Minebea Sartorius Intec Maxxis 4 PR 5500 User manual

Instrument Manual
Process Controller Maxxis 4
PR 5500
Instrument Manual 9499 050 55000 Edition 2 24.07.2015
for PR 5500 Release 2.20
Sartorius Mechatronics T&H GmbH, Meiendorfer Str. 205, 22145 Hamburg, Germany
Tel: [phone] Fax: [phone]

Please note
Any information in this document is subject to change without notice and does not represent a commitment
on the part of SARTORIUS INTEC unless legally prescribed. This product should be operated only by trained and
qualified personnel. In correspondence concerning this product the type, name and release number as well as
all license numbers in relation to the product have to be quoted.
Important
This product is partly copyrighted. It may not be modified or copied and may not be used without purchasing
or written authority from the copyright owner (SARTORIUS INTEC). By using this product, you agree to be
bound by the terms stated herein.

PR 5500 Instrument Manual Table of Contents
Sartorius EN-I
Table of Contents
1 Introduction.........................................................................................................................................................................1
2 Safety Information.............................................................................................................................................................2
2.1 Electrical Protective Class............................................................................................................................................................................2
2.2 Intended Use....................................................................................................................................................................................................2
2.3 Initial Inspection ............................................................................................................................................................................................2
2.4 Before Commissioning..................................................................................................................................................................................3
2.4.1 Installation............................................................................................................................................................................................3
2.4.2 Opening the Instrument...................................................................................................................................................................4
2.4.3 Mains Connection and Protective Grounding Conductor for PR 5500.............................................................................4
2.5 RF Interference Suppression.......................................................................................................................................................................6
2.6 Failure and Excessive Stress........................................................................................................................................................................6
2.7 Important Note...............................................................................................................................................................................................6
2.8 Repairs and Maintenance............................................................................................................................................................................6
2.8.1 Static Sensitive Components...........................................................................................................................................................6
2.8.2 Replacing Fuses ...................................................................................................................................................................................6
3 Process Controller...............................................................................................................................................................7
3.1 General Information .....................................................................................................................................................................................7
3.2 Overview of the Instrument .......................................................................................................................................................................7
3.3 Housing .............................................................................................................................................................................................................9
3.3.1 Housing dimensions...........................................................................................................................................................................9
3.3.2 Housing Dimensions with Strain Relief and Reinforcing frame....................................................................................... 10
3.3.3 Control Panel Cut-Out................................................................................................................................................................... 11
3.4 Display and Control Panel........................................................................................................................................................................ 12
3.4.1 Overview............................................................................................................................................................................................. 12
3.4.2 Display................................................................................................................................................................................................. 13
3.4.3 Operating Elements......................................................................................................................................................................... 15
3.4.4 Operation using the VNC Program............................................................................................................................................. 19
3.5 Overview of Connections ......................................................................................................................................................................... 20
3.5.1 Plug-in Cards..................................................................................................................................................................................... 21
3.5.2 Application Licenses........................................................................................................................................................................ 23
3.6 Instrument Versions ................................................................................................................................................................................... 24
3.6.1 Combinatorics for the Options.................................................................................................................................................... 24

