Milwaukee M18 ONESX User manual

M18 ONESX
Original instructions

2 3
11
12
6
8
7 16 4
17
5
151410
18
Text section with Technical Data, important Safety
and Working Hints and description of Symbols
STARTSTOP

4 5
Remove the battery pack
before starting any work on
the machine.
1
1
2
2
click
78-100 %
55-77 %
33-54 %
10-32 %
< 10 %

6 7
2
1
3

8 9
1
2
2
1
!
!
!
!

10 11
START
STOP
Insulated gripping surface

12 13
1 !
!
2
3
click
click
click

14 15
1
2
3
1
2
3

16 17
1
1
2
2
3V CR2032
+
1500 2400 3000 3000
1 sec 2 sec 3 sec
SPM
Ramp-up
Time

18 19ENGLISH
Clamp your workpiece with a clamping device. Unclamped
workpieces can cause severe injury and damage.
Do not use cracked or distorted saw blades.
Plunge cuts without pre-drilling a hole are possible with soft
materials (wood, light building materials for walls). Harder
materials (metals) must fi rst be drilled with a hole
corresponding to the size of the saw blade.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household
refuse or by burning them. Milwaukee Distributors off er to
retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
No metal parts must be allowed to enter the battery section
of the charger (short circuit risk).
Use only System 18 V chargers for charging System 18 V
battery packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store
only in dry rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under
extreme load or extreme temperatures. In case of contact
with battery acid wash it off immediately with soap and
water. In case of eye contact rinse thoroughly for at least 10
minutes and immediately seek medical attention.
Warning! To reduce the risk of fi re, personal injury, and
product damage due to a short circuit, never immerse your
tool, battery pack or charger in fl uid or allow a fl uid to fl ow
inside them. Corrosive or conductive fl uids, such as
seawater, certain industrial chemicals, and bleach or bleach
containing products, etc., can cause a short circuit.
WARNING This device contains a lithium button/coin cell
battery. A new or used battery can cause severe internal
burns and lead to death in as little as 2 hours if swallowed or
enters the body. Always secure the battery cover. If it does
not close securely, stop using the device, remove the
batteries, and keep it away from children. If you think
batteries may have been swallowed or entered the body,
seek immediate medical attention.
EC-DECLARATION OF CONFORMITY
We declare as the manufacturer under our sole
responsibility that the product described under “Technical
Data” fulfi lls all the relevant regulations and the directives
2011/65/EU (RoHS), 2014/30/EU, 2006/42/EC, and the
following harmonized standards have been used:
EN 62841-1:2015
EN 62841-2-11:2016 + A1:2020
EN 55014-1:2017 + A11:2020
EN 55014-2:2015
EN 62479:2010
EN 300 328 V2.2.2
EN 301 489-1 V2.2.3
EN 301 489-17 V3.1.1
EN 301 489-17 V3.1.1
EN IEC 63000:2018
Winnenden, 2020-11-01
Alexander Krug
Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
SELECTING MODE
Allow the tool to come to a complete stop before changing
modes. Press the selector button to cycle between the
settings. Select wireless to change the default settings
via the ONE-KEY App on your smart device.
ONE-KEY™
To learn more about the ONE-KEY functionality for this tool,
please reference the Quick Start guide included with this
product or go to www.milwaukeetool.com/one-key. To
download the ONE-KEY app, visit the App Store or Google
Play from your smart device.
When the product experiences ESD, the speed LED shuts
down and the product cannot adjust speed. It needs the
battery and coin cell removed and reinserted to recover (see
page 4 & 17).
Also, when the product experiences ESD, the Bluetooth
communication will be disconnected. It needs to be reset
manually to recover.
We considered the results to be within our minimum
acceptable performance level according to EN 55014-2 / EN
301489-1 / EN 301489-17.
ONE-KEY™ Indicator
Solid Blue Wireless mode is active and ready to be
confi gured via the ONE-KEY™ app.
Blinking Blue Tool is actively communicating with the
ONE-KEY™ app.
Blinking Red Tool is in security lockout and can be
unlocked by the owner via the ONE-
KEY™ app.
SPECIFIED CONDITIONS OF USE
This sabre saw cuts wood, plastic, and metal. It can cut
straight lines, curves, and internal cut-outs. It cuts pipes and
can cut fl ush to a surface.
Do not use this product in any other way as stated for
normal use.
ELECTRIC BRAKE
The electric brake engages when the trigger is released,
causing the blade to stop and allowing you to proceed with
your work. Generally, the saw blade stops within two
seconds. However, there may be a delay between the time
you release the trigger and when the brake engages.
Occasionally the brake may miss completely. If the brake
misses frequently, the saw needs servicing by an authorized
Milwaukee service facility.
You must always wait for the blade to stop completely
before removing the saw from the workpiece.
BATTERIES
Battery packs which have not been used for some time
should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure
to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
For an optimum life-time, after use, the battery packs have
to be fully charged.
To obtain the longest possible battery life remove the battery
pack from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C
and away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
ENGLISH
WARNING Read all safety warnings, instructions,
illustrations and specifi cations provided with this power
tool. Failure to follow all instructions listed below may result
in electric shock, fi re and/or serious injury. Save all
warnings and instructions for future reference.
SABRE SAW SAFETY WARNINGS
Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting accessory
contacting a „live“ wire may make exposed metal parts of
the power tool „live“ and could give the operator an electric
shock.
Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by your hand or against the body leaves it unstable
and may lead to loss of control
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Use protective equipment. Always wear safety glasses when
working with the machine. The use of protective clothing is
recommended, such as dust mask, protective gloves, sturdy
non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to
health. Do not inhale the dust. Wear a suitable dust
protection mask.
Do not machine any materials that present a danger to
health (e.g. asbestos).
Switch the device off immediately if the insertion tool stalls!
Do not switch the device on again while the insertion tool is
stalled, as doing so could trigger a sudden recoil with a high
reactive force. Determine why the insertion tool stalled and
rectify this, paying heed to the safety instructions.
The possible causes may be:
• it is tilted in the workpiece to be machined
• it has pierced through the material to be machined
• the power tool is overloaded
Do not reach into the machine while it is running.
The insertion tool may become hot during use.
WARNING! Danger of burns
• when changing tools
• when setting the device down
Chips and splinters must not be removed while the machine
is running.
When working in walls ceiling, or fl oor, take care to avoid
electric cables and gas or waterpipes.
*1 with saw blade bimetal, dimension 230 x 1,6 mm and tooth pitch 5 mm The AxTM
*2 with saw blade bimetal, dimension 150 x 1,25 mm and tooth pitch 5 mm
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for diff erent
applications, with diff erent accessories or poorly maintained, the vibration emission may diff er. This may signifi cantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
TECHNICAL DATA CORDLESS RECIPROCATING SAW
Production code.......................................................................
Cutting depth max. in:
Soft- wood ............................................................................
Steel .....................................................................................
Aluminium .............................................................................
Non-ferrous metal .................................................................
Metal pipe .............................................................................
Stroke rate ..............................................................................
Lengths of stroke .....................................................................
Battery voltage.........................................................................
Bluetooth version .....................................................................
Frequency band.......................................................................
Radio-frequency power ...........................................................
Weight according EPTA-Procedure 01/2014 (2.0 Ah - 12.0 Ah) ...
Recommended ambient operating temperature ......................
Recommended battery types...................................................
Recommended charger ...........................................................
Noise/vibration information
Measured values determined according to EN 62841.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty K=3dB(A))......................
Sound power level (Uncertainty K=3dB(A)) ..........................
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 62841.
Vibration emission value ah
Cutting particleboard *1 ........................................................
Uncertainty K= ......................................................................
Cutting wooden beams *2 ....................................................
Uncertainty K= ......................................................................
M18 ONESX
..................... ...4580 45 05
...000001-999999
.....................300 mm
.......................20 mm
.......................25 mm
.......................25 mm
.....................150 mm
................0-3000 min-1
....................28,6 mm
.......................18 V
......................4.0
.......2402 – 2480 MHz
......................1,8 dBm
.............3,8 – 4,8 kg
.................-18...+50 °C
................M18B2... M18HB12
.............. M12-18 ... ; M1418C6
........................85,5 dB (A)
........................96,5 dB (A)
........................15,9 m/s2
........................1,95 m/s2
........................18,3 m/s2
..........................1,5 m/s2

