SERVICE MANUAL
Electro-Pneumatic Regulator
MAER200 series
To ensure safe operation, please read this service manual carefully before use. When designing and
manufacturing equipment using Mindman products, the manufacturer is obligated to ensure that the
safety of the mechanism, pneumatic control circuit and/or air control circuit and the system that runs
the electrical controls are secured.
Explanation of label
Observe the warnings and cautions on the following pages to prevent accidents. These instructions
indicate the level of potential hazard by labels of "WARNING" or “CAUTION”. Note that some items
indicated with “CAUTION” may lead to serious results depending on the conditions. All items
contain important information and must be observed.
2021/12
Order example
Model
MAER200 –8A –9K –111 –B1 –S1 –G
1
1
Port size
8A: 1/4
10A: 3/8
2
Pressure
range
1K: 0.1 MPa
5K: 0.5 MPa
9K: 0.9 MPa
3
Bracket
Blank: Without
B1: L type
B2: Flat type
5
Cable connector
Blank: Without
S1: Straight 1m
S3: Straight 3m
L1: Right angle 1m
L3: Right angle 3m
6
Port thread
Blank: Rc thread
G: G thread
NPT: NPT thread
7
2 3 4 5 6 7
1: Current DC4~20mA
2: Voltage DC0~10V
3: Voltage DC0~5V
1: Analog output DC1~5V
2: Switch output NPN
3: Switch output PNP
4: Analog output DC4~20mA ( Source type )
40: Preset input
1: MPa
2: kgf/cm2
3: bar
4: psi
5: kPa
–
Signal input Signal output Pressure
display unit
4

2
注意事項Precaution
To ensure safe operation, please read this service manual carefully before use. When designing and
manufacturing equipment using Mindman products, the manufacturer is obligated to ensure that the
safety of the mechanism, pneumatic control circuit and/or air control circuit and the system that runs
the electrical controls are secured.
Explanation of label
Observe the warnings and cautions on the following pages to prevent accidents. These instructions
indicate the level of potential hazard by labels of "WARNING" or “CAUTION”. Note that some items
indicated with “CAUTION” may lead to serious results depending on the conditions. All items
contain important information and must be observed.
WARNING
CAUTION
A dangerous situation may occur if handling is mistaken, leading to fatal or serious injuries.
A dangerous situation may occur if handling is mistaken, leading to minor injuries or
property damage.
Let the designer of pneumatic system or rule tester to determine if this direction control
valve is suitable or not.
The product must be operated by the person who has professional knowledge and practical
experience.
Please confirm product specifications before use. Do not use input signal exceeding
specifications. This product could malfunction fire if input signal exceeding the working
range is applied.
If an abnormality occurs during operation, immediately turn off the power and air pressure
and stop using it.
This product is adjusted for each specification at the time of shipment from the factory.
Disassemble and reformation are prohibited, as this way might lead to malfunction.
Avoid using this regulator where it will be subject to direct sunlight, water or oil, etc.
Use in place where the temperature changes drastically or at high humidity may cause
damage due to dew condensation in the product.
If supply pressure to this product is interrupted while the power is still on, the inner
solenoid valve will continue to operate and a humming noise may be generated. Since the
life of the product may be shortened, shut off the power supply also when supply pressure
is shut off.
If electric power is shut off while pressure is being applied, the output pressure will be
retained. However, this output pressure is held only temporarily and is guaranteed.
1
3
4
5
2
1
3
4
2