Table of Contents PR 5500 Instrument Manual
EN-II Sartorius
4 Device Installation............................................................................................................................................................27
4.1 General Information .................................................................................................................................................................................. 27
4.2 Mechanical Preparation............................................................................................................................................................................ 28
4.3 Hardware Construction............................................................................................................................................................................. 30
4.3.1 Main Board ........................................................................................................................................................................................ 30
4.3.2 Network Port..................................................................................................................................................................................... 31
4.3.3 USB Connection ............................................................................................................................................................................... 32
4.3.4 SD Card Slot....................................................................................................................................................................................... 36
4.3.5 RS-232 Interface (built-in)........................................................................................................................................................... 37
4.4 Accessories .................................................................................................................................................................................................... 42
4.4.1 PR 5500/04 2x RS-485 Interface................................................................................................................................................ 42
4.4.2 PR 5500/32 2x RS-232 Interface................................................................................................................................................ 52
4.4.3 PR 5500/07 Analog Inputs and Outputs................................................................................................................................... 57
4.4.4 PR 5500/10 Weighing Electronics Board.................................................................................................................................. 59
4.4.5 PR 5500/12 Digital Inputs and Outputs ................................................................................................................................... 69
4.4.6 PR 5500/13 Digital Inputs and Outputs ................................................................................................................................... 76
4.4.7 PR 5500/17 Digital Inputs and Outputs ................................................................................................................................... 83
4.4.8 PR 1721/61 ProfiBus-DP................................................................................................................................................................ 91
4.4.9 PR 1721/64 DeviceNet ................................................................................................................................................................... 94
4.4.10 PR 1721/65 CC-Link........................................................................................................................................................................ 98
4.4.11 PR 1721/66 ProfiNet I/O..............................................................................................................................................................101
4.4.12 PR 1721/57 EtherNet-IP..............................................................................................................................................................104
5 Commissioning ............................................................................................................................................................... 107
5.1 Power Failure/Data Protection/Warm Start/Cold Start ................................................................................................................107
5.1.1 General Information .....................................................................................................................................................................107
5.1.2 Power Failure...................................................................................................................................................................................107
5.1.3 Warm Start ......................................................................................................................................................................................107
5.1.4 Cold Start .........................................................................................................................................................................................108
5.1.5 Overwrite Protection ....................................................................................................................................................................109
5.2 Switching on the Device.........................................................................................................................................................................111
5.3 Switching off the Device........................................................................................................................................................................113
5.4 Warm-up Time...........................................................................................................................................................................................113
5.5 Configuring and Calibrating via the Front Keys/PC Keyboard...................................................................................................113
5.6 Configuring and Calibrating via a Notebook/PC ............................................................................................................................114
5.6.1 Connecting the Device to the Network and Determining the IP Address...................................................................114
5.6.2 Activating the ‘DHCP’ Network.................................................................................................................................................116
5.6.3 Searching for Devices in the Network using ‘IndicatorBrowser’....................................................................................118
5.6.4 Operation using the VNC Client Program..............................................................................................................................119
5.6.5 Operation via a Web Browser ....................................................................................................................................................120
5.6.6 Resetting Network.........................................................................................................................................................................123
5.7 Help Function.............................................................................................................................................................................................124
5.8 Selecting the Operating Language......................................................................................................................................................124

