Mini SA 6NE User manual
Tested MP3 Players and USB Devices.
01
BMW Group, April 2012, 1/6
Overview
The ‘Bluetooth mobile phone kit
with USB audio interface’ (SA 6NE)
or ‘Bluetooth hands-free kit with
USB audio interface’ (SA 6ND) for
MINI enables you to connect a
compatible MP3 player, such as an
Apple iPod, to your car via a USB
interface and control it using the
vehicle’s input elements.
In addition to MP3 players, you can also
connect USB sticks to the USB audio
on them.
When you connect your USB-equipped
mobile phone to the USB audio
interface, please note that some
mobile phone models will turn off the
Bluetooth function, i.e. it cannot be
guaranteed that you will be able to
receive or place calls.
You can access your stored audio
search by genre, artist, album
or song title.
and displayed properly in your car if
player (e.g. ID3 tags) includes Latin
characters only.
You can only play back video and
by using the designated adapter
cable: not compatible with Radio MINI
Boost (SA 6FC).
Due to the high number of MP3
players and USB sticks available
on the market and their technical
differences, it cannot be guaranteed
with the USB audio interface.
The BMW Group therefore
communicates the devices that it
has tested as being compatible on
a regular basis.
The compatibility statements in this
product information refer to new
vehicles (date of manufacture later
than August 2011).
General conditions
The USB audio interface supports
the following device classes.
Please refer to the following notes
and tables for details:
Apple iPod and Apple iPhone
MP3 players and USB sticks
(USB mass storage devices
conforming to the ‘USB Mass
MP3 players with Media Transfer
Protocol (MTP)
Mobile phones with USB mass
storage memory (conforming
to the ‘USB Mass Storage Class’
Protocol (MTP)
Only one Apple device may be
connected at any one time in
conjunction with Radio MINI Boost
‘Not supported’ appears on the car
display if the device class you are using
is not compatible.
BMW recommends using Windows
Media Player (version 11 or later)
MTP-compatible MP3 players or
mobile phones.
Other MP3 players or USB sticks can
be connected to the car using a USB
cable; it is not possible to access copy-
device is supplied with power via the
USB cable.
Do not connect it to the car’s 12-V
socket at the same time.
Note: Charging is not 100%
guaranteed via the cable due to
the different external general
conditions.
To optimise this function, the Apple
(part number 2167663) is available
for purchase.
The USB audio interface supports the
common compression formats of MP3
(.mp3), AAC (.aac, .m4a, .m4b), WAV/
PCM (.wav) and WMA (.wma), as well as
playlists in M3U and other formats.
To guarantee stable system
operation, the device memory should
be no more than 90% full.
Refer to the device operating
instructions if you wish to leave MP3
players or USB sticks in the vehicle.
We do not recommend that you leave
MP3 players or USB sticks in the vehicle
for prolonged periods as they may
(temperature, humidity).
Always follow the instructions on the
following pages.
Tested MP3 player and USB devices.
02
BMW Group, April 2012, 2/6
You can connect your device to the
vehicle in the following ways:
1. Direct connection (e.g. a USB stick)
in your car’s designated USB port.
Please ensure that your device
does not come into contact with
If it does, we recommend using
a USB cable from the MINI parts
range.
2. Using the USB cable supplied by
the device manufacturer.
3. Using a USB snap-in adapter (only
for use with the Bluetooth mobile
phone kit with USB audio interface
(SA 6NE)) available for selected
devices. In addition to the lock and
charging functions, a USB snap-in
adapter also allows you to connect
Since various cable and snap-in adapter
solutions are available, please contact
your MINI dealer for the best technical
solution and to ensure compatibility.
of your Apple device, MINI can offer
the right cable adapters and snap-in
adapter solutions to connect your iPod/
iPhone to the vehicle.
Note about the cable adapter:
You will need the Apple iPod/iPhone
audio adapter (part number 0440812)
for Radio MINI Boost (SA 6FC)
iPod/iPhone video/audio adapter (part
number 2179623) when using the
Radio MINI Visual Boost (SA 6FP) or
Apple iPods are generally supported
from the fourth generation onward.
This includes iPod Nano, iPod
Classic, iPod Touch and iPhone
(fourth generation and later devices
feature the click wheel; older models
have a scroll wheel or touch wheel and
are not supported).