3
Precaution
To ensure safe operation, please read this service manual carefully before use. When designing and
manufacturing equipment using Mindman products, the manufacturer is obligated to ensure that the
safety of the mechanism, pneumatic control circuit and/or air control circuit and the system that runs
the electrical controls are secured.
Explanation of label
Observe the warnings and cautions on the following pages to prevent accidents. These instructions
indicate the level of potential hazard by labels of "WARNING" or “CAUTION”. Note that some items
indicated with “CAUTION” may lead to serious results depending on the conditions. All items
contain important information and must be observed.
The product characteristics are confined to no flow in the pipeline. When air is consumed on
the output side, pressure may become unstable.
In order to avoid the error caused by noise, please take the following measures:
Set the line filter on AC power line to remove the power noise.
Keep the product away from the engine and power line to avoid noise affects.
Induced charge (like solenoid valve, relay), must prevent them from negative charge.
In order to avoid the effects of power fluctuation, please cut off the power before plug
the connector.
The cable plug is four-core wire. When the monitor output is not being used, prevent it from
touching the other wires as this can cause a malfunction.
Please note that the right angled cable connector does not rotate and is limited to only one
entry direction.
Use clean compressed air that does not contain corrosive gas. Poor air quality adversely
affects function and life.
Do not use a lubricator on the supply side of this product, the lubricated air might cause
malfunction. When lubrication of terminal equipment is necessary, connect a lubricator on the
output side of the equipment and set a check valve. When the secondary pressure is lowered
with an input signal, etc., the secondary air passes through the product and is discharged
from the EXH port. Contamination on the secondary piping and the inside of the load will
have an adverse effect on performance, etc. Keep the inside of the piping as clean as possible.
When supplying compressed air for the first time after connecting pipes, confirm that no air is
leaking from any pipe connections.
Tighten pipes with the appropriate torque to prevent air leakage and screw damage. First
tighten the screw by hand to prevent damage to screw threads, then use a tool.
For the pneumatic source, use cleaned air from which the solid, water and oil contents were
eliminated sufficiently, using an air dryer, filter and oil mist filter. Recommend selecting a
filtration precision of 5µm or less.
6
7
8
9
10
11
12
13
a
b
c
d
5
Air filter
(5µm)
Regulator
(Pressure
switch)
Oil/mist filterAir dryer

4
Application of proportional pressure controls
Controlling pressure for painting Controlling pressure for grinding force
The product characteristics are confined to no flow in the pipeline. When air is consumed on
the output side, pressure may become unstable.
In order to avoid the error caused by noise, please take the following measures:
Set the line filter on AC power line to remove the power noise.
Keep the product away from the engine and power line to avoid noise affects.
Induced charge (like solenoid valve, relay), must prevent them from negative charge.
In order to avoid the effects of power fluctuation, please cut off the power before plug
the connector.
The cable plug is four-core wire. When the monitor output is not being used, prevent it from
touching the other wires as this can cause a malfunction.
Please note that the right angled cable connector does not rotate and is limited to only one
entry direction.
Use clean compressed air that does not contain corrosive gas. Poor air quality adversely
affects function and life.
Do not use a lubricator on the supply side of this product, the lubricated air might cause
malfunction. When lubrication of terminal equipment is necessary, connect a lubricator on the
output side of the equipment and set a check valve. When the secondary pressure is lowered
with an input signal, etc., the secondary air passes through the product and is discharged
from the EXH port. Contamination on the secondary piping and the inside of the load will
have an adverse effect on performance, etc. Keep the inside of the piping as clean as possible.
When supplying compressed air for the first time after connecting pipes, confirm that no air is
leaking from any pipe connections.
Tighten pipes with the appropriate torque to prevent air leakage and screw damage. First
tighten the screw by hand to prevent damage to screw threads, then use a tool.
For the pneumatic source, use cleaned air from which the solid, water and oil contents were
eliminated sufficiently, using an air dryer, filter and oil mist filter. Recommend selecting a
filtration precision of 5µm or less.
Please confirm the product specification and read wiring method carefully before wiring.
The color of connector pins and cable conductors must be checked when wiring. Check
wire color with handling precaution, since improper wire connection leads to destruction/-
failure and malfunction.
Do not use power voltage exceeding specifications. The product could malfunction or
catch fire if voltage exceeding the working range is applied.
Short-circuiting the load could result in rupture or fire.
The connection between the cable plug and the wire is weak. Excessive bending may
shorten the life of the plug set, causing breakage or damage.
Connect the cable to the connector on the body with arranged as shown next page.
WARNING
1
2
3
4
5
Wiring method
PLC
SUP.
MAF302
MAER200
PLC
SUP.
MAF302
MAER200
Solenoid
valve
Air cylinder
Coarse
grinding wheel
Robot arm
Workpiece
Fine
grinding wheel