PR 5500 Instrument Manual Table of Contents
Sartorius EN-III
5.9 User Management.....................................................................................................................................................................................125
5.9.1 General Information .....................................................................................................................................................................125
5.9.2 Activating User Management....................................................................................................................................................125
5.9.3 Deactivating User Management................................................................................................................................................133
5.9.4 User Login/Logout..........................................................................................................................................................................134
5.10 System Menu..............................................................................................................................................................................................135
5.10.1 System Setup: Connected Devices............................................................................................................................................135
5.10.2 System setup: Date & Time.........................................................................................................................................................136
5.10.3 System setup: Operating parameters ......................................................................................................................................137
5.10.4 System setup: Network parameters.........................................................................................................................................138
5.10.5 System setup: Network share connections............................................................................................................................139
5.10.6 System setup: Fieldbus parameters..........................................................................................................................................140
5.10.7 System setup: Weighing point – Weighing point A ...........................................................................................................140
5.10.8 System setup: Weighing point: Weighing point A: Internal weighing point.............................................................141
5.10.9 System setup: Weighing point: Weighing point A: xBPI scale........................................................................................143
5.10.10 System setup: Weighing point: Weighing point A: SBI scale..........................................................................................144
5.10.11 System setup: Weighing point: Weighing point A: Pendeo Truck.................................................................................145
5.10.12 System setup: Weighing point: Weighing point A: Pendeo Process .............................................................................148
5.10.13 System setup: Weighing point: Weighing point A: PR-Net Weighing Point..............................................................151
5.10.14 System setup: Weighing point: Weighing point A: Mettler-Scale.................................................................................151
5.10.15 System setup: Weighing point: Weighing point A: SMA scale .......................................................................................152
5.10.16 System setup: Display settings ..................................................................................................................................................152
5.10.17 System setup: License settings ..................................................................................................................................................152
5.10.18 System setup: User management .............................................................................................................................................153
5.11 Calibrating the Internal Weighing Point...........................................................................................................................................154
5.11.1 General Information .....................................................................................................................................................................154
5.11.2 Showing the Calibration Data ...................................................................................................................................................155
5.11.3 Increased Resolution (10-fold)..................................................................................................................................................156
5.11.4 Selecting the Calibration Mode ................................................................................................................................................157
5.11.5 Determining the Maximum Capacity [Max]..........................................................................................................................159
5.11.6 Determining the Scale Interval [Scale interval]...................................................................................................................162
5.11.7 Determining the Dead Load [Dead load at]...........................................................................................................................163
5.11.8 Calibrating with Weight [Max at] ............................................................................................................................................165
5.11.9 Calibrating with mV/V [Max at] ................................................................................................................................................167
5.11.10 Calibrating the Scale with Load Cell Data (Smart Calibration) [by data]....................................................................168
5.11.11 Subsequent Dead Load Correction...........................................................................................................................................169
5.11.12 Linearity............................................................................................................................................................................................170
5.11.13 Saving the Calibration..................................................................................................................................................................172
5.11.14 Canceling Calibration...................................................................................................................................................................172
5.11.15 Display Units....................................................................................................................................................................................173
5.11.16 Parameter Input .............................................................................................................................................................................175

Table of Contents PR 5500 Instrument Manual
EN-IV Sartorius
5.12 Configuring a xBPI Scale........................................................................................................................................................................182
5.12.1 General Information .....................................................................................................................................................................182
5.12.2 xBPI Parameter Input for Serial Interface .............................................................................................................................182
5.12.3 xBPI Parameter Input for Scale Function...............................................................................................................................183
5.12.4 Setting up an xBPI Platform ......................................................................................................................................................185
5.12.5 Setting the xBPI Dead Load........................................................................................................................................................189
5.12.6 xBPI Calibration with the User Weight...................................................................................................................................190
5.12.7 xBPI Calibration with Automatic Weight Detection ..........................................................................................................192
5.12.8 xBPI Calibration with Default Weight.....................................................................................................................................193
5.12.9 xBPI Calibration with Internal Weight....................................................................................................................................194
5.12.10 xBPI Linearization..........................................................................................................................................................................196
5.12.11 xBPI Display Units..........................................................................................................................................................................198
5.13 Setting the SBI Scale ...............................................................................................................................................................................199
5.13.1 General Information .....................................................................................................................................................................199
5.13.2 Parameter for Serial Interface...................................................................................................................................................199
5.13.3 Parametereingabe..........................................................................................................................................................................200
5.14 Calibrating Digital Weighbridge Load Cell ‚Pendeo® Truck‘........................................................................................................201
5.14.1 General Information .....................................................................................................................................................................201
5.14.2 Parameter Input for Serial Interface .......................................................................................................................................201
5.14.3 Calibration Sequence....................................................................................................................................................................202
5.14.4 Search for load cells and set dead load..................................................................................................................................202
5.14.5 Search for Load Cells ....................................................................................................................................................................203
5.14.6 View and Assign Load Cells.........................................................................................................................................................204
5.14.7 Calibrating Load Cells...................................................................................................................................................................207
5.14.8 Assign Load Cell Name.................................................................................................................................................................210
5.14.9 Service Function.............................................................................................................................................................................210
5.14.10 Corner Correction..........................................................................................................................................................................212
5.14.11 Parameter input .............................................................................................................................................................................214
5.14.12 Subsequent Dead Load Correction...........................................................................................................................................217
5.15 Calibrating Digital Precision Compression Load Cell ‘Pendeo® Process’ .................................................................................218
5.15.1 General Information .....................................................................................................................................................................218
5.15.2 Parameter Input for Serial Interface .......................................................................................................................................218
5.15.3 Calibration Sequence....................................................................................................................................................................219
5.15.4 Search for load cells and set dead load..................................................................................................................................219
5.15.5 Search for Load Cells ....................................................................................................................................................................220
5.15.6 View and Assign Load Cells.........................................................................................................................................................221
5.15.7 Calibrating Load Cells...................................................................................................................................................................224
5.15.8 Assign Load Cell Name.................................................................................................................................................................227
5.15.9 Service Function.............................................................................................................................................................................227
5.15.10 Corner Correction..........................................................................................................................................................................229
5.15.11 Parameter input .............................................................................................................................................................................230
5.15.12 Subsequent Dead Load Correction...........................................................................................................................................233