Jumping forwards/back in podcasts
previous podcast. You cannot jump to
chapter markers.
problems when playing back a
combination of audio/video playlists.
If the iPod freezes, try restarting it.
For details, go to:
http://support.apple.com/kb/HT1320
To determine the software version of
the iPod, select ‘About’ from the main
menu. For more information, please
refer to the Apple websites.
Please note that iTunes can
automatically update the iPod’s
software, which could compromise
the iPod’s compatibility with the USB
audio interface.
To identify your iPod model:
http://docs.info.apple.com/article.
html?artnum=61688
You can safely disconnect your iPod
device from the vehicle at any time.
MP3 player and USB sticks
MP3 players that feature ‘Media
Transfer Protocol’ (MTP) are
supported. Some MTP devices allow
you to switch to ‘Mass Storage Class’
mode. Please refer to your MP3 player’s
user guide for details.
MP3 players compliant with the
‘USB Mass Storage Class’ (MSC)
are supported.
On some MP3 players, you may need to
activate the USB connection or enable
mass storage mode (USB Mass Storage
Class).
Please refer to your MP3 player’s user
guide for details.
When you connect your MP3 player
transfers information about its music
content to the vehicle. This lets you
easily select your music by genre,
artist, composer, album, song title
or playlist. If the device contains very
high volumes of data, you can initially
only access music via the directory
structure.
It can take up to 30 minutes to
synchronise a device with 32GB of Flash
The amount of time required for
synchronisation and the operating
speed depend on the memory capacity
and technology used in the device and
the number and types of songs stored.
USB hard drives and USB hubs or
memory card readers with multiple
ports cannot be used.
When using Radio MINI Boost, directory
names may not be longer than 34
characters.
It is not recommended that you use USB
sticks with a built-in hard drive. Tests
quality cannot be guaranteed.
You can safely remove your MP3 player
or USB stick from the vehicle at any
time.
Tested MP3 player and USB devices.
03
BMW Group, April 2012, 3/6
Mobile phones
After connecting the mobile phone via
a USB cable or using the appropriate
USB snap-in adapter, please refer to the
display on the phone itself.
You can set most mobile phones to
advance (see table column: ‘USB mode
to be used’).
Please note that using a different
mode (e.g. PC sync mode) can
compromise the operation of
so-me mobile phones. You should
pair the mobile phone to the USB audio
interface as a Bluetooth device before
physically connecting it.
Some mobile phones support only one
storage medium in conjunction with the
be stored on either the mobile phone
memory or on the memory card.
Support
If your MP3 player or USB stick does not
work with the USB audio interface as
encoding (e.g. a bit rate higher than
256 kbit/s).
Please also see the instructions for the
various mobile devices.
When you synchronise your MP3 player
with a PC, the system sometimes
updates the MP3 player’s software
automatically. This could compromise
the compatibility of the MP3 player with
the USB audio interface.
Due to the high number of MP3 players
and USB sticks available on the market
and their technical differences, it cannot
be guaranteed that every device will
interface.
The devices tested by the BMW Group
are listed in the tables below.
If you have any questions, please
contact your MINI Service Partner.
Tested MP3 player and USB devices.
06
BMW Group, April 2012, 6/6
a1 You may need to change the following settings for
video play-back: TV output: on, TV signal: NTSC.
b1
the song does not necessarily start playing from the last
playback position when you restart the vehicle.
b2
If a memory card is installed, wait three minutes after
switching on the ignition and connecting/disconnecting
before using the device again.
b3
Playlists may not be displayed.
b4
select MSC mode.
For Radio MINI Visual BOOST (SA 6FP) or Navigation Sys-
tem Business (SA 606), select MTP mode.
b5 When using a ‘Bluetooth hands-free kit with USB audio
interface’ (SA 6ND) together with Radio MINI Visual Boost
(SA 6FP) or Navigation System Business (SA 606), select
MTP mode.
b6 If the contents of the memory card cannot be displayed,
please copy the contents to the internal memory.
b7 If the device is not recognised when reconnected, you
b8 MSC mode is recommended.
b9 After starting the ignition, you may need to reconnect the
device for it to be recognised.
b10 A memory card must be installed.
b11 It can take up to one minute for the device to be
recognised.
