 1A, slow
blow, 250 V, Littelfuse 218 or equiv. For 200-240 VAC mains, use
two 5 x 20 mm, 1A, slow blow, 250 V, Littelfuse 218 or equiv.
5. Power Entry —IEC Power Receptacle for use with removable
cords. Use only the power cord provided. (Export units’ cords are
provided by the distributor.)
7
6
10
12
8
4
5
3
2
1
Media & Music Systems
5
1
2
3
4
9
11

Millennia Media NSEQ-2 Quick Start Guide
030322
page 2 of 2
World Wide Warranty
We will repair our products, free of charge, in the
event of defect of materials or workmanship for
two (2) years following date of purchase.
This limited warranty covers failures due only to
defects in materials and workmanship which
occur during normal, intended use and does not
cover damage which occurs in shipment or
failures which are caused by products not
supplied by Millennia Media.
This limited warranty does not cover failures
which arise from accident, misuse, abuse,
neglect, mishandling, misapplication, faulty
installation, improper adjustment, alteration or
modification of product, incompatibilities, line-
power surges, acts of God, or service performed
by anyone other than Millennia Media or its
authorized agent.
Limits and Exclusions –There are no express
warranties except as listed above. Millennia shall
not be liable for special, subsequent, incidental,
consequential, or punitive damages, including,
but not limited to: damage to recordings,
broadcasts, microphones, mixing consoles, or
any associated equipment, downtime costs, loss
of goodwill, or claims of any party dealing with
purchaser for such damages resulting from the
use of this product. All warranties express and
implied, including the warranties of
merchantability and fitness for a particular
purpose are limited to the applicable warranty
period set forth above.
Vacuum tube and bulb failures are not covered
under warranty. Shipping costs to/from factory
are not covered under this warranty.
International warranty law may vary from
country to country, and Millennia will abide by
the law of each country from which the product
was initially sold.
For North American repairs and service, contact
Millennia ([e-mail]) to obtain a
Return Authorization number. Please include
your shipping address, daytime phone number
and description of the problem. Outside of North
America, please contact your local Millennia
Distributor.
Discarding Units
In the event that any Millennia equipment
manufactured after July 1, 2006 needs to be
discarded, you must return it to Millennia, at our
headquarters in California, USA. Please contact
the distributor in your country or Millennia
directly for instructions. We will make
arrangements to have the equipment shipped to
us at no cost to you, and we will dispose of it in a
manner that complies with whatever regulations
are in existence at that time.