PR 5500 Instrument Manual Table of Contents
Sartorius EN-V
5.16 PR-Net Weiging Point.............................................................................................................................................................................234
5.16.1 General Information .....................................................................................................................................................................234
5.16.2 Parameter Input .............................................................................................................................................................................234
5.17 Mettler-Scale..............................................................................................................................................................................................236
5.17.1 General Information .....................................................................................................................................................................236
5.17.2 Parameter Input in Mettler-Scale Menu................................................................................................................................236
5.17.3 Parameter Input for Serial Interface .......................................................................................................................................236
5.17.4 Parameters Input for Scale Function.......................................................................................................................................238
5.18 Setting the SMA Scale.............................................................................................................................................................................240
5.18.1 General Information .....................................................................................................................................................................240
5.18.2 Parameter for Serial Interface...................................................................................................................................................240
5.18.3 Parametereingabe..........................................................................................................................................................................241
5.19 General Parameter Settings...................................................................................................................................................................242
5.19.1 Equipment Settings.......................................................................................................................................................................242
5.19.2 Setting the Date and Time..........................................................................................................................................................253
5.19.3 Setting the Operating Parameters ...........................................................................................................................................255
5.19.4 Network Parameters .....................................................................................................................................................................260
5.19.5 Network Share Connections.......................................................................................................................................................262
5.19.6 Fieldbus Parameters......................................................................................................................................................................266
5.19.7 Display Settings..............................................................................................................................................................................271
5.19.8 License Settings..............................................................................................................................................................................272
5.20 System Information..................................................................................................................................................................................274
5.20.1 Showing the Version.....................................................................................................................................................................274
5.20.2 Showing the Status.......................................................................................................................................................................275
5.20.3 Showing Alarm information.......................................................................................................................................................276
5.20.4 Showing Hardware Options........................................................................................................................................................277
5.20.5 ModBus-TCP IO Modules.............................................................................................................................................................278
5.20.6 Browsing the Alibi Memory........................................................................................................................................................279
5.20.7 Showing Calibration Check Numbers......................................................................................................................................279
5.20.8 Showing Pendeo data...................................................................................................................................................................279
5.20.9 Displaying Event Log.....................................................................................................................................................................282
5.20.10 Printing Out Configuration Settings .......................................................................................................................................283