5
Wiring method
The cables are available in both straight type and right angle type. A right angle type
connector is attached facing left (towards the SUP port). The direction of the straight type
arrow is aligned with socket latch.
Wiring diagram (Power supply and input signal)
1: Brown
3: Blue
2: White
4: Black
1: Brown
3: Blue
2: White
4: Black
Brown
White
Blue
Black
3: Blue 1: Brown
2: White4: Black
Current / Voltage type —Power supply 24VDC
Preset input type — Power supply 24VDC
Input signal Model
4~20mADC MAER200-*-*-1*
0~10VDC MAER200-*-*-2*
0~5VDC MAER200-*-*-3*
Preset pressure P_1 P_2 P_3 P_4
S1 OFF ON OFF ON
S2 OFF OFF ON ON
S1
S2
Input signal
Power supply
Power supply
CAUTION
Input signal —Preset input type
1
2
Input signal 1
GND(COMMON)
Power supply
3
Input signal 2 4
Input signal —Current / Voltage type
1
2White
Input signal
Blue GND(COMMON)
Brown Power supply
3
Black
White
Blue
Brown
Black
Monitor output 4

6
Wiring method
When the monitor output is not being used, prevent it from touching the other wires as this can
cause a malfunction.
When a current of approx. 125mADC or more is applied, the over current is archived, "Er6"
is displayed and the operation stops. Please turn off power supply and check the cause of
overload current or lower the current load under 125mA, and then restart the power supply.
Wiring diagram (Monitor output)
WARNING
(MAER200-*-*-*2) (MAER200-*-*-*3)
1: Brown
3: Blue
2: White
4: Black
1: Brown
3: Blue
2: White
4: Black
Switch output．NPN type Switch output．PNP type
Load Load
(MAER200-*-*-*1)
Please select a device with a load
impedance greater than 1KΩ
(MAER200-*-*-*4)
Please select a device with a load
impedance less than 750Ω
1: Brown
3: Blue
2: White
4: Black
1: Brown
3: Blue
2: White
4: Black
Analog output．Voltage type Analog output．Current type (source type)
Monitor output voltage Monitor output current
DC4~20mA (source type)DC1~5V

7
Setting method
It is recommended that the settings are changed without supply pressure.
Please refer to each content about operation method.
The professional setting mode must be operated by people with professional knowledge and
practical experience.
Improper operation of the setting mode may cause malfunction or performance loss.
CAUTION
1
2
3
4
Flow of the setting
Power on
Run mode
Unlock keys Lock keys
Detail settingFunction setting
Save setting
Save setting
Min. pressure
Max. pressure
Switch output
Preset pressure
Gain
Sensitivity
Zero clear
Reset setting
Unit setting
Display
pressure
Display
unit
Click ClickPress Click
Refer to P.9
Refer to
P.10-12
Professional setting
Save setting
Basic I/P ET
Basic D/P ET
Additional I/P ET
Additional D/P ET
Refer to
P.13-16
Refer to P.9
over 2 sec
Press +
over 2 sec
ET: Energizing time; I/P: Increase Pressure; D/P: Decrease Pressure
Display Symbols description of professional setting
vp / dn
Svp / sdN
Basic energizing time of increase / decrease pressure valve.
The additional energizing time of increase / decrease pressure valve due to the
switching action. It only acts for a short time when triggered.

