OPERATOR'S MANUAL
Cat. No.
2592-20
TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND OPERATOR'S
MANUAL.
M12™ JOBSITE SPEAKER

23
IMPORTANT SAFETY INSTRUCTIONS
WARNING READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS.
Failure to heed all warnings listed below, may result in electric shock,fire and/or serious
personal injury. KEEP THESE INSTRUCTIONS.
SPECIFIC SAFETY RULES
•Read these instructions.
•Keeps these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water. Never im-
merse the apparatus in liquid or allow a liquid to flow
inside the apparatus. Water entering an apparatus
will increase the risk for electric shock.
•Clean only with dry cloth. Certain cleaning agents
andsolvents are harmfulto plastics andother insulat-
edparts. Some ofthese include: gasoline,turpentine,
lacquerthinner,paint thinner,chlorinatedcleaningsol-
vents,ammoniaand household detergents containing
ammonia.Cleandust and debrisfromvents. Keep the
apparatus handle clean, dry and free of oil or grease.
•Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
•Donot use near any heat sources suchasradiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
•Use only attachments/accessories specified by
the manufacturer.
•Onlyoperatethisapparatusinawellventilatedarea.
•Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture or does not oper-
ate normally. Service or maintenance performed by
unqualified personnel could result in a risk of injury.
•A battery operated apparatus with integral batter-
ies or a separate battery pack must be recharged
only with the specified charger for the battery. A
charger that may be suitable for one type of battery
maycreateariskoffirewhenusedwithanotherbattery.
•Use battery operated apparatus only with specifi-
cally designated battery packs. Use of any other
batteries may create a risk of fire.
•When battery pack is not in use, keep it away
from other metal objects like: paper clips, coins,
keys, nails, screws, or other small metal objects
that can make a connection from one terminal to
another. Shortingthe batteryterminals together may
cause sparks, burns, or a fire.
•Avoid body contact with grounded surfaces such
as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your
body is grounded.
•Never disassemble the apparatus or try to do any
rewiring on the apparatus's electrical system.
•Donotexposethisapparatustodrippingandsplash-
ing, or place objects filled with liquids on this unit.
•Maintain labels and nameplates. These carry im-
portantinformation. If unreadable or missing,contact
aMILWAUKEEservice facility fora free replacement.
•
This apparatus is designed to be powered by a
12 volt MILWAUKEE Li-ion battery pack. Do not
attemptto use with anyother voltage orpowersupply.
Federal Communications Commission
FUNCTIONAL DESCRIPTION
Volts
Direct Current
To reduce the risk of injury, user
must read operator’s manual.
Federal Communications
Commission
Cat.
No. Input Volts USB Output Volts USB Output Amps
2592-20 12 DC 5 DC 2.1
13
10
78
2
SYMBOLOGY
SPECIFICATIONS
9
4
6
5
ASSEMBLY
WARNING Recharge only with the
charger specified for the battery. For specific
charging instructions, read the operator’s
manualsuppliedwithyourchargerandbattery.
Inserting/Removing the Battery
To remove the battery, push in the release buttons
and pull the battery pack away from the speaker.
To insert the battery, slide the pack into the body of
thespeaker.Makesureit latches securelyinto place.
Fuel Gauge
The Fuel Gauge will show the remaining battery
charge for 2-3 seconds after turning on the speaker.
Tosignaltheendofcharge,1lightonthefuelgaugewill
blink slowly until the speaker shuts off automatically.
Battery Pack Protection
To protect the life ofthe battery pack, the speakerwill
shut off when the battery’s charge becomes too low.
If this happens, remove the battery pack and charge
it according to the charger’s instructions.
Connecting an Auxiliary Device
Connect an MP3 player, CD player, or other audio
device directly to the speaker using the stereo aux-
iliary jack AUX IN.
USB Power Outlet
Thisoutlet can beused to chargea cell phone,power
anMP3 player or anyother device thatusesless than
2.1A of DC electrical current.
NOTE: Any device that uses more than 2.1 A of DC
electricalcurrent will tripa self-resetting overloadand
disable the output.
OPERATION
WARNING To reduce the risk of fire or
electric shock, do not expose this speaker to
rain or moisture.
Turning On/Off and Connecting to Bluetooth
Press the Power/Bluetooth button to turn the
speaker on and off.
MAINTENANCE
WARNING To reduce the risk of injury,
always unplug the charger and remove the
battery pack from the charger or tool before
performing any maintenance. Never disas-
semble the tool, battery pack or charger.
Contact a MILWAUKEE service facility for
ALL repairs.
Maintaining Tool
Keep your tool, battery pack and charger in good
repairby adopting aregular maintenance program.
If the tool does not start or operate at full power
withafully charged batterypack,clean the contacts
on the battery pack. If the tool still does not work
properly, return the tool, charger and battery pack,
to a MILWAUKEE service facility for repairs.
WARNING: Changes or modifications to
this unit not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuanttoPart 15 of theFCCRules.Theselimits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordancewith the instructions, may causeharmful
interferencetoradio communications. However,there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
whichcanbe determined byturningthe equipment off
andon, the useris encouraged totry to correctthe in-
terferenceby one or more ofthe following measures:
•Reorient or relocate the receiving antenna.
•Increase the separationbetween the equipmentand
receiver.
•Connect the equipment into an outlet on a circuit
differentfromthatto which the receiveris connected.
•Consult the dealer or an experienced radio/TV
technician for help.
1. Volume down
2. Power/Pair
3. Stereo AUX jack
4. USB power outlet
5. Fuel gauge
6. Volume up
7. Indicator light
8. Hang hook
9. Battery bay
10. Bass port
WARNING To reduce the risk of per-
sonal injury and damage, never immerse your
tool, battery pack or charger in liquid or allow
a liquid to flow inside them.
Cleaning
Clean dust and debris from charger and tool
vents. Keep tool handles clean, dry and free of oil
or grease. Use only mild soap and a damp cloth
to clean the tool, battery pack and charger since
certain cleaning agents and solvents are harmful
to plastics and other insulated parts. Some of these
include gasoline, turpentine, lacquer thinner, paint
thinner,chlorinated cleaning solvents,ammoniaand
household detergents containing ammonia. Never
useflammableorcombustiblesolvents around tools.
Repairs
For repairs, return the tool, battery pack and char-
ger to the nearest service center listed on the back
cover of this operator's manual.
•If no Bluetooth device was previously paired,
Bluetooth pairing will begin automatically and the
indicator light will flash continuously.
• The speaker will continue to search for a signal for
10 minutes.
• To manually pair a device, turn on the speaker and
select "M12 Speaker" on the Bluetooth capable
device.
• Once paired, the speaker will automatically re-
connect to the same device when the speaker is
turned on.
•
To pair the speaker to a different device, press
and hold the power/pair button for 3 seconds un-
til the indicator light flashes. It will then be in pair
mode and can be connected to a different device.
• Once the device has successfully paired with the
speaker, use the device controls to move through
tracks and control volume.
Volume
Use the to increase or decrease the volume.
NOTE: To control the volume using the device's
controls, first turn the speaker volume to max (a
beep will sound).
