mimsafe Multicage Double User manual

www.mimsafe.se
MULTICAGE
double
ASSEMBLY INSTRUCTIONS

6254M
6260M
6275M
Product no No of items
2X
EDivider anchor
6254S
6260S
6275S
Product no No of items
2X
FDivider anchor
6254A
6260A
6275A
Product no No of items
1X
AFloor
6254N
6260N
6275N
Product no No of items
4X
HFrame bar
6260P
Product no No of items
4X
IHandle
6260R
Product no No of items
4X
JAnchor
6254T
6260T
6275T
Product no No of items
2X
KLocking plate
6254E
6260E
6275E
Product no No of items
1X
BRoof
6254J
6260J
6275J
Product no No of items
1X
CDivider panel
6254C
6260C
6275C
Product no No of items
2X
DSidebars GDoor section
6254I
6260I
6275I
Product no No of items
2X
30X 6X 4X 4X
4X4X
4X
2X 2X4X 2X
6X 8X
8X
IKP1915-17S
M-SM6x14IA M-SM6x45-IK M-460641D M-MM6NyS
M-BR8x19x1,5SM-460641I
M-SM6x55-IK
M-B1687-6SLD M-SFF206M622SM-VBM8x20S88 M-VBM6x12FZB
M-VBM6x45FZB M-MM6MHM-6FZB
M-BR6,4x12x1S
plastic end caps
rubber
AG
C
F
E
B
I
J
D
H
1X
4X1X
ALLEN KEY 4
M-10520Combination spanner
6254C - 8X
6260C - 12X
6275C - 20X

1a
STEP
1b
STEP
2
STEP
Follow this step only if you choose
not to install the divider
4
X
CLICK!
A
Floor
C
F
E
D
F
F
K
E
F
Divider panel
Divider anchors
Sidebars
Divider
anchors
Divider anchors
Locking plate
Divider anchors
Divider anchorsDivider anchors
2X 6X
M-SM6x14IA M-SM6x45-IK
2X
6X 8X
8X
M-VBM6x12FZB
M-VBM6x45FZB M-MM6MHM-6FZB
M-BR6,4x12x1S

3
STEP
4
STEP
4
X
CLICK!
2X 2X
M-B1687-6SLD M-SFF206M622S
4X
M-SM6x14IA
B
Roof

6
STEP
90
5
STEP
G
Door section
16X
M-SM6x14IA
S
T
E
P
-
1
S
T
E
P
-
2
IMPORTANT
Gently insert all the screws
before tightening

7
STEP
8
STEP
HHandle
H
Frame bars
4X
4X
4X4X
M-460641D
M-MM6NySM-SM6x55-IK
rubber
8X
M-SM6x14IA

9
STEP
10
STEP
4X
4X
J
Anchor
4X
4X
4X
M-BR8x19x1,5S
M-460641I
M-VBM8x20S88
12X
IKP1915-17S
plastic end caps

www.mimsafe.se
MultiCage double Edition 2019-01
4
X
11
STEP
Where to place the MultiCage
IMPORTANT
All the FOUR ratchet straps
must be looped twice
12”
300mm