20 21
BATTERY PACK PROTECTION
In extremely high torque, binding, stalling and short circuit
situations that cause high current draw, the tool will stop for
about 2 seconds and then the tool will turn OFF.
To reset, release the trigger.
Under extreme circumstances, the internal temperatur of the
battery could become to high. If this happens, the battery
will shut down.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in
accordance with local, national and international provisions
and regulations.
• The user can transport the batteries by road without
further requirements.
• Commercial transport of Lithium-Ion batteries by third
parties is subject to Dangerous Goods regulations.
Transport preparation and transport are exclusively to be
carried out by appropriately trained persons and the
process has to be accompanied by corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and
insulated to prevent short circuit.
• Ensure that battery pack is secured against movement
within packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice
MAINTENANCE
The ventilation slots of the machine must be kept clear at all
times.
Use only Milwaukee accessories and spare parts. Should
components need to be replaced which have not been
described, please contact one of our Milwaukee service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the machine type printed as well as the six-digit
No. on the label and order the drawing at your local service
agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, 71364 Winnenden, Germany.
SYMBOLS
CAUTION! WARNING! DANGER!
Remove the battery pack before starting any
work on the machine.
Please read the instructions carefully before
starting the machine.
Do not swallow the coin cell battery!
Always wear goggles when using the
machine.
Accessory - Not included in standard
equipment, available as an accessory.
Do not dispose electric tools, batteries/
rechargeable batteries together with
household waste material.
Electric tools and batteries that have reached
the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.
Check with your local authority or retailer for
recycling advice and collection point.
n0Stroke rate under no-load
VVolts
Direct current
European Conformity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
ENGLISH

22 23

(10.20)
4100 4148 30
Copyright 2020
Techtronic Industries GmbH
Max-Eyth-Str. 10
71364 Winnenden
Germany
[phone]
www.milwaukeetool.eu
Techtronic Industries (UK) Ltd
Fieldhouse Lane
Marlow Bucks SL7 1HZ
UK