8
Error indicating function
Be sure to confirm the product specification and the following items before use.
Please confirm that the supply pressure is correct.
Please confirm that the power supply and input signal is correct.
Despite the error indication function, this product may malfunction if the power or signal
exceeds the specification range.
CAUTION
1
2
3
Display Contents of error Countermeasure
Er1Input signal
exceeds the rated
value range
Er2
Er3
Output pressure
did not reach the
set value for ten
seconds or more
consecutively
Er4
Er5
Er6
Out of range
error of zero clear
Over current errors
in switch output
Check controller power specifications, set power
voltage and input signal within the rated range, and
turn power ON again.
Caution: This product has this error indication function,
but the input is too large or not specified, it may cause
direct burnout or malfunction. Please confirm the
specifications before use.
Please contact us when MAER do not operate normally
after restarting the power supply.
1. Check the supply pressure within the rated range.
2. Check that there is no leakage from the pipes, fittings,
or other components, correctly connect the pipes and
turn on the power again.
3. Try increasing the gain value to improve the situation.
If you restart the power supply after the above method, you
still cannot improve the situation. Contact your nearest
Mindman sales office or distributor.
Wait three seconds or press any key to return setting.
Please operate "zero clear" after the secondary pressure
of MAER is became to atmosphere. Please operate "zero
clear" within the range of 5%F.S..
Please turn off power supply and check the cause of
overload current or lower the current load under 125mA,
and then restart the power supply.
Reading or writing
errors occurred in
EEPROM
Error occurred setting
the range of the min.
and max. pressure

9
注意事項Key locking function
This product has key locking function. Please operate unlocking the keys before adjusting the
setting data. Please operate locking the keys to return RUN mode after finish setting.
Function introduce
Unlocking the keys
In RUN mode, press for more than 2
seconds.
Locking the key
In RUN mode and unlocking, press for
more than 2 seconds, and then press to
return RUN mode.
Operation flow Operation flow
4.00
Loc
vnL
Display pressure
Display Loc
Unlock and return to
RUN mode
Press key to
unlock
Press key to
lock
4.00
vnL
Loc
Display pressure
Display unL
Lock and return to
RUN mode
Press key for 2
seconds or more
Press key for 2
seconds or more

10
Setting linearity of output pressure to input signal
Set the minimum and maximum value of output pressure corresponding to the input signal.
Note: This function is current input and voltage input type only.
The adjustment like making the relation of F_1 > F_2 is not available. If you try doing, an error
ER4 will be indicated. You must be return to set F_1 and F_2.
F_1 is adjustable in range from 0% to 50% of the rated value. (DEFAULT VALUE: 0%)
F_2 is adjustable in range from 10% to 100% of the rated value. (DEFAULT VALUE: 100%)
Function introduce
Operation flow
Control pressure %
Input signal %
0 100
120
50
0
000
0 100
Control pressure %
Input signal %
100
0
-10
50
Unlocking key
Press
Press
Press
F=1
F=2
Press /
key to adjust
Press /
key to adjust
900
Save setting and
return to RUN mode
....

11
Mode of switch output
Operation flow
Switching the Window comparator mode or the Hysteresis mode according to the needs of the
users.
Note: Only NPN/PNP switch output type has this function. (MAER200-*-*-*2，MAER200-*-*-*3)
The adjustment like making the relation of P_1 > P_2 is not available. If you try doing, an error
Er4 will be indicated. You must be return to set P_1 and P_2.
Function introduce
Window comparator mode Hysteresis mode
P_2
P_1
Switch output
Output pressure
of E/P regulator
P_2
P_1
Switch output
Output pressure
of E/P regulator
ON
OFF
ON
OFF
Press
Press
Press
Press
Press /
key to adjust
Press /
key to adjust
Save setting and
return to RUN mode
: Window comparator
: Hysteresis
y;n
KYS
Unlocking key
P=1 0.50
Kys
P=2
SAU
4.00
....

12
Setting of preset pressure
Four preset operating pressures (P_1~P_4) can be set according to customer requirements.
Note: P_1 to P_4 are adjustable within the setting pressure range.
One of the preset pressures P_1 through P_4 is selected by the ON/OFF combination of S1 and
S2.
Function introduce
Preset pressure and switch
Preset pressure P_1 P_2 P_3 P_4
S1 OFF ON OFF ON
S2 OFF OFF ON ON
Operation flow
Press
Press
Press
Press /
key to adjust
Press /
key to adjust
4.00
0.50
Save setting and
return to RUN mode
Unlocking key
P=4
P=1
SAU
....
....

