Millenium HD-120 User manual

HD-120
E-Drum Module
User Manual

Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
Internet: www.thomann.de
17.06.2022, ID: 461227 (V2) Software V1.8

Table of contents
1 General information................................................................................................................................. 6
1.1 Further information........................................................................................................................... 7
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 9
2 Safety instructions.................................................................................................................................. 10
3 Features....................................................................................................................................................... 12
4 Installation.................................................................................................................................................. 13
5 Connections and controls................................................................................................................... 14
6 Operating.................................................................................................................................................... 18
6.1 Functions............................................................................................................................................. 18
6.2 Selecting drum kits.......................................................................................................................... 19
6.3 Playing the drum kit........................................................................................................................ 21
6.4 Metronome function....................................................................................................................... 21
6.5 Adjusting the pedals....................................................................................................................... 23
6.6 MIDI implementation..................................................................................................................... 24
7 Technical specications....................................................................................................................... 28
8 Plug and connection assignment.................................................................................................... 30
9 Cleaning....................................................................................................................................................... 32
Table of contents
HD-120 3
E-Drum Module

10 Protecting the environment.............................................................................................................. 33
Table of contents
4HD-120
E-Drum Module

HD-120 5
E-Drum Module

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
6HD-120
E-Drum Module

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
1.2 Notational conventions
This manual uses the following notational conventions:
General information
HD-120 7
E-Drum Module

The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
References to other locations in this manual are identied by an arrow and the specied page
number. In the electronic version of the manual, you can click the cross-reference to jump to
the specied location.
Example: See Ä ‘Cross-references’ on page 8.
Letterings
Displays
Instructions
Cross-references
General information
8HD-120
E-Drum Module

1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
HD-120 9
E-Drum Module

2 Safety instructions
Drum modules are intended to be used for converting digital trigger signals from drum pads
to various percussion sounds. Use the unit only as described in this manual. Any other use or
use under other operating conditions is considered to be improper and may result in personal
injury or property damage. No liability will be assumed for damages resulting from improper
use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking
hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and
choke! Never let children unattended use electrical devices.
CAUTION!
Possible hearing damage
With loudspeakers or headphones connected, the device can produce volume levels that may cause temporary or permanent
hearing impairment. Do not operate the device permanently at a high volume level. Decrease the volume level immediately if you
experience ringing in your ears or hearing impairment.
Intended use
Safety instructions
10 HD-120
E-Drum Module

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid
direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctuations and do not switch the device on immediately
after it was exposed to temperature uctuations (for example after transport at low outside temperatures). Dust and dirt inside can
damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other malfunction.
NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the external power supply, ensure that the input voltage (AC
outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do
so could result in damage to the device and possibly the user. Unplug the external power supply before electrical storms occur and
when the device is unused for long periods of time to reduce the risk of electric shock or re.
Safety instructions
HD-120 11
E-Drum Module

3 Features
nSpace-saving, complete e-drum set for beginners
n12 preprogrammed drum kits
nMetronome
nConnections for headphones, AUX, USB and MIDI
nincluding drum track, cabling, sticks, stick holders, headphones and seat
Features
12 HD-120
E-Drum Module

4 Installation
Setup and assembly of the pads and pedals are described in detail in the enclosed assembly
guide. Finally check that all cables between the pads and the e-drum module have been prop‐
erly connected.
Connect the included power adapter to the 9V input of the e-drum module. Then plug the
mains plug into the socket.
Connect your stereo headphones to the phones output of the drum module.
Connect the inputs of your amplier or active monitors to the [OUTPUT] sockets of the drum
module.
Connect a CD or MP3 player to the input socket [AUX] IN of the drum module.
Connect external MIDI devices or your computer to the USB port of the drum module.
Setup, connecting pads and
pedals
Connecting the power adapter
Connecting headphones
Connecting audio devices
Connecting a CD or MP3 player
Connecting USB devices
Installation
HD-120 13
E-Drum Module

5 Connections and controls
,
+
*
)
#
'
(&%$
Front panel
Connections and controls
14 HD-120
E-Drum Module

1 Display
2[DC 9V]
Connection socket for the power adapter
3
Selects an option or sets a value.
4
Turns the metronome on and o.
5
Selects an option or sets a value.
6[VOLUME]
Volume control. Controls the volume of the drum kits.
7
Pressing turns the device on. Holding down turns the device o.
8[OUTPUT]
Line output for external audio devices, designed as 3.5 mm jack socket
9
Headphones output, designed as 3.5 mm stereo jack socket.
Connections and controls
HD-120 15
E-Drum Module

10 [AUX]
Input for external audio devices like MP3 or CD players, designed as 3.5 mm stereo jack socket.
11 [USB]
USB MIDI port, designed as USB-B socket
Connections and controls
16 HD-120
E-Drum Module

-.
12 Holder for attaching the drum module to the drum set
13 Connection socket for connecting cable to the drum set, designed as 25-pin D-sub connector socket
Rear panel
Connections and controls
HD-120 17
E-Drum Module

6 Operating
6.1 Functions
Check all cable connections for correct t before turning on
Before switching on, turn the [VOLUME] control to minimum.
Press to turn the drum module on. Press and hold to turn the drum module o.
To adjust the volume, hit a pad and at the same time adjust the volume of the drum module
with the [VOLUME] control.
To display the system information, press and hold for 3 seconds with the device switched
on. The current software version is displayed.
To reset the drum module to factory settings, turn it o rst. Press and hold and simulta‐
neously. The display shows ‘CLr’ . The drum module is reset to factory default settings.
Turning on / o
Adjusting the volume
Software version
Reset to factory defaults
Operating
18 HD-120
E-Drum Module

6.2 Selecting drum kits
A drum kit is a compilation in which a certain sound (Voice) and several sound parameters are
assigned to each pad. Selecting dierent drum kits lets you customise the sound in seconds to
the desired music genre.
Operating
HD-120 19
E-Drum Module

To select a certain drum kit, proceed as follows:
Press or to select the desired drum kit.
ðThe current kit name and kit number are displayed.
The following drum sets are available:
Number Drum kit Number Drum kit
1 Rock Kit 7 Metal Live
2 Jazz Kit 8 Elec Live
3 Funk Kit 9 GM Standard
4 Metal Kit 10 GM Room
5 Elec Kit 11 GM Power
6 Rock Live 12 Percussion
Selecting a drum kit