Table of Contents PR 5500 Instrument Manual
EN-VI Sartorius
6 Extended Functions....................................................................................................................................................... 284
6.1 System Maintenance................................................................................................................................................................................284
6.1.1 General Information .....................................................................................................................................................................284
6.1.2 Saving to selected Media (Backup)..........................................................................................................................................284
6.1.3 Restoring Backup Data from External Media .......................................................................................................................289
6.1.4 Exporting to selected Media ......................................................................................................................................................295
6.1.5 Importing Data from External Media......................................................................................................................................298
6.1.6 Alibi Memory Maintenance........................................................................................................................................................303
6.1.7 SD Card Maintenance...................................................................................................................................................................314
6.1.8 Creating a Service Report ...........................................................................................................................................................316
6.1.9 Switching Off the Device ............................................................................................................................................................317
6.1.10 Updating the Software ................................................................................................................................................................318
6.1.11 Resetting the Device to the Factory Settings.......................................................................................................................329
6.1.12 Hardware Test .................................................................................................................................................................................330
6.1.13 Functions via the WEB Site.........................................................................................................................................................338
6.2 Alibi Memory..............................................................................................................................................................................................346
6.2.1 General Information .....................................................................................................................................................................346
6.2.2 Erasing the Alibi Memory............................................................................................................................................................346
6.2.3 Browsing the Alibi Memory........................................................................................................................................................348
6.2.4 Exporting and Printing Alibi Data Records............................................................................................................................351
6.3 BIOS Menu ..................................................................................................................................................................................................352
6.3.1 General Information .....................................................................................................................................................................352
6.3.2 Accessing the BIOS Menu............................................................................................................................................................352
6.3.3 Troubleshooting Menu.................................................................................................................................................................354

PR 5500 Instrument Manual Table of Contents
Sartorius EN-VII
7 ModBus Protocol ........................................................................................................................................................... 356
7.1 General Description..................................................................................................................................................................................356
7.2 ModBus-RTU...............................................................................................................................................................................................357
7.3 ModBus-TCP/UDP......................................................................................................................................................................................358
7.4 Functions .....................................................................................................................................................................................................359
7.5 Error Messages...........................................................................................................................................................................................364
7.6 Word Addresses .........................................................................................................................................................................................365
8 EW Com Protocol........................................................................................................................................................... 366
8.1 Weight Function Commands.................................................................................................................................................................366
8.2 Other Commands ......................................................................................................................................................................................367
8.3 SPM Commands.........................................................................................................................................................................................368
8.4 Error Messages for EW Com Commands............................................................................................................................................369
9 Repairs and Maintenance............................................................................................................................................. 370
9.1 Battery for Date/Time..............................................................................................................................................................................370
9.2 Rechargeable Battery for Voltage Supply.........................................................................................................................................370
9.3 Solder Work ................................................................................................................................................................................................370
9.4 Cleaning.......................................................................................................................................................................................................371
10 Disposal ........................................................................................................................................................................... 372
11 Error Messages............................................................................................................................................................... 373
11.1 Error Messages in Measuring Circuit..................................................................................................................................................373
11.2 Error Messages with xBPI Scales..........................................................................................................................................................375
11.2.1 Error Messages................................................................................................................................................................................375
11.2.2 Error during "Set zero" and "Set tare" ....................................................................................................................................376
11.3 Error Messages with Pendeo® Load Cells ..........................................................................................................................................377
11.4 Error messages with PR-Net Weighing Point ..................................................................................................................................378
11.5 Error messages with Type ‚Mettler-Scale‘ Weighing Point..........................................................................................................378
11.6 Error Messages during Calibration......................................................................................................................................................379
11.6.1 Determining the Maximum Capacity (MAX).........................................................................................................................379
11.6.2 Determining the Scale Interval .................................................................................................................................................380
11.6.3 Determining the Dead Load........................................................................................................................................................381
11.6.4 Calibrating with Weight..............................................................................................................................................................382