13
Detail setting mode
Operation flow
After Unlocking, enter the Detail setting mode to adjust the parameters.
Detail setting mode: Gain, Sensitivity, Reset, Zero clear and Unit setting. Please refer to the
following instructions to operate.
Function introduce
Changing the response of the inner solenoid
valve by changing the gain, and then reaching
to control regulated pressure speed of the
MAER.
Caution: When the gain is changed to more
large, the response become quickly, but there is
a possibility that stability is lost.
Save setting and
return to RUN mode
Press key to switch the setting item.
Press key for 2 seconds or more
Unlocking key
Gn
5b
-0-
rSt
uNt
sau
Gain, please refer to page 14.
Sensitivity, please refer to page 14.
Zero clear, please refer to page 15.
Reset function, please refer to page 15.
Unit setting, please refer to page 16.

14
Gain setting Sensitivity setting
Changing the response of the inner solenoid
valve by changing the gain, and then reaching
to control regulated pressure speed of the
MAER.
Caution: When the gain is changed to more
large, the response become quickly, but there is
a possibility that stability is lost.
Function introduce
Relation between setting
of gain and response time
Setting of sensitivity
Response Slow Quick
Setting of Gain 1 2 3 ...... 7 8 9 ...... 14 15 16
Function introduce
Sensitivity High Low
Setting of
Sensitivity 1 2 ...... 5 6 7 ...... 14 15 16
Change the sensitivity (Sb) of the MAER for
pressure fluctuation.
Caution:
Normal operation does not require the
adjustment of sensitivity.
When the sensitivity is changed to sharp, the
hunting of pressure might be occurred, and
the secondary pressure might be unstable.
And, when the sensitivity is changed to dull,
the accuracy of the set pressure might be lost.
1
2
Press /
key to adjust
Press /
key to adjust
Press key for 2 seconds or more
Operation flow
16
Unlocking key
Gn
55b
Save setting and
return to RUN mode
SAU
....

15
Zero clear function
Function introduce
Reset function
Function introduce
Operating the Zero clear function can set
displayed pressure to zero again. Pressure
varies in different areas due to altitude
differences, so pressure zeroing must be set.
Caution:
Operate the Zero clear function after changing the outlet pressure to atmosphere pressure.
The adjustable range of the Zero clear function is 5% F.S.. When more than this range, ER5
is displayed. Please change the outlet pressure and return the setting.
Operate the Reset function can reset the
pressure linearity and switch output.
Note: Gain (Gn), Sensitivity(Sb), and Unit(Unt)
will not be reset. .
1
2
Change the sensitivity (Sb) of the MAER for
pressure fluctuation.
Caution:
Normal operation does not require the
adjustment of sensitivity.
When the sensitivity is changed to sharp, the
hunting of pressure might be occurred, and
the secondary pressure might be unstable.
And, when the sensitivity is changed to dull,
the accuracy of the set pressure might be lost.
Press /
key to adjust
Press /
key to adjust
Press key for 2 seconds or more
Operation flow
Unlocking key
-0- YES
RsT YES
SAU
Save setting and
return to RUN mode
....

16
Unit setting function
Function introduce
Select pressure unit according to customer requirements.
Note: Limited to the minimum display unit, there may be numerical deviations in unit exchange.
Please use linearity pressure setting to modify. Linearity pressure setting refer to page 10.
Caution:
The pressure unit is set according to the order specification before leaving the factory.
If you operate the function to change unit, the product will be inconsistent with the label content.
Press key for 2 seconds or more
Pressure unit
Unit kgf/cm2bar Psi kPaMPa
Min. display unit 0.01 0.01 0.1 0.001 1
Operation flow
Unlocking key
UnT
SAU
Save setting and
return to RUN mode
.... bAr
kgf/cm2
bar
psi
MPa
kPa
Press / key to select pressure unit