Table of Contents PR 5500 Instrument Manual
EN-VIII Sartorius
12 Specifications................................................................................................................................................................. 383
12.1 Note on Using ‘Free Software’..............................................................................................................................................................383
12.2 Decoding the Serial Number.................................................................................................................................................................383
12.3 General Data...............................................................................................................................................................................................383
12.3.1 Battery for Date/Time...................................................................................................................................................................383
12.3.2 Rechargeable Battery for Voltage Supply..............................................................................................................................383
12.3.3 Display...............................................................................................................................................................................................383
12.3.4 Power Connection 230 V AC......................................................................................................................................................383
12.3.5 Power Connection 24 V DC.........................................................................................................................................................384
12.4 Effect of Ambient Conditions...............................................................................................................................................................384
12.4.1 Ambient Conditions ......................................................................................................................................................................384
12.4.2 Electromagnetic Compatibility (EMC).....................................................................................................................................384
12.4.3 RF Interference Suppression.......................................................................................................................................................385
12.5 Mechanics....................................................................................................................................................................................................385
12.5.1 Design................................................................................................................................................................................................385
12.5.2 Dimensions.......................................................................................................................................................................................385
12.5.3 Weights .............................................................................................................................................................................................385
12.6 Documentation on the Enclosed CD...................................................................................................................................................385
13 Appendix......................................................................................................................................................................... 386
13.1 Configuration Printout ...........................................................................................................................................................................386
13.2 Test Printout...............................................................................................................................................................................................388
13.3 Alibi Printout..............................................................................................................................................................................................389
13.4 LEDs ...............................................................................................................................................................................................................390
13.5 Terminal Coding ........................................................................................................................................................................................391
13.6 Exchanging the Plug-In Cards..............................................................................................................................................................392
13.6.1 Safety Information........................................................................................................................................................................392
13.6.2 Optional and Fieldbus Cards.......................................................................................................................................................392
13.7 Replacing the Device ...............................................................................................................................................................................393
13.8 Replacing the SD Card.............................................................................................................................................................................395

PR 5500 Instrument Manual Introduction
Sartorius EN-1
1 Introduction
ttPlease read all the instructions carefully and completely before using the instrument.
ttRead the safety precautions carefully.
ttThese instructions are part of the product. Keep them in a safe and easily accessible location.
Symbols and Signs
The following symbols are used in this manual:
Warning of dangerous electrical voltage.
DANGER indicates death or severe, irreversible personal injury which will occur if the
corresponding safety measures are not observed.
!Danger
Warning of a hazard area.
WARNING indicates that death or severe, irreversible injury may occur if the corresponding
safety measures are not observed.
!Warning
Warning of personal injury and/or property damage.
CAUTION indicates that minor, reversible injury or damage to property may occur if the
corresponding safety measures are not observed.
!Caution
Note User tips, useful information, and notes.
ttIndicates a required action
tyDescribes the result of an action
- Indicates an item in a list
[ ] Encloses menu items and soft keys
Hotline
Phone: [phone]
Fax: [phone]
E-mail: [email protected]

Safety Information PR 5500 Instrument Manual
EN-2 Sartorius
2 Safety Information
2.1 Electrical Protective Class
Warning!
This instrument has been built and tested in compliance with the safety regulations
for measuring and control instrumentation for protective class I (protective grounding
conductor) according to IEC 1010/EN 61010 or VDE 0411. The instrument was in
perfect condition with regard to safety features when it left the factory. To maintain
this condition and to ensure safe operation, the operator must follow the instructions
and observe the warnings in this manual.
!Warnung
2.2 Intended Use
This instrument is only intended for use in weighing and metering systems, and is especially well-suited for tank
and container scales, weigh bridges, platform weighers, crane weighers, dispensing systems and as a weighing
indicator in intelligent control systems. Product operation, commissioning and maintenance must be performed
by trained and qualified personnel who are aware of and able to deal with the related hazards and take suitable
measures for self-protection.
The instrument reflects the state of the art. No warranty is given that the product is free of faults, especially not
in conjunction with third-party software and hardware components required for operation.
The manufacturer does not accept any liability for damage caused by other system components or due to
incorrect use of the product. The use of this product signifies recognition of the stipulations listed above.
2.3 Initial Inspection
Check the contents of the consignment for completeness. Check the contents visually to determine whether any
damage has occurred during transport. If there are grounds for rejection of the goods, a claim must be filed with
the carrier immediately. The Sartorius Intec sales or service organization must also be notified.

PR 5500 Instrument Manual Safety Information
Sartorius EN-3
2.4 Before Commissioning
Visual inspection!
Before commissioning as well as after storage or transport, inspect the device visually for
signs of mechanical damage.
2.4.1 Installation
Design Protection class Installation
Control cabinet housing IP 65, back IP 20 Control Panel Cut-Out
To ensure proper cooling of the instrument, make sure air circulation around the instrument is not blocked.
Avoid exposing the instrument to excessive heat; e.g., from direct sunlight. Ambient conditions must be taken
into account at all times.
With outdoor mounting, make sure that adequate weather protection is provided (for temperatures,
see Chapter 12.4.1).

Safety Information PR 5500 Instrument Manual
EN-4 Sartorius
2.4.2 Opening the Instrument
High Voltage!
Working on the instrument while it is switched on may have life-threatening
consequences.
Disconnect the instrument from the supply voltage.
When removing covers or parts using tools, live parts or terminals may be exposed.
Please note that capacitors in the instrument may still be charged even after
disconnecting the device from all voltage sources.
!Danger
This instrument contains electrostatically sensitive components. For this reason, an equipotential bonding
conductor must be connected when working on the open instrument (antistatic protection).
2.4.3 Mains Connection and Protective Grounding Conductor for PR 5500
2.4.3.1 Version 230 V AC
Mains connection
Safe interruption of both supply voltage conductors must be provided for, either by
disconnecting the power connector or using a separate switch.
The instrument is protected via two fuses (see Chapter 12.3.4) on the back of the
device (primary side).
The instrument is equipped with a wide range power supply and covers AC systems
with a frequency of 50 Hz/60 Hz and a voltage range of 100 V AC to 240 V AC
+10%/-15 % automatically (without manual selection).
The power supply is protected against short circuits and overloads, and disconnects
automatically in case of a fault.
If the electrical protection has triggered:
- Disconnect the device from all power sources and wait at least 1 minute.
- Determine and eliminate the cause of the error.
- Reconnect the device to the supply voltage.
Protective grounding conductor
The instrument must be connected to a protective ground via a protective grounding
conductor (PE) in the power connector.
The power cable contains a protective grounding conductor which must not be
interrupted inside or outside the device. The protective grounding conductor is
connected to the back of the housing inside the instrument.

PR 5500 Instrument Manual Safety Information
Sartorius EN-5
2.4.3.2 Version 24 V DC
Mains connection
This version is designed for 24 V direct current.
The supply is established via three spring clamp terminals (+ PE -). The
instrument is protected against incorrect polarity.
Protective grounding conductor
The protective grounding must be connected to the central
terminal (PE).
Fuse
The instrument is protected in the + line via a fuse (see Chapter 12.3.5)
inside the device (primary side).

PR 5500 Instrument Manual Safety Information
Sartorius EN-5
2.5 RF Interference Suppression
The device is intended for use in the industrial sector and can cause RF interference if used in residential areas
(see Chapter 12.4.3). In this case, the operator may be required to put suitable countermeasures in place.
2.6 Failure and Excessive Stress
If there is any reason to assume that safe operation of the instrument is no longer ensured, shut it down and
make sure it cannot be used. Safe operation is no longer ensured if any of the following is true:
- The instrument is physically damaged.
- The instrument does not function.
- The instrument has been subjected to stresses beyond the tolerance limits (e.g., during storage or transport).
2.7 Important Note
Make sure that the construction of the instrument is not altered to the detriment of safety. In particular,
leakage paths, air gaps (of live parts) and insulating layers must not be reduced. Sartorius Intec cannot be held
responsible for personal injury or property damage caused by an instrument repaired incorrectly by an operator
or installer.
2.8 Repairs and Maintenance
Repairs are subject to inspection and must be carried out at Sartorius Intec. In case of defect or malfunction,
please contact your local Sartorius Intec dealer or service center for repair. When returning the instrument for
repair, please include a precise and complete description of the problem.
Maintenance work must be carried out only by a trained technician aware of the involved hazards, whereby the
relevant precautions must be taken in account.
2.8.1 Static Sensitive Components
This instrument contains electro-statically sensitive components. Therefore, potential equalization must be
provided when working on the device (antistatic protection).
2.8.2 Replacing Fuses
Warning!
The use of repaired fuses and bypassing the fuse holder is prohibited.
Only the fuses specified in Chapter 12.3 are allowed.
!Warning

PR 5500 Instrument Manual Process Controller
Sartorius EN-7
3 Process Controller
3.1 General Information
This instrument is equipped with a TFT color display, and a function/alphanumeric keypad. With the
corresponding application, this device is a powerful system for managing/documenting weighing and dosing
processes. It combines the functions of a user-friendly interface as well as a weighing and dosing instrument,
PLC and interfaces.
The instrument is programmable according to the IEC 61131-3 standard (requires the PR 1750/60 development
tool accessory).
3.2 Overview of the Instrument
- Accuracy 10.000 d at 0,5 µV/d for the weighing electronics
- High-speed conversion with response times from 5 msec
- Weight display with status and weight unit on a TFT color display
- Housing for installation in a control cabinet. Protection type front IP 65, else IP 20
- Integrated LAN connection (10/100 Mbps) for data transmission
- USB 2.0 connection (Type A, i = 200 mA), integrated for printer, USB stick, PC keyboard, barcode scanner,
external splitter (hub)
- SD card slot (incl. SD card)
- Integrated RS-232 interface, e.g. for connecting a PC, printer or remote display
- Can be expanded using the following plug-in cards:
- 2x RS-485 interface card PR 5500/04
- Analog E/A interface card PR 5500/07
- Weighing electronics board PR 5500/10 (W1)
- Digital E/A interface card PR 5500/12
- Digital E/A interface card PR 5500/13
- Digital E/A interface card PR 5500/17
- 2x RS-232 interface card PR 5500/32
- Fieldbus cards PR 1721/6x
- Wide range power supply for 100 to 240 V AC, protection class I (protective grounding conductor)
- Version for 24 V direct current
- Plug-in connections on the rear side of the device for load cells, inputs/outputs, LAN connection, serial
interfaces
- Alternative operation using PC tool (Browser/VNC)
- Calibration using weights, by entering mV/V values, or directly, using load cell data (Smart Calibration)
- Software configuration of the interface cards, e.g. for remote display or printer
- Analog test for the weighing electronics
- Overwrite protection:
- via a max. of 3 CAL switches (two on the main board and one on the weighing electronics board)
- via software

Process Controller PR 5500 Instrument Manual
EN-8 Sartorius
Communication Protocols
For the internal RS-232: Fieldbus slave (accessories):
- Remote display protocol - PR 1721/61 ProfiBus DP
- Printer - PR 1721/64 DeviceNet
- ModBus protocol - PR 1721/65 CC Link
- xBPI protocol - PR 1721/66 ProfiNet I/O
- SBI protocol - PR 1721/67 EtherNet IP
- EW-Com protocol
For the internal LAN interface:
- ModBus-TCP
- Ethernet-TCP/IP
- OPC

PR 5500 Instrument Manual Process Controller
Sartorius EN-9
3.3 Housing
3.3.1 Housing dimensions
The keypad and the display form one unit with the front. A rectangular cut-out is required for the installation.
Cable connections are made at the back of the housing.
157
90
96
192
Front view Side view
Reset key
Back view
Note All dimensions in mm.

Process Controller PR 5500 Instrument Manual
EN-10 Sartorius
3.3.2 Housing Dimensions with Strain Relief and Reinforcing frame
The dimensions with the following options must be observed for installation:
Pos. Designation
1 Reinforcing frame
2 Screen clamping rail
3 Cable clamps
146 186
90
203
96
25
192
199
8
1 2 3
Side view Front view
1
2
3
Back view
Note All dimensions in mm.
